Otodata C020 BLE-ES3016 Operating and maintenance manual

Installaon Procedure
C020 BLE—ES3016

ES3016
Telemetry I2C interface with
BT transceiver for mulple
sensor and control
capabilies
INPUT
I2C bus with Bulk M12 for Hall eect, Thermal or level sensors
REPORTING & OUTPUTS
Measured parameter (5% variaon)
Low baery
High/Excessive variaon
Temperature
Data Interface Raw data
Client mobile app
Automated Tesng Connecon status
Baery status
ELECTRICAL SPECIFICATIONS
Baery Pack Hybrid LTC 8.5Ah ~ 3.6 Vdc
RADIO SPECIFICATIONS
Receiver Freq. : 2402.000MHz ~ 2480.000MHz
Modulaon : GFSK
Transmier Freq. : 2402.000MHz ~ 2480.000MHz
Modulaon : GFSK
Output: 4.73dBm
FEATURES
• Auto-Pairing to any Otodata ready sensor
• Android and IOS apps
• Ready to install
ENVIRONMENTAL SPECIFICATIONS
Operang & storage -40C to +85C -40F to 185F
temp. range
Relave humidity range 0% to 100%
Enclosure rang IP67
Warranty 1 year
CERTIFICATIONS
ISED RSS-247, Issue 2 IC Registraon: 12649A-BEHT3AD
FCC Part 15 Subpart C FCC ID: 2ADQFBEHT3AD
DIMENSIONS
Height 41mm[1.6in], Width 130mm[5.1in], Depth 66mm [2.6in]
ORDERING OPTIONS
ES3016-DH - Digital Hall sensor
ES3016-DT - Digital Temperature sensor
ES3016-DL - Digital Lidar sensor
This device complies with part 15 of the FCC Rules. Changes or modicaons not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment operaon is
subject to the following two condions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operaon.
This device is compliant with Industry Canada's RSS standards for licence-exempt radio apparatuses. Authorized use depends on the following two condions: (1) the device must not create radio interference,
and (2) the device user must accept all radio interference, even if this interference could potenally impair its funconing. This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful interference in a residenal installaon. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instrucons, may cause harmful interference to radio communicaons. However, there is no guarantee that interference will not occur
in a parcular installaon. If this equipment does cause harmful interference to radio or television recepon, which can be determined by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separaon between the equipment and receiver. --Connect the equipment into an
outlet on a circuit dierent from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help.

M/N: ES3016
F/W: 1.0
IC: 12649A-BEHT3AD
FCC ID: 2ADQFBEHT3AD
FAIT AU
CANADA
Barcode
ISED non-interference disclaimer
This device contains licence-exempt transmier(s)/receiver(s) that comply with
Innovaon, Science and Economic Development Canada’s licence-exempt RSS(s).
Operaon is subject to the following two condions:
1. This device may not cause interference
2. This device must accept any interference, including interference that may cause
undesired operaon of the device.
L’émeeur/récepteur exempt de licence contenu dans le présent appareil est
conforme aux CNR d’Innovaon, Sciences et Développement économique Canada
applicables aux appareils radio exempts de licence. L’exploitaon est autorisée
aux deux condions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est suscepble d’en compromere le fonconnement.
RF Exposure statement for ISED
This equipment complies with ISED RSS-102 radiaon exposure limits set forth for
an uncontrolled environment. This equipment should be installed and operated
with minimum distance 20 cm (7.6 inches) between the radiator and any part of
your body. This transmier must not be co-located or operang in conjuncon
with any other antenna or transmier.
Our se conformer aux exigences de conformité ISED RSS-102 RF exposion, une
distance de séparaon d'au moins 20 cm doit être maintenue entre l'antenne de
cet appareil et toutes les personnes. Lanceurs ou ne peuvent pas
coexister cee antenne ou capteurs avec d'autres.
RF Exposure statement for FCC
This equipment complies with FCC radiaon exposure limits set forth for an
uncontrolled environment. This transmier must not be co-located or operang in
conjuncon with any other antenna or transmier. In order to avoid the
possibility of exceeding the FCC radio frequency exposure limits, this equipment
should be installed and operated with minimum distance 20 cm (7.8 inches)
between the antenna and your body during normal operaon. Users must follow
the specic operang instrucons for sasfying RF exposure compliance.
Label on Device:

Installaon of the device
3. Proceed to the Bluetooth pairing by downloading the Otodata TechApp, available for Android or IOS.
3.1 Start the app on your phone
Sensor Connector
1. Unpack your device and ensure all parts look good with no damage.
2. If the sensor was shipped disconnected from the box, you can connect it now. Look for the correct posion of
the connector by aligning the half moon marks.

3.5 Once the process is
nished you will be able
to use your device in the
regular Nee-Vo app.
BLE Pairing
3.3 Conrm
This process will link your
Otodata ES3016 to this
Smartphone.
3.4 Select your device
from the displayed list
3.2 Select BLE Pairing
My Tank
