Orisec CK-60 User manual

Master User Guide
CK-10, CT-10, CP-10, CK-20, CT-20, CP-20,
CP-30, CP-50, CK-60, CT-60, CP-60, CP-100 & CP-200
Designed and Manufactured
in the United Kingdom

2
Contents
1. About your Security System ..............................................................................................4
Introduction.............................................................................................................................................4
About this Manual.................................................................................................................................4
Alarm Transmission System................................................................................................................4
Zones and Areas....................................................................................................................................4
Access code.............................................................................................................................................4
NFC Tags..................................................................................................................................................5
Keypads.....................................................................................................................................................5
Emergency Keys.....................................................................................................................................8
2. Operating your Security System......................................................................................11
Introduction............................................................................................................................................11
User Menu...............................................................................................................................................11
Before Arming the Security System................................................................................................11
Full Arming Your Security System .................................................................................................. 12
Part Arming your Security System.................................................................................................. 13
Disarming your security system ...................................................................................................... 14
Area full arming.................................................................................................................................... 15
Area part arming.................................................................................................................................. 16
Area disarming ..................................................................................................................................... 17
Resetting after an alarm .................................................................................................................... 18
Resetting after a Fault Condition.................................................................................................... 19
Omitting Zones.....................................................................................................................................20
Changing Your Code.......................................................................................................................... 21
Turn chime on/off................................................................................................................................22
System Event Logs...............................................................................................................................23
View event log......................................................................................................................................24
View mandatory log............................................................................................................................24
View chime log.....................................................................................................................................25

3
Print Log .................................................................................................................................................25
System Tests.......................................................................................................................................... 31
Test Bell & Strobe................................................................................................................................32
Walk Test Zones...................................................................................................................................33
View Inactive Zones............................................................................................................................34
View Zone Status.................................................................................................................................35
View Module Status ............................................................................................................................36
Do a Test Call........................................................................................................................................37
Review Voice Messages.....................................................................................................................37
Send SMS Message.............................................................................................................................38
Change Settings...................................................................................................................................39
Set Time & Date...................................................................................................................................40
Holiday Dates........................................................................................................................................40
Add/Delete Users.................................................................................................................................41
Alter chime zones................................................................................................................................46
Coms Modules......................................................................................................................................47
About.......................................................................................................................................................49
3. Additional Features........................................................................................................... 50
4. Troubleshooting .................................................................................................................51
5. Touch-Tone Remote Control.......................................................................................... 52
Introduction...........................................................................................................................................52
Remote Control Menu .......................................................................................................................52
Remote Access .....................................................................................................................................52
Full Arm...................................................................................................................................................53
Part Arm..................................................................................................................................................53
Disarm .....................................................................................................................................................53
Turn Remote Controlled Outputs On and Off ...........................................................................54
Record and Playback Speech Messages......................................................................................54
Installer Information............................................................................................................................55

4
1. About your Security System
Introduction
Your security system is made up of several component parts comprising of a control panel,
one or more remote keypads, external sounder and various detection devices that are
connected to either the control panel or zone expansion modules. The control panel houses
the system’s electronics and stand-by battery and is normally installed out of sight in a utility
room or under stairs cupboard etc.
The remote keypad provides the user interface for the system and is used to send commands
to the system and to display the current system status via a graphic display. The remote keypad
also provides audible feedback annunciation of fault and alarm tones. Remote keypads are
normally mounted in convenient locations inside the protected premises, near to the points of
entry and exit.
Please read this manual carefully and have your installer instruct you on your system’s
operation. Become familiar with the features that have been implemented on your system. All
users of this system should be equally instructed in its use.
About this Manual
This manual provides a thorough explanation of all system functions that are available to the
master user, including basic system operation, user code programming, remote control and
troubleshooting.
Alarm Transmission System
Your security system may be fitted with an automatic alarm transmission system, which will
communicate alarms, faults and other events to a 24hr manned Alarm Receiving Centre (ARC).
If you accidently cause a false alarm activation, immediately call the ARC to prevent an
unnecessary emergency response.
Zones and Areas
A zone is an input that is normally used to monitor a single detection device like a motion
detector, door contact or shock sensor etc. An area is one or more zones grouped together to
allow independent arming and disarming of areas.
Access code
As a user of the security system, you will be assigned a 4, 5 or 6 digit access code. Access codes
are used to arm and disarm the system. Some access codes can perform additional system
functions, such as programming system options, omitting zones and performing system tests.

