The Orbinox mo el MU is a 4 si e sealing penstock. The
gates are suitable for ifferent types of applications with
a highly versatile flow control for waste water treatment
plants, irrigation, hy raulic works an hy ro-electric
power plants.
From sizes 150 mm x 150 mm to 1200 mm x 1200 mm,
the MU mo el has a unique seal esign that can achieve
minimal equal seating an unseating (bi irectional)
leakage rates. Sizes 1300 mm x 1300 mm up to 2000 mm
x 2000 mm are available in both uni- irectional (only
suitable for seating water hea s) an bi- irectional
configurations. The maximum leakage rate is lower the
maximum allowable recommen e by DIN 19569-4
(class 5) an AWWA C561 un er normal con itions.
Orbinox also esigns an manufactures the MU mo el
penstock in larger sizes, for more eman ing service
con itions.
For more information please contact an Orbinox
representative.
The MU penstock is manufacture in general accor ance
to DIN 19569. Other stan ar s such as AWWA C561 an
BS 7775 also available.
The stan ar MU mo el is manufacture in stainless steel
which has a higher corrosion resistance in many
applications which results into a longer life cycle with little
or no maintenance. Other materials of construction are
available upon request, such as AISI 904L, Duplex
stainless, etc.
GENERAL DESCRIPTION
CONSTRUCTION DESIGN
MODEL

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
• Option of Rising or Non-Rising stem configurations.
• Design allows for elevate or flush bottom installation.
• Suitable for actuation with manual, electric, pneumatic
or hy raulic actuators.
• HMWPE gui es for seating an unseating hea s,
re uces the friction coefficient uring operation,
minimizing actuation thrust an exten ing seal life.
• Self-cleaning HMWPE gui es.
• Machine slot for sli e on gui es to prevent “see-saw”
effect when opening an closing the sli e.
• The unique seal esign is self a justing.
• Seal an gui es bolting is completely separate from
the frame anchoring.
• Orbinox penstocks are completely factory assemble
an teste eliminating the nee for on site a justment.
• All gate fasteners are stainless steel.
L akag Allowanc :
The leakage rate on MU mo el is lower than the maximum
allowable efine by ifferent stan ar s un er normal
con itions:
• DIN 19569-4 (class 5): 1,20 l/min per meter.
• AWWA C-561: 1.24 l/min per meter.
• Mo ular esign allows for both Open Frame an Self-
Containe configurations.
• Frame configuration options:
- Square (stan ar ) - Roun
- Rectangular
• Mounting configuration options:
- Wall Mount (stan ar ) - Curve Wall Mount
- Stan ar flange Mount - Thimble Mount
S lf-cl aning guid s.
Siz S ating h ad pr ssur Uns ating h ad pr ssur
MU BI-DIRECTIONAL
150 mm x 150 mm - 1000 mm x 1000 mm 10 meters of water column 10 meters of water column
MU BI-DIRECTIONAL
1100 mm x 1100 mm - 2000 mm x 2000 mm 6 meters of water column 6 meters of water column
MU UNI-DIRECTIONAL
1300 mm x 1300 mm - 2000 mm x 2000 mm 6 meters of water column 0 meters of water column
S ating / Uns ating D sign H ad:
NOTE: For higher hea pressures, please consult an Orbinox representative.
DESIGN FEATURES
MODEL
OBX 11/12 Revision 1
MU-2

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
S al D sign: siz s 150 mm x 150 mm to 1200 mm x 1200 mm
S al D sign: siz s 1300 mm x 1300 mm to 2000 mm x 2000 mm
S al D sign: siz s 1300 mm x 1300 mm to 2000 mm x 2000 mm
BI-DIRECTIONAL
SIDE SEAL TOP SEAL BOTTOM SEAL
BI-DIRECTIONAL
SIDE SEAL TOP SEAL BOTTOM SEAL
UNI-DIRECTIONAL
SIDE SEAL TOP SEAL BOTTOM SEAL
MODEL
HMWPE
Gui e
HMWPE
Gui e
HMWPE
Gui e
HMWPE
Gui e
HMWPE
Gui e
HMWPE Gui e
Si e
HMWPE
Gui e
OBX 11/12 Revision 1
MU-3

