oxic AC24V12VDC User manual

Thank you for choosing this high quality camera, before attempting to
connect or operate this product, please read these instructions completely
DIGITAL COLOR VIDEO CAMERA
ON-SCREEN-DISPLAY
HIGH RESOLUTION
AC24V12VDC Model
AC85 〜265V
OPERATING MANUAL
zWA R N I N G :
TO REDUCETHE RISK OF FIRE OR ELECTRONIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE AND DO NOT REMOVE COVER OR BACK.
zCAUTION:
1.CONNECT 24VAC UL LISTED CLASS 2 POWER SUPPLY.
2.INSTALL THE CAMERA UNDER UNSTABLE LIGHT SOURCE
MAY CAUSE THE ABNORMAL FUNCTION.
3.ONLY USE CAMERA UNDER CONDITIONS WHERE
TWMPERATURES ARE BETWEEN -10°C to 50°C.
zFIELS INSTALLATION MARKING:
THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED
SERVICE PERSON AND SHOULD CONFORM TO ALL LACAL
CODES
P02-KL-007-C

-2 -
1. General
This a color CCD video camera employs a 1/3 inch charge coupled device
solid-state imaging device with 470/410 k or 310/270k picture elements, This
unit is equipped with a newly developed DSP (Digital Signal Processor) for
processing the video signal. This superior and high sensitive series ensure to
meet any strike 24 hours’ surveillance monitoring demand. A micro-controller is
also introduced to provide high color reproduction, sharp, stable picture and
most of the function’s control; the special feature for this camera is it can
accept IR illumination under minimal lighting condition.
2. Features
z1/3” SONY Exview HAD / Super HAD with 470 K pixels (410K pixels for NTSC)
zSONY digital signal processor (DSP) allows better picture quality
zAdvanced Dual mode resolution form more than 500 TV Lines in color mode to
540 TV Lines in B/W mode
zIR accuracy: Vivid color performance in the day time and sharp B&W image with
no focus shift in the nighttime.
zSmart Optical Low Pass Filter (O.L.P.F) switching mechanism allows changing
between color and monochrome.
zEnhanced O.L.P.F control system (4 modes)
Automatic
Manual
Schedule
External I/O
zIntegration GPIO (day/night, IR projector control)
zOn Screen Display control (OSD)
zRemote control by RS232C
zInfrared light-sending response wavelength from 700 to 1100 nm
zIntelligent time delay switch
zFriendly back focus mechanical structure to adjust focus distance
zAdvanced intelligent circuit design to increase the low light sensitivity 0.1 Lux
color mode down to 0.01 Lux B&W mode (Exview HAD)
zOutstanding signal to noise ratio better than 50 dB
z255 Areas Auto detects back light compensation
zInternal or
Line-lock external sync
zIsolated switching power DC12V /AC24V , AC85 〜265 V
.

-3 -
3. Name of Parts and Functions
A
B
C
D
E
F
K
G
I
J
DC12V/AC24 MODEL
AC 85V ~ 265V
3P-PLUG MODEL
AC 85V ~ 265V
2P-PLUG MODEL
AC 85V ~ 265V
AC CORD MODEL

-4 -
A. C (CS) mount adapter if a CS mount lens is to be used, remove the C mount ring
B. Holder screw hole
Standard photographic pan-head screw size (1/4” – 20) Flange focal lock screw
C. Flange focal lock screw
D. Flange focal distance adjuster—if back focus adjustment this ring
E. Auto iris lens connector (MINI JACK)
Use the accompanying auto iris lens control connector plug.
For auto iris lens is with built-in EE amp. (VIDEO Type)
Set the lens selector switch to ”VD” position.
Connector cable leads
1.Red --- power 3.White --- video
2.NC 4.Black --- shielded
For auto iris lens is without EE amp. (DC Type)
Set the lens selector switch to “DD” position.
Connector cable leads
1. Damping coil (-) 3. Driving coil (+)
2. Damping coil (+) 4. Driving coil (-)
F. Video output terminal (BNC)
This connector is used to connect with the VIDEO IN connector of monitor.
G. On-Screen Display keypad
H. Slide out for control panel
I. Power pilot LED
J. DC12V / AC 24V Block Terminal
This terminal accepts DC 12V(Non-polarity) or AC 24V.
The other model: AC 85 ~ 265V.
K. External project control I/O and Remote control terminal
Back focus
thumbwheel
Thumbwheel locking screw
and provided screwdriver

