Orbic Buds User manual

Buds
True Wireless Ear Headphones
User Manual

Contents
1. Product Overview------------------------------------------------------------------- 1
2. Basic operating functions--------------------------------------------------------- 2
3. Bluetooth Pairing and Connection --------------------------------------------- 4
4. Earbud LED Indicator ------------------------------------------------------------- 5
5. Remaining Power in the Charging Case LED Indicator------------------- 6
6. Charging LED Indicator------------------------------------------------------------ 7
7. Charging------------------------------------------------------------------------------- 8
8. Product Specification--------------------------------------------------------------- 9
9. Cautions and Q & A --------------------------------------------------------------10

1
1. Product Overview
Device Layout: Orbic buds
Package Contents：
A) Orbic Buds (True Wireless Ear Headphones) 1 set
B) User manual 1pcs
A)
B)
User Manual

2
2.Basic operating functions
Button
Function
Operation instruction
Multi-
function
button
Power On
The headset can be turned on by opening the cover in the
charging box (it will be automatically connected to the last
connected device if there is pairing record).
Power Off
1. Put the earphone into the charging case to turn it off.
2.10 minutes no connection or battery voltage lower than
3.0V.
3. When disconnected, click the multi-function key 3 times
to clear the pairing shutdown.
Left / Right
pairing
The earbuds can be paired automatically by putting it into
the charging case and opening the cover. The Left / Right
pairing record is cleared by this.
Low power alarm
When the battery level is low, “Battery Low” alarm sounds
every three minutes.
Automatic
shutdown
If the pair is disconnected more than 10 minutes, or the
battery voltage is lower than 3.0V, earbuds are
automatically shut down
Switching main
and secondary
Put the main earbud into the charging box and turn it off
while talking or listening to music, the secondary earbud will
connect with the mobile phone and turn to the host. In
TWS(True Wireless Stereo) mode, either of an earbud will
be put into the charging box, the other earbud can keep
working.
Bluetooth pairing
When the left and right earbuds are paired successfully (or
disconnected from the Bluetooth device), the main earbud
automatically enters the Bluetooth pairing mode (blue LED
blinks).
Previous Song
Double click the "multi-function button" on the left earbud to
playback the previous song.
Play / Pause
Press the “multi-function button” to play/pause the music
(for both of left and right earbuds).
Next Song
Double click the "multi-function button" on the right earbud
to switch to the next song.
Volume Up
Hold down the multifunction button on the right earbud more
than one second to increase the volume. When the volume
reaches maximum level, buds generate beep.

3
Volume Down
Hold down the "multi-function button" on the left earbuds
more than one second to reduce the volume.
Answer a call
Press the "multi-function button" to answer the incoming call
(either of earbud).
Hang up a call
Press the "multi-function button" to hang up the ongoing call
(for both of earbuds).
Reject a call
Long press the “multi-function button” for 1 second to reject
the incoming call (for both of earbuds).
Wake up voice
assistant
In standby or music mode, tap the "multi-function button" on
the right earbud to activate the voice assistant of the mobile
phone (right ear operation) (*This requires mobile phone
support).
Clearing pairing
records
When the phone is unconnected to standby, press the
"multi-function button" 3 times, indicate the red and blue
lights flash 3 times at the same time, the earbuds can clear
pairing records (including mobile phone pairing records and
TWS pairing records).
Notes:
When clearing paring records, need to click the “multi-
function key” of two earbuds 3 times to turn off TWS.
When two earbuds are put into the charging box at the
same time, the TWS brothers will be paired automatically
after activation; if a single earbud is put into the charging
box and activated, the blue light will flash slowly waiting for
the TWS brothers to pair up.

4
3.Bluetooth Pairing and Connection
For the first connection, pick out the earbuds from the charging case, and
the earbuds automatically enters the Bluetooth pairing (main earbud blue
LED blinks; No LED for secondary earbud lights). In case there were
connection record before, by turning on the earbuds, the pairing is restarted
to connect back.
r
1) pairing
After powering on, main earbud’s
blue LED blinks and starts paring
2) connection
Turn on the Bluetooth device & Bluetooth, search
and click“Orbic Buds”for pairing and connection
1m

5
4. Earbud LED Indicator
Mode
LED Indicator
Power on
Blue LED flashes 1 second
Power off
Red LED flashes 1 time
Left / Right pairing
Blue LED blinks
Bluetooth pairing
Blue LED blinks
Connected standby
No LED indicator
Clearing pairing records
Red and blue LED blink 3 times simultaneously
Talking status
No LED indicator
Music playing status
No LED indicator
Charging
Red LED steadily turns on
Fully charged
Red LED turns off
Low power level
Red LED blinks every 4 seconds

