Organic Lighting liniLED Diffuse Top 1/2" User manual

12/19 Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865
|
626.969.6140
|
www.organiclighting.com
Diffuse Top 1/2", Diffuse Top 3/4", Diffuse Side 3/4"
UV RESISTANT FROST
RESISTANT
SWIMMING POOL
ENVIRONMENT
MAC
ADAM
2
S D C M
BEND RADIUS
R
1.2" CRI
80+
SEA WATER
RESISTANT
RoHS
F5
System
IP40/IP68 ........
Table of Contents General
Warning
Product Information Product Dimensions Product
Specifications Asymmetric Diagram Cable Selection
Area Advice
Product Care and Handling Cutting Instructions
Connect
Soldering
Power Supply
Symbols
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION & LEAVE
A COPY FOR THE END USER/ MAINTANANCE ENGINEER FOR FUTURE REFERENCE.
2
2
2
3
4
5
6
8
Table of Contents
Warning
Product Information
Product Dimensions
General
Ip68 Connector Options
Cable Selection
Product Specifications
Symbols
USER MANUAL

Warning
This product comes with a 5year warranty.
Warranty void if:
1. The installation guide has not been consulted (installation mistake).
2. The installation is not done by a certified installer.
3. Local rules and guidelines are not respected.
4. The invoice cannot be shown and/or has been altered.
5. Damage is caused by negligence, abnormal use or improper handling, use, maintenance and/or cleaning
of the product.
This product is intended for professional use only! This product must be installed by a qualified and
certified installer according to local rules and guidelines. Organic Lighting Systems, Inc. cannot
be held liable for (consequential) damage and/or injuries due to unintended use and/or installation
errors.
Product Information
Maximum bending radius is 1.2 in. Solely bend up or downward. Do not compress, stretch or bend the LED
strip.
Bending Radius
User Manual | liniLED® Diffuse Top & Side
The liniLED® LED strip (IP40) is a high quality, flexible LED strip with a unique co-extrusion technology.
Designed for an endless range of indoor and outdoor applications.
* For use in wet environments, use mirror welded connectors or IP68 waterproof kits.
Product Dimensions
2
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com
.71in
.47 in
5.9 in
5.9 in
.71in
.47 in
liniLED strip front view:
Side 1/2"
.71in
.71 in
Top 3/4"
.71in
.71in
1.3in
.12in
.71in
.39in
.18in
Top 1/2"
.47in
.47in
1.3in
.12in
.71in
.39in
.18in

Read the instructions and safety precautions before installation, usage and storage of the products to secure
safety of the user and reliability of the product. Hand over the instructions to the end-user and/or those
responsible for installation, maintenance and usage.
- Organic Lighting Systems, Inc. cannot be held responsible for improper handling, product installation,
usage or storage.
Handling
- Handle with care.
- The product may not be modifi ed or converted otherwise than prescribed.
- Products are transported in proper packaging. Products should remain packed until installation.
Installation
- Attention: The power has to be switched off the main power supply or the connection before installation.
Not doing so may damage the product.
- Use a suitable LED power supply/driver: 24 V DC constant voltage. Do not drive the product on other
voltages than described in their datasheet/products specifi cations.
- Installation has to be done by a certifi ed professional with knowledge of electrical circuits or a specialised
maintenance person known with valid directives.
- General and local construction, safety- and installation regulations should be respected.
- Use only supplied parts, accessories and required tools as prescribed in the installation manual to
guarantee a safe installation and use of the product.
- Products may solely be installed in the areas according to their prescribed IP-rating, IK-rating,
temperature range and chemical resistances.
- Do not fasten anything on the product, same applies for hanging.
- Do not install the product in the following cases:
- Damage is visible on the product or its cables.
- The inside of the product is moistened or dirty.
- The product or its cables have been modifi ed. It could lead to an electrical shock or a short circuit
may occur.
- Children may not play unsupervised with electrical products as they cannot judge the dangers in dealing
with electrical circuits correctly.
Operation and Use
Solely use the productwhen its working correctly. If not, switch the power offimmediately and advise
an electrical specialist in the following c-ase.
-Damage is visible on the product.
-The product does not function.
-Smoke or steam rises from the product.
-Crackling sounds are noticeable.
-The product is overheating.
-Repairs on the installation may only be performed by qualifi ed electricians. Product repairs may solely
be done by Organic Lighting Systems, Inc.
Cleaning and Maintanence
- Attention: Disconnect the power before maintenance and cleaning.
- Dust and dirt accumulated over time should be removed from the light-emitting surface to assure
optimal functioning of the product.
- Paints, solvents and corrosive cleaning chemicals may not contact and thus aff ect the product.
Environment and Waste
- Exterior decorative lighting should only be used after sunset.
- This product may not be treated as household waste. Dispose of the material through the waste
recycling of electrical and electronic equipment.
General User Manual | liniLED® Diffuse Top & Side
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com
3

