Osram Sylvania SP672-ASST-PL User manual

WIRELESS SPEAKER
SP672-ASST-PL
M
SYLVANIA is a registered trademark of
OSRAM Sylvania Inc. used under license.
Thank you for purchasing this product.
Please read this manual carefully, and
save it for future reference.

r
Speaker Overview....................................................................................... 4
Control Buttons (Top) ................................................................................. 5
Installing the USB Power Cable.................................................................. 6
Charging the Built-in Battery ...................................................................... 6
Power On/Off the Speaker ......................................................................... 7
Bluetooth Audio Streaming......................................................................... 8
Using the USB Port .................................................................................... 9
Using the TF Card Slots .............................................................................10
Listening to the Radio.................................................................................11
Using the AUX Input ...................................................................................12
13
13

Use of any controls or adjustments or performance of procedures other
than those herein specified may result in hazardous radiation exposure.
CAUTION:
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
WARNING:
Do not place the unit on top of any soft, porous,or sensitive surfaces to
avoid damaging the surface. Use a protective barrier between the unit and surface to
protect the surface.
WARNING:
WARNINGS AND PRECAUTIONS
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture.
-1-
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type.
CAUTION:
The battery, batteries, and battery pack shall not be exposed to excessive
heat such as sunshine, fire, or the like.
WARNING:
Lithium batteries, like all rechargeable batteries are recyclable and should
be recycled or disposed of in normal household waste. Contact your local government
for disposal or recycling practices in your area. They should never be incinerated since
WARNING:
Shock hazard - Do Not Open.
WARNING:
they might explode.

.
IMPORTANT SAFETY INSTRUCTIONS
.
.
.
Special note:
2

PRODUCT FEATURES
-3-
Bluetooth technology: V3.0
Stereo sound output: 3W x 2 (max.)
Power rating: DC 5V / 1.0A (via Micro-USB port)
PACKAGE CONTENTS
Please make sure that the items shown below are included in the package.
Instruction manual: 1 pcs
USB charging cable: 1 pcs
3.5mm stereo audio cable: 1 pcs
Warranty card: 1 pcs
Should an item be missing, please contact the local retailer from which you
purchased this product.
Bluetooth speaker: 1 pcs
3.5mm auxiliary input (stereo mini jack)
Built-in Lithium-ion rechargeable battery
Bluetooth transmission range: 10M (Free space)
Aluminum carry handle
FM radio
USB & TF card support direct music play

DEVICE OVERVIEW
-4-
Speaker Overview
M
Left Speaker
Control Panel
Right Speaker
Carry Handle

-5-
Control Buttons (Top)
Skips to previous tracks.
Skips to next tracks.
4
Press and release to decrease
the volume in steps.
Press and hold to progressively
decrease the volume.
5
Press and release to increase the
volume in steps.
Press and hold to progressively
increase the volume.
6
1 2 3 4 5 6
7
8
Changes modes: USB, TF
card, FM, AUX, or Bluetooth.
M (MODE)
Lights red: Charging
Lights off: Fully charged
8
Charge LED Indicator
In Bluetooth, Aux,USB, or TF
card mode: short press to
Play / Pause playback
Note: You can press and hold the button to unpair
your current device and search for new devices in
Bluetooth mode.
Note: You will hear an audible alert when the maximum
volume level has been reached.
Note: Will automatically skip USB/TF card mode
when there is no USB/TF card inserted on the
speaker device
Note: Not available for AUX IN mode
Note: Not available for AUX IN mode
Note: You will hear an audible alert when the
minimum volume level has been reached.
In FM mode: press and hod
it for 3 seconds to start
auto-scan and memory,or
short press to mute sound,
press again to resume sound.
- Flashes in blue quickly:
Scanning channels
- Flashes in blue slowly:
FM listening
- Lights solid blue: FM muted by
pressing Play/Pause button.
Press again to resume sound.
- Lights solid green: Connected
to an external device.
- Flashes in green slowly: Audio
playback.
- Lights solid green: No playing
or playback paused.
- Lights solid blue: Device
connection established or
playback paused.
- Flashes in blue slowly: Audio
playback.
FM Mode
AUX mode
USB/TF Card Mode
Bluetooth Mode
- Flashes in blue quickly:
Waiting for connection
7
Work LED Indicator

GETTING STARTED
Notes:
Before moving or installing this product, make sure the Power switch
of the unit is in OFF position.
Disconnect the USB cable from the speaker when unused for long
periods of time.
1.
2.
3.
Notes:
When the speaker is working with the built-in battery and it prompts
that the battery is low, please connect the USB cable to charge it
immediately, or stop using it and power it off to avoid malfunction.
off
USB TF CARD AUX DC 5V OFF-ON

-7-
Power On/ Off the Speaker
Set the Power switch in ON position to power on the speaker, and the LED
working mode indicator lights up.
Set the Power switch in OFF position to power off the speaker. The LED
power indicator turns off.
OPERATING THE SPEAKER
OFF ON
USB TF CARD AUX DC 5V OFF-ON

