Oreck APU255 User manual

USER’SGUIDE
•IMPORTANT•
SAVE THIS BOOKLET!
Includes:
• Safety Warnings
• Warranty
• Operating Instructions
• Trouble Diagnosis
• Accessories
APU255
SIMPLY AMAZING™
26852-03 REV C

2
Table of Contents
BEFORE OPERATING
CLEANER, READ ALL
INSTRUCTIONS IN THIS
MANUAL CAREFULLY.
Table of Contents,
Maintenance and Customer Service,
Important Safety Instructions . . . . . . . . . . page 2
Warranty,
Troubleshooting Guide . . . . . . . . . . . . . page 3
Operating Instructions,
To Store the Cleaner . . . . . . . . . . . . . . . page 4
To Replace Filter Bag . . . . . . . . . . . . . . . page 5
To Replace Belt . . . . . . . . . . . . . . . . . . . page 6
To Clean Clogged Power Nozzle . . . . . . . page 7
Accessories . . . . . . . . . . . . . . . . . . . . . page 8
When using an electrical appliance, basic
precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE
USING THIS VACUUM CLEANER
WARNING
To reduce the risk of fire,
electric shock, or injury:
IMPORTANT
SAFETY INSTRUCTIONS
• Do not leave appliance unattended when plugged in. Unplug
from outlet when not in use and before servicing.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close attention is necessary
when used by or near children.
• Use only as described in this manual.
• Do not use with damaged cord or plug. If appliance is not
working as it should, has been dropped, damaged, left outdoors,
or dropped into water, return it to a service center or call
customer service at
US: 1-800-989-3535
Canada: 1-888-676-7325
• Do not pull or carry by cord, use cord as a handle, close door on
cord, or pull cord around sharp edges or corners. Keep cord
away from heated surfaces.
•Do not run appliance over cord.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not
the cord.
•Do not handle plug or appliance with wet hands.
•Do not put any object into openings. Do not use with any opening
blocked; keep free of dust, lint, hair and anything that may reduce
air flow.
• Keep hair, loose clothing, fingers and all parts of body away from
openings and moving parts.
• Do not use to pick up anything that is burning or smoking, such as
cigarettes, matches, or hot ashes.
•Do not use without filter bag assembly in place.
•Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids, such as
gasoline or lighter fluid, or use in areas where they may be
present.
• Do not use appliance in an enclosed space where flammable,
explosive or toxic vapors are given off by oil base paint, paint
thinner, some mothproofing substances, or in an area where
flammable dust is present.
•Do not pick up toxic material such as chlorine bleach, drain
cleaner, gasoline, etc. with this appliance.
Polarized Plug Notice
This product is equipped with a polarized alternating
current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact an
electrician to replace the obsolete outlet. Do not defeat
the purpose of the polarized plug.
SAVE THESE INSTRUCTIONS
Household Use Only
Your ORECK vacuum cleaner is a product of precise
engineering. The motor bearings are permanently
lubricated and should not be oiled. If you require
additional information or have problems with your
ORECK appliance, you may call ORECK customer
service at:
US: 1-800-989-3535
Canada: 1-888-676-7325
Please specify the model number and serial/code
number which can be found on the data plate on the
back of the vacuum.
Save your sales or purchase slip. Should your
ORECK appliance require warranty service in the
U.S.A., present this slip to the Authorized Service
Center as your proof of purchase date or, in
Canada, call customer service.
Maintenance and
Customer Service

