Oshkosh Corporation 0300236299 Use and care manual

ANSI
®
Operation and Safety Manual
Original Instructions - Keep this manual with the machine at all times.
AS/NZS
Boom Lift Models
600SC
660SJC
S/N 0300236299 to Present
3121775
November 5, 2018 - Rev D
To order go to Discount-Equipment.com

WARNING
Operating, servicing and maintaining this vehicle or equipment
can expose you to chemicals including engine exhaust, carbon
monoxide, phthalates, and lead, which are known to the State of
California to cause cancer and birth defects or other
reproductive harm. To minimize exposure, avoid breathing
exhaust, do not idle the engine except as necessary, service your
vehicle or equipment in a well-ventilated area and wear gloves
or wash your hands frequently when servicing. For more
information go to www.P65Warnings.ca.gov.
To order go to Discount-Equipment.com

FOREWORD
3121775 a
FOREWORD
This manual is a very important tool! Keep it with the machine at all times.
The purpose of this manual is to provide owners, users, operators, lessors, and lessees with the precautions and operating
procedures essential for the safe and proper machine operation for its intended purpose.
Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without
prior notification. Contact JLG Industries, Inc. for updated information.
To order go to Discount-Equipment.com

FOREWORD
b3121775
SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS
INDICATES AN IMMINENTLY HAZARDOUS SITUATION. IF NOT AVOIDED, WILL
RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE A RED BACK-
GROUND.
INDICATES A POTENTIALLY HAZARDOUS SITUATION. IF NOT AVOIDED, COULD
RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE AN ORANGE BACK-
GROUND.
INDICATES A POTENTIALLY HAZARDOUS SITUATION. IF NOT AVOIDED, MAY RESULT
IN MINOR OR MODERATE INJURY. IT MAY ALSO ALERT AGAINST UNSAFE PRACTICES.
THIS DECAL WILL HAVE A YELLOW BACKGROUND.
INDICATES INFORMATION OR A COMPANY POLICY THAT RELATES DIRECTLY OR INDI-
RECTLY TO THE SAFETY OF PERSONNEL OR PROTECTION OF PROPERTY.
This is the Safety Alert Symbol. It is used to alert you to the potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury or
death
To order go to Discount-Equipment.com

FOREWORD
3121775 c
THIS PRODUCT MUST COMPLY WITH ALL SAFETY RELATED BULLETINS. CONTACT JLG
INDUSTRIES, INC. OR THE LOCAL AUTHORIZED JLG REPRESENTATIVE FOR INFORMA-
TION REGARDING SAFETY-RELATED BULLETINS WHICH MAY HAVE BEEN ISSUED FOR
THIS PRODUCT.
JLG INDUSTRIES, INC. SENDS SAFETY RELATED BULLETINS TO THE OWNER OF
RECORD OF THIS MACHINE. CONTACT JLG INDUSTRIES, INC. TO ENSURE THAT THE
CURRENT OWNER RECORDS ARE UPDATED AND ACCURATE.
JLG INDUSTRIES, INC. MUST BE NOTIFIED IMMEDIATELY IN ALL INSTANCES WHERE
JLG PRODUCTS HAVE BEEN INVOLVED IN AN ACCIDENT INVOLVING BODILY INJURY
OR DEATH OF PERSONNEL OR WHEN SUBSTANTIAL DAMAGE HAS OCCURRED TO PER-
SONAL PROPERTY OR THE JLG PRODUCT.
Contact:
Product Safety and Reliability Department
JLG Industries, Inc.
13224 Fountainhead Plaza
Hagerstown, MD 21742
USA
or Your Local JLG Office
(See addresses on inside of manual cover)
In USA:
Toll Free: 877-JLG-SAFE (877-554-7233)
Outside USA:
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
For:
• Accident Reporting
• Product Safety Publica-
tions
• Current Owner Updates
• Questions Regarding
Product Safety
• Standards and Regulations
Compliance Information
• Questions Regarding Special
Product Applications
• Questions Regarding Prod-
uct Modifications
To order go to Discount-Equipment.com

