OTO Machines BOUM User manual


01
BOUM USER MANUAL
Safety warnings and recommendations
Do not eat BOUM. Before using BOUM, make sure to
read all the instructions below, and this User Manual.
BOUM has some openings on its enclosure and 4
adhesive feet for cooling purpose. To ensure sufcient
cooling, do not obstruct the openings and/or remove the
adhesive feet. BOUM should be connected to the included
AC adaptor or a power supply of the type described in
this manual. Do not place things on the top of the AC
adaptor which could prevent normal cooling.
If your BOUM is unused for a long period of time,
disconnect the AC adaptor from the outlet.
BOUM, in combination with an external amplication
system or headphones, may generate a high sound
level, which could potentially damage your ears. Do
not operate BOUM for a long period of time at a high
volume level. It’s safer to keep reasonable levels and
start with low volume. Do not expose BOUM and its
AC adaptor to rain, moisture, dust, sand or dirt. Do not
pour liquids into BOUM. Never use or store BOUM near
water, for example sea, swimming pool, bathtub, kitchen
or bathroom sink. BOUM should be located away from
high temperatures (> 35 degrees C), for example direct
sunlight in a closed vehicle, radiators, heat registers,
stoves or other heat sources. Only clean BOUM with a
soft, dry cloth. Do not apply any liquids or alcohol.
Do not apply excessive vibration forces to BOUM, do not
drop it and always transport it in its original packaging
or in shock absorbing material. Never climb on top of,
nor place heavy objects on BOUM. Some parts of BOUM
are fragile (such as the housing and some electronic
components), so dropping it might damage your BOUM.
Repair work resulting from dropped BOUM is not covered
by the normal warranty of the product. Do not leave
small children alone with BOUM, and do not let them use
BOUM unless they are capable of following all the rules
for the safe operation of BOUM. Do not open (or modify
in any way) BOUM or its AC adaptor. There are no user-
serviceable parts inside. Refer all servicing to qualied
personnel only. If you think your BOUM needs repair,
you can send us an e-mail at : support@otomachines.com.
Warranty
BOUM is sold with one year full warranty. This warranty
covers all malfunctions that may occur from normal use,
and does not cover damage due to abuse, faulty
connections or operation under other than specied
conditions. Warranty is void when serial number is
unreadable, when the device is repaired by unauthorized
persons, opened, or tampered with in any way, or if
the product was not sold to the end-user through
an authorized dealer or the OTO Machines website.
This warranty is limited to replacement or repair of
the product. The unit can only be returned for repair
after agreement from OTO Machines. Customer covers
shipping costs of faulty BOUM to OTO Machines and
OTO Machines covers shipping costs back to customer.
Disposal
The trash can symbol indicates that your product must be
disposed of properly according to local laws and regulations.
Warning on epilepsy
A very small percentage of individuals may experience
epileptic seizures or blackouts when exposed to certain
light patterns or ashing lights. If you have an epileptic
condition or have had seizures of any kind, consult your
physician before using BOUM.

