Otic HJ10PRB01 User manual

MODEL: HJ10PRB01
PLEASE READ CAREFULLY BEFORE OPERATING THIS EQUIPMENT
KEEP IT IN ASAFE PLACE FOR FUTURE REFERENCE
10.1" BLUETOOTH PORTABLE
DVD PLAYER

2
CONTENTS
Important Safety Information..........................................................................................3-8
General Operations.......................................................................................................9
Remote Control Operation.......................................................................................10-11
Bluetooth Operation........................................................................................................11
About Discs....................................................................................................................12
Location of Controls...................................................................................................13-14
Remote Control...............................................................................................................15
Battery Installation..........................................................................................................16
Remote Control Working Range.....................................................................................16
Power Source.................................................................................................................17
Swivel Panel...................................................................................................................18
USB or Card Playback....................................................................................................19
Other Way to Play...........................................................................................................20
System Setup..................................................................................................................21
Care and Maintenance....................................................................................................22
Specification...................................................................................................................23
Accessories....................................................................................................................23

3
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CAUTION:
THIS DIGITAL VIDEO DISC PLYER
EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS
PRODUCT.
PLEASE READ THIS OWNER`S
MANUAL CAREFULLY AND RETAIN
FOR FUTURE REFERENCE .
SHOULD THE UNIT REQUIRE
MAINTENANCE, CONTACT AN
AUTHORIZED SERVICE LOCATION
SEE SERVICE PROCEDURE.
USE CONTROLS, ADJUSTMENTS
OR THE PERFORMANCE OF
PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO
LASER BEAM, DO NOT TRY TO OPEN
THE ENCLOSURE. VISIBLE LASER
RADIATION MAY BE PRESENT WHEN
THE ENCLOSURE IS OPENED. DO NOT
STARE INTO BEAM.
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR
MOISTURE.
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, AND ANNOYING
INTERFERENCE, USE THE
RECOMMENDED ACCESSORIES
ONLY.
SURGE PROTECTORS:
It is recommended to use a surge
protector for AC connection. Lightning
and power surges ARE NOT covered
under warranty for this product.
The lightning flash with
arrowhead symbol within an
equilateral triangle is intended
to alert the user to the presence of
uninsulated dangerous voltage within
the product`s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
DANGER:
Invisible and hazardous laser
radiation when open and
interlock failed or defeated. Avoid direct
exposure to beam.
Caution
Invisible laser beam.
Please do not look into or touch the
lens.

4
IMPORTANT SAFETY INSTRUCTIONS
FCC NOTICE:
This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of
the FCC rules. These limits are designed
to provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not Installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct
the interference by one or more of the
following measures:
●Reorient or relocate the receiving
antenna. Increase the separation
between the equipment and receiver.
●Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
●Consult the dealer or an experienced
radio/TV technician for help.
FCC WARNING:
To assure continued compliance, follow
the attached installation instructions and
use only shielded cables when connecting
to other devices. Modifications not
authorized by the manufacturer may void
user`s authority to operate this device.
WARNING
USE UNDER SUPERVISION OF AN
ADULT DUE TO LONG CORD
This unit has a long AC cord or other long
cord that can easily be tripped on or
pulled on, causing injury. Please make
sure it is arranged so it will not drape over
a tabletop etc. where it can be pulled on
by children or tripped over accidentally.
EXERCISE CAUTION AS UNIT HAS
SHARP POINTS.
Before using the unit, be sure to read all
operating instructions carefully. Please
note that these are general precautions
and may not pertain to your unit.
1 ) Read these instructions
All the safety and operating instructions
should be read before the product is
operated.
2 ) Keep these instructions
The safety and operating instructions
should be retained for future reference.
3 ) Heed all warnings
All warnings on the product and in the
operating instructions should be adhered
to.
4 ) Follow all instructions
All operating and use instructions should
be followed.
5 ) Do not use this apparatus near
water
Do not use this product near water and
moisture, for example: near a bathtub,
washbowl, kitchen sink or laundry tub; in
a wet basement or near a swimming pool.
6 ) Clean only with dry cloth
Unplug this product from the wall outlet
before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a dry
cloth for cleaning.