FOREWORD
d3121775
REVISION LOG
Original Issue A - October 23, 2017
Revised B - March 23, 2018
Revised C - June 29, 2018 - Revised Covers, Prop 65
Revised D - November 5, 2018
To order go to Discount-Equipment.com

3121775 i
SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE
TABLE OF CONTENTS
SECTION - 1 - SAFETY PRECAUTIONS
1.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 PRE-OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Operator Training and Knowledge . . . . . . . . . . . . . . . . . 1-1
Workplace Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Machine Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.3 OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Trip and Fall Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Electrocution Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Tipping Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Crushing and Collision Hazards . . . . . . . . . . . . . . . . . . 1-10
1.4 TOWING, LIFTING, AND HAULING. . . . . . . . . . . . . . . . . . . . 1-11
1.5 MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Maintenance Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Battery Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
SECTION - 2 - USER RESPONSIBILITIES, MACHINE PREPARATION,
AND INSPECTION
2.1 PERSONNEL TRAINING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Operator Training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Training Supervision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Operator Responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 PREPARATION, INSPECTION, AND MAINTENANCE . . . . . 2-2
Pre-Start Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Walk-Around Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Function Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
SkyGuard Function Test. . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
SECTION - 3 - MACHINE CONTROLS AND INDICATORS
3.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 CONTROLS AND INDICATORS . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Ground Control Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Ground Control Indicator Panel . . . . . . . . . . . . . . . . . . 3-10
Ground Control Console Display Gauge . . . . . . . . . . 3-13
Platform Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Platform Control Indicator Panel . . . . . . . . . . . . . . . . . 3-22
SECTION - 4 - MACHINE OPERATION
4.1 DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 OPERATING CHARACTERISTICS AND LIMITATIONS . . . . 4-1
Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Stability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.3 ENGINE OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Starting Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Shutdown Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Air Shutoff Valve (ASOV) (If Equipped). . . . . . . . . . . . . . 4-6
Fuel Reserve / Shut-Off System. . . . . . . . . . . . . . . . . . . . . 4-7
4.4 TRAVELING (DRIVING) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Traveling Forward and Reverse . . . . . . . . . . . . . . . . . . . . 4-8
Traveling on a Grade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
To order go to Discount-Equipment.com

ii 3121775
TABLE OF CONTENTS
SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE
4.5 PLATFORM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Platform Level Adjustment . . . . . . . . . . . . . . . . . . . . . . . 4-15
Platform Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
4.6 BOOM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Swinging the Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
Raising and Lowering the Main Boom . . . . . . . . . . . . . 4-16
Telescoping the Main Boom . . . . . . . . . . . . . . . . . . . . . . 4-16
4.7 SHUT DOWN AND PARK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
4.8 MACHINE SAFETY SYSTEM OVERRIDE (MSSO)
(CE ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
4.9 SKYGUARD OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
SkyGuard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
SkyGuard SkyLine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
SkyGuard SkyEye . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
SkyGuard Function Table . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
4.10 AUXILIARY POWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Activating from the Platform Control Station . . . . . . 4-20
Activating from the Ground Control Station . . . . . . . 4-20
4.11 TIE DOWN AND LIFTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
SECTION - 5 - EMERGENCY PROCEDURES
5.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 INCIDENT NOTIFICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.3 EMERGENCY OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Operator Unable to Control Machine. . . . . . . . . . . . . . . 5-1
Platform or Boom Caught Overhead . . . . . . . . . . . . . . . 5-2
5.5 MACHINE SAFETY SYSTEM OVERRIDE (MSSO)
(CE ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
SECTION - 6 - ACCESSORIES
6.1 SKYPOWER™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Generator Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Accessory Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Preparation and Inspection . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6.2 SKYWELDER™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Welding Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Accessory Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Preparation and Inspection . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
6.3 SKYGLAZIER™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Preparation and Inspection . . . . . . . . . . . . . . . . . . . . . . . 6-10
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
To order go to Discount-Equipment.com