02
PRESENTATION
Congratulations and thank you for purchasing BOUM !
BOUM is a full analog stereo warming unit, combining
an easy-to-use compressor, a versatile distortion generator
and a smooth hi cut lter. BOUM is the perfect tool when
you need to add warmth, thickness, and character
to your sounds, but also apply severe distortion and
extreme compression treatments.
BOUM is based on an original and unique circuit,
including the following stages:
INPUT GAIN: boost your signal up to +18db to adapt
BOUM to various signal levels, and also improve the
distortion content and the compressor sensitivity.
COMPRESSOR: with a single knob, control the 3 essential
parameters of a compressor, threshold, ratio and makeup
gain, without thinking about how a compressor works ! The
ratio ranges from 1:1 (no compression) to inf. :1 (limiter),
but also negative compression up to 1: -1 ! 6 different
attack and release times are available for ne tuning.
LO CUT FILTER: attenuate the distortion content of the bass
frequencies with this 6 dB/octave lo cut lter, making your
distorted sound easier to mix with the original one.
DISTORTION GENERATOR: choose one of the 4
different distortion circuits:
- BOOST: soft clipping amplier, perfect for subtle
harmonic enhancement.
- TUBE: asymmetrical tube distortion emulator based
on MOSFET technology. Generate mostly a second
harmonic distortion.
TABLE OF CONTENTS
Presentation - Features
Front panel - Rear panel
Diagram
Compressor pot
Setup examples
Parameters
In Gain
Attack
Release
Lo Cut
Disto
Gate - Sidechain
Display mode - Local mode
Presets - Recall - Save
Factory Presets
Memory protect
MIDI
Program Change list
MIDI control of the sidechain
MIDI CC list
VU meter / Gain reduction display
Note about noise
Specications - Reset
Shortcuts summary
Page 03
Page 04
Page 06
Page 07
Page 08
Page 09
Page 10
Page 11
Page 12
Page 13
Page 14
Page 15
Page 16
Page 17
Page 18
Page 19
Page 19
Page 21
Page 21
Page 22
Page 23
Page 24
Page 25
Page 26
03
- FUZZ: symmetrical hard clipping amplier, similar to an
overdriven mixer preamp.
- SQUARE:pure square wave generator based on a
comparator. The ultimate fuzz !
HI CUT FILTER: soften the high frequencies with this
smooth and musical 12 dB/octave hi cut lter.
NOISE GATE: remove the noise coming from the different
treatments, or use it for interesting chopping effects.
All these analog effects are packaged in a compact
format, with 36 user presets and full MIDI control.
BOUM will give you a wide range of compression,
distortion and ltering effects, ranging from subtle
harmonic enhancement to an insane square distortion,
and everything in between !
FEATURES
• Analog signal path and sidechain
• One knob compressor (Ratio 1:1 to 1: -1) with attack
& release parameters
• 4 distortions : Boost, Tube, Fuzz and Square
• Variable Hi Cut Filter, 12 dB/oct. from 20 kHz to 20 Hz
• Gate with threshold up to 0 dB for production purposes
• Input Gain up to +18 dB
• Lo Cut Filter: Flat, 75 Hz, 150 Hz, 300 Hz
• 36 user presets
• MIDI input: BOUM responds to CCs, Pgm Change, Note
• Nice and simple user interface via 16 white LEDs
• Rugged steel enclosure
• Neutrik® jack connectors
• Power supply included

data
compressor
active
in gain
15 vdc midi in out r
sc
out l in r in l/mono
release lo cut gate
preset
attack disto
hi cut
drive
level
mix
01 - COMPRESSOR. Sets 3 parameters of the compressor with 1 knob (cf p. 7)
02 - DRIVE. 0 to 55 dB (depending on the disto type)
03 - MIX. Mix between the dry and wet sound
04 - DATA. Sets the selected parameter (cf p. 9)
05 - HI CUT. 12 dB/octave non resonant Hi Cut Filter (from 20 kHz to 20 Hz)
06 - LEVEL. Sets the level of the whole audio path for the wet signal
07 - ACTIVE. Turns the effect on or off (when it’s off, Boum is bypassed)
08 - LEDS. Display the parameters, presets, midi settings and other info
09 - PRESET. Save and Recall presets
10 - FUNCTION KEYS. Enable access to the parameters (cf p. 10 to 15)
11 - POWER SUPPLY INPUT. 15 Volts DC 0.5 Amps, center positive
12 - MIDI IN. Midi input
13 - OUT R. Right output. Unbalanced 1/4” jack
14 - OUT L. Left output. Unbalanced 1/4” jack
15 - IN R. Right input. Unbalanced 1/4” jack
16 - IN L/MONO. Left or mono input. Unbalanced 1/4” jack
17 - SIDECHAIN INPUT. 1/8’’ mono jack
08
06
03
09
17
04
01
07
10
12 15
05
02
11 14
13 16
FRONT PANEL & REAR PANEL
04 05