6
5.Charging Case LED Indicator
Mode
LED Indicator of Charging Case
Remaining power: 0-5%
The first indicator blinks at 1Hz for 4sec,
then turns off
Remaining power: 5%-33%
The first indicator lights for 4sec,
then turns off
Remaining power: 33%-66%
The first and second indicator lights for
4sec and turns off
Remaining power: 66%-100%
The first, second and third indicator lights
are on for 4sec, then turns off

7
6. Charging LED Indicator
Mode
LED Indicator
Charged 0%-33%
The first indicator blinks at 1Hz
Charged 33% - 66%
The first indicator is always on, the second
indicator blinks at 1Hz
Charged 66% - 99%
The first and the second indicators are
always on, the third indicator blinks at 1Hz
Fully charged
Three indicators are steadily on

8
7.Charging
When the Orbic Buds’ battery remains low, red light blinks. Charge the
earbuds immediately. It takes 2 hours around to be fully charged. When
the red light turns off, the battery is fully charged.
A. Earbuds charging
Plug the earbuds into charger box, close the cover to charge the earbuds.
B. Charging case charging
Connect the USB connector of the micro-USB charging cable to the
charging box to charge the charging box.
*Notice：
When Orbic Buds are not in use, please charge them at least once per 2
months.

9
8.Product Specification
Bluetooth Version
Bluetooth V5.2
Bluetooth Chipset
BT8926B
Communication Distance
10 meters
Operation Range
Up to 10 meters
Bluetooth Protocols
HFP, HSP, AVRCP, A2DP
CODEC Code
SBC,AAC
Talking Time
Earbuds：About 3.5 hrs @ 70% volume
Use with charging case：About 10.5 hrs
@70% volume
Call the noise reduction
Single microphone ENC call
Music Time
Earbuds：About 5 hrs @70% volume
Use with charging case：About 15 hrs @70%
volume
Stand-by Time
About 45 hrs
Battery Capacity
Earbuds：3.7V 45mAh
Charging case：3.7V 350mAh
Working temperature
-10℃‐55℃
Net weight
Total：40g
（Earbuds：5g*2；Charging case：30g）
*Actual use time will differ from environment and music

10
9. Cautions and Q & A
A．How to connect back? What should I do if I can't connect back? How to
reconnect after long-distance disconnection?
In case earbuds are connected to mobile phone successfully, it will automatically
connect to the mobile phone every time turn it on. If the connection fails, re-pair the
connection. It is required to be able to connect back within 10 minutes. After 10
minutes, it will automatically shut down. After a long-distance disconnection, it will
only report once (Disconnected) and start pairing. It will report (Connected) when it
returns to the connectable range within 10 minutes.
B. How to clear the pairing records?
When the phone is not connected to standing-by, triple press the "multi-
function button" to indicate red and blue lights blinks 3 times at the same
time, then the earbuds can clear pairing records (including mobile phone
pairing records and TWS pairing records).
Notes: When clearing, need to click the “multi-function key” of two earbuds 3
times, to power off TWS. When the two earbuds are put into the charging
box to activate, TWS will be paired automatically after activation. In case a
single earbud is placed into the charging box, when activated, blue light
flashes slowly waiting for brother TWS to pair up. If the pairing record is
cleared, the connection cannot be traced back, need to pair the connection
again.
C. What’s the pairing password ?
Some connection devices require password for pairing. Please try 0000 or 8888 or
1111 or 1234.
D. What devices could charge for the earbuds?
Charging case charging: Charging Orbic Buds by putting the earbuds into the case
and closing the cover.
E. What to do if there are some abnormalities such as unable to boot,
abnormal connection, etc.?
Charging reset can be tried, the method is: close the charger box 3sec to reset (note
that the problem caused by rapid opening and closing repeatedly, may fail to reset).
F. When earbuds will automatically be shut down?
Automatic shutdown without connection for more than 10 minutes, or battery voltage
is less than 3.0V.

11
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.

12
This device contains licence-exempt transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic Development Canada’s licence-
exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil
est conforme aux CNR d’Innovation, Sciences et Développement é
conomique Canada applicables aux appareils radio exempts de licence. L’
exploitation est autorisée aux deux conditions suivantes :
(1) L' appareil ne doit pas produire de brouillage;
(2) L' appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d' en compromettre le fonctionnement.
FCC ID: 2ABGH-ORBIC
- End of manual -