5
IMPORTANT SAFETY INSTRUCTIONS
7 ) Do not block any ventilation
openings. Install in accordance with
the manufacturer's instructions.
Slots and openings in the cabinet and
in the back or bottom are provided for
ventilation, to ensure reliable operation
of the product and to protect it from
overheating. These openings must not be
blocked or covered. The openings should
never be blocked by placing the product
on a bed, sofa, rug or other similar
surface. This product should never be
placed near or over a radiator or heat
source. This product should not be
placed in a built-in installation such as a
bookcase or rack unless proper ventilation
is provided or the manufacturer's
instructions have been adhered to.
8 ) Do not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including amplifiers)
that produce heat.
9)Do not defeat the safety purpose of
the polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for
replacement of the obsolete outlet.
10 ) Protect the power cord from being
walked on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11 ) Only use attachments/accessories
specified by the manufacture .
12 ) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus
combination to avoid injury
from tip-over.
An appliance and cart
combination should be moved with care.
Quick stop, excessive force and uneven
surfaces may cause the appliance and
cart combination to overturn.
13 ) Unplug this apparatus during
lightning storms or when unused for
long periods of time.
To protect your product from a lightning
storm, or when it is left unattended and
unused for long periods of time, unplug
it from the wall outlet and disconnect the
antenna or cable system.
This will prevent damage to the product
due to lightning and power-line surges.
14 ) Refer all servicing to qualified
service personnel. Servicing is required
when the apparatus has been damaged
in any way, such as power-supply cord or
plug is damaged, liquid has been spilled
or objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture does not operate normally, or
has been dropped.
15 ) Power source
This product should be operated only
from the type of power source indicated
on the marking label.
If you are not sure of the type of power
supply to your home, consult your
appliance dealer or local power company.
For products intended to operate from
battery power, or other source, refer to
the operation instructions.
Portable Cart Warning

6
IMPORTANT SAFETY INSTRUCTIONS
16 ) Power lines
An outside antenna system should not be
located in the vicinity of overhead power
lines or other electric light or power
circuits, or where it can fall into such
power lines or circuits.
When installing an outside antenna
system, extreme care should be taken
to keep from touching such power lines
or circuits as contact with them might be
fatal.
17 ) Overloading
Do not overload wall outlets and extension
cords as this can result in a risk of fire or
electric shock.
18 ) Object and liquid entry
Never push objects of any kind into the
product through openings as they may
touch dangerous voltage points or short
out parts that could result in fire or electric
shock. Never spill or spray any type of
liquid on the product.
19 ) Outdoor antenna grounding
If an outside antenna is connected to the
product, be sure the antenna system is
grounded so as to provide some
protection against voltage surges and
built up static charges. Section 810 of
the National Electric Code ANSI/NFPA
70 provides information with respect
to proper to grounding of the mast and
supporting structure, grounding of the
lead-in wire to an antenna discharge
product, size of grounding conductors,
location of antenna discharge product,
connection to grounding electrodes
and requirements for the grounding
electrodes.
20 ) Service
Do not attempt to service this product
yourself as opening or removing covers
may expose you to dangerous voltage
or other hazards. Refer all servicing to
qualified service personnel.
21 ) Replacement parts
When replacement parts are required,
be sure the service technician uses
replacement parts specified by the
manufacturer or those that have the same
characteristics as the original parts.
Unauthorized substitutions may result in
fire or electric shock or other hazards.
22 ) Safety check
Upon completion of any service or repairs
to this product, ask the service technician
to perform safety checks to determine
that the product is in proper operational
condition.
23 ) Wall or ceiling mounting
The product should be mounted to a wall
or ceiling only as recommended by the
manufacturer.
24 ) Damage requiring service
Unplug this product from the wall outlet
and refer service to qualified service
personnel under the following conditions.
a ) When the power-supply cord or plug is
damaged.
b ) If liquid has been spilled or objects
have fallen into the product.
c ) If the product has been exposed to
rain or water.
d ) If the product does not operate
normally by following the operating
instructions. Adjust only those controls
that are covered by the operating
instructions, as an adjustment of other
controls may result in damage and will
and require extensive work by a
qualified technician to restore in the
product to its normal operation.
e ) If the product has been dropped or the
cabinet has been damaged.