VCA
VCA
AMP
AMP
AMP
AMP
FILTER
FILTER
FILTER
FILTER
DISTORTION
GENERATOR
DISTORTION
GENERATOR
SIDECHAIN
PROCESSOR
RIGHT
INPUT
IN GAIN
IN GAIN
LO CUT
LO CUT
DISTO
DISTO
DRIVE
DRIVE
HI CUT
HI CUT
MIX
MIX
LEFT
OUTPUT
RIGHT
OUTPUT
LEVEL
LEVEL
SC INPUT
COMPRESSOR
ATTACK RELEASE GATE
LEFT
INPUT
COMPRESSOR
1: -11: 1
1: -0.6
5: 1
1: -0.3
10: 1
∞: 1
COMPRESSOR POT
The COMPRESSOR pot sets the 3 essential parameters of
a compressor : Threshold, Ratio, and Makeup.
Threshold is the point at which the compressor begins
to react. A signal below this threshold won’t be affected
by the compression process, and a signal above the
threshold will be compressed. Threshold of the BOUM
compressor varies between -30 and -15 dB, depending
on the position of the COMPRESSOR pot.
Ratio determines the intensity of the compression
effect, and is expressed by the relation in dB between
the input and the output signals. For instance a ratio of
10:1 means that a 10 dB increase above the threshold
at the input will lead to a progression of only 1 dB at the
output. Therefore the dynamic range of the input signal
is attenuated at the compressor output.
A 1:1 ratio is equivalent to no compression.
A ∞:1 ratio is called a limiter because the output level
stays constant when the input signal rises above the
threshold.
1:-1 is a kind of over compression since a progression
of 1 dB at the input above the threshold will lead to an
attenuation of 1 dB at the output. The more the input
signal rises above the threshold, the more the output
signal is lowered. This kind of ratio can create dynamic
reversal effects.
Makeup is the output amplier gain and compensates
for the level loss generated by the compressor action.
With BOUM, you don’t have to know how to set these 3
parameters, you just have to turn the COMPRESSOR pot
for more or less compression !
Here is a layout of the ratios :
PROTECT YOUR EARS !
BOUM, in combination with an external amplication
system or headphones, may generate a high sound
level, which could potentially damage your ears.
Do not operate BOUM for a long period of time at a
high volume level. It’s safer to keep reasonable level
and start with low volume.
07

PARAMETERS
BOUM has 6 function keys:
In Gain, Attack, Release, Lo Cut, Disto and Gate.
Each function key gives you access to a parameter.
You can modify this parameter with the DATA pot.
To exit parameter selection press the function key again.
SETUPEXAMPLES
1. Instrument Function Key Overview
1. In Gain: sets the gain of the input buffer.
It is the rst stage of the circuit.
2. Attack: sets the attack time of the compressor.
3. Release: sets the release time of the compressor.
4. Lo Cut: a 6 dB/octave lo cut lter, located after the
compressor and before the distortion generator.
5. Disto: selects one of the 4 distortion circuits.
6. Gate: a noise gate that can also be used for
chopping effects.
lo cut distoreleaseattackin gain gate
2. Auxiliary
data
NOTE: turn the MIX pot to its maximum position
(clockwise)
Outputs Outputs
Inputs
Inputs
Aux ReturnAux send
Stereo Line Inputs
Main Outputs
Outputs
Boum Synthesizer
MixerMonitor Speakers
Main Outputs
Mixer
Monitor Speakers Boum
08 09

+ 18 dB+ 6 dB
IN GAIN
This is the rst stage of the circuit. Raising the input gain
also raises the compressor sensitivity.
+12 dB0 dB 50 us 1 ms 10 ms
In Gain Attack
330 us 3,3 ms 33 ms
ATTACK
Sets the attack time of the compressor.
10 11

RELEASE
Sets the release time of the compressor.
LO CUT
This 6 dB/octave Lo Cut lter is located before the
distortion. It can help make your distorted sound
easier to mix with the original one.
12 13
500 ms
350 ms 1 sec100 ms
250 ms
50 ms
Release
300 Hz75 Hz
150 Hz
FLAT
Lo Cut

DISTO
Selects one of the 4 different distortion circuits.
Boost: Soft clipping amplier.
Tube: Emulates the sound of an asymmetrical tube amp distortion.
Fuzz: Symmetrical hard clipping amplier.
Square: Pure square wave distortion, based on a comparator circuit.
GATE
Actives a noise gate with several thresholds. Thresholds above -40 dB let you create a chopping effect.
IMPORTANT NOTE ABOUT SIDECHAIN : When a signal is connected to the sidechain (SC) input and the Gate
parameter is not set to «OFF », the SC input becomes a gate trigger input. This means that when a signal is present
at the SC input, the gate is opened (the wet sound of BOUM is on). With no signal at the SC input, the gate is closed
(the wet sound of BOUM is muted). If you want the sidechain input to control the compressor the normal way, set the
Gate parameter to « OFF ». The Compressor pot will control the intensity of SC signal used for the compression.
14 15
SQUARETUBE
FUZZ
BOOST
Disto
- 30 dB- 50 dB - 10 dB
- 40 dB 0 dB
OFF - 20 dB
Gate

