Otterbine/Barebo MR16 User manual


Manual
P

P
N: 75-0116
R

I
n
R
ev 02 
MR
n
stall
a
16
R
a
tion/
O
R
GB
W
O
pera
t
W
Lig
t
ion
M
hts
M
anu
a
a
l

Otterbine Barebo Inc.
2 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
CONTENTS
SafetyInstructions..............................................................................................................3
LampInstallation.................................................................................................................4
WirelessRemoteControl....................................................................................................5
Batteries.......................................................................................................................5
Linking..........................................................................................................................6
Unlinking.......................................................................................................................6
Operation.....................................................................................................................7
WiFiiBoxController‐Optional...........................................................................................8
Installation....................................................................................................................8
Troubleshooting..................................................................................................................9

Otterbine Barebo Inc.
3 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
SafetyInstructions
ALL ELECTRICAL WORK MUST BE PERFORMED BY A QUALIFIED LICENSED ELECTRICIAN AND CONFORM
WITH ALL APPLICABLE ELECTRICAL SAFETY CODES
Tous travaux électriques doivent être effectués par un électricien professionnel qualifié et conforme à tous les codes
applicables sécurité électrique
ALWAYS SWITCH OFF/DISCONNECT ALL EQUIPMENT IN THE WATER BEFORE SERVICING OR PERFORMING
ANY MAINTENANCE
Toujours éteindre l'équipement dans l'eau avant entretien ou de tout entretien
DO NOT OPERATE THE FOUNTAIN WHEN PEOPLE ARE IN THE WATER
Ne pas utiliser la fontaine quand les gens sont dans l’eau
CAUTION: KEEP HANDS CLEAR OF THE IMPELLER WHEN OPERATING!
ATTENTION: Garder les mains loin la turbine lors de l’utilisation!
WARNINGS
• Before entering, wading in or swimming in the water in which Otterbine Aerators or Fountains are installed, make sure
they are PHYSICALLY disconnected from their electrical power sources.
• Aerators located in or near garden ponds and similar locations must be equipped with Ground Fault Circuit Interrupter.
• The permissible temperature range for this equipment is -12oto 40oC/10oto 104oF.
• If the power cord is damaged, it must be replaced by a special cord or assembly available from Otterbine/ Barebo, Inc.
or an authorized Otterbine/Barebo, Inc. sales and service center.
• Avant d'entrer, pataugeant dans ou en nageant dans l'eau dans laquelle Aérateurs Otterbine ou fontaines sont
installées, assurez-vous qu'ils sont physiquement déconnectés de leur source d'alimentation électrique.
• Aérateurs situés dans ou à proximité des bassins de jardin et des emplacements similaires doivent être équipés de
disjoncteur.
• La plage de température admissible pour cet appareil est-12 o à 40 oC/10 o à 104 oF aux.
• Il est possible pour que l'eau devient légèrement polluées dans les rares cas où une fuite d'huile se produit.
• Si le cordon d'alimentation est endommagé, il doit être remplacé par un cordon spécial ou de montage disponible à
partir Otterbine / Barebo, Inc ou une autorisation Otterbine / Barebo, les ventes Inc et centre de service.

Otterbine Barebo Inc.
4 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
LampInstallation

IMPORTANT:AlwaysreplacethesealingO‐ringwhenchangingthelamp.
(O‐ringisincludedwithOtterbinelampreplacementkits)

LampReplacemetKit
PN:09‐0030‐060(MR16RGBWLampw/O‐ring)

A. Physicallydisconnectthepowerfromtheunitandthelightset.Allowthelightstocooltoavoidskinburns.
B. Removethelightfixture(s)fromthefloatandfromthewater.Dryexcesswateroffofthelightfixture.
C. Removethelightringfromthehousingbytwistingitcounter‐clockwiseandliftingitoff.
D. RemovetheglasslensandO‐ring.
E. Removethelampbypullingitstraightoutofthesocket.
F. Pushthelamppinsstraightintothesockettoavoiddamage.

Note:Thesocketwillbedamagedifthelampisnotinstalledproperly,becertainthelamppinsareinstraight
alignmentwiththesocketwhenremovingandreplacingthelamp.

G. ReinstalltheglasslensandanewO‐ringontothetopofthehousing.Placethelightringontopofthehousing
soitrestsinthetabsandtwistitclockwiseuntilitsnapsintoplace.
Note:Ifthelightringisonthehousingproperly,therewillbeapproximatelya1/8”gaptotherightofeachtabonthe
housingwhenlookingfromthetop.Ifthisgapisnotpresent,thelightringisnotonproperlyandneedstobetwisted
furtherclockwise.