7
f ) When the product exhibits a distinct
change in performance-this indicates a
need for service.
25 ) Note to CATV system installer
This reminder is provided to call the CATV
system installer's attention to Article 820-
40 of the NEC that provides guidelines
for proper grounding and, in particular,
specifies that the cable ground shall be
connected to the grounding system of the
building, as close to the point of cable
entry as practical.
NOTE: Refer all servicing to qualified
service personnel servicing is required
when the unit has been damaged in any
way such as the following: the power
supply cord or plug has been damaged,
liquid has been spilled into unit, the unit
has been exposed to rain or moisture, the
unit has been dropped or the unit does
not operate normally.
IMPORTANT SAFETY INSTRUCTIONS
NOTES ON HANDLING:
●When shipping the unit, always use the
original shipping carton and packing
materials. For maximum
protection, repack the unit as it was
originally packed at the factory.
●Do not use volatile liquids, such as
insect spray, near the unit. Do not
leave rubber or plastic products in
contact with the unit for a long time.
They will leave marks on the finish.
●The top and rear panels of the unit
may become warm after a long period
of use. This is normal and not a
malfunction.
●When the DVD player is not in use, be
sure to remove the disc and turn off
the power.
NOTES ON LOCATING THE DVD
PLAYER:
When you place this unit near a TV, radio
or VCR, the playback picture may become
poor and the sound may be distorted. In
this case, move the unit away from the
TV, radio or VCR.
NOTES ON CLEANING:
Use a soft, dry cloth for cleaning
●For stubborn dirt, soak the cloth in a
weak detergent solution, wring well
and wipe. Use a dry cloth to wipe it
dry. Do not use any type of solvent,
such as thinner and benzene, as they
may damage the surface of the unit.
●If you use a chemical-saturated cloth
to clean the unit, follow that product's
instructions.
Warning: Cleaning and adjustment of
lenses and/or other components of
playback mechanism should be performed
by a qualified service technician.

8
IMPORTANT SAFETY INSTRUCTIONS
NOTES ON MOISTURE
CONDENSATION:
Moisture condensation damages the
DVD player.
Please read the following carefully.
●Moisture condensation occurs, for
example, when you pour a cold drink
into a glass on a warm day. Drops of
water form on the outside of the glass.
In the same way, moisture may
condense on the optical pick-up lens
inside this unit, one of the most crucial
internal parts of the DVD player.
Moisture condensation occurs during the
following cases:
●When you bring the DVD player directly
from a cold place to a warm place.
●When you use the DVD player in a
room where you just turned on the
heater, or a place where the cold wind
from the air conditioner directly hits the
unit.
●In summer, when you use the DVD
player in a hot and humid place just
after you moved the unit from an air
conditioner room.
●When you use the DVD player in a
humid place.
Do not use the DVD player when moisture
condensation may occur:
●If you use the DVD player in such
a situation, it may damage discs and
internal parts. Remove the disc,
connect the AC/DC adapter to the DVD
player and the wall outlet, turn on the
DVD player and leave it on for two or
three hours. After two or three hours,
the DVD player will have warmed up
and evaporated any moisture.
WARNING:
- Do not use or leave the device in direct
sunlight or a hot environment such as a
vehicle etc. that is in hot environment.
Overheating can damage the device.
- Do not overcharge the device – do not
leave the device on the charger for
very long after the battery has been fully
charged.
- Device should be protected from any
physical impact or damage and care
should be taken not to drop the device.
- Only use the factory supplied charger.
The use of unapproved charger or cable
may cause the battery to fail, explode
and/or damage the device.
- Do not disassemble, puncture, crush or
expose your device to temperatures
above 40°C / 104°F.
- Keep your device away from fire or
water.
- Keep your device from moisture and
extreme temperatures.
- Should your battery swell or expand,
please immediately discontinue use of
your device.