LOCAL MODE (MIX)
Each Preset contains its own Mix value.
Sometimes it can be useful to load a preset while
keeping the current Mix settings.
To change the Local mode, press and hold the RELEASE
function key for at least 2 seconds.
The RELEASE function key and one of the following
LEDs will ash to indicate the current Local mode:
Led 1. Preset mode. The Mix value is loaded.
Led 2. Local mode. The Mix value from the loaded
preset is ignored and the current Mix value is used.
You can change the Local mode with the DATA pot.
To exit the Local mode settings, wait for 10 seconds
or press the RELEASE function key.
DISPLAY MODE
When no parameter is selected, you can choose what
the screen will display.
To change the DISPLAY mode, press and hold the
ATTACK function key for at least 2 seconds.
The ATTACK function key and one of the following LEDs
will ash to indicate the current Display mode:
Led 1. Off mode. The screen will display nothing.
Led 2. Vu meter / Gain reduction mode. The 8 LEDs
of the upper line act as a signal input VU-meter.
The 8 LEDs of the lower line display the gain reduction
of the compressor (cf p. 23).
Led 3. Preset mode. The 16 LEDs show the current preset
and bank number (cf p. 17).
You can change the Display mode with the DATA pot.
To exit the Display mode settings, wait for 10 seconds
or press the ATTACK function key.
mix
16 17
PRESETS
BOUM has 36 presets; 6 banks of 6 presets each.
The upper line of LEDs (1 to 6) indicates the bank.
The lower line of LEDs (9 to 14) indicates the preset.
Recall a preset
Press the PRESET switch. The PRESET switch lights up
and one of the upper line LEDs blinks. Press one of
the 6 switches (from IN GAIN to GATE) to select a bank.
Then one of the lower line LEDs blinks. Press one of the
6 switches (from IN GAIN to GATE) to select a preset.
Your preset is loaded.
Save a preset
Press the PRESET switch for 2 seconds. The PRESET
switch ashes to indicate you are in Save mode.
One of the upper line LEDs blinks. Press one of the
6 switches (from IN GAIN to GATE) to select a bank.
Then one of the lower line LEDs blinks. Press one of
the 6 switches (from IN GAIN to GATE) to select a preset.
All the parameters and pot positions are now saved
in the selected preset.
Use these 6 switches
to select the bank
and the preset
in gain releaseattack
These 6 LEDs indicate
the bank number These 6 LEDs indicate
the preset number
lo cut gatedisto
1 2 3 4 5 6

EXIT WITHOUT LOADING
OR SAVING A PRESET
If you press the PRESET switch before selecting the bank
or the preset, the preset won’t be loaded or saved.
You can also wait 10 seconds.
POTENTIOMETERS POSITION
Once you recall a preset, the physical position of
a pot may not be the same as in the preset. To prevent
a sudden jump of volume when you turn a pot, the
preset value will reach the pot value with a smooth fade.
MEMORY PROTECT
You can prevent overwriting your presets with
the Memory Protect function. Press PRESET and GATE
switches and hold them for at least 2 seconds.
The PRESET and GATE switches, and one of the following
LEDs will ash to indicate the current Memory
Protect mode:
Led 1. OFF. The memory is not protected.
Led 2. ON. The memory is protected and you cannot
save presets. If you attempt to save a preset, LEDs 1 to
6 and 9 to 14 will ash briey to indicate that memory
is protected.
You can now change the memory protect mode with
the DATA pot.
To exit the Memory Protect setting, wait for 10 seconds
or press the PRESET or the GATE switch.
MIDI
The MIDI settings menu gives you access to the following
functions:
•MIDI Channel selection
•MIDI Filters
•Program Change map
To access the MIDI menu, press the ACTIVE
switch while pressing the PRESET switch.
The IN GAIN, ATTACK and RELEASE switches ash.
Press any of these switches to access the corresponding
sub-menu.
1. CHANNEL
One of the 16 LEDs will ash and display which channel
is selected. You can select a MIDI channel by turning
the DATA pot.
FACTORY PRESETS
The rst 2 banks are lled with 12 factory presets.
These 12 factory presets are listed on table 1.
Table 1: Factory Presets list
1.1
Fatter, Higher, Stronger
2.1
Ural exciter
1.2
Give it a triode
2.2
Broken Radio
1.3
Buzz Tone
2.3
Transient Expression
1.4
Tube comp
2.4
I’m Crispy
1.5
Drum Reverse
2.5
Scissors
1.6
Be square
2.6
Boum Box
18 19
in gain releaseattack
Channel PGM map
Midi Filters

