XMC X8 Gen 2 Host Cable Adapter
OSS-XMC-HIB25-X8
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

One Stop Systems OSS-XMC-HIB25-X8
Specifications subject to change without notice Page 2
Table of Contents
1. Components
1.a. Host Interface board............................................................................................................................3
1.b. Block diagram......................................................................................................................................3
1.c. Conceptual Architecture......................................................................................................................4
1.d. Host interface board specifications......................................................................................................4
2. Installation Instructions
2.a. Connecting PCIe cable........................................................................................................................5
2.b. Removing PCIe cable..........................................................................................................................5
3. Technical Information
3.a. Connector pin-outs..............................................................................................................................6
3.b. Lane width indicators...........................................................................................................................7
3.c. Compatibility identification block..........................................................................................................7
3.d. Signal descriptions..............................................................................................................................7
4. Ordering Information
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

One Stop Systems OSS-XMC-HIB25-X8
Specifications subject to change without notice Page 3
1. Components
1.a. Host Interface Board
PCIe x8 Gen 2 host cable adapter is an XMC form factor that enables high-speed expansion over a PCIe x8 cable from a host
system at 40Gb/s to a PCIe downstream device or expansion chassis.
1.b. Block diagram
X8 PCI
EXPRESS
CABLE
CONNECTOR
XMC P15
CONNECTOR
PCIe LVPECL
CLOCK
BUFFERS
PCI EXPRESS
SIGNAL
RE-DRIVERS
LEDS
XMC connector
PCIe x8 connector
XMC connector
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

One Stop Systems OSS-XMC-HIB25-X8
Specifications subject to change without notice Page 4
1.c. Conceptual architecture
1.d. Host interface board specifications
Form Factor
XMC card; does not include PMC connectors
Operating Temperature
0˚C to +70˚C environment
Storage Temperature
-40˚C to 85˚C
Operating Humidity
10% to 90% relative humidity non-condensing
Storage Humidity
5% to 95% relative humidity non-condensing
Power
3.3V
Connectors
• PCIe x8 cable connector
• XMC P15 connector
Industry Specifications
• PCIe External Cabling Specification, Rev. 1.0
• PCI Express™ Card Electromechanical Specification,
Rev. 2.0
• PCI Express ® Base Specification, Rev. 2.0
• VITA 42.0-2005
• ANSI/VITA 42.3-2006
Re-drivers
• 5.0 Gbps 4-Lane PCI Express Gen 2 Re-Driver
with Equalization & de-emphasis
• Pericom Part number PI2EQX5804
Bracket
• XMC bezel
• LEDs on bracket
Agency Compliance
Designed to Meet:
• FCC Class B
• CE
PCB
• Form Factor: Short XMC.3
• PCIe x8 cable connector to front panel
• PCB thickness .063 +/- 0.008 inch (1.6 +/-0.2 mm)
• PCIe signals routed with 85 ohm differential
impedance
• Two stand-off mounting holes
PCIe backplane in
the host enclosure
PCIe backplane in the
target system
Downstream target adapter
XMC-HIB25 in
host mode
X8 PCIe cable
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

One Stop Systems OSS-XMC-HIB25-X8
Specifications subject to change without notice Page 5
2. Installation Instructions
2.a. Connecting PCIe cable
1) To install the PCIe cable, Insert into the expansion link board firmly or until you feel it lock into place.
2.b. Removing PCIe cable:
2) To remove PCIe cable pull back on green thumb tab to release metal pins and gently separate.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

