oxic XCAA201 User manual

1
WDR Day/Night 650 TVL
Backfocus Camera
Version2010-A
Oringinal English user Manual. Keep for future use

2
Introduction
Dear Customer,
Thank you for purchasing this product.
This product meets the requirements of the applicable European and national
guidelines. The corresponding declarations and documents can be obtained
from the manufacturer.
To maintain this condition and to ensure risk-free operation, you as the user must
observe these operation instructions!
Before initial start-up, read through the complete operating instructions observing
operating and safety instructions.
All company and product names mentioned in this document are registered
trademarks.
All rights reserved.
If you have any questions, please contact your installer or your local dealer!
Disclaimer
This user manual was prepared with greatest care. If you should notice omissions or
inaccuracies, please inform us about these on the back of this manual given
address.
product or user manual without a previous announcement.
The company is not liable or responsible for direct and indirect subsequent
damages which are caused in connection with the equipment, the performance and
the use of this product.
No guarantee for the content of this document is taken.

3
Important safety instructions
The warranty will expire for damage due to non-compliance with these
operating instructions. We shall not be liable for any consequential loss!
We do not accept liability for damage to property or personal injury caused
by incorrect handling or non-compliance with the safety-instructions. In
such cases the warranty will expire.
Dear customer,
The following safety instructions are intended not only for the protection of your health,
but also for the protection of the device. Please read through the following points
carefully:
•There are no parts on the inside of the product which need to be serviced. Apart from
this, the license (CE) and the guarantee/warranty will lapse if you open/take the
product apart.
•The product will be damaged even it falls from a low height.
Avoid using the device under the following unfavorable ambient conditions:
•wetness or excessive air humidity
•extreme cold or heat
•direct sunlight
•dust or combustible gases, vapors or solvents
•strong vibration
•strong magnetic fields, such as those found in the vicinity of machinery or
loudspeakers
•the camera should not positioned with opened iris towards the sun -
this can lead to destruction of the sensor.
•the camera may not be installed on unstable surfaces
General safety instructions:
•Do not leave packaging material lying around carelessly. Plastic/ foil/bags and
polystyrene parts etc. could become dangerous toys for children.
•For safety reasons don’t give the camera into child hands due to them being able to
swallow small parts.
•Please do not insert objects through the openings into the device.

4
•Use only accessories which are specified by the manufacturer.
Please do not connect incompatible parts to the device.
•Please pay attention to the safety instructions and user manuals of the other
connected devices.
•Check the device for damages before installation. If this should be the case please do
not use it.
•Please adhere to the operational voltage limitations listed in the technical data. High
voltage could destroy the device and pose a health hazard (electric shock).
During the installation into an existing video surveillance system make sure that all
devices are disconnected from the low and supply voltage circuit.
If in doubt allow a professional electrician to mount, install and wire-up your device.
Improper or make-do electrical connection to the mains does only represent at
threat to you but also to other persons.
Wire-up the entire system making sure that the mains and low voltage circuit
remain separated and cannot come into contact with each other in normal use or
due to any malfunctioning.

5
Table of contents
1. Intended use.............................................................................................................06
2. Explanation of symbols...........................................................................................06
3. Scope of delivery.....................................................................................................07
4. Features and functions ...........................................................................................07
5. Description of device ..............................................................................................07
5.1 Overview – article numbers ..............................................................................07
5.2 Unpacking ........................................................................................................07
6. Mounting...................................................................................................................08
6.1 Power supply....................................................................................................08
6.2 Lens mounting..................................................................................................08
6.3 Mounting of the video cable..............................................................................09
6.4 Mounting of the camera....................................................................................09
7. Rear view..................................................................................................................10
8. OSD...........................................................................................................................11
9. Servicing and cleaning............................................................................................14
9.1 Function test.....................................................................................................14
9.2 Cleaning ...........................................................................................................14
10. Disposal....................................................................................................................14
11. Technical data..........................................................................................................15

6
1. Intended use
The WDR Day/Night 540 TVL Standard Camera is equipped with a high quality image
sensor. It is used for video surveillance in internal areas in connection with a recorder
or monitor.
You can find a detailed description of functions in section “4. Features and functions”.
The product should not become damp or wet. The camera is only for use in dry indoor
areas.
Any other use than that described above can lead to damage to the
product and in addition involve other risks. This does not include
operation for other applications and would in case of doing so the
guarantee and any related liability will lapse. This is also the case if any
unauthorized changes or additions have been made to the product.
Please read through the entire manual carefully before putting this
product into operation. This operating manual contains guidelines that
are important for correct mounting and operating.
2. Explanation of symbols
A flash in the triangle is used if there is danger for the health, e.g. by an
electric shock.
An exclamation mark in the triangle points to an important note in this
user manual which must be minded.
This symbol can be found when you are to be given tips and information
on operation.