2. MIDI FILTERS
One of the IN GAIN, ATTACK or RELEASE switch is lit
(the lter is off, BOUM will accept the corresponding
MIDI message) or ashing (the lter is on, BOUM will
ignore the corresponding MIDI message).
The 3 MIDI FILTERS are:
1. Continuous Controllers (IN GAIN switch)
2. Program Change (ATTACK switch)
3. Note (RELEASE switch). cf. p. 21
To activate or deactivate a lter, press the corresponding
switch.
3. PGM CHANGE MAP
BOUM has 36 presets and MIDI Program Change
messages have 128 values. You can associate any
BOUM preset to any Program Change message number.
When the PGM Change Map sub-menu is selected, send
a Program Change message from your computer,
sequencer or any MIDI device. As soon as BOUM receives
a Program Change message, it will give you access to a
preset selection menu (same as “Recall a preset” cf p. 17).
Reset Program Change map
If you press DISTO and GATE switches simultaneously
while you are in the PGM CHANGE MAP sub-menu,
the Program Change map will be reset (cf Table 2).
To exit the MIDI menu, press the ACTIVE or the PRESET
switch.
Table 2: Default Program Change list
Preset Preset PresetPGM Chge Nr PGM Chge Nr PGM Chge Nr
1.1 3.1 5.1
1 - 37 - 73 - 109 13 - 49 - 85 - 121
25 - 61 - 97
1.2 3.2 5.2
2 - 38 - 74 - 110 14 - 50 - 86 - 122
26 - 62 - 98
1.3 3.3 5.3
3 - 39 - 75 - 111 15 - 51 - 87 - 123
27 - 63 - 99
1.4 3.4 5.4
4 - 40 - 76 - 112 16 - 52 - 88 - 124
28 - 64 - 100
1.5 3.5 5.5
5 - 41 - 77 - 113 17 - 53 - 89 - 125
29 - 65 - 101
1.6 3.6 5.6
6 - 42 - 78 - 114 18 - 54 - 90 - 126
30 - 66 - 102
2.1 4.1 6.1
7 - 43 - 79 - 115 19 - 55 - 91 - 127
31 - 67 - 103
2.2 4.2 6.2
8 - 44 - 80 - 116 20 - 56 - 92 - 128
32 - 68 - 104
2.3 4.3 6.3
9 - 45 - 81 - 117 21 - 57 - 93
33 - 69 - 105
2.4 4.4 6.4
10 - 46 - 82 - 118 22 - 58 - 94
34 - 70 - 106
2.5 4.5 6.5
11 - 47 - 83 - 119 23 - 59 - 95
35 - 71 - 107
2.6 4.6 6.6
12 - 48 - 84 -120 24 - 60 - 96
36 - 72 - 108
21
in gain attack release
CC lter Note lter
Program
change lter
20
MIDI CONTROL OF THE SIDECHAIN
You can control the compressor sidechain by MIDI in 2
different ways :
1. Continuous Controller nr 24: CC value 000
corresponds to no compression, CC value 127
corresponds to the maximum compression.
2. Midi Note: the velocity value of any played note will
control the compression. Velocity value 000 corresponds
to no compression, velocity value 127 corresponds to the
maximum compression.
The compressor pot sets the amount of the MIDI controlled
compression.