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
Note: For materials other than the above, please consult an Orbinox representative.
ITEM DESCRIPTION MATERIAL (standard)
1 Frame Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
2 Sli e Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
3 Gui es High Molecular Weight Polyethylene (HMWPE)
4 Seal EPDM
5 Seal Retainer Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
6 Bottom Seal EPDM
7 Bottom Seal Retainer Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
8 Frame Gui e Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
9 Stem Stainless Steel Type 303 (1.4305), other on request
10 Stem Nut Bronze
11 Yoke Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
Siz s 150 mm x 150 mm to 1200 mm x 1200 mm
STANDARD MATERIALS OF CONSTRUCTION
MODEL
OBX 11/12 Revision 1
MU-4

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
Note: For materials other than the above, please consult an Orbinox representative.
ITEM DESCRIPTION MATERIAL (standard)
1 Frame Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
2 Sli e Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
3 Front Gui es High Molecular Weight Polyethylene (HMWPE)
4 Gui es High Molecular Weight Polyethylene (HMWPE)
5 Seal EPDM
6 Seal Retainer Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
7 Bottom Seal EPDM
8 Bottom Seal Retainer Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
9 Stem Stainless Steel Type 303 (1.4305), other on request
10 Stem Nut Bronze
11 Stem Nut Bracket Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
12 Yoke Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
13 Stem Coupling Stainless Steel Type 304L or 316L (1.4306 or 1.4404)
Siz s 1300 mm x 1300 mm to 2000 mm x 2000 mm
STANDARD MATERIALS OF CONSTRUCTION
MODEL
OBX 11/12 Revision 1
MU-5

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
The following rawings show the most common mounting
options for MU penstocks. For other types of mounts,
please consult an Orbinox representative.
All Orbinox actuators can be yoke or pe estal mounte ,
below are some examples of the most common types.
Various typ s of actuators as shown abov :
(A) Han wheel on incline floor stan .
(B) Han wheel on straight floor stan .
(C) Gear operator on straight floor stan .
(D) Electric actuator on straight floor stan .
(E) Hy raulic or pneumatic actuator.
(F) Square nut (ISO 5211) operator (For Non-Rising stem).
(G) Yoke mounte han wheel.
(H) Yoke mounte gear an crank.
Acc ssori s:
• Mechanical stops
• Actuator manual overri es
• Locking evices
• Solenoi valves
• Positioners
• Limit / Proximity switches
Siz s 150 mm x150 mm to 1200 mm x 1200 mm
Siz s 1300 mm x 1300 mm to 2000 mm x 2000 mm
(B)
(C)
(D)
(F)
(A)
(G)
)
(H)
(E)
MOUNTING OPTIONS ACTUATORS
CURVED WALL MOUNT
THIMBLE MOUNT
WALL MOUNT (STANDARD)
MODEL
EMBEDDED IN CONCRETE
OBX 11/12 Revision 1
MU-6

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
In many cases, the operating floor level is locate
substantially higher than the opening. In or er to be able
to operate the gate, stem extensions are necessary.
Stem gui es are use to limit the “unsupporte ” length of
the stem extension in or er to avoi any buckling failure.
The stem gui e has a HWMPE gui e to re uce friction
between the gui e an the extension.
Non-Rising St m Configuration
As stan ar , non-rising stem gate configurations are use
with self-containe frame esigns. Therefore, the stem
extension oes not support the axial loa (only torque)
an less wall brackets are require .
As a general rule, a stem gui e shoul be installe every
3 meters of unsupporte stem extension.
Rising St m Configuration
As stan ar , rising stem gate configurations are use with
open-frame esigns. Therefore, the stem extension has to
support the axial loa when the gate is operate . In
consequence, the use of stem gui es are critical to avoi
any buckling failure. As a general rule, a stem gui e
shoul be installe every 2 meters of unsupporte stem
extension.
This section briefly escribes the installation, operation an
maintenance of MU penstocks. For more etaile
information please refer to the “MU IOM Manual”.
Installation:
Orbinox MU penstocks are installe by means of Anchor
Bolts. Depen ing on the size an working con itions they
shall be either of the mechanical or chemical type (see
table below).
In or er to avoi leakage between the concrete wall an
the frame, Orbinox recommen s the use of construction
sealant equivalent to Sikaflex 11FC sealant (200ml per
meter of opening perimeter).
The minimum concrete strength shall be 20.7 MPa.
The tolerance of the concrete construction (flatness,
levelness an plumbness) shall be in accor ance to
DIN 18202.
For etaile information about type, size an quantity of
the require anchor bolts at the installation, please refer to
the notes on the “General Arrangement Drawing”.
Maint nanc and Op ration:
The Orbinox MU penstocks nee practically no
maintenance. The stem shall be kept lubricate an seals
shall be replace if amage . The MU penstock is close
by applying a clockwise rotation.
Applying too much force on the operator when closing the
gate may cause amage to the stem.
Cl ar St m Prot ctor
Handwh l
Straight Floor Stand
St m Ext nsion
St m Guid s
St m Guid & Slid Stopp r
Slid Gat
(Rising St m, Op n Fram )
B v l G ar
MU Siz Wat r Pr ssur Standard Mounting Typ
MU BI-DIRECTIONAL
150 mm x 150 mm - 1200 mm x 1200 mm
Seating an Un-Seating
(Bi-Directional)
Wall mount:
• Stu Type Mechanical Anchor Bolts
MU BI-DIRECTIONAL
1300 mm x 1300 mm - 2000 mm x 2000 mm
Seating an Un-Seating
(Bi-Directional) Embe e in concrete
MU UNI-DIRECTIONAL
1300 mm x 1300 mm - 2000 mm x 2000 mm
Seating (Uni-Directional) Wall mount:
• Stu Type Mechanical Anchor Bolts
STEM EXTENSIONS
INSTALLATION, OPERATION AND MAINTENANCE
MODEL
OBX 11/12 Revision 1
MU-7