7
3. Scope of delivery
•WDR Day/Night 650 TVL Standard Camera
•C-Mount lens adapter ring
•Mounting bracket and screws for camera bracket
•User manual
4. Features and functions
•Sony Effio-Pro newest DSP
•Backlight compensation with high dynamic range (WDR)
•Day/Night camera with removable IR cut filter (ICR)
•2D + 3D DNR Support.
•On-Screen-Menu for easy camera setup (OSD)
•Dual-Video output (2 x BNC)
5. Description of device
5.1 Overview – article numbers
Article Number DUAL POWER AC TYPE
Resolution 650 650
Day/Night
(removable IR cut-filter)
√√
Operating voltage 12VDC/24VAC 110-240VAC
5.2 Unpacking
While you are unpacking the device please handle it with utmost care.
If you notice any damage of the original packaging, please check at first the
device.
If the device shows damages, please contact your local dealer.

8
6. Mounting
6.1 Power supply
Before you start with the installation please make sure that the main voltage and the
nominal voltage of the camera comply together.
MONITOR
VIDEO
POWER
EXT
12VDC/24VAC
DUAL POWER
MONITOR
VIDEO
POWER
EXT
110-240VAC
AC TYPE
(1) DUAL POWER is run by a 12VDC/24VAC power supply. The polarity can be
ignored.
In order to connect a 12VDC power supply (DC Connector 5.5mm x 2.1mm)
to the camera you have to first install the included connector cable. Therefore
you need to press the pins and insert the cable ends into the terminals.
(2) AC type is run by a 110~240VAC power supply (preinstalled cable).
6.2 Lens mounting
The camera is designated for lenses with CS-Mount. A lens with C-Mount
can be mounted with the enclosed lens adapter ring.
Before a lens with C-Mount can be mounted, please make sure that the
lens adapter ring is mounted on the camera. Otherwise you may damage
the image sensor.

9
For lenses with DC-drive the connector for the lens cable is on the right
side of the camera. The lens type is identified automatically by the
camera. A lens with DC-drive is recommended for an optimal image
quality.
Back-Focus adjustment:
6.3 Mounting of the video cable
To connect the video signal of the camera with a monitor or recorder, use a coaxial
cable of the type RG59 with BNC-Connector (male) at the “VIDEO” connector.
The cable length up to the next device should not rise 100 meters.
6.4 Mounting of the camera
For the mounting of the camera, mount the provided socket at the upper or underside
of the camera. For this the plate is aligned with the already predefined screw openings
and fastened with the enclosed screws.
ATTENTION!
During the assembly the camera must be separated from the main
voltage.
CAUTION!
The camera should not be positioned with opened iris towards the sun.
This can lead to the destruction of the sensor.

10
7. Rear view
MONITOR
VIDEO
POWER
EXT
12VDC/24VAC
12VDC Version
MONITOR
VIDEO
POWER
EXT
110-240VAC
110~240VAC Version
(1) OSD menu buttons
(2) Relay output (triggered by motion, max. 60VDC/400mA)
(3) Power Supply (12VDC/24VAC or 110~240VAC)
(4) Status LED (active if power is connected)
(5) BNC Video output (MONITOR)
(6) BNC Video output (VIDEO)
(7) Auto iris DC lens driver connector
Buttons Function
(1) Enter : Enter menu / execute
(2) Up : Navigate upwards
(3) Down : Navigate downwards
(4) Left : Increase value / select option
(5) Right : Decrease value / select option
2
3
1
4
5
1
1
2 2
3 3
4
4
5
5
6 6
7 7

11
8. OSD
8.1 Setup the camera by QIS
Call out the OSD function and select into QIS item. Follow QIS
guidance step by step until it is finished
The menu „Quick Install“ has the following steps:
A description of the different steps you can find in following table below.
To move to the next step inside “Quick Install” please activate the menu item
“Next” in the On-Screen-Display.
Using “Back” you move to the previous step.
Function Description Default
WDR
Setting
Bright Area: Adjust Exposure level of bright area
Dark Area: Adjust Exposure level of bright area
Priority: Select the main
WB
Setting
Mode: ATW/AWB/PTL
Setup the white balance parameters
ATW : Auto Tracking White Balance. The white
balance will be performed dynamically and
continuously in a range of 1800~10500K
AWB : Auto White Balance. The white balance is
performed once in with non limited range.
PTL : Auto White Balance. The white balance is
performed once in with non limited range
ATW