Table 3: MIDI CC list
Mix 14
Hi Cut 15
Level 16
Active 17
In Gain 18
Attack 19
Release 20
Lo Cut 21
Disto 22
Gate
Sidechain control
23
24
Drive 13
Compressor 12
Param CC
22
VU METER / GAIN REDUCTION DISPLAY
The 8 LEDs of the upper line act as a signal input VU-meter.
The 8 LEDs of the lower line display the gain reduction of the compressor.
-6 dB
-6 dB
-16 dB
-2 dB
0 dB
- 10 dB
+8 dB
-20 dB
-12 dB
-4 dB
+3 dB
-15 dB
-26 dB
-1 dB
-3 dB
-8 dB
VU meter
Gain reduction
23

DUE TO CONTINUOUS PRODUCT IMPROVEMENT, THESE
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
SPECIFICATIONS
Inputs
Connectors:1/4” phone jacks
Input type:single ended
Impedance:1 MOhm
Max input level:+20 dBu (@ 1% THD+N)
Sidechain input: 1/8’’ mono jack
Outputs
Connectors:1/4” phone jacks
Output type:single ended
Impedance:100 Ohm
Max output level: +20 dBu
Dry signal specications
THD+N:0.025 % @ 1kHz
(20 Hz - 20 kHz, 0 dBu)
Frequency response: - 0.005 dBu @ 20 Hz
- 0.004 dBu @ 20 Hz
Dynamic range:108 dB
Reset
If you want to restore the default system settings, power up
BOUM while pressing the ACTIVE and IN GAIN switches.
The ACTIVE and IN GAIN switches are lit and the 16
LEDS will display a little animation for 3 seconds.
Wet signal specications
(no compression, boost mode, minimum drive):
THD+N:0.038 %
(@ 1 kHz, 0 dBu)
Frequency response: - 0.78 dBu @ 20 Hz
+ 0.69 dBu @ 20 kHz
Dynamic range:89 dB
General
Dimensions:145 x 145 x 65 mm
Weight:762 g
Power supply
Input:100 to 240 VAC
50 to 60 Hz, 0.6 Amp
Output:+15 VDC, 1 Amp,
center positive
Dimensions:74 x 43 x 35 mm
Weight:165 g
If you want to restore the 12 Factory Presets, power up
BOUM while pressing the PRESET and GATE switches.
The PRESET and GATE switches are lit and the 16 LEDS
will display a little animation for 10 seconds.
25
Note about noise
BOUM is a high gain device (up to 75 dB depending on
the pots positions and distortion settings).
With maximum In Gain and Fuzz distortion altogether,
some extreme settings of the Compressor, Drive, Hi Cut
and Level pots may lead to a certain amount of noise.
Even with its carefully designed low-noise circuits,
BOUM can produce internal noise, but also amplify
incoming noise. If you experienced too much noise
under certain circumstances, rst disconnect the input
jack(s) to evaluate the noise coming from the source
and the noise coming from BOUM itself.
Sometimes you can reduce the noise from your source
with simple actions. For instance, depending on the
machine, it could be turning the level up, disconnect
or mute unused effects, oscillators or tracks, use a better
power supply…
You can also use the included noise gate, but it’s always
better to reduce the noise from the source.
24

27
26
SHORTCURTS SUMMARY
Midi
Press ACTIVE + PRESET:
IN GAIN: Channel
ATTACK: MIDI Filters
RELEASE: Pgm Chge Map
Memory protect
Press PRESET + GATE
for 2 seconds :
LED1: Off
LED2: On
Display mode
Press ATTACK for 2
seconds :
LED 1: Off
LED 2: Vu-meter / GR
LED 3: Preset
Local mode
Press RELEASE
for 2 seconds :
LED 1: Preset
LED 2: Local
ARTWORK : H5 (P. MANAS & L. HOUPLAIN).
ILLUSTRATIONS : PIERRE MANAS.
BOUM USER MANUAL - OTO MACHINES SARL
27 BOULEVARD SAINT MARTIN, 75003 PARIS FRANCE
+33 (0)1 75 50 61 04
WWW.OTOMACHINES.COM
in gain
active preset
release lo cut disto gateattack
Copyright © 2018 OTO Machines SARL. All rights reserved.
No part of this manual may be reproduced in any form without the written permission of OTO Machines SARL.
Product features, specications, availability and informations in this manual are subject to change without notice.

Tested to comply with FCC Standards for ofce use. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions :
(1) This device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may cause undesired operation.
28

Table of contents