3121775 iii
SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE
TABLE OF CONTENTS
SECTION - 7 - GENERAL SPECIFICATIONS & OPERATOR
MAINTENANCE
7.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.2 OPERATING SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Dimensional Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Engine Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Critical Stability Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Serial Number Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
7.3 OPERATOR MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16
7.4 SUPPLEMENTAL INFORMATION . . . . . . . . . . . . . . . . . . . . . 7-25
SECTION - 8 - INSPECTION AND REPAIR LOG
To order go to Discount-Equipment.com

iv 3121775
TABLE OF CONTENTS
SECTION - PARAGRAPH, SUBJECT PAGE SECTION - PARAGRAPH, SUBJECT PAGE
This Page Left Blank Intentionally
To order go to Discount-Equipment.com

3121775 v
LIST OF FIGURES
FIGURE NUMBER - TITLE PAGE FIGURE NUMBER - TITLE PAGE
2-1. Basic Nomenclature - Upperstructure - 600SC. . . . . . . . . 2-4
2-2. Basic Nomenclature - Upperstructure - 660SJC . . . . . . . . 2-5
2-3. Basic Nomenclature - Chassis. . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2-4. Daily Walk-Around Inspection Diagram . . . . . . . . . . . . . . . 2-8
2-5. Daily Walk-Around Inspection Points - Sheet 1 of 2 . . . . 2-9
2-6. Daily Walk-Around Inspection Points - Sheet 2 of 2 . . . 2-10
3-1. Ground Control Station - 600S. . . . . . . . . . . . . . . . . . . . . . . . 3-3
3-2. Ground Control Station - 600S with Machine Safety System
Override (MSSO)(CE Only) . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3-3. Ground Control Station - 660SJ. . . . . . . . . . . . . . . . . . . . . . . 3-5
3-4. Ground Control Station - 660SJ with Machine Safety
System Override (MSSO)(CE Only) . . . . . . . . . . . . . . . . . . 3-6
3-5. Ground Control Indicator Panel . . . . . . . . . . . . . . . . . . . . . 3-11
3-6. Splash Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
3-7. Diagnostic Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3-8. Engine Diagnostic Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3-9. Ground Control Console Display Gauge . . . . . . . . . . . . . 3-15
3-10. Platform Control Console . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
3-11. Platform Control Indicator Panel. . . . . . . . . . . . . . . . . . . . . 3-23
3-12. Fuel Level Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
4-1. Position of Least Backward Stability . . . . . . . . . . . . . . . . . . 4-2
4-2. Position of Least Forward Stability . . . . . . . . . . . . . . . . . . . . 4-3
4-3. ASOV Reset (Closed to Open Position) . . . . . . . . . . . . . . . . 4-6
4-4. Machine Motion Hazard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4-5. Drive Function Operating Range Diagrams -
Sheet 1 of 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
4-6. Drive Function Operating Range Diagrams -
Sheet 2 of 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
4-7. Traveling on a Grade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
4-8. Grade and Sideslope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
4-9. Boom Function Operating Range Diagram. . . . . . . . . . . 4-17
4-10. Lifting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
4-11. Decal Installation - Sheet 1 of 8 . . . . . . . . . . . . . . . . . . . . . . 4-23
4-12. Decal Installation - Sheet 2 of 8 . . . . . . . . . . . . . . . . . . . . . . 4-24
4-13. Decal Installation - Sheet 3 of 8 . . . . . . . . . . . . . . . . . . . . . . 4-25
4-14. Decal Installation - Sheet 4 of 8 . . . . . . . . . . . . . . . . . . . . . . 4-26
4-15. Decal Installation - Sheet 5 of 8 . . . . . . . . . . . . . . . . . . . . . . 4-27
4-16. Decal Installation - Sheet 6 of 8 . . . . . . . . . . . . . . . . . . . . . . 4-28
4-17. Decal Installation - Sheet 7 of 8 . . . . . . . . . . . . . . . . . . . . . . 4-29
4-18. Decal Installation - Sheet 8 of 8 . . . . . . . . . . . . . . . . . . . . . . 4-30
6-1. SkyWelder™ - Sheet 1 of 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
6-2. SkyWelder™ - Sheet 2 of 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
7-1. Serial Number Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
7-2. Engine Operating Temperature Specifications -
Deutz 2.9L . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
7-3. Engine Operating Temperature Specifications - Deutz
2011. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
7-4. Hydraulic Oil Operation Chart - Sheet 1 of 2. . . . . . . . . . 7-12
7-5. Hydraulic Oil Operation Chart - Sheet 2 of 2. . . . . . . . . . 7-13
7-6. Operator Maintenance & Lubrication Diagram - Deutz
2011 Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14
7-7. Operator Maintenance & Lubrication Diagram - Deutz 2.9L
To order go to Discount-Equipment.com