-5 -
4. USER OSD SETTING
SETTING SWITCHES AND FUNCTIONS
1.UP Button-This button is used to move the cursor
upwards. Use this button to select item.
2.LEFT Button –This button is used to move the cursor
left. Use to select or adjust the parameters of the
selected item.
3.RIGHT button-This button is used to move the cursor to the right. Use to select or
adjust the parameters of the selected item.
4.DOWN Button-This button is used to move the cursor downwards. Use this button
to select item.
5.ENTER Button-Press this button to display the setting menu, if the selected item
has its own menu; press this button to enter sub menu.
PC control
For window 95/98
1. Insert the floppy into diskette, and run OSDV1.exe for auto extract all files into
hard disk
2. Execute Kampro_VK.exe
3. A virtue keypad icon will display on screen
4. Use mouse to point the icons for on-screen-display setting.
RS-232 Connection Please refer to the Setup option
In the program window (com2 default)
1.RX pin----SD (D-sub 9) pin 3 from PC
2.TX pin----RD (D-sub 9) pin 2 from PC
3.NC
4.GND------GND (D-sub9) pin 5
I/O PORT The port can send or receive signal by external device.
Select option mode by OSD D/N function.
The camera can switch day or night by external device when it select external mode.
And other mode can send signal to external device. Day (0V). Night (+5V).

-6 -
5. SETTING MENU AND FUNCTIONS
1. Press the ENTER key to enter main
menu.
2.PressUP/DOWNkeytoselectthe
item for adjusting.
3. Press the ENTER key to enter the
sub menu of selected item.
4. Move the cursor to END at the
bottom line and press the ENTER to close the setup menu and return to normal
camera operation mode.
5. Move the cursor to INIT and press the ENTER to return all parameters to the
factory default settings. (Don’t press INIT unless it is necessary)
6. Move the cursor to DEMO and press the ENTER to enter function demo mode, turn
off the power or press the ENTER at 3 seconds to stop the demo.
7. Move the cursor to↑position and press the ENTER key for menu position setting.
8. Move the cursor to UNLOCK and press the ENTER to LOCK the setup menu.
Note: If no button is pressed for 2 minutes while any setting menu displayed, all
modified data will be stored and returns to the normal camera picture mode.
6. Setting Procedure
6.1. Camera Identification Setting (CAMERA ID)
Move cursor to CAMERA ID then press ENTER key to enter ID sub menu
Move the cursor to the character you want to enter or modify by pressing UP, DOWN,
RIGHT, LEFT key. After selecting the character, by press the ENTER key, the
selected character will display on editing data area.
SETUP MENU
CAMERA ID OFF
LIGHT CNTL AES
WHITE BAL ATW
D/N CNTL
PICTURE VIDEO
DISPLAY COLOR POS
OPD WINDOW
MISC
END INIT DEMO ↑UNLOCK
Character Area
CAMERA ID
0 1 2 3 4 5 6 7 8 9 :
A B C D E F G H I J K
L M N O P Q R S T U V
WX Y Z a b c d e f g
h i j k l m n o p q r
s t u v w x y z , .
□□□□□□□□□□□□
RET POSI ←→
Blinking
Editin
g
Data Area
Command area
UNLOCK PASSWORD
Press UP, DOWN, DOWN, RIGHT then ENTER key to unlock the menu.