9
GENERAL OPERATIONS
1. Lift up the panel and turn to desired angle. Slide the Power ON/OFF switch to "ON"
position to power on the unit, the Blue Indicator on front of the player will light.
2. Slide the OPEN switch to left to open the disc door. Place the disc on the center
spindle with label side facing up. Close the disc door and the player will start
playback automatically.
3. During playback:
~ Press the or buttons repeatedly to fast search for a specific section forward
or backward. Press the button to resume normal playback.
~ Press the or buttons repeatedly to skip to specific track.
~ Press the button to pause, press it again to resume normal playback.
~ Press the VOL(volume)+/- buttons to adjust volume level.
~ Press the button to stop playback. The player will remember the point where the
disc was stopped. Press the button to start playback from this point.
Press the button twice to stop completely, press the button to start playback
from the beginning of the disc.
4. Press the POWER button on the Remote Control to turn the player to standby mode.
The Red Indicator will light. Press the POWER button again to turn the player on from
standby mode (For saving energy, always power off the player by slide the Power
ON/OFF switch on the player to OFF position or unplug the AC/DC Adaptor from
player and wall outlet.)
Repeat Playback: (DVD)
● During playback, press the REPEAT button once to repeat the current chapter.
● Press the REPEAT button twice to repeat the current title.
● Press the REPEAT button the third time to repeat all.
● Press the REPEAT button repeatedly to turn off the repeat mode.
Repeat Playback: (CD)
● During playback, press the REPEAT button once to repeat the current track.
●Press the REPEAT button twice to repeat all the tracks.
● Press the REPEAT button repeatedly to turn off the repeat mode.
(CD/DVD) Program:
1. During CD or DVD playback, press the PROG ( Program ) button.
2. Using the Direction and Numeric buttons to select and set the desired TT (Title), CH
(Chapters), tracks (for CD) of the movie (music) you wants. The Program menu will
appear as follows.
3. Using the Direction buttons to select and highlight the "Start" button on the screen
then press the OK button to start program playback.

10
REMOTE CONTROL OPERATIONS
LCD ON/OFF: Press to turn on or off the LCD display.
POWER: Press to turn to standby mode, press again to turn on.
VOLUME +/–: Press to increase or decrease volume.
MUTE: Press to turn off the sound, press again to resume.
SOURCE: Press to switch to AV IN mode, press again to resume normal mode.
OSD: (On Screen Display)
During playback, press the OSD button repeatedly to read the information of playback
status.
SUBTITLE:
During DVD playback, press repeatedly to select desired subtitle (Function depends on
the recording of disc).
STEP:
During movie playback, press STEP button repeatedly to play the movie frame by
frame. Press the button to resume normal playback.
TITLE/MENU:
Press repeately to return to disc's title /menu page (Function depends on the recording
of the disc).
ANGLE:
During DVD playback, press repeatedly to select the viewing angle (Function depends
on the the recording of the disc).
AUDIO:
During DVD playback, press repeatedly to select the desired language or channel.
(Function depends on the recording of the disc)
ZOOM:
During movies playback, press this button repeatedly to zoom in/out the picture. When
in zoom mode, press Direction buttons to select the parts of the zoomed picture to
watch. (Function depends on the recording of the disc.)
Note: Zooming into an image will degrade the quality as the pixels of the image are
being enlarged.
SLOW:
During playback, press the SLOW button repeatedly to set the slow motion speed.
Press button to resume normal playback.
GOTO ( DVD ):
~ Press the GOTO button once to display the Title and Chapter selection menu.
Use Direction and Numeric buttons to select the desired title and chapter.
The player will play the selected chapter automatically.
~ Press the GOTO button twice to display the time selection under Title, using the
Direction and Numeric buttons to enter the desired time.
The unit will start play the movie from the selected time automatically.

11
REMOTE CONTROL OPERATIONS
BLUETOOTH OPERATION
~ Press the GOTO button the third time to display the time selection under Chapter.
Using the Direction and Numeric buttons to enter the desired time.
The unit will start play the movie from the selected time automatically.
GOTO ( CD )
~ Press the GOTO button once, using the Numeric and OK buttons to set the desired
playback time of disc.
~ Press the GOTO button twice, using the Numeric and OK buttons to set the desired
playback time of track.
~ Press the GOTO button the third time, using the Numeric and OK buttons to set the
desired track.
A-B Repeat
During Playback, press the A-B button to select the starting point, press it again to select
the ending then the player will play the selected section repeatedly and continuously.
Press the A-B button again to resume normal playback (This function is not available on
all discs).
After initial pairing, the DVD player will stay paired unless you unpaired it manually, or
erased due to a reset device. If this occurs or you find the unit is unable to connect,
please repeat below steps:
1. Lift up the panel and turn to desired angle. Slide the Power ON/OFF switch to "ON"
position to power on the unit, the Blue Indicator on front of the player will light.
2. Press the PAIR button once on your DVD player, the Blue indicator on front will blink
fast to indicate you it is searching for a bluetooth device.
3. Activate the bluetooth function on your bluetooth device, after a while, the pairing will
be connected automatically.
The indicator on front of your DVD will light with solid Blue.
4. During playing, press the Play/Pause button on DVD or remote control to pause,
press it again to resume the playing.
Press the VOL- or VOL+ button on DVD or remote control to adjust the volume level.
NOTE:
● The Build-in Bluetooth transmitter function device (such as smart phone) can not be
connected with your DVD player.
● To reconnect to a different device, deactivate the bluetooth on unwanted unit, then
access the bluetooth settings and activate the bluetooth function on the new device
which you wish to pair with your DVD player.