vi 3121775
LIST OF FIGURES
FIGURE NUMBER - TITLE PAGE FIGURE NUMBER - TITLE PAGE
Engine7-15
This Page Left Blank Intentionally
To order go to Discount-Equipment.com

3121775 vii
LIST OF TABLES
TABLE NUMBER - TITLE PAGE TABLE NUMBER - TITLE PAGE
1-1 Minimum Approach Distances (M.A.D.) . . . . . . . . . . . . . . . 1-6
1-2 Beaufort Scale (For Reference Only). . . . . . . . . . . . . . . . . . . 1-9
2-1 Inspection and Maintenance Table . . . . . . . . . . . . . . . . . . . 2-3
4-1 600SC Decal Legend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-31
4-2 660SJC Decal Legend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-35
6-1 Available Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6-2 Options/Accessories Relationship Table. . . . . . . . . . . . . . . 6-2
6-3 Welding Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6-4 Specifications for SkyGlazier™ . . . . . . . . . . . . . . . . . . . . . . . . 6-9
7-1 Operating Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7-2 Dimensional Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
7-3 Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
7-4 Deutz D2011L04 Specifications . . . . . . . . . . . . . . . . . . . . . . . 7-3
7-5 Deutz D2.9L4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
7-6 Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
7-7 Mobilfluid 424 Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
7-8 Mobil DTE 10 Excel 32 Specs. . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
7-9 Quintolubric 888-46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
7-10 Mobil EAL 224H Specs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
7-11 Mobil EAL H 46 Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
7-12 Exxon Univis HVI 26 Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
7-13 Critical Stability Weights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
7-14 Lubrication Specifications.. . . . . . . . . . . . . . . . . . . . . . . . . . .7-16
8-1 Inspection and Repair Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
To order go to Discount-Equipment.com

We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,
Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power
Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,
Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic, Dynapac,
MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti, Morrison, Contec,
Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S. Curtis, Gehl Pavers, Heli,
Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin, Rice, CH&E, General Equip-
ment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent, Stanley, Tamco, Toku, Hatz,
Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air, APT, Wylie, Ingersoll Rand /
Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith Surface Prep,Small Line,
Wanco, Yanmar
Discount-Equipment.com is your online resource for
commercial and industrial quality parts and equipment sales.
561-964-4949
visit us on line @ www.discount-equipment.com
TO PURCHASE THIS PRODUCT PLEASE CONTACT US
Select an option below to find your Equipment
Equipment Financing and
Extended Warranties Available

