Otodynamics Otoport Advance User manual

Otoport OAE+ABR
Otoport Advance model
Issue 8.1
Otoport OAE+ABR
User Manual for Otoport Advance model

0120
User Manual for
Otoport OAE+ABR
Otoport Advance model
Issue 8.1 : December 2016
Otoport Advance V1.17.1.32 onwards
Doc Ref: MANOA-BK.8.1
Copyright Notice
No part of this publication may be copied by any means,
translated or distributed to third parties without the express
written permission of Otodynamics Ltd.
Copyright © 2016 Otodynamics Ltd. All Rights Reserved.
Otodynamics Ltd
30-38 Beaconseld Rd
Hateld Herts AL10 8BB UK

Contents
1Introduction 9
1.1 Intended Use 9
1.2 General Guidance 10
1.3 General use precautions 11
1.4 Types of otoacoustic emissions 12
1.5 Advanced DPOAE test measurements 15
1.6 Auditory Brainstem Response 20
1.7 Training 21
2 Equipment identication 22
2.1 Supplied only in Otoport OAE+ABR kit 22
2.2 Supplied only in Otoport OAE kit 23
2.3 Supplied in OAE and OAE+ABR kits 24
2.4 Optional accessories 27
2.5 Controls, indicators and connections 29
2.6 Scanner 30
2.7 OAE labelling 31
2.8 Otoport OAE+ABR controls, indicators and connections 33
2.9 ABR labelling 34
3Getting started 36
3.1 Assembling the ABR Module with an Otoport 36
3.2 Removing the Otoport from the ABR Module 39
3.3 Otoport OAE+ABR with non-removable module 39
3.4 Connecting probes and electrodes 40
3.5 Initial charge 42
3.6 Quickstart 42
3.7 Using the keys and keypad 48
3.8 Connecting the probe 53
3.9 Disconnecting the probe 54

4Switching on 56
4.1 Switch on screen 56
4.2 Logo screen 57
4.3 Login 58
4.4 Scrolling modules 59
5Test preparation 60
5.1 General checks before testing 60
5.2 Environment checks for ABR 60
5.3 Tip selection and probe tting 61
5.4 Helpful hints 63
5.5 Electrode tting 64
6Test troubleshooting 67
6.1 OAE test problems 67
6.2 ABR test problems 68
6.3 OAEs and screening 70
7Testing options 71
8Patient details 73
8.1 Entering patient data 74
8.2 Beginning a test 76
9TEOAE test 77
9.1 Test choice 77
9.2 TEOAE Checkt 78
9.3 TEOAE recording 82
9.4 TEOAE test results 88
4

10 DPOAE test 89
10.1 Test choice 89
10.2 DPOAE Checkt 91
10.3 Calibration 95
10.4 DPOAE recording 96
10.5 DPOAE test results 103
10.6 DP Growth 104
11 ABR test 107
11.1 Test choice 107
11.2 Impedance check 108
11.3 ABR Checkt 112
11.4 ABR test 114
11.5 Bilateral ABR testing 120
12 Saving a test 122
12.1 Test review screens 123
13 Multi-Test 124
14 Records 126
14.1 Records menu 126
14.2 Find patient 127
14.3 Work list 135
14.4 Database summary 138
14.5 Erase all 139
15 System 140
15.1 System menu 140
15.2 Controls menu 141
15.3 Battery 143
15.4 System details 144
15.5 About 144
Otoport OAE+ABR
User Manual for Advance and Screener
5

16 Management 145
16.1 Management menu 145
16.2 Users menu 146
16.3 Facility and risk 151
16.4 Date and time 153
16.5 Other options 154
17 Test set-up 156
17.1 Test setup menu 156
17.2 Edit mode menu 158
17.3 Test cong 158
17.4 TEOAE test cong 159
17.5 DPOAE test cong 162
17.6 ABR test cong 166
17.7 Stop criteria 167
17.8 Automation 174
17.9 OAE Other settings 179
17.10 ABR Other settings 181
17.11 Multi-Test cong 183
17.12 Test setup defaults 184
18 Transfer (printing and downloading) 193
18.1 Bluetooth wireless printing and download 193
18.2 Wired downloading 194
18.3 When you can print and download 195
18.4 Transfer menu 196
18.5 The printing process 199
18.6 Printer fault detection 202
18.7 Printer light summary 203
18.8 Paper 204
18.9 Charging the printer 205
18.10 Changing the battery 206
19 Scanning 207
19.1 Scanning facility 207
19.2 Scanner types 207
19.3 When to use the scanners 209
6