12
ABOUT DISCS
The region number for this DVD Player is: 1
See the following page for information regarding region numbers.
PLAYABLE DISCS:
The following discs can be played back on this DVD player:
DISC TYPES:
DVD
Data on most DVDs is divided into sections called
titles and then into subsections called chapters, each
of which is given a title or chapter number. Some
features of this DVD player will not operate with some
DVD discs as they are preset. If a function you
selected does not run as desired, refer to the manual
accompanying the DVD disc.
AUDIO CD
Data on an audio CD is divided into sections called
tracks, each of which is given a track number.
IMPORTANT:
It is important that you read the manual that accompanies the DVD disc, as there are
features that are on the DVD player that cannot be used with certain DVDs .
There are also extra features on the DVD disc that are different for each DVD disc, so
they are not explained in this owner's manual.
This player conforms to the NTSC and PAL color systems. However, if you are in the
USA, Canada or Mexico, leave this setting on NTSC. If incorrectly set to PAL, the TV
picture may roll vertically. In this case, set the TV system to NTSC.
Notes on Copyright:
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public and
rent copyrighted material without permission. DVD video discs are copy protected,
and any recordings made from these discs will be distorted. This product incorporates
copyright protection technology that is protected by method claims of certain U.S.
Patents and other intellectual property rights owned by Macrovision Corporation, and is
intended for home and other limited viewing uses only, unless otherwise authorized by
Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Region Management Information:
This DVD Player is designed and manufactured to respond to the Region Management
Information that is recorded on a DVD disc. If the Region number described on the DVD
disc does not correspond to the Region number of this DVD player, this DVD player
cannot play that disc. You may not be able to play back some DVD video discs on this
player if they were purchased from outside your geographic area or made for business
purposes. When you try to play back an unauthorized disc, Wrong Region appears on
the TV screen.

13
LOCATION OF CONTROLS
SOURCE
DVD
USB SD/
VOL- VOL+
SETUP
OPEN
1
2
3
5
5
6
7
8
9
10
11
4
4
PAIR
1. SOURCE: Press to switch to AV IN mode, press again to resume normal mode.
2. DVD/USB/SD: When USB device and/or SD Card was inserted, press repeatedly to
select the playback source as desired.
3. VOL(volume) - : Press to decrease the volume level.
VOL(volume) + : Press to increase the volume level.
4. In disc playback mode, press repeatedly to skip to previous/next chapters/
tracks as desired.
In setting menu, press repeatedly to move the cursor upward or downward
within the menu.
5. In disc playback mode, press to fast backward or fast forward.
In setting menu, press repeatedly to move the cursor left or right within the
menu, or return to previous menu.
6. OK: Press to confirm the selection.
7. While DVD/CD playing, press this button once to pre-stop (In this mode,
when press the button, the player will start to play from the point stopped)
Press this button twice to stop playback completely (In this mode, when
press the button, the player will start to play the current disc from the
beginning)
8. During playback, press this button to pause, press again to resume normal
playback.
9. SETUP: Press this button to enter setting menu, when setting finished, press this
button again to save and exit.
10. PAIR: Press to pair with the Bluetooth device.
11. OPEN: Slide to left to open the disc door.

