oventrop DynaTemp TR-80 Operating instructions

For an overview of our global presence Subject to technical modification without notice.
visit www.oventrop.com. 115305581 05/2017
Valves, controls and systems
“DynaTemp”;
“TR-80”, “TR-250”
Installation instructions for first commissioning by the specialised installer
Before installing the transformers “TR-80” (item 1153053)
and “TR-250” (item no. 1153055) as well as their accessory
components, you must carefully read and follow through
these installation instructions and the operating manual for
the respective “DynaTemp” system!
Installation, commissioning, operation and maintenance
must only be performed by trained and specialised staff in
compliance with applicable rules and regulations!
The installation instructions, the operating manual for the
respective “DynaTemp” system as well as all additionally
applicable documentation must be forwarded to the system
operator!
Content
1General information ...........................................................1
2Safety instructions .............................................................2
3Transport, storage and packaging .....................................2
4Technical specifications.....................................................2
5Assembly and installation ..................................................3
6Commissioning..................................................................3
7Accessories.......................................................................3
8Maintenance and servicing ................................................3
9Declaration of conformity ...................................................3
10 Warranty............................................................................3
Transformers “TR-80” and “TR-250”
OVENTROP GmbH & Co. KG
Paul-Oventrop-Straße 1
D-59939 Olsberg
Phone [phone]
Fax [phone]
E-mail [email protected]
Internet www.oventrop.com
1 General information
1.1 Information about the installation and operating in-
structions
These installation instructions are to be used by the trained and
specialised staff to properly install, commission and configure
the transformers “TR-80” and “TR-250” for the first time. Follow-
ing installation, additional documentation like for example the
operating manual for the associated system “DynaTemp” is to
be downloaded from the control and regulation unit (DDC) in the
“HELP/INFO - Documentation” menu item with an Internet
browser, e.g. “Mozilla Firefox”.
Additionally applicable documentation - instructions for all sys-
tem components as well as applicable technical rules - are to be
complied with.
1.2 Safekeeping of documentation
These installation instructions are to be stored in a safe place by
the system operator for later use.
EN

- 2 -
1.3 Symbol explanation
Safety guidelines are displayed by symbols. These guidelines
are to be observed to prevent accidents, damage to property
and malfunctions.
DANGER indicates a hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING indicates a hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION indicates a hazardous situation
which, if not avoided, may result in minor or moderate injury.
NOTICE indicates a situation which, if not
addressed, may result in property damage.
1.4 Copyright
These installation instructions are protected by copyright.
2 Safety instructions
2.1 Intended use
Operational safety can only be ensured for intended use of the
“DynaTemp” control and regulation unit and its accessories.
Any additional and/or other usage of the transformers “TR-80”
and “TR-250” is prohibited and is considered as contrary to
intended use. Any claims against the manufacturer and/or his
authorised representatives for damages as a result of non-
intended use cannot be recognised. The intended use also
includes proper compliance with the installation instructions.
The content of these installation instructions is solely intended
for the transmission of information.
2.2 Risks posed by the place of installation and transport
The possibility of an external fire was not considered when
designing the control and regulation unit and its accessories.
Dangerous electrical voltage!
Danger to life
Installation, commissioning and maintenance must only be
performed by competent personnel.
During installation, the respective VDE regulations are to be
observed (VDE 0100).
Any work on the transformer must only be carried out when it is
in a de-energised state
3 Transport, storage and packaging
3.1 Transport inspection
Check consignment for completeness and any transport dam-
age immediately after receipt and before installation.
If such or other defects are found, only accept the consignment
with reservation. File a complaint. Observe complaint deadlines
in doing so.
3.2 Storage
Only store the transformers “TR-80” and “TR-250” under the
following conditions:
Store indoors in dry and dust-free conditions.
Do not expose to aggressive media or heat sources.
Protect from solar radiation and excessive mechanical
vibrations.
Storage temperature: -20°C …+60°C
Relative humidity (r.h.): 10 ...95%, non-condensing
3.3 Packaging
All packaging material is to be disposed of in an environmentally
sound manner. Please do not let your children play with any
packaging materials –they could be a danger to them.
4 Technical specifications
Electrical connection:
Primary: 230V / 50-60Hz
Secondary: TR-80 (item: 115 30 53): 24V/1x80W
TR-250 (item: 115 30 55): 24V/1x250W
Operating conditions:
Temperature: 0 ...+40°C
Humidity: 10 ...95% r.h., non-condensing
Switch-on time: 100%
Internal thermal protection: 110°C
Storage conditions:
Temperature: -20 ...+60°C
Humidity: 10 ...95% r.h., non-condensing
Housing:
Dimensions (item 115 30 53) without attachment/cabling:
85 × 70 × 70 (L x W x H in mm)
Dimensions (item 115 30 55) without attachment/cabling:
100 × 85 × 105 (L x W x H in mm)
Type of installation: Assembly
Material / colour: Durethan, black
Protection class: II, double insulated
Protection type: IP54 / IP00 (cabling)
Labels and safety instructions:
Replacement fuse in compliance with DIN 41662 / IEC 60127-2/3