SECTION 1 - SAFETY PRECAUTIONS
3121775 1-1
SECTION 1. SAFETY PRECAUTIONS
1.1 GENERAL
This section outlines the necessary precautions for proper and
safe machine usage and maintenance. It is mandatory that a daily
routine is established based on the content of this manual to pro-
mote proper machine usage. A maintenance program, using the
information provided in this manual and the Service and Mainte-
nance Manual, must also be established by a qualified person and
must be followed to ensure that the machine is safe to operate.
The owner/user/operator/lessor/lessee of the machine must not
accept operating responsibility until this manual has been read,
training is accomplished, and operation of the machine has been
completed under the supervision of an experienced and quali-
fied operator.
This section contains the responsibilities of the owner, user, oper-
ator, lessor, and lessee concerning safety, training, inspection,
maintenance, application, and operation. If there are any ques-
tions with regard to safety, training, inspection, maintenance,
application, and operation, please contact JLG Industries, Inc.
(“JLG”).
FAILURE TO COMPLY WITH THE SAFETY PRECAUTIONS LISTED IN THIS MANUAL
COULD RESULT IN MACHINE DAMAGE, PROPERTY DAMAGE, PERSONAL INJURY OR
DEATH.
1.2 PRE-OPERATION
Operator Training and Knowledge
• The Operation and Safety Manual must be read and under-
stood in its entirety before operating the machine. For clarifi-
cation, questions, or additional information regarding any
portions of this manual, contact JLG Industries, Inc.
To order go to Discount-Equipment.com

SECTION 1 - SAFETY PRECAUTIONS
1-2 3121775
• An operator must not accept operating responsibilities until
adequate training has been given by competent and autho-
rized persons.
• Allow only those authorized and qualified personnel to oper-
ate the machine who have demonstrated that they under-
stand the safe and proper operation and maintenance of the
unit.
• Read, understand, and obey all DANGERS, WARNINGS, CAU-
TIONS, and operating instructions on the machine and in this
manual.
• Ensure that the machine is to be used in a manner which is
within the scope of its intended application as determined by
JLG.
• All operating personnel must be familiar with the emergency
controls and emergency operation of the machine as specified
in this manual.
• Read, understand, and obey all applicable employer, local, and
governmental regulations as they pertain to your utilization
and application of the machine.
Workplace Inspection
• Precautions to avoid all hazards in the work area must be
taken by the user before and during operation of the machine.
• Do not operate or raise the platform from a position on trucks,
trailers, railway cars, floating vessels, scaffolds or other equip-
ment unless the application is approved in writing by JLG.
• Before operation, check work area for overhead hazards such
as electric lines, bridge cranes, and other potential overhead
obstructions.
• Check operating surfaces for holes, bumps, drop-offs, obstruc-
tions, debris, concealed holes, and other potential hazards.
• Check the work area for hazardous locations. Do not operate
the machine in hazardous environments unless approved for
that purpose by JLG.
• Ensure that the ground conditions are adequate to support
the maximum tire load indicated on the tire load decals
located on the chassis adjacent to each wheel. Do not travel
on unsupported surfaces.
To order go to Discount-Equipment.com

SECTION 1 - SAFETY PRECAUTIONS
3121775 1-3
Machine Inspection
• Do not operate this machine until the inspections and func-
tional checks as specified in Section 2 of this manual have
been performed.
• Do not operate this machine until it has been serviced and
maintained according to the maintenance and inspection
requirements as specified in the machine’s Service and Main-
tenance Manual.
• Ensure all safety devices are operating properly. Modification
of these devices is a safety violation.
MODIFICATION OR ALTERATION OF AN AERIAL WORK PLATFORM SHALL BE MADE
ONLY WITH PRIOR WRITTEN PERMISSION FROM THE MANUFACTURER.
• Do not operate any machine on which the safety or instruction
placards or decals are missing or illegible.
• Check the machine for modifications to original components.
Ensure that any modifications have been approved by JLG.
• Avoid accumulation of debris on platform floor. Keep mud, oil,
grease, and other slippery substances from footwear and plat-
form floor.
1.3 OPERATION
General
• Machine operation requires your full attention. Bring the
machine to a full stop before using any device, i.e. cell phones,
two-way radios, etc. that will distract your attention from
safely operating the machine.
• Do not use the machine for any purpose other than position-
ing personnel, their tools, and equipment.
• Before operation, the user must be familiar with the machine
capabilities and operating characteristics of all functions.
• Never operate a malfunctioning machine. If a malfunction
occurs, shut down the machine. Remove the unit from service
and notify the proper authorities.
• Do not remove, modify, or disable any safety devices.
• Never slam a control switch or lever through neutral to an
opposite direction. Always return switch to neutral and stop
before moving the switch to the next function. Operate con-
trols with slow and even pressure.
• Do not allow personnel to tamper with or operate the
machine from the ground with personnel in the platform,
except in an emergency.
To order go to Discount-Equipment.com