Otoport OAE+ABR
User Manual for Advance and Screener
7
20 QA area 211
20.1 QA area menu 211
20.2 Probe test 212
20.3 ABR cable test 217
21 Probe, tips and accessories 229
21.1 Probe and service accessories 229
21.2 Probe cable clip 229
21.3 Probe tips 231
22 Probe care 234
22.1 Cleaning 234
22.2 Changing probe coupler tubes 234
22.3 Probes safety note 236
23 Care of the Otoport 237
23.1 Use of the Otoport and cleaning 237
24 Otoport power 239
24.1 Battery life 239
24.2 Initial charge 239
24.3 Standby 240
24.4 Battery charge 241
24.5 Charging the Otoport 243
24.6 Conditioning the Otoport battery 247
25 Troubleshooting 248
25.1 Otoport lock-up 248
25.2 Switch on 248
25.3 System details 249
25.4 Instrument fault message 250
25.5 Hardware fault messages 251

8
26 Training 252
27 Obtaining service 253
28 Calibration 254
29 Mode of operation 255
29.1 TE Test 255
29.2 DP Test 257
29.3 ABR test 258
30 Response detection 264
30.1 Condence levels in DPOAE tests 264
30.2 Condence levels in TEOAE tests 267
30.3 Conclusions 269
31 Technical specications 271
31.1 General 271
31.2 Electromagnetic Compatibility: Otoport 275
31.3 Electromagnetic Compatibility: Otoport OAE+ABR 280
31.4 EN60645-3 conformance notes 286
31.5 ABR Module 288
31.6 Symbol explanations 289
32 Index 291

1Introduction
This manual provides instructions for the use of the Otoport OAE+ABR
(Otoport Advance and Screener models). Instructions that apply only to the
Otoport Advance are indicated with the following symbol:
The Otoport provides high quality OAE and ABR measurement features in
a compact, hand-held format.
The Otoport is simple to use and with powerful measurement features
performs an automatic analysis of cochlear status within seconds.
Customisable Stop criteria control the test’s automatic stop.
1.1 Intended Use
This Otodynamics Otoport/Otocheck OAE+ABR device is indicated for use
when there is a requirement to screen for hearing disorders by objective
and non-invasive means. ABR, TEOAE and DPOAE screening test
results are automatically interpreted and a clear ‘Pass’ or ‘Refer’ result is
presented to the user who will be a trained screener, audiologist or medical
professional. Use of the device is indicated when the patient is unable
to give reliable voluntary responses to sound, especially with infants.
Use of the device facilitates the early detection of hearing loss and its
characterization.
The TEOAE and DPOAE analytical functions of the device are
indicated when objective non-invasive clinical investigations require the
characterization and monitoring of the functional status of the peripheral
auditory function. For this purpose the device is intended to be used by
audiologists or other audiologically skilled professionals. These TEOAE
and DPOAE tests are applicable to populations of any age to obtain
objective evidence of peripheral auditory function.
OTOPORT
ADVANCE
ONLY
Introduction
Otoport OAE+ABR
User Manual for Advance and Screener
9

1.2 General Guidance
Each test type provides evidence of normal peripheral hearing function
objectively and non-invasively.
The screening functions of this instrument are especially suitable for
use with infants. The ABR screening function uses conventional Fsp
methodology to detect the response supported by waveform identication
(Template Correlation) which is optimised for infants from 34 weeks to
6 months gestational age. Template-free pass criteria for ABR may be
selected for use with patients outside this age range (see chapter 17 Test
Setup, section 17.7.3, ABR stop criteria). OAE screening functions include
Otodynamics classic Quickscreen TEOAE technology and Rapid DPOAE
technology (depending on the model).
The device can be used in a wide range of di󰀨erent environments for
example in the well-baby nursery, the NICU, a doctor’s o󰀩ce, an audiology
clinic, the outpatient clinic or in the home. For optimum results and short
test times the room should be quiet and the patient should be very quiet
and still during the test. The device will clearly indicate levels of acoustic
noise and electrical interference (with ABR). Use this as a guide to improve
the testing environment.
The screening functions of the device are intuitive and suitable for
operation by trained screeners without specialized knowledge. Testing and
interpretation is automated. The TEOAE and DPOAE analysis functions
of the device are intended for clinical audiological investigations when
objective non-invasive characterisation and monitoring of the functional
status of the peripheral auditory function is required. These functions
are intended for use as a part of the audiological diagnostic test battery,
not as solitary diagnostic tests. The OAE analysis functions provided on
some models are of particular interest to Audiologists, Ear, Nose and
Throat specialists, Neurology specialists, researchers and other health
professionals concerned with the di󰀨erential diagnosis of hearing problems,
the monitoring of changes to hearing, the conservation of hearing or the
detailed measuring of peripheral auditory function.
Introduction
CHAPTER ONE
Introduction