- 3 -
5 Assembly and installation
Installation, commissioning and maintenance must only be
performed by competent personnel. During installation, the
respective VDE regulations are to be observed. (VDE 0100) All
work on the transformer must only be performed in a de-
energised state.
In order to prevent heating up of the transformer above 85°C,
the transformer is to be installed in such a way its ambient
temperature does not exceed 40°C. It is not suited to operation
in or under water and in rooms with ambient temperatures
above 40°C or in rooms with permanent humidity. It must be
ensured that installed protective and safety elements are acces-
sible at all times. In order to ensure sufficient air circulation,
apart from the mounting surface a distance to adjacent surfaces
of at least 10cm should be adhered to.
Mounting must only occur as stationary transformer with fixed
wiring. The transformer must be firmly attached immediately in
its place of operation. The transformers are to be charged in
accordance with their rated output if possible.
The overall performance of the connected consumers must
never exceed the rated output of the transformer. In case of
branching as well as reduction of the cable cross section, the
line and short-circuit protection according to VDE100 part 559 is
to be ensured during installation. In general, the following ap-
plies: The primary as well as secondary lines are to be protected
against overload and short circuit.
Important information about installation:
The parallel circuit of the secondary side of several transformers
is principally prohibited, as reverse voltages form on the 230V
side.
For an increase of the output power use a correspondingly more
powerful transformer or additional separate transformers.
When using several transformers, the 24-volt-circuits are to
be separated from each other!
The transformers must only be operated with laid out cables
which are not bundled or rolled up.
A connecting cable firmly attached to the transformer by the
manufacturer cannot be replaced in case of damage. The trans-
former can then no longer be operated and must be replaced.
The transformers are to be charged in accordance with their
rated output if possible. The power rating refers to the perfor-
mance on secondary side during permanent operation, the rated
input voltage, rated frequency 50/60 Hz, cos.φ 1 and an ambient
temperature of 40°C with an installation altitude of max. 1000m
above sea level. It is calculated from secondary rated voltage in
volt and secondary rated current in ampere to VA or kVA re-
spectively.
Never connect the secondary side of several transformers in
parallel, as reverse voltages form on the 230V side.
6 Commissioning
All transformers are produced in accordance with the applicable
VDE regulations and undergo 100% electrical routine tests
during production. The transformers are built and designed as
safety transformers according to EN6155a-2-6 and are suited to
operating systems with extra-low voltage. The low voltage trans-
formers are equipped with a temperature switch which cannot
be reset independently. Transformers with a capacity of 250VA
are protected from short-circuits and overloads with an addition-
al safety fuse. If the temperature switch is actuated due to an
overload of the transformer, proceed as follows:
Disconnect the transformer from the electrical network
Eliminate the cause of the error
Let the transformer cool down
Transformer is ready again
If a device fuse fails, it is to be replaced with the same rated
value with the same trip characteristic according to DIN 41662,
lEC 127-2/111. Only fuses from the following table may be used
as replacement fuse.
Transformer capacity Fine-wire fuse slow
250VA T 2.00A / 250V
Before inserting a fuse the transformer is to be disconnected
from the electrical network and the system is to be checked for
any damage.
7 Accessories
See operating manual.
8 Maintenance and servicing
The product is maintenance-free. A repair must only be per-
formed by a qualified electrician. Clean the product with a soft,
clean, dry and lint-free cloth. Do not use any cleaning agents
containing solvents or abrasive substances. The plastic housing
and the labelling could be damaged by it.
9 Declaration of conformity
Oventrop GmbH & Co. KG hereby declares that the appliance
complies with the following directive.
Low-voltage directive (LVD) 2014/35/EU
The complete text of the EU declaration of conformity is availa-
ble on the Oventrop Internet page.
10 Warranty
Oventrops general conditions of sales and delivery valid at the
time of supply are applicable.