-7 -
SETUP MENU
CAMERA ID OFF
LIGHT CNTL AES
WHITE BAL ATW
D/N CNTL
PICTURE VIDEO
DISPLAY COLOR POS
OPD WINDOW
MISC
END INIT DEMO ↑UNLOCK
Repeat the step above until all characters are input or edited.
Move the cursor to ← → to edit a specific character in editing data area.
Move the cursor to BLANK (between “z” and “,”) character position then press
enter to erase the character
Move the cursor to POSI, then press ENTER, the
camera id will display on screen, move the camera
ID to the desired position by pressing UP, DOWN,
RIGHT, LEFT key, then press ENTER to fix the ID
position and return to previous menu.
6.2. Light Control
Move cursor to LIGHT CNTL then press ENTER key to enter sub menu
Press RIGHT or LEEFT key to select item, then Press the ENTER to enter
Item sub menu
Mode sequence:
AES AES LOW FLICKERLESS
ME AUTO IRIS + SHUTTER AUTO IRIS
↑
← CAM 001 →
↓
AUTO EXPOSURE MODE:
AES mode: 1/50(1/60) to 1/100,000 sec. AGC 0-36 dB.
AES LOW mode: 1/120(1/100) to 100,000 sec. AGC 0-36dB.
FLICKERLESS mode: 1/120 PAL; 1/100 sec. NTSC, AGC 0-36dB.
AUTO IRIS mode: 1/50(1/60) sec. AGC 0-36dB.
A
U
T
OIRIS + SHUTTER mode: 1/50
(
1/60
)
to 1/10,000 sec. AGC 0-36 dB.
AES MENU
BLC ON
Av:Pk 8:4
AGCMAX 36 dB
RESPONSE 03
AGCMIN 01 dB
SHUTLIM 1/100000
RETURN
Press
ENTER to
sub menu

-8 -
6.2.1. BLC setting
LEFT/RIGHT key to turn Back Light Compensation function ON/OFF
Press ENTER key to display BLC sub menu
HIST BLC—ON/OFF
The HIST BLC (histogram) is good for
when the subject has only a slightly
darker luminance and moving around
the screen, backlight compensation is
performed through exposure luminous
intensity to the dark areas. The internal
u-com will detect the overall picture
contrast and turn on or off the back light
compensation function automatically.
zBLC LEVEL-for histogram BLC
The compensation level of histogram backlight compensation can be
modified from 0 to 255, the default setting is 13, increase the number to
increase the compensation effect.
zWINDOWS BLC ON/OFF—Press RIGHT or LEFT key
This method is suited for cases where the main
subject is fixed within the screen.
The important object in a scene is usually
placed in the center of the monitor’s screen. In
this mode more photometric weight is given to
the center of the screen than to the edge of
the picture, this function will eliminate the
interference by strong background light, which
makes the camera picture dark.
The size and location of center window can be adjust freely by user within 225
area on screen (detail please see OPD setting)
zWindows Weighting Setting
The weighting for windows 0 to 3 can be set independently in a range from 0 to
15. Windows 4 in the center is fixed to the maximum value 15.
WNDW0 WEIGHT 0—15, default setting 1
WNDW1 WEIGHT 0—15 1
WNDW2 WEIGHT 0—15 3
WNDW3 WEIGHT 0—15 3
The combination of two types backlight compensation makes it easier to
arrange backlight compensation operation to match the imaging
conditions and installation location.
Note:
Compensation may be insufficient when the background is extremely bright
Move to RETURN position and press ENTER key back to LIGHT CONTROL
sub menu.
BLC SETUP MENU
HIST BLC ON
BLC LEVEL 12
WINDOWS BLC OFF
WNDW 0 WEIGHT 01
WNDW 1 WEIGHT 01
WNDW 2 WEIGHT 03
WNDW 3 WEIGHT 03
RETURN
WNDW0
WNDW1
WNDW2 WNDW3
CENTRAL
WNDW