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
SIZES: 150 mm x 150 mm to 1200 mm x 1200 mm SIZES: 1300 x 1300 mm to 2000 x 2000 mm
OPEN FRAME - RISING STEM - DIMENSION
MODEL
The following drawings show the most common frame and stem configurations and their dimensional charts. Note that any
frame (open and self-contained), stem (rising and non-rising) and actuator combination can be manufactured for MU
penstocks.
OBX 11/12 Revision 1
MU-8

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
SIZES: 150 mm x 150 mm to 1200 mm x 1200 mm
SIZES: 1300mm x 1300 mm to 2000mm x 2000 mm
BI-DIRECTIONAL
Note: For imensions other than above, please contact an Orbinox representative.
These imensions are for information only. Do not use for installation or submittal purposes.
UNI-DIRECTIONAL
OPEN FRAME - RISING STEM - DIMENSION
MODEL
SIZE (mm) ABA1 CDØG E x F
(op ning)
200x200 290 380 70 41 82 225 70x75
300x300 390 480 70 41 82 225 70x75
400x400 490 580 70 42 85 310 70x75
500x500 590 680 70 42 85 310 70x75
600x600 690 780 70 42 115 310 70x75
700x700 790 880 70 42 115 310 70x75
800x800 890 980 70 42 125 310 70x75
900x900 1000 1100 82 56 136 410 70x85
1000x1000 1100 1200 82 56 136 410 70x85
1100x1100 1250 1300 82 56 136 410 70x85
1200x1200 1350 1400 82 56 136 410 70x85
SIZE (mm) ABA1 A2 CDJØG E x F
(op ning)
1300x1300 2725 1650 115 220 145 275 2350 450 280x150
1400x1400 2925 1750 115 220 145 275 2450 450 280x150
1500x1500 3125 1850 115 220 145 275 2550 450 280x150
1600x1600 3325 1950 115 220 145 275 2650 650 280x150
1700x1700 3525 2050 115 220 145 275 2750 650 280x150
1800x1800 3725 2150 115 250 145 275 2850 650 280x150
1900x1900 3925 2250 115 250 145 275 2950 650 280x150
2000x2000 4125 2350 115 250 145 275 3050 650 280x150
SIZE (mm) ABA1 A2 CDJØG E x F
(op ning)
1300x1300 2725 1650 115 220 145 275 2350 450 280x150
1400x1400 2925 1750 115 220 145 275 2450 450 280x150
1500x1500 3125 1850 115 220 145 275 2550 450 280x150
1600x1600 3325 1950 115 220 145 275 2650 650 280x150
1700x1700 3525 2050 115 220 145 275 2750 650 280x150
1800x1800 3725 2150 115 250 145 275 2850 650 280x150
1900x1900 3925 2250 115 250 145 275 2950 650 280x150
2000x2000 4125 2350 115 250 145 275 3050 650 280x150
OBX 11/12 Revision 1
MU-9