3
Warranty
ORECK MANUFACTURING COMPANY: (ORECK gives
you the following limited warranty for this product only if it
was originally purchased for use, not resale, from ORECK
or an ORECK Authorized Retail Dealer.)
ORECK will repair or replace, free of charge, to the
original purchaser, any part that is found to be defective
in material or workmanship within two (2) years of the
date of purchase. This limited warranty applies to normal
domestic use. Any commercial use of this product will
void this limited warranty.
Drive belts, revolving brushes, bulbs, disposable bags,
and other parts subject to normal wear are not covered by
this limited warranty.
This limited warranty does not apply to any part subjected
to accident, abuse, commercial use, alteration, misuse,
damage caused by fire or act of God, the use of voltages
other than indicated on the serial number plate of this
product or service of this product by other than ORECK or
an ORECK Factory Authorized Service Center.
ORECK does not authorize any person or representative to
assume or grant any other warranty obligation with the
sale of this product.
ORECK’S limited warranty is valid only if you retain proof
of purchase from ORECK or an ORECK Authorized Retail
Dealer for this product. If you purchase this product from
any other source, your purchase is “AS IS,” which means
ORECK grants you no warranty, and that you, not ORECK,
assume the entire risk of the quality and performance of
this product, including the entire cost of any necessary
servicing or repairs of any defects.
ORECK’S liability for damages to you for any costs
whatsoever arising out of this statement of limited warranty
shall be limited to the amount paid for this product at the
time of original purchase, and ORECK shall not be liable
for any direct, indirect, consequential or incidental
damages arising out of the use or inability to use this
product.
Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS
PRODUCT, INCLUDING IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED IN DURATION TO THE
WARRANTY PERIOD, AND NO WARRANTIES, WHETHER
EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD.
Some states do not allow limitations on the duration of
implied warranties, so the above limitation may not apply
to you.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
SAVE SERVICE CALLS...CHECK THESE FIRST:
•Is the disposable filter dust bag full?
•Are pores of filter dust bag clogged with powder or fine dust?
• Is anything clogging the revolving brush, intake opening?
• Is the belt in place and turning the brush?
• Does the brush turn freely? Are hair, string or rug fibers wound
around the brush?
Troubleshooting Guide
CLEANER
WILL NOT RUN
CLEANER
SUCTION LOW
POWER NOZZLE
DOES NOT PICK UP
FILTER BAG ASSEMBLY
DIFFICULT TO INSTALL
AND REMOVE
CLEANER NOZZLE
WILL NOT SWIVEL
HANDLE WILL NOT
STAY IN POSITION
Not plugged in
properly.
No electricity in
wall outlet.
Filter bag is full.
Nozzle is clogged.
Belt is broken or
stretched.
Brush roll is
jammed.
Powerbrush nozzle
is not turning.
Debris in bottom
of filter bag
housing opening.
Filter bag not in
place.
Swivel ring posts
not in correct
position.
or
Debris around
swivel ring.
Handle collar lock
not tightened
securely.
Be sure cleaner is
firmly plugged
into wall outlet.
Check electrical
source–fuse or
circuit breaker.
Replace filter bag.
See “To Install
Paper Filter Dust
Bag.”
Clear obstruction.
Replace belt.
Remove debris
from nozzle brush
roll.
Ensure power-
brush nozzle cord
is plugged in.
Clean seal area at
bottom of filter bag
housing opening.
Install filter bag
properly.
Remove swivel
clamp screws from
bottom of nozzle
carefully.
Reassemble nozzle
to unit, making
certain swivel ring
posts are seated
correctly.
Firmly tighten
handle collar lock
in clockwise
direction.
PROBLEM POSSIBLE SOURCE AREAS TO CHECK
Whenever calling, please be sure to have your model and
serial number from data plate.
CALL CUSTOMER SERVICE HOT LINE
US: 1-800-989-3535
CANADA: 1-888-676-7325
ALL OTHER SERVICING SHOULD BE DONE BY AN
ORECK AUTHORIZED SERVICE CENTER.
WARNING: Unplug cord from
electrical outlet before servicing.

Plug cord into electrical outlet.
Power Switch
Push power switch to “ON” (l) position.
4
Operating Instructions
ELECTRIKBROOM
POWER SWITCH
Power Nozzle Operation
Your ORECK ELECTRIKBROOM cleaner features a power
brush nozzle designed for effective cleaning on all types
of carpets or bare floors.
When cleaning rugs or floors, glide the nozzle with slow,
easy strokes.
For deep cleaning carpets, depress the powerbrush switch
to “ON” (l) position, then glide the nozzle with slow, easy
strokes. For bare floors and light rugs, you may stop the
powerbrush roll by switching back to the “OFF” (0)
position.
NOZZLE
POWER SWITCH
Swivel Nozzle
The swivel nozzle feature allows you to clean under
furniture easily. Simply twist cleaner to side until the unit
lies flat and parallel to the floor. Then guide the nozzle
into hard to reach places.
SWIVEL NOZZLE
OPERATION
Cord Restraint
A cord restraint clip is conveniently molded into the handle
to lift cord out of your way while vacuuming.
CORD RESTRAINT
Telescopic Handle
To adjust the handle height, simply grasp handle grip and
rotate collar lock at lower end of handle counter-
clockwise to loosen. Then slide handle up or down to
desired height. Gently tighten collar lock down clockwise
onto threads to lock handle into place.
COLLAR LOCK
ToStore the Cleaner
Wrap the power cord around rear of unit. For compact
storage, retract telescoping handle down. Hang cleaner
on a hook from the opening located at the top of the
handle.
The convenient ORECK ELECTRIKBROOM vacuum cleaner
is always at your fingertips for quick clean-ups anywhere.
NOTE: These cleaners do not stand upright
alone. Make sure the cleaner is properly
supported when not in use or unattended.