IP68 Connector Options
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com
Outdoor environment | (IP68)
liniLED® Diffuse ½" Connector Straight 16'L
Product code: 011271
liniLED® Diffuse ¾" Connector Straight 16'L
Product code: 011251
Outdoor environment | (IP68)
liniLED® Diffuse ½" Connector 90º Angle, 16'L
Product code: 011261
liniLED® Diffuse ¾" Connector 90º Angle, 16'L
Product code: 011246
4
Outdoor environment | (IP68)
liniLED® Diffuse ½" Extension Cord 90º Angle
Product code: 011277
liniLED® Diffuse ¾" Extension Cord 90º Angle
Product code: 011276
Outdoor environment | (IP68)
liniLED® Diffuse ½" Extension Cord Straight
Product code: 011279
liniLED® Diffuse ¾" Extension Cord Straight
Product code: 011278
Outdoor environment | (IP68)
liniLED® Diffuse ½" Extension Straight Female
Product code: 011287
liniLED® Diffuse ¾" Extension Straight Female
Product code: 011283
liniLED® Diffuse ½" Extension Angle Female
Product code: 011285
liniLED® Diffuse ¾" Extension Angle Female
Product code: 011281
Outdoor environment | (IP68)
liniLED® Diffuse ½" Extension Straight Male
Product code: 011286
liniLED® Diffuse ¾" Extension Straight Male
Product code: 011282
liniLED® Diffuse ¾" Extension Angle Male
Product code: 011280
liniLED® Diffuse ½" Extension Angle Male
Product code: 011284

Cable Selection
Result = Maximum cable length based on the cable thickness and power supply voltage.
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 110' 215' 53' 105' 18' 39' 7' 18'
20 AWG 165' 324' 79' 158' 28' 59' 11' 27'
18 AWG 220' 430' 106' 211' 37' 79' 14' 35'
16 AWG 331' 647' 159' 317' 56' 119' 22' 53'
14 AWG 551' 1077' 265' 528' 93' 198' 36' 89'
3' 6' 16' 33'
Diffuse 2400K, 2700K
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 118' 231' 53' 105' 20' 42' 8' 19'
20 AWG 178' 347' 79' 158' 30' 64' 12' 29'
18 AWG 236' 462' 106' 211' 40' 86' 16' 38'
16 AWG 356' 695' 159' 317' 61' 129' 24' 58'
14 AWG 592' 1156' 265' 528' 101' 214' 40' 96'
3' 6' 16' 33'
1. Color Temperature
2. LED Strip Length
3. Voltage 24V DC 25V DC 24V DC 25V DC 24V DC 25VDC 24V DC 25V DC
4. Cable Size 22 AWG 114' 223' 55' 109' 19' 41' 7' 18'
20 AWG 171' 335' 82' 164' 29' 62' 11' 27'
18 AWG 228' 445' 109' 218' 39' 82' 15' 36'
16 AWG 343' 670' 165' 329' 58' 124' 23' 54'
14 AWG 571' 1115' 275' 547' 97' 206' 37' 92'
3' 6' 16' 33'
Diffuse 3000K
Diffuse 4000K, 6500K
User Manual | liniLED® Diffuse Top & Side
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com
6
1
2
Top/Side Connector, 3ft
Result
4
- +
3
The following chart gives the maximum 24V supply cable run lengths based on 22AWG, 20AWG, 18AWG,
16AWG and 14AWG wire gauge to avoid voltage drop to the strips, with a 3ft liniLED connector cable
length.
A wiring plan with branches from a single power supply connection cannot exceed the maximum
connector strip length shown on the charts and if complex will require special electrical calculations to
ensure adequate power to maintain full LED output.

Product Specifications
Product code [m]
Luminous efficiency
2400K 2700K 4000K 3000K 6500K
Luminous flux
011829 011830 011832011831 011833
51 lm/ft
19 lm/W
56 lm/ft
21 lm/W
55 lm/ft
21 lm/W
51 lm/ft
20 lm/W
56 lm/ft
21 lm/W
Top Diffuse 1/2"
Product code [m]
Power (24 V DC)
Power (25 V DC)
CRI
Spool length
Section length
LED
Number of LEDs
Max. connection length
Operation voltage
Max. operation voltage
Beam angle
Dimensions
Dimmable
Weight
Expected lifetime
Degree of protection (IP)
Storage temperature
Operation temperature
Minimal bending radius
110°
0.47 x 0.71 in (1/2")
PWM dimming, 0-10V dimming
2.6 oz/ft
B50/L70 > 50,000 hours @ 104 °F
IP68 +/ IP69 with mirror welded connector
-4 °F - 131 °F
-22 °F - 131 °F1
5.9 in
Max. connection length between -4 °F and -22 °F is 23 ft
2400K 2700K 4000K
3000K 6500K
Binning ± 50K
2.7 W/ft
2.8 W/ft
90
2.7 W/ft
2.8 W/ft
2.6 W/ft
2.7 W/ft
2.5 W/ft
2.6 W/ft
2.6 W/ft
2.7 W/ft
Max. 32.8 ft
2 in
Duristm E 3
6 per section / 36.5 per ft
32.8 ft
24 V DC
25 V DC
011819 011820 011822011821 011823
Side Diffuse 1/2"
Luminous efficiency
Luminous flux 31 lm/ft
11 lm/W
34 lm/ft
13lm/W
35 lm/ft
13 lm/W
31 lm/ft
12 lm/W
34 lm/ft
13 lm/W
Symmetric Diagram
User Manual | liniLED® Diffuse Top & Side
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com
7