H. Reinstallthelightfixture(s)tothefloat.
I. Reconnectpowertotheunitandthelightset.


Otterbine Barebo Inc.
5 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
WirelessRemoteControl
Thelampsmaybecontrolledbythewirelessremotecontrol.Thewirelessremotecontroloperatesat2.4GHzandis
capableofcontrollinglampsinuptofour(4)zones.Ithasamaximumrangeof30m(98ft).
Batteries
Thewirelessremotecontrolusestwo(2)AAAbatteries.Batteriescanbereplacedbyremovingtherearcoverofthe
remotecontrol.Thereisasmallslotlocatedonthelowersideoftheremote.Useafingernail,screwdriver,orothertool
tobegintoprythecoveroff.Slowlyworkyourwayaroundthecoveruntilitcomesoff.

Replacebatteriesobservingthecorrectpolarity.

Replacecoverbysnappingthecoverbackontheunit.

Slot

Otterbine Barebo Inc.
6 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
Linking
Inorderfortheremotetocontrolthelamps,thelampsneedtobelinkedtotheremote.Theremotecontrolcancontrol
lampsassignedtofour(4)zones.Whenaremoteissuppliedwithasetoflamps,thelampswillbelinkedtozone1.
Followtheinstructionsbelowtolinkthelampstoaremote:
A. Turnpowerofftothelamps.
B. Turnpowerontothelamps
C. Withinthree(3)secondsofturningonthelamps,pressthedesiredzoneonbuttonthree(3)times.

D. Ifsuccessful,thelampswillblinkthree(3)timesandthenbesteadyon.
Unlinking
Followthebelowinstructionstounlinkthelampfromtheremote.
A. Turnpowerofftothelamps.
B. Turnpowerontothelamps
C. Withinthree(3)secondsofturningonthelamps,pressthedesiredzoneonbuttonfive(5)times.

D. Ifsuccessful,thelampswillblinkten(10)timesandthenbesteadyon.

ZoneOnButtons
ZoneOnButtons

Otterbine Barebo Inc.
7 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
Operation
Theremoteusesatechnologysimilartoacellphonetouchscreen.The“buttons”ontheremotearetouchsensitive
areasthatwillrespondtofingersoratouchstylus.Whentheremoteissensingatouch,anorangeindicatorlightwillbe
visibleinthecenterofthecircularareaonthefaceoftheremote.Iftheremotegetsstuckandthelightwillnotgoout,
removeandreplacethebatteriestoresetthetouchsensor.

Buttonoperationisdescribedbelow:
A. MasterOn–Willturnonalllampslinkedtothisremote.
B. MasterOff–Willturnoffalllampslinkedtothisremote.Holdingthemasteroffbuttonwillsetalllinkedlamps
tonightlightmode.
C. Colorring–Touchtheareaoftheringcorrespondingtothedesiredcolortochangethecolorofthelampsfor
theactivezone.
D. Indicator–Indicatesthatabuttonontheremoteisbeingpressed.Iftheindicatorlightisblinkingfast,it
indicatesthattheremotebatteriesneedtobereplaced.
E. ColorTemperature–Thisareaoftheremotewillchangethelightingcoloroftheactivelampstowhiteandset
thedesiredcolortemperature.Touchingtowardtherightwillselecthighercolortemperaturesandtouchingto
theleftwillselectlowercolortemperatures.
F. SaturationControl–Thiscontrolwilladjusttheamountofwhitelightaddedtotheselectedcoloroftheactive
lamps.Thehigherupthecontrol,themorewhitelightwillbeadded.
G. BrightnessDimming–Thiscontroladjuststhebrightnessoftheselectedcolorsfortheactivelamps.Thehigher
upthecontrol,thebrighterthelights.
H. Mode–Thiscontrolwillinitiateoneofthepreprogrammedsequencingmodesontheactivelamps.
I. Speed+–Thiscontrolwillspeedupthepreprogrammedsequencingmodeifitiscurrentlyrunningontheactive
lamps.
J. Speed‐–Thiscontrolwillslowdownthepreprogrammedsequencingmodeifitiscurrentlyrunningonthe
activelamps.
K. ZoneOn–Turnsonthelampslinkedtozone1andmakeszone1lampsactivefortheremote.
L. ZoneOff–Turnsoffthelampslinkedtozone1.Holdingthezoneoffbuttonwillsetallzone1lampstonight
lightmode.

Otterbine Barebo Inc.
8 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
WiFiiBoxController‐Optional
TheWiFiiBoxcontrollerallowstheMR16RGBWlampstobecontrolledviasmartphoneapp.TheiBoxprovidesabridge
betweenaWiFiwirelessnetworkandtheRFcontrolforthelamps.TheiBoxhasarangeof30m(98ft)andmustbe
locatedwithin30m(98ft)ofthelampstobecontrolled.WiFirangeisdependentonthedevicebeingusedtoconnectto
theiBox.Typicalruleofthumbfortherangeof2.4GHzWiFiis46m(150ft)indoorsand92m(300ft)outdoors.
Installation
TheMi‐Lightapplicationwillneedtobeinstalledonthedevicethatwillbeusedtocontrolthelamps.Theapplication
canbefoundbysearchingforMilightintheapplestore,searchingforMilightfromtheGooglePlaystore,orbyscanning
thecodefoundintheinstructionsthatcomewiththeWiFiiBoxcontroller.
TheiBoxcontrollerissuppliedwithacableand5VUSBpowersupply.Plugthepowersupplyintoanappropriateoutlet
andconnectthecablefromthepowersupplytotheiBoxcontroller.WhentheiBoxcontrollerispoweredup,thesys
lightwillblink.
Whenpurchasedwithasetoflamps,theiBoxcontrollerwillbeshippedalreadylinkedtothesuppliedlampsandsetfor
thecontrollingdevicetoconnectwirelesslydirectlytotheiBoxcontroller.Thelampswillbelinkedtozone2oftheiBox
controller.Forotherconfigurations,pleaserefertotheinstructionsprovidedbythemanufacturerofthesoftware.