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX S.A. Pol. In . s/n - 20270 ANOETA - Tel.: [phone] - Fax: [phone] - e-mail: [email protected]
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
SIZES: 1300 mm x 1300 mm to 2000 mm x 2000 mm SIZES: 150 mm x 150 mm to1200 mm x 1200 mm
CLOSED FRAME - NON RISING STEM - DIMENSION
MODEL
OBX 11/12 Revision 1
MU-10

MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
BI-DIRECTIONAL
Note: For imensions other than above, please contact an Orbinox representative.
These imensions are for information only. Do not use for installation or submittal purposes.
UNI-DIRECTIONAL
CLOSED FRAME - NON RISING STEM - DIMENSION
SIZE (mm) ABA1 CDØG E x F
(op ning)
200x200 492 380 70 41 82 41 70x75
300x300 692 480 70 41 82 41 70x75
400x400 893 580 70 42 85 42 70x75
500x500 1093 680 70 42 85 42 70x75
600x600 1294 780 70 42 115 42 70x75
700x700 1496 880 70 42 115 42 70x75
800x800 1696 980 70 42 125 42 70x75
900x900 1976 1100 82 56 136 42 70x85
1000x1000 2176 1200 82 56 136 42 70x85
1100x1100 2389 1300 82 56 136 42 70x85
1200x1200 2589 1400 82 56 136 42 70x85
MODEL
SIZES: 1300 mm x 1300 mm to 2000 mm x 2000 mm
SIZES: 150 mm x 150 mm to 1200 mm x 1200 mm
SIZE (mm) ABA1 A2 CDØG E x F
(op ning)
1300x1300 2916 1650 115 220 145 275 450 280x150
1400x1400 3116 1750 115 220 145 275 450 280x150
1500x1500 3316 1850 115 220 145 275 450 280x150
1600x1600 3528 1950 115 220 145 275 650 280x150
1700x1700 3728 2050 115 220 145 275 650 280x150
1800x1800 3988 2150 115 250 145 275 650 280x150
1900x1900 4188 2250 115 250 145 275 650 280x150
2000x2000 4458 2350 115 250 145 275 650 280x150
SIZE (mm) ABA1 A2 CDØG E x F
(op ning)
1300x1300 2871 1610 115 220 145 275 450 280x150
1400x1400 3071 1710 115 220 145 275 450 280x150
1500x1500 3271 1810 115 220 145 275 450 280x150
1600x1600 3483 1910 115 220 145 275 650 280x150
1700x1700 3683 2010 115 220 145 275 650 280x150
1800x1800 3943 2110 115 250 145 275 650 280x150
1900x1900 4143 2210 115 250 145 275 650 280x150
2000x2000 4413 2310 115 250 145 275 650 280x150
OBX 11/12 Revision 1
MU-11

PENSTOCK DESIGN
mm Wall Opening Wi th:
inch Wall Opening Height:
Seating Water Hea :
Unseating Water Hea :
Invert to Operating Floor height:
Non Rising Stem (NRS) Uni-Directional Close Frame
Rising Stem (RS) Bi-Directional Open Frame
PENSTOCK MOUNTING
Concrete Wall Mount
Wall thimble Mount
Embe e In Concrete
Fram Inv rt Mounting:
Stan ar Wall Mount (a)
Flush Bottom Mount (b)
E= F=
ACTUATORS
Han wheel
Crank (w/ B.Gear an Sqr. Nut)
Square Nut - ISO 5211(NRS Only)
Bevel Gear
Electric Motor
Pneumatic Cylin er
Hy raulic Cylin er
MATERIALS
Frame & Sli e
Stem
Extension
Floor Stan
Seal
Stem Cover
MU
ORBINOX reserves the right to change specifications without notice.
ORBINOX CANADA, ORBINOX USA, ORBINOX BRAZIL, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA , ORBINOX S.E.A.
.orbinox.com
MU PENSTOCK SELECTION FORM
Size
Name: Signature:
Units:
Actuator Mounting:
Incline Floor Stan (a)
Straight Floor Stan (b)
Wall Bracket (for Sqr.Nut)(c)
Frame Mounte ( )
304L SS
303 SS
304L SS
Carbon Steel
EPDM
Carbon Steel
Customer:
Or er Number:
Tag No.: Date:
Qty.:
REMARKS
316L SS
316 SS
316L SS
304L SS
PVC
Other:
Other:
Other:
Other:
Other:
Other:
(a) (b)
( )
Position Indicator:
(For RS Only)
Position Label
Limit Switch
Proximity Switch
MODEL
OBX 11/12 Revision 1
MU-12