Product Specifications
Product code [m]
Luminous efficiency
2400K 2700K 4000K 3000K 6500K
Luminous flux
011799 011800 011802011801 011803
61 lm/ft
22 lm/W
67 lm/ft
25 lm/W
65 lm/ft
25 lm/W
60 lm/ft
24 lm/W
69 lm/ft
26 lm/W
Top Diffuse 3/4"
Power (24 V DC)
Power (25 V DC)
CRI
Spool length
Section length
LED
Number of LEDs
Max. connection length
Operation voltage
Max. operation voltage
Beam angle
Dimensions
Dimmable
Weight
Expected lifetime
Degree of protection (IP)
Storage temperature
Operation temperature
Minimal bending radius
110°
0.71" x 0.71" (for 3/4")
PWM dimming, 0-10V dimming
2.6 oz/ft
B50/L70 > 50,000 hours @ 104 °F
IP68 +/ IP69 with mirror welded connector
-4 °F - 131 °F
-22 °F - 131 °F1
5.9 in
Max. connection length between -4 °F and -22 °F is 23 ft
Binning ± 50K
2.7 W/ft
2.8 W/ft
90
2.7 W/ft
2.8 W/ft
2.6 W/ft
2.7 W/ft
2.5 W/ft
2.6 W/ft
2.6 W/ft
2.7 W/ft
Max. 32.8 ft
2 in
Duristm E 3
6 per section / 36.5 per ft
32.8 ft
24 V DC
25 V DC
User Manual | liniLED® Diffuse Top & Side
Organic Lighting, 205 W. Blueridge Avenue, Orange, CA 92865 | 626.969.6140 | www.organiclighting.com
7
Symmetric Diagram

Symbols
RoHS
5
System
F
IP40/IP68
BEND RADIUS
R
1.2"
CRI
80+
MAC
ADAM
2
S D C M
UV
CLEANING
FROST
SEA
POOL CL
POOL
CL
UL is a world leader in product safety testing and certification. UL sets standards and tests products to make sure
they meet standards.
The ETL Listed mark indicates that your product has been tested by Intertek and found in compliance with
accepted UL standards.
Electro Static Discharge (ESD) sensitive device, apply standard ESD precautions when handling the product.
Manufacturer’s declaration that the product meets the applicable EC directives.
Suitable for mounting on all surfaces and suitable to cover with insulating material.
Restriction of Hazardous Substances (RoHS): product complies with the RoHS directive and each homogeneous
material does not exceed the limits for the materials mentioned under the RoHS directive (Pb, Hg, Cd, Cr6+, PBB and
PBDE).
This product is IP68 depending on the configuration and application. See the documentation for the exact IP rating.
Bending of the LED strip is possible with a radius of ≥ 1.2 inches in the specified direction.
Electrical appliance class III: this product is designed to be supplied from an extra-low voltage (≤ 60.0 V DC or ≤ 42.4 V
AC).
System guarantee of 5 years when the complete system consist of liniLED® products with the 5 year system warranty
logo.
Product is resistant against ultraviolet (UV) light or sunlight. Non-UV resistant products can degrade or discolor fast
when exposed to UV.
Product can be cleaned with normal cleaning agents as specified in the datasheet under 'chemical compliances.'
This product can be stored and used below 32 degrees Fahrenheit. Verify the minimum storage and operation
temperature in the datasheet for the lowest temperature allowed.
This product can be applied in seawater and its environment. Elements in seawater will have no harmful effect on the
product. For chemical specifications see datasheet. Verify the IP rating for proper use.
This product can be applied inside swimming pool environments. Elements in the air will have no harmful effect on
the product. For chemical specifications of these elements see datasheet. Verify the IP rating for proper use.
This product is available on request and can be submerged n swimming pools and their environments. Disinfectants
will have no harmful effect on product. For chemical specifications of these elements see datasheet. Verify the IP
rating for proper use.
The CRI value of this product is 80 or higher.
The binning tolerance of this product is 2 MacAdam.
Disclaimer
The published information is checked to be as accurate as possible, however Organic Lighting, or any reseller of liniLED® cannot be
held liable for any damages resulting from errors or outdated information. Organic Lighting reserves the right to modify the
information without informing the costumers. When this document is printed or downloaded, please check for the latest version on
the internet, the most up to date information will be published on www.organiclighting.com. This product should not be used in
applications, devices or systems where incorrect operation of the product may result in personal injury (includes emergency lighting)
without written permission from the board of Organic Lighting. If nevertheless used in such applications, devices or systems Organic
Lighting cannot be held liable for any resulting injury. 8
