Orion HCCA3000.2H User manual

OWNER'S MANUAL- 2
I N TRODUCTION
Thank you for your purchase of Orion’s amplifier. Each Orion
amplifier is designed to be the leader in its class offering ease of use,
advanced features, and the most power. orion amplifiers are
designed as the best affordable high end car audio amplifier money
can buy. listed below are the features of these new orion amplifiers.
• HCCA1200.2 - 450 Watts per channel, two-channel amplifier with
dual built-in high-pass and low-pass 12dB / octave crossover and Bass
Boost. The HCCA1200.2 is capable of 3,2, or 1 channel operation with
a maximum power of 1200 watts RMS into 4Ωmono bridged.
• HCCA1500.2 - 500 Watts per channel, two-channel amplifier with
dual built-in high-pass and low-pass 12dB / octave crossover and Bass
Boost. The HCCA1500.2 is capable of 3,2, or 1 channel operation wit
a maximum power of 1500 watts RMS into 4Ωmono bridged.
• HCCA2000.2 - 600 Watts per channel, two-channel amplifier with
dual built-in high-pass and low-pass 12dB / octave crossover and Bass
Boost. The HCCA2000.2 is capable of 3,2, or 1 channel operation wit
a maximum power of 2000 watts RMS into 4Ωmono bridged.
• HCCA3000.2H - 900 Watts per channel, two-channel amplifier
with dual built-in high-pass and low-pass 12dB / octave crossover
and Bass Boost. The HCCA3000.2H is capable of 3,2, or 1 channel
operation with a maximum power of 3000 watts RMS into 4Ωmono
bridged.
• HCCA2000.4 - 300 Watts per channel, four-channel amplifier with
dual built-in high-pass and low-pass 12dB / octave crossover and Bass
Boost. The HCCA2000.4 is capable of 5,4,3, or 2 channel operation
witha maximum power of 2000 watts RMS into 4Ωmono bridged.
• HCCA3000.4H - 450 Watts per channel, two-channel amplifier with
dual built-in high-pass and low-pass 12dB / octave crossover and Bass
Boost. The HCCA3000.4H is capable of 3,2, or 1 channel operation wit
a maximum power of 3000 watts RMS into 4Ωmono bridged.
• HCCA4000.4H - 600 Watts per channel, two-channel amplifier with
dual built-in high-pass and low-pass 12dB / octave crossover and Bass
Boost. The HCCA4000.4H is capable of 3,2, or 1 channel operation wit
a maximum power of 4000 watts RMS into 4 mono bridged.
• HCCA5000.1DV2 - 5000 Watts single-channel Class D amplifier
with built-in subsonic filter, with Bass Boost, and remote gain.
• HCCA8000.1DV2 - 8000 Watts single-channel Class D amplifier
with built-in subsonic filter, with Bass Boost, and remote gain.
• HCCA11100.1DV2 - 11000 Watts single-channel Class D amplifier
with built-in subsonic filter, with Bass Boost, and remote gain.
• HCCA4000.2H - 1200 Watts per channel, two-channel amplifier
with dual built-in high-pass and low-pass 12dB / octave crossover
and Bass Boost. The HCCA4000.2H is capable of 3,2, or 1 channel
operation with a maximum power of 4000 watts RMS into 4Ωmono
bridged.
• HCCA1000.4 - 200 Watts per channel, four-channel amplifier with
dual built-in high-pass and low-pass 12dB / octave crossover and Bass
Boost. The HCCA1000.4 is capable of 5,4,3, or 2 channel operation
witha maximum power of 1000 watts RMS into 4Ωmono bridged.
• HCCA1500.4 - 255 Watts per channel, four-channel amplifier with
dual built-in high-pass and low-pass 12dB / octave crossover and Bass
Boost. The HCCA1500.4 is capable of 5,4,3, or 2 channel operation
witha maximum power of 1500 watts RMS into 4Ωmono bridged.
The HCCA5000.1DV2 is capable of one-channel operation
with a maximum power of 5000 watts RMS @ into 1Ω.
The HCCA8000.1DV2 is capable of one-channel operation
with a maximum power of 8000 watts RMS @ into 1Ω.
The HCCA1100.1DV2 is capable of one-channel operation
with a maximum power of 11000 watts RMS @ into 1Ω.