12
DNR
Setting
DNR Mode: 2D DNR / 3D DNR /2D+3D DNR
You can select the Digital Noise Reduce Mode-
2D DNR : 2D DNR is for still object to keep the
resolution and low light noise
3D DNR : More details in darker image areas
High dynamic range
Useful for high contrast indoor scenarios
2D+3D
Focus
Setting
In this mode is optimize setting to easy set in right
focus
-
8.2 ADVANCE MENU
ADVANCE MENU has functions that are less used. This is for
application purpose
zExposure:
WD: The user can set the shutter level of Bright/Dark area.
(The Auto iris level in WD mode is automatic adjusted by DSP
itself)
DC: this mode is running in Non-WD , adjust the DC lens driver
level
ME :This mode is running in Non-WD , adjust the manual shutter
and Gain
AES: it sets the upper/lower auto electronic shutter limit.
ADVANCE MENU
Exposure
W.B
Enhance
D/N
Detect
Miscellaneous
RestoreDefault
Return End

13
zW.B:
AWB: in this mode the white balance range is unlimited
ATW: in this mode the tracking white balance is within
1800-10500K
PTL: in this mode color temp. is locked
zEnhance:
AGC: The camera can adjust the AGC up to 62.8 dB
Gamma: The camera has 6 gamma curve to be selected
Aperture : This is for sharpness adjustment
Slow shutter: Max. at 128X
zD/N: This item can set the detail for D/N switching
Auto Mode: the D/N switch is basee on AGC or CDS level and
also can adjust delay time / level, color setting.
Fixed mode: Day / Night mode only.
zDetect:
Face : the camera DSP can detect max 4 human faces at the
same time
Motion Detection: this item can set Motion detection ON/OFF.
Max. 128 blocks can be selected
zMiscellaneous : This item is for additional function adjustments
DNR: This camera has 2D/3D Digital Noise Reduction, and
camera can work at 2D , 3D or 2D+3D mode
Mirror: The camera has Vertical and Horizontal image reverse
Mask: The camera has max. 8 areas to be set with color and
position
Camera ID: Each camera can be set with its own ID
Winker: This is an OSD blinking in upper right corner of image,
this function is to indicate the camera is working in condition that
has no object movements
E-Zoom: The camera has max 5X digital Zoom.
zRestore Default: Restore the default by this item

14
9. Servicing and cleaning
9.1 Function test
Check the technical safety of the product such as damage to the housing at regular
intervals.
When it can be assumed that the safe operation is no longer possible, the product
must be put out of service and precautions taken o ensure that it is not used
unintentionally.
It must be assumed that safe operation is not longer possible if
•the device shows visible signs of damage
•the device no longer operates and
•has been stored for longer periods under unfavorable conditions or
•has been subjected to considerable stress in transit.
Please note:
The product is absolutely maintenance-free for you. There are no
components on the inside of the product to be checked or services by you,
never open it.
9.2 Cleaning
Clean the product with a clean, soft cloth. To remove severe contamination, the cloth
can be dampened with luke-warm water.
Make sure that no liquids can enter the equipment as the device can be
destroyed. Never use chemical detergents as they could attack the surface
of the device.
10. Disposal
Products which are labeled with this pictogram may not be
disposed by the domestic rubbish. Please dispose the product in
accordance with the prevailing legal regulations at the end of its life
time.
Please consult your dealer or dispose the product over the municipal gathering point
for electric scarp.

15
11. Technical data
Article no. XCAA201A XCAA201B XCAA201A XCAA201B
Image sensor 1/3” Interline Transfer SuperHAD II dual scan CCD
Signal system PAL NTSC
Picture element 976 (H) x 582 (V) 976 (H) x 494 (V)
Horizontal resolution 650 TVL
Synchronization Internal
Scanning 2:1 Interlace
Min. illumination (day) 0.1 Lux @ F1.0, 30 IRE
0.01 Lux @ F1.0, 30 IRE (B/W Modus)
Min. illumination (night)
0 Lux @ F1.0, 30 IRE (IR An)
Wide dynamic range 54dB
Sense up 4x factory default (2x - 256x customization)
S/N ratio better than 50dB
AGC 62.8dB (analog + Digital)
White balance control ATW (1800°K - 10500°K) / AWB
DNR 2D / 3D / 2D+3D DNR
Gamma 8 level adjustment
OSD control OSD control (QIS / Advance)
BLC ON / OFF
Masking 16 Areas
Digital zoom x1 ~ x5
Mirroring Horizontal and Vertical
Automatic day/night
switching Removable IR cut filter (ICR), Color / B/W
Iris level adjustment Yes
Lens CS/C-Mount, manual or DC controlled
Intelligent MD/FD ON / OFF
Video output composite: 1.0 Vp-p at 75Ωload
Operating temperature -10°C ~ +50°C
Humidity 0~85%, not condensing
Power supply 12 VDC / 24 VAC 110~240 VAC 12 VDC / 24 VAC 110~240 VAC
Power consumption 4.4W 4.5W 4.4W 4.5W
Dimensions (WxHxD) 65 x 72 x 119mm
Weight 420g

16
A
CI
K
H
VIDEO
POWER
EXT
12VDC/24VAC
118.6mm
109.13mm
64.3mm
64.55mm
72.05mm
