ORiNG RFA-O5-NF2-W3GG Series User manual
Mounting Instruction
Plan your installation procedure carefully
and completely before begin.
Mount antenna at highest position on a flat
roof without any obstacles within a radius of
approximately 1 meter or more.
Clear the area where the antenna is
mounted from paint, corrosion or anodized
layer.
Clear this area from any dust, brake dust,
cutting chip and oil.
Dimension (Unit=mm)
Version 1.0
Outdoor Omnidirectional Antenna
Quick Installation Guide
QIG PRINTED ON RECYCLED PAPER
RFA-O5-NF2-W3GG Series
Do not use a metal ladder when installing
your antenna
Top View
Keep away from catenary and high voltage
lines.
If an accident or emergency occurs with
the power lines, call for qualified
emergency help immediately.
Side View
Non GPS Model GPS Model
The four screw enclosures are
suggested to be sealed by silicone.
1907-2-29-RFAO5NF2W3GG-1.0
RFA-O5-NF2-W3GG Series
Bottom View
Mounting surface must be cleaned before
installation
Always make sure the screws are tightened.
Use a hex-head screw M10 plus the enclosed
sealing washer.
MIMO
Antenna
Rail
7.00
145.00
115.00
Φ 12.00
85.00
56.00
115.00
Outdoor
145.00
115.00
Φ 12.00
22.00
46.5046.50
56.00
85.00
Antenna Cable
Antenna Cable
145.00
115.00
Φ 12.00
22.00
46.5046.50
56.00
85.00
Antenna Cable
Antenna Cable
GPS Cable
Indoor
Outdoor
Indoor
Mounting surface
Max 0.15mm
Min 2.0mm
Washer
Washer
NUT
QIG PRINTED ON RECYCLED PAPER
Version 1.0
Quick Installation Guide
Drilling holes for a new antenna deployment
Drilling the mounting hold according
to the sketch plane
RFA-O5-NF2-W3GG Series
ORing Industrial Networking Corp.
Copyright© 2015 ORing
All rights reserved.
TEL: +886-2-2218-1066
FAX: +886-2-2218-1014
Website: www.oring-networking.com
E-mail: [email protected]
Outdoor Omnidirectional Antenna
RFA-O5-NF2-W3GG Series
MIMO
Antenna
Rail
Find a suitable surface and clean the
area
115.00
15.0015.00
Max Φ 12.00 Hole x4
Antenna Cable
Antenna Cable
GPS Cable
Max Φ 40.00 Hole
14.50 14.50
56.00