Otterbine Barebo Inc.
9 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
Troubleshooting
A. Lampsdon’tturnon
a. Verifythatthelampshavepower.
i. Thestandardlightingtransformerhasaphotoeyeandonlypowersthelightswhenitisdark.
ii. Ifthelampsareonatimerverifythatthetimerissendingpowertothelamps.
b. Thelampsthemselveshavetobeturnedoninorderforthemtoturnonwiththepowersupply.Try
turningonthelampswiththeremoteorsmartphone.Ifthelampsareonatimerorphotocell,donot
turnoffthelampswiththeremoteorsmartphoneapp.
c. Lampsarenotlinkedtotheremote/iBoxcontroller.Relinkthelamps.
d. Remoteissettothewrongzone.Tryusingthemasteronbutton.
B. Remoteindicatorlightisstuckon
a. Removeandreplacebatteries
C. Remoteindicatorlightflashing
a. Batteriesarelow–Removeandreplacebatteries.
D. Lampsareon,butremotecontroldoesn’tcontrolthelamps.
a. Incorrectzoneselected.Tryoperatingthelampswitheachzoneactive.
b. Remoteisoutofrangeoflamps.Tryoperatingfromacloserlocation,orfromadifferentangle.
c. Lampsarelotlinkedtotheremote.Relinkthelamps.
d. Lampsaresubmerged.Waterwillblockradiowaves.Makesurethelampsareabovethesurfaceofthe
water.

Otterbine Barebo Inc.
10 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
Limited 3 Year Warranty – 3 Months on Lamps
Otterbine® Product
WARRANTY: Barebo, Inc 3840 Main Road East, Emmaus Pennsylvania 18049,USA. hereby warrants,
subject to the conditions hereinbelow set forth, that should the OTTERBINE product prove defective by
reason of improper workmanship or materials at any time during the warranty period the Purchaser at retail
will be guarantee that BAREBO will repair or replace the said OTTERBINE product as may be necessary
to restore it to satisfactory operating condition, without any charge for materials or labor necessarily
incident to such repair or replacement, provided that:
a) The enclosed Warranty Registration Card should be mailed to BAREBO within fifteen (15) days of
the original receipt by the Purchaser at retail in order to avoid delays:
b) The OTTERBINE product must be delivered or shipped, prepaid, in its original container or a
container offering an equal degree of protection, to BAREBO or a facility authorized by BAREBO
to render the said repair or replacement services or, if purchased from an authorized OTTERBINE
dealer, to such dealer;
c) The OTTERBINE product must not have been altered, repaired or serviced by anyone other than
BAREBO, a service facility authorized by BAREBO to render such service, or by an authorized
BAREBO dealer, and the serial number of the OTTERBINE product must not have been removed
or altered: and
d) The OTTERBINE product must not have been subjected to lightning strikes and other Acts of
God, vandalism, freezing-in, accident, misuse or abuse, and must have been installed in
conformance with applicable electrical codes (including proper electrical protection), and also
installed, operated and maitained in accordance with guidelines in the Owner's Manual shipped with
the Otterbine product.
No implied warranties of any kind are made by BAREBO in connection with this OTTERBINE product,
and no other warranties, whether expressed or implied, including implied warranties of merchantability and
fitness for a particular purpose, shall apply to this OTTERBINE product. Should this OTTERBINE
product prove defective in workmanship or material, the retail Purchaser's sole remedy shall be repair or
replacement as is hereinabove expressly provided and, under no circumstances, shall BAREBO be liable
for any loss, damage or injury, direct or consequential, arising out of the use of, or inability to use, the
OTTERBINE product, including but not limited to retail Purchaser's cost, loss of profits, goodwill,
damages due to loss of product or interruption of service, or personal injuries to Purchaser or any person.


Otterbine Barebo Inc.
11 75-0116 MR16 RGBW Lights www.otterbine.com
1-800-AER8TER
Water Works With Otterbine!
Otterbine/Barebo, Inc.
3840 Main Rd. East
Emmaus, PA. 18049
U.S.A.
TOLL FREE: 1-800-AER8TER (237-8837)
PHONE: [phone]
FAX: [phone]
E-mail: [email protected]
www.otterbine.com
