AC Antennas KUM803 Series User manual

466.67
466.67
PCB
(Coax cable
not included)
Box
Box Lid
M3 Machine
Screws
(4 pcs)
TX15 Tapping
Screw with
Washer
M10 nuts
(reused from
antenna)
Bottom section
Middle section
Top section
Mounting
Sleeve
(2 pcs)
200mm
50mm
Tighten the M12
bolts with max 9Nm
of torque.
Use sleeve supplied
with antenna.
(Do not use
additional sleeve)
140
75
11
65mm
11mm
130mm
155mm
60mm
145mm
120mm
13.5mm
Installation Guide
for 3 Section
KUM803,
KUM903 Series
and Mounts
457-0004.04
(Only applicable for type -1 and -2)
Package content:
M8 set screws
(3 pcs)
M6 set screws
(2 pcs)
N115F-Set Clamp Mount
Stainless Ø38-Ø70mm
MWM mount DMC mount DM mount
AC Antennas A/S
Fabriksparken 40, DK-2600 Glostrup, Denmark
WWW.ACANTENNAS.COM

A
B
C
DETAIL A
SCALE 2 : 5
2:
Tighten the M6 set screws
(2 pcs) with 3-5Nm
recommended torque.
(Use loctite on the set
screws for extreme
cases - Not supplied)
1:
Assemble the top and middle
antenna sections with 20-25 Nm
recommended torque
DETAIL B
SCALE 2 : 5
3:
Assemble the middle and
bottom antenna sections with 80-
100 Nm recommended torque
4:
Tighten the M8 set
screws (3 pcs) with 6-8 Nm
recommended torque.
(Use loctite on the set
screws for extreme
cases - Not supplied)
DETAIL C
SCALE 1 : 3
(Only applicable for coax cable installation type -1 and -2)
Grounding Cable
(Termination is
system dependable)
Connect coax
shield here
Connect coax
center here
TX15 Tapping Screw
fixes box to antenna
Installation Guide
This is a guide only and does not form any contract or warranty
