Outback Jupiter 4 User manual

0359
Assembly and Operating Instructions for Outback®
Jupiter 4 Burner Gas BBQ
Drawings are not to scale.
Specifications subject to change
without prior notice.
WARNING
• For outdoor use only. Not for commercial use.
• Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
• Warning: accessible parts may be very hot. Keep young children and pets away.
• Do not move the appliance during use.
• Turn off the gas supply at the gas bottle after use.
• Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
rights.
• Retain these instructions for future reference.
• Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
• For Flare-up control please refer to the ‘OPERATION’ section of this manual.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and
contact your local dealer.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
MS4491

2
CODE PART QTY Outback®
Jupiter 4 Burner Gas BBQ
HOOD
A1 Hood (Pre-Assembled to Body) 1 
A2 Hood Handle 1 
A3 Heat Indicator 1 
A4 Warming Rack 1 
BODY
B1 Barbecue Body 1 
B2 Burner 4 
B3 Control Panel 1 
B4 Knob 4 
B5 Hose and Regulator Assembly 1 
B6 Large Lava Rock in Basket 1 
B7 Small Lava Rock in Basket 1 
B8 Grill W ith Hole 1 
B9 Round Grill 1 
B10 Cooking Grill 1 
B11 Drip Tray Left Bracket 1 
B12 Drip Tray Right Bracket 1 
B13 Drip Tray 1 
B14 Drip Pan 1 
B15 Ignition Button 1 
TROLLEY
C1 Side Burner Shelf 1 
C2 Side Burner Shelf Panel 1 
C3 Side Shelf 1 
C4 Side Shelf Panel 1 
C5 Tool Hook 1 
C6 Side Burner Grid 1 
C7 Knob Bezel 1 
C8 Side Burner Knob 1 
C9 Side Burner 1 
C10 Left Cabinet Panel 1 
C11 Right Cabinet Panel 1 
C12 Upper Support 1 
C13 Door Handle 2 
C14 Left Door 1 
C15 Right Door 1 
C16 Rear Panel 1 
C17 Bottom Panel 1 
C18 Front Wheel Skirt 1 
C19 Storage Unit 1 
C20 Caster 2 
C21 Lockable Caster 2 
HARDWARE
D1 M6x35 Bolt 8 
D2 ST4.0x10 Screw 21 
D3 M6x15 Bolt 26 
D4 M6 Nut 14 
D5 M4x10 Bolt 6 
D6 M4 Nut 3 
Pre-Assembled Component
Quantity varies according to model purchased
 Appearance, size, and construction may differ according to model purchased
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.

3
Parts Diagram
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
A2
A4
B1
B2
B4
B6
B11 B12
B15
B10
B13
C16
C13
B7
C14 C15
B14
B3
A1
C3
B5
C20
C21
C12
C4
C11
C10
C1
C6
C9
C2
C8
C7
A3
C5
C17
C18
C19
B9
B8

4
Hardware Reference Diagram
Specifications subject to change without prior notice.
D1
D2
D5
D3
D6
D3 D4

5
Assembly
IMPORTANT!
• TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,
adjustable spanner or metric spanner set.
• Remove any internal component or packaging from the barbecue body.
• Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
• Please read the Important Information section carefully before assembly and use of your
barbecue.
1
2
Attach the Left Cabinet Panel (C10) and Right Cabinet Panel (C11) to the Bottom Panel (C17)
using M6x35 Bolts (D1x8pcs) and M6 Nuts (D4x8pcs), ST4.0x10 Screw (D2x6pcs) as shown.
Please note: Three small holes on bottom panel should be located at the front of BBQ.
C17
Attach the Front Wheel Skirt (C18) onto the Bottom Panel (C17) using M4x10 Bolts
(D5x3pcs) and M4 Nuts (D6x3pcs) as shown.
C18
C10 C11
D1
D5 D6
D4
C17
D2
Front
Rear
Front
Rear

6
Attach the Rear Panel (C16) to the cabinet assembly using ST4.0x10 Screws
(D2x7pcs) as shown.
3
4
C16
C19
Attach the Storage Unit (C19) onto the Bottom Panel (C17) using M6x15 Bolts
(D3x4pcs) as shown.
D3
Bottom View
D2

7
Attach the Drip Tray Left Bracket (B11) to the left cabinet panel using ST4.0x10 Screws
(D2x2pcs) as shown. Repeat above process for Drip Tray Right Bracket (B12).
Please note: Drip tray brackets will attach at a slight angle.
5
6
Front
B11
Attach the Upper Support (C12) to the left/right cabinet panel using M6x15 Bolts (D3x4pcs).
Rear
D3
D3
C12
Side view of drip tray bracket

8
7
8
Remove the retaining bolts from one Door Handle (C13), and then attach the door
handle onto the Left Door (C14) using the retaining bolts as shown.
Repeat above process for Right Door (C15).
Carefully turn the cabinet upside-down.
Attach the Lockable Casters (C21x2pcs) into the rear side holes of the left/right cabinet panel
and the Casters (C20x2pcs) into the front side holes of the left/right cabinet panel, as shown.
C21
C21
C20
C20
C13
C14

9
9
10
Carefully place the Barbecue Body (B1) onto the cabinet assembly and fix using
M6x15 Bolts (D3x4pcs) as shown.
Fit the doors to the cabinet by depressing the spring pins and placing into the cabinet.
B1
D3
D3

10
11
12
Attach Side Shelf Panel (C4) onto Side Shelf (C3) using M6x15 Bolts (D3x2pcs) and M6 Nut
(D4x2pcs) as shown.
Connect the Hose and Regulator Assembly (B5) to the barbecue.
Ensure the mating faces of the connection are clean and not damaged. Do not use any sealing
tape, paste, or liquid on the connection. The nut must be tightened with the use of a spanner.
Do not use force which may damage the assembly.
B5
C3
C4 D3
D4