5
Your access code may not allow you to access certain system functions. For instance, if your
code is only allowed to arm the system you will not be able to disarm the system, once the
system is armed.
NFC Tags
NFC tags can be assigned to users of the system. The tag behaves just like an access code
when presented to the NFC reader built into the keypad. NFC technology is built into credit
cards, bank cards, smart phones and other devices. (Not on CK-10 or CT-10)
Keypads
One or more remote keypads will be installed throughout the protected premises, usually close
to the entry and exit door. The CK-10, CK-20, CT-10, and CT-20 control panels have built in
keypads.
Keypad Layout: RK-400-LCD & RK-450-LCD
1. LCD display
2. NFC reader –present your NFC tag in this area (not on CK-10 or CT-10)
3. Status Icons
4. Keyboard –see below
Keyed Keypad buttons
Actions
u
Arm system and to navigate upwards in the menu
p
Part arm system and to navigate down in the menu
r
Chime tone selection and can be used to enter menu
o
Omit zones and if held for 1 second can work to go ‘back’ in a menu
0
If held for 1 second can be used to toggle options and outputs
✓
Selection button
X
Cancel Button. Press and hold for 1 second to delete a selection.

6
Keypad Layout: CK-10, CK-20, CK-60, RK-500, RK-550, MK-700 & RK-700
1. LCD display
2. NFC reader –present your NFC tag in this area (not on CK-10 or CT-10)
3. Status Icons
4. System status LED
5. Ambient light sensor –used automatically adjusts the keyboard and LCD backlight level
6. Keyboard –see below
Keyed Keypad buttons
Actions
A
Arm system
P
Part arm system
a
Area arm system
E
Selection button
c
Chime tone selection
B
Escape button
C
Cancel button

7
Touchscreen Keypad Layout: CT-10, CT-20, CT-60, TK-650
1. Full colour touch display
2. NFC Reader –present your NFC tag in this area (not on CK-10 or CT-10)
3. Status Icons
4. System status LED
Touch Keypad buttons
Function
Arm system
Part arm system
Area arm system
Selection button
Chime tone selection
Escape button
Cancel button

8
Status Icons
The system status area on the display is used to show the following information:
Status Icon
Indicates
#$%K
Battery is charging / is charged
L
Mains power is connected
&
Mains power is disconnected
p
External strobe is flashing
M
External bell is sounding
N
Chime is enabled
Q
Wi-Fi module connected
T
GSM module connected
H
Ethernet module connected
Z
Phone line connected
3
User programmed timer running
[
User programmed alarm running
Status LED
The keypad has a single multi-colour LED and is used to indicate the following:
Colour
System Status
Blue
Normal operation, all zones are healthy
Green
User menu selected and system is ready for arming
Yellow
One or more zones are active, system may not arm
Red
Alarm active
Emergency Keys
The keypad provides three different emergency functions. Depending on the setup of your
system, activation from these keys can alert the local police, key holders and security personal
via your Alarm Receiving Centre (ARC).
The emergency keys for each keypad can be individual enabled or disabled and may
not be enabled on your installation due to local standards and police requirements.
The Panic alarm (Police) function for each keypad can be programmed for either an
audible or silent operation.
Keyed Keypad Emergency Keys
To activate the emergency functions, press together the keys shown below for a duration of 1
second:

9
Emergency Alarm
Keys
Fire
Press 1& 3
Panic Alarm (PA)
Press 4& 6
Medical
Press 7& 9
Touch Keypad Emergency Keys
1. To activate the emergency keys on your touch screen keypad you will need to be on the
Home screen:
2. From the top part of the screen select one of the emergency functions, for example ‘Fire’:
3. You will then be prompted to press the Fire Alarm icon, and then select the icon again
to confirm the activation. This is in place to ensure it is a confirmed event and not an
accidental button press:

10
4. Press the ‘CONFIRM’ icon to generate the selected emergency or press the ‘Back’ icon
to cancel.