5
ToReplace Filter Bag
To ensure that your ORECK ELECTRIKBROOM Powerbrush
cleaner provides you with optimal performance, use only
ORECK brand bags. Replace the filter bag more
frequently when picking up fine materials such as
powders, plaster dust, ashes and soot. These materials
may seal the filter bag before it appears full.
STEP 1: Remove Filter Bag Assembly
Remove the filter bag assembly by:
A) Grasping its top and pushing down.
B) Pulling top of filter bag assembly out and away from
the cleaner.
STEP 2: Remove Used Filter Bag
Remove used filter bag by grasping the cardboard collar
and pulling it past the raised locking tabs on the dirt tube.
Discard used bag.
STEP 3: Install New Filter Bag
Install new filter bag by pushing cardboard collar past
locking tabs on the dirt tube. Make sure the filter bag is
fully extended and tucked into the filter bag assembly.
WARNING: Unplug cord from electrical
outlet before servicing.
BAG ASSEMBLY
STEP 4: Replace Filter Bag Assembly
Replace bottom of the filter bag assembly into the side of
the cleaner. While pressing down, pivot top of filter bag
assembly in until to catch snaps into place.
To order:
Replacement Filter Bags Part No. OR162
Call your authorized ORECK Service Center, your
authorized ORECK dealer, or the Service Center Hotline
toll free at: US: 1-800-989-3535
CANADA: 1-888-676-7325
IMPORTANT: Do not operate cleaner
without filter bag in place.
Damage to the motor will occur.
2
1
2
1

STEP 1: Remove Power Nozzle Assembly
Lay cleaner on flat surface with bottom side of nozzle
(brush side) facing you then:
A) Remove swivel clamp screws and clamp.
B) Remove the two screws at the outer rear corners of the
nozzle base plate only.
STEP 2: Remove Belt
Gently rock rear wheels and base plate up and out of
nozzle. Lift brush roll from holder. Remove old belt and
debris. (Dirt and debris may have been the cause of a
broken belt.)
STEP 3: Install New Belt
Place new belt over end of motor shaft and brush roll.
Be Sure Belt Is Not Twisted.
Place brush roll back into its holder. Be sure flat side of
metal brush roll ends are up.
6
ToReplace Belt
WARNING: Unplug cord from electrical
outlet before servicing.
CLAMP SCREWS
STEP 4: Replace Power Nozzle Assembly
Line up tabs in front of base plate with slots in nozzle
cover. Press down on front while rocking base back into
place. Be sure front tabs are in lock position. Replace
screws at rear corners. Reattach swivel clamp to nozzle
base.
To order:
Replacement Belts Part No. OR114
Call your authorized ORECK Service Centerr, your
authorized ORECK dealer, or the ORECK Service Center
Hotline toll free at: US: 1-800-989-3535
CANADA: 1-888-676-7325
SCREWS

7
ToClean Clogged Power Nozzle
STEP 1: Remove Power Nozzle Assembly
Lay cleaner on flat surface with bottom side of nozzle
(brush side) facing you then:
A) Remove swivel clamp screws and clamp.
B) Remove the two screws at the outer rear corners of the
nozzle base plate only.
C) Lift unit body inlet section out of power nozzle base.
STEP 2: Inspect
Inspect nozzle and cleaner inlet for clogs and debris.
WARNING: Unplug cord from electrical
outlet before servicing.
STEP 3: Replace Power Nozzle Assembly
After cleaning, replace unit body inlet section into power
nozzle base. Line up tabs in front of base plate with slots
in nozzle cover. Press down on front while rocking base
back into place. Be sure front tabs are in lock position.
Replace screws at rear corners. Reattach swivel clamp to
nozzle base.
INLET
CLAMP SCREWS
SCREWS

ACCESSORIES
SOLD SEPARATELY
USA: 1-800-989-3535 CANADA: 1-888-676-7325
ITEM PART NUMBER
1. Filter Dust Bag, 3 Pack OR162
2. Belts, 2 Pack OR114
©2002 Oreck Holdings, LLC. All Rights Reserved. All word marks, logos, product configurations, and registered trademarks are owned and used under the authority of Oreck Holdings, LLC.
Printed in America
26852-03 REV C
09/02 ECN# R-6614