SECTION 1 - SAFETY PRECAUTIONS
1-4 3121775
• Do not carry materials directly on platform railing unless
approved by JLG.
• When two or more persons are in the platform, the operator
shall be responsible for all machine operations.
• Always ensure that power tools are properly stowed and never
left hanging by their cord from the platform work area.
• When driving, always position boom over rear axle in line with
the direction of travel. Remember, if boom is over the front
axle, steer and drive functions will be reversed.
• Do not assist a stuck or disabled machine by pushing or pull-
ing except by pulling at the chassis tie-down lugs.
• Fully lower platform and shut off all power before leaving
machine.
• Remove all rings, watches, and jewelry when operating
machine. Do not wear loose fitting clothing or long hair unre-
strained which may become caught or entangled in equip-
ment.
• Persons under the influence of drugs or alcohol or who are
subject to seizures, dizziness or loss of physical control must
not operate this machine.
• Hydraulic cylinders are subject to thermal expansion and con-
traction. This may result in changes to the boom and/or plat-
form position while the machine is stationary. Factors
affecting thermal movement can include the length of time
the machine will remain stationary, hydraulic oil temperature,
ambient air temperature, and boom and platform position.
Trip and Fall Hazards
• During operation, occupants in the platform must wear a full
body harness with a lanyard attached to an authorized lanyard
anchorage point. Attach only one (1) lanyard per lanyard
anchorage point.
• Enter and exit only through gate area. Use extreme caution
when entering or leaving platform. Ensure that the platform
assembly is fully lowered. Face the machine when entering or
leaving the platform. Always maintain “three point contact”
with the machine, using two hands and one foot or two feet
and one hand at all times during entry and exit.
To order go to Discount-Equipment.com

SECTION 1 - SAFETY PRECAUTIONS
3121775 1-5
• Before operating the machine, make sure all gates are closed
and fastened in their proper position.
• Keep both feet firmly positioned on the platform floor at all
times. Never position ladders, boxes, steps, planks, or similar
items on unit to provide additional reach for any purpose.
• Keep oil, mud, and slippery substances cleaned from footwear
and the platform floor.
Electrocution Hazards
• This machine is not insulated and does not provide protection
from contact or proximity to electrical current.
To order go to Discount-Equipment.com

SECTION 1 - SAFETY PRECAUTIONS
1-6 3121775
• Maintain distance from electrical lines, apparatus, or any ener-
gized (exposed or insulated) parts according to the Minimum
Approach Distance (MAD) as shown in Table 1-1.
• Allow for machine movement and electrical line swaying.
• Maintain a clearance of at least 10 ft. (3m) between any part of
the machine and its occupants, their tools, and their equip-
ment from any electrical line or apparatus carrying up to
50,000 volts. One foot additional clearance is required for
every additional 30,000 volts or less.
Table 1-1. Minimum Approach Distances (M.A.D.)
Voltage Range
(Phase to Phase)
MINIMUM APPROACH DISTANCE
in Feet (Meters)
0to50KV 10(3)
Over50KVto200KV 15(5)
Over200KVto350KV 20(6)
Over350KVto500KV 25(8)
Over500KVto750KV 35(11)
Over750KVto1000KV 45(14)
NOTE: This requirement shall apply except where
employer, local or governmental regulations are
more stringent.
To order go to Discount-Equipment.com