-8-
Bluetooth Audio Streaming
This Bluetooth Speaker features wireless Bluetooth audio streaming function.
Follow the instructions:
Pairing the speaker with a Bluetooth device
Pairing is the process required to create a link between Bluetooth devices
to allow wireless connection. You must pair a device with the speaker before
you start using it.
Press MODE button on the speaker to select Bluetooth mode, the blue LED
indicator flashes quickly when waiting for connection.
1.
Turn on the Bluetooth function on the Bluetooth device, search for
devices and select "Sylvania SP672" to connect.
2.
If a Passkey is requested, enter “0000.”
When the Bluetooth connection has been established, the LED indicator
glows blue permanently.
3.
Listening to Music of the Registered Device
Press MODE button on the speaker to select Bluetooth mode.
1.
On the Bluetooth device, select "Sylvania SP672".
2.
After Bluetooth connection is established, start playback on the
Bluetooth device.
3.
Depending on the Bluetooth device, the playback may also be
controlled with certain control buttons on the top of the speaker.
4.
Once Bluetooth devices are paired, there is no need to pair them again.
Notes:
The ultimate sound volume can be adjusted by using the volume controls
of both your connected Bluetooth device and the speaker.
Notes:

-9-
The speaker has a USB port for you to insert a compatible USB drive and
directly play stored WMA / MP3 audio contents.
1. Make sure the speaker is power on.
2. Insert your USB drive into the USB port on the back panel of the speaker.
3. Press Mode button to select USB mode.
4. If playback doesn’t start automatically, press the Play/Pause button
to start playback.
5. Use the control buttons on the top of the speaker to adjust the volume
and control the playback.
Notes:
The USB drive will only fit in one direction, do not force it as this would
damage it and the built-in reader of the speaker.
Not all music formats are supported.
Music playback may start automatically after a USB drive is inserted.
Using the USB Port
USB TF CARD AUX DC 5V OFF-ON

-10
-
The speaker has a TF (Micro SD) card slot for you to insert your compatible
memory cards and directly play stored WMA / Mp3 audio contents.
1. Make sure the speaker is power on.
2. Insert your TF card to the TF card slot on the back of the speaker.
3. Press Mode button to select the mode of Card player.
4. If playback doesn’t start automatically, press the Play/Pause button
to start playback.
5. Use the control buttons on the top of the speaker to adjust the volume
and control the playback.
Notes:
The TF cards will only fit in one direction, do not force it as this
would damage it and the built-in card reader.
Not all music formats are supported.
Music playback may start automatically after a TF card is inserted.
Using the TF Card Slots
USB TF CARD AUX DC 5V OFF-ON

-11-
The speaker features FM radio function.
1. Make sure the speaker is power on.
2. Inserted the 3.5mm audio cable (supplied)to work as FM antenna.
3. Press the Mode button on the top of the speaker repeatedly to select FM
Radiomode.
4. Press Play/Pause button and hold it for 3 seconds to start auto-scan of
available FM channels, and store them in built-in memory. Once the scan
is finished, the first stored radio channel will be playing.
5. Press Next or Prev button to select your desired channel.
6. Use - / + buttonsto decrease/increase volume of the speaker.
7. Press Play/Pause button to mute sound, and press it again or
press + button to restore sound.
Notes:
This function is subject to FM radio signal strength and availability in
Adjust the inserted audio cable to get the best reception.
your area.
Listening to the Radio
USB TF CARD AUX DC 5V OFF-ON

-12-
Using the AUX input
Switch the speaker on.
2.
3. Press the MODE button on the unit to select Line In mode.
4. The speaker will play the sound input through the connected cable.
The Bluetooth Speaker has an AUX input (Line In) at its back, for you to use
a 3.5mm stereo audio cable to connect it to other audio player.
Notes:
In AUX (Line-In) mode, the control buttons on the unit don’t work,
except the volume and play/pause control buttons.
Connect one end of the 3.5mm stereo audio cable (supplied) to the
AUX jack at the back of the speaker, and the other end to your audio
player, smart phone or audio device etc.
1.
The ultimate sound volume can be adjusted by using the volume
controls of both your connected device and the speaker.

For service assistance and product information, please call: 1-800-968-9853.
Curtis International Ltd.
7045 BECKETT DRIVE, UNIT 15, MISSISSAUGA, ON, L5S 2A3 www.curtisint.com
PRODUCT SPECIFICATIONS
Output Power
Sensitivity >60db
Frequency Range 40Hz-20KHz
Distortion
<0.1% (@1W)
SNR >60db
2 x 3"
3W x 2 Max.
Speaker Units
Dimensions W255 × D85 × H140 mm
Power Input
DC 5V/1.0A, via Micro-USB port
Built-in Battery:
Rechargeable Lithium-ion battery
Power Consumption < 6W
TROUBLE SHOOTING GUIDE
Symptoms
No sound
No power
No sound after initial
Bluetooth connection
Solutions
Make sure the USB cable is connected to
Charge the built-in battery.
the unit and the power output.
Check whether the volume is set at
minimum level.
Check if your Bluetooth enabled device
via Bluetooth.
and the speaker is successfully paired
-13-
Make sure the power switch is set in the
“ON” position.
Capacity: 3.7V/1800mAH
Charging time: 4 hours
Play time: approx. 5 hours