14
LOCATION OF CONTROLS
Right Side View:
Front Side View:
12 13 516141
DC INOFF ON
AV IN-AV OUT-
CARD
USB
17 18
12. USB port
13. Card slot (for SD/MMC card)
14. Earphone jack
15. AV OUT jack
16. AV IN jack
17. Power ON/OFF switch
18. DC IN jack
19 20 21
19. Charging indicator 20. Remote sensor 21. Power indicator

15
REMOTE CONTROL
1. POWER button
2. VOLUME +/– buttons
3. MUTE button
4. SOURCE button
5. Direction buttons
6. Skip Next button
7. Fast Forward button
8. ( Play/Pause ) button
9. DVD/USB/SD button
10. TITLE/MENU button
11. (STOP) button
12. AUDIO button
13. GOTO button
14. REPEAT button
15. SLOW button
16. LCD ON/OFF button
17. Numeric buttons
18. SETUP button
19. Skip Previous button
20. Fast Backward button
21. OSD (On Screen Display button
22. SUBTITLE button
23. ANGLE button
24. PROG ( Program ) button
25. OK button
26. STEP button
27. ZOOM button
28. A-B Repeat button

16
BATTERY INSTALLATIONS (Remote Control)
1. Press the tabs on the battery door and lift it off.
2. Install two (2) x AAA size batteries into the battery
compartment as the figure on right and the
polarity markings inside battery compartment.
3. Replace the battery door.
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated next to
the battery compartment. Reversed batteries may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and
Carbonzinc) or old batteries with fresh ones.
4. If the device is not to be used for a long period of time, remove the batteries to
prevent damage or injury from possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged; they can overheat and
rupture. (Follow battery manufacturer's directions.)
6. Do not dispose of batteries in fire, batteries may explode or leak.
7. Clean the battery contacts and also those of the device prior to battery installation.
BATTERY INSTALLATION
REMOTE CONTROL WORKING RANGE
Remarks:
1. When there is an obstacle between the unit and the transmitter, the transmitter may
not operate.
2. When direct sunlight, an incandescent lamp, fluorescent lamp or any other strong
light shines on the remote control of the unit, the remote operation may be unstable.

17
POWER SOURCE
Charging by AC/DC Adapter:
1. Connect the small plug of AC/DC Adapter to the DC IN Jack on the right of unit.
2. Connect the AC/DC Adapter to the wall outlet with AC 100-240V~; 50/60Hz.
3. During charging in power on mode, the Charge Indicator will light up red. When
finished, it will turn Yellow.
Note: Your battery will last longer if you follow these simple guides for caring for and
storing it.
A. Recharge and store the device within the temperature range of 5°C~35°C
(40°F~95°F).
B. Do not overcharge (longer than 24 hours). Excessive charging or discharging may
shorten the battery's life.
C. Battery life naturally shortens slowly over time.
D. The rechargeable battery incorporated in this product is not replaceable.
Charging by Car Adapter:
1. Connect to the cigarette lighter socket of a vehicle with 12V battery as the figure
below.
NOTE: It is NOT compatible with a vehicle with 24V battery.
2. This is a special negative ground Car Adapter. Using this Car Adapter with a plus
grounded car can cause malfunction.
3. Do not plug in the Car Adapter until the car ignition is turned on.
4. Disconnect the Car Adapter from the cigarette lighter and the unit after use.

18
SWIVEL PANEL
The viewing angle of the swivel panel can be adjusted as below as desired:

19
USB OR CARD PLAYBACK
1. Insert the USB Device or SD/MMC memory card into the USB port/card slot as the
figure below.
2. In power ON mode, press the DVD/USB/SD button, the "DISC, CARD, USB"
selection window will pop up on the screen. Using the Direction buttons to select and
highlight the desired source then press the OK button to confirm.
3. During playback:
~ Press the or button repeatedly to skip tracks.
~ Press the or button repeatedly to select and set the fast searching speed.
~ Press the Play/Pause button to pause, press it again to resume normal
playback.

20
OTHER WAY TO PLAY
Connecting to a TV or Video Player (such like DVD; VCR; DVR Players ... ) with AV
connection cable.
NOTE:
● The default setting of the unit is AV OUT, if connect to external video player (such
like DVD; VCR; DVR Players ... ), press the SOURCE button to set to AV IN mode
("AV IN" will appear on the screen). Press again to turn back to resume normal
mode.
● Using the supplied earphone to listen privately.