One Stop Systems OSS-XMC-HIB25-X8
Specifications subject to change without notice Page 6
3. Technical Information
3.a. Connector Pin-outs
PCI Express x8 Cable Connector
Row A
Row B
Row A
Row B
Row A
Row B
Pin #
Signal Name
Signal Name
Pin #
Signal Name
Signal Name
Pin #
Signal Name
Signal Name
1
GND
GND
13
GND
GND
24
PETn4
PERp4
2
PETp0
PERp0
14
CREFCLK+
PWR (3.3V)
25
GND
GND
3
PETn0
PERn0
15
CREFCLK-
PWR (3.3V)
26
PETp5
PERp5
4
GND
GND
16
GND
PWR (3.3V)
27
PETn5
PERn5
5
PETp1
PERp1
17
RSVD
PWR RTN
28
GND
GND
6
PETn1
PERn1
18
RSVD
PWR RTN
29
PETp6
PERn6
7
GND
GND
19
SB_RTN
PWR RTN
30
PETn6
PERn6
8
PETp2
PERp2
20
CPSRNT$#
CWAKE#
31
GND
GND
9
PETn2
PERn2
21
CPWRON
CPERST#
32
PETp7
PERp7
10
GND
GND
22
GND
GND
33
PETn7
PERn7
11
PETp3
PERp3
23
PETp4
PEPp4
34
GND
GND
12
PETn3
PERn3
24
PETn4
PERp4
XMC 42.3 P15 Connector Pin Definition
Row/
Column
A
B
C
D
E
F
1
PET0p0
PET0n0
3.3V
PET0p1
PET0n1
VPWR
2
GND
GND
TRST#
GND
GND
MRSTI#
3
PET0p2
PET0n2
3.3V
PET0p3
PET0n3
VPWR
4
GND
GND
TCK
GND
GND
MRSTO#
5
PET0p4
PET0n4
3.3V
PET0p5
PET0n5
VPWR
6
GND
GND
TMS
GND
GND
+12V
7
PET0p6
PET0n6
3.3V
PET0p7
PET0n7
VPWR
8
GND
GND
TDI
GND
GND
-12V
9
RFU
RFU
RFU
RFU
RFU
VPWR
10
GND
GND
TDO
GND
GND
GA0
11
PER0p0
PER0n0
MBIST#
PER0p1
PER0n1
VPWR
12
GND
GND
GA1
GND
GND
MPRESENT#
13
PER0p2
PER0n2
3.3V AUX
PER0p3
PER0n3
VPWR
14
GND
GND
GA2
GND
GND
MSDA
15
PER0p4
PER0n4
RFU
PER0p5
PER0n5
VPWR
16
GND
GND
MVMRO
GND
GND
MSCL
17
PER0p6
PER0n6
RFU
PER0p7
PER0n7
RFU
18
GND
GND
RFU
GND
GND
RFU
19
REFCLK+0
REFCLK-0
RFU
WAKE#
ROOT0#
RFU
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

One Stop Systems OSS-XMC-HIB25-X8
Specifications subject to change without notice Page 7
3.b. Lane Width Indicators
3.c. Compatibility Identification Block
3.d. Signal Descriptions
Short XMC.3
P15
PCIe
Standard
8 Lane
Link 0
5Gb/s*
LED \ Lane
Width
x1/x4 Link
x8 Link
x1/x4 LED
ON
OFF
x8 LED
OFF
ON
PETp(x)
PCI Express Transmit Positive signal of (x) pair.
PETn(x)
PCI Express Transmit Negative signal of (x) pair.
PERp(x)
PCI Express Receive Positive signal of (x) pair.
PERn(x)
PCI Express Receive Negative signal of (x) pair.
CREFCLK+/-
Cable REFerence CLocK: Provides a reference clock from the host system to the
remote system.
SB_RTN
Side Band ReTurN: return path for single ended signals from remote systems.
CPRSNT#
Cable PReSeNT: Indicates the presence of a device beyond the cable.
PWR
PoWeR: Provides local power for in-cable redriver circuits. Only needed on long
cables. Power does not go across the cable.)
PWR_RTN
PoWeR ReTurN: Provides local power return path for PWR pins.
CWAKE#
Cable WAKE
CPERST#
Cable PCI Express Reset