-9 -
6.2.2. Av:Pk setting (for all AE mode)
Adjust the Av:Pk value by press the LEFT or
RIGHT key.
Greater Av. value for average photometric
method, the electronic convergence is
automatically adjusted with the average video
signal level of the object as the right
photometric value.
Increase the Pk. value for the peak photometric method, the electronic
convergence is automatically adjusted with the peak video signal level of
the object as the right photometric value.
it is recommend to adjust this setting on DC iris lens after level setting.
Variation range: 0:12 1:11 2:10 3:9 4:8 5:7 6:6 7:5 8:4 9:3 10:2 11:1 12:0
, The default setting is 8:4.
6.2.3. AGCMAX/AGCMIN setting (for all AE mode)
Press the LEFT or RIGHT key for AGC maximum or minimum setting.
The default setting for AGCMIN is 0dB, and the AGCMAX is 30 dB, the
range of AGCMAX is from 0 dB up to 36 dB and AGCMIN is from 0 dB 20
dB.
6.2.4. AE response speed setting (for all AE
mode)
If you want to adjust the response speed
of exposure, move the cursor to RESPONSE
position, adjust the value by press LEFT or
RIGHT key, the response time of exposure
system can be set from 0.5 second (01) up to 15 second (255), by increase
the figures for slower response. The default setting is 0.5 second for normal
applications, If you don’t want the monitor screen picture been influenced by
auto exposure response speed when suddenly a spot light displayed on
screen which makes the camera picture become dark.
This function is very useful when the camera is installed at car parking
area or on the street at night, you can see objects more clearly inside the car
and the number of license plate or like that.
6.2.5. Shutter limit setting (for AES/CCD iris mode only)
Move the cursor to SHUTLIM position, press LEFT
or RIGHT key for shutter limit setting
The shutter speed range of AES (CCD IRIS) is
from 1/50(1/60) second to 1/100,000 second, for
some applications need higher quality picture or
minimize the sensor smear, the Manxman shutter
can be limited on1/500 to 100,000 second.
AES MENU
BLC ON
Av:Pk 8:4
AGCMAX 36 dB
RESPONSE 03
AGCMIN 01 dB
SHUTLIM 1/100000
RETURN
AES MENU
BLC ON
Av:Pk 8:4
AGCMAX 30 dB
RESPONSE 03
AGCMIN 00 dB
SHUTLIM 1/100000
RETURN
AES MENU
BLC ON
Av:Pk 8:4
AGCMAX 30 dB
RESPONSE 03
AGCMIN 00 dB
SHUTLIM 1/100000
RETURN

-10 -
SETUP MENU
CAMERA ID OFF
LIGHT CNTL AES
．WHITE BAL ATW
D/N CNTL
PICTURE VIDEO
DISPLAY COLOR POS
OPD WINDOW
MISC
END INIT DEMO ↑UNLOCK
1/500, 1/1000, 1/2000, 1/5000, 1/10000, 1/20000, 1/50000, 1/100000
6.2.6. Shutter speed (for Auto iris + shutter mode)
Move the cursor to SHUTSPEED position on
AUTOIRIS+SHUT mode sub menu, press LEFT
or RIGHT key for shutter speed setting.
Under appropriate shutter speed setting, the blurring of motion objects will
be greatly reduced, when the camera with auto iris lens been installed at
highway , production line or like that.
6.2.7. ME Setting
Press ENTER key at LIGHT CNTRL menu, the
MANUAL EXPOSURE menu will display on
screen, move the cursor by UP/DOWN key to
select adjustment item.
Shutter speed: 1/50(1/60), 1/120(1/100), 1/250,
1/500, 1/1,000, 1/2,000, 1/5,000, 1/10,000 sec.
Gain: 0, 6, 12, 18 dB.
6.3. WHITE BALANCE
Move cursor to WHITE BAL then press ENTER key to enter sub menu
Item sequence:
ATW→AWB→PUSH TO LOCK→MANUAL→PRESET→ATW
1. ATW—Auto tracking white balance
Detecting frame range setting
ATW response speed setting
Faster 1 → 15 Slower
White balance detecting windows setting
press LEFT or RIGHT key for range setting
AUTO IRIS-SHUT MENU
BLC ON
Av:Pk 8:4
AGCMAX 30 dB
RESPONSE 03
AGCMIN 00 dB
SHUTSPEED 1/60
RETURN
ME MENU
SHUTTER 1/50 SEC
GAIN 0 dB
RETURN
ATW MENU
FRAME STD
2500K-9500K
SPEED 13
WNDW SEL FULL
RETURN
ENTER
ATW MENU
FRAME STD
2500K-9500K
SPEED 13
WNDW SEL FULL
RETURN

-11 -
SETUP MENU
CAMERA ID OFF
LIGHT CNTL AES
WHITE BAL ATW
．D/N CNTL
PICTURE VIDEO
DISPLAY COLOR POS
OPD WINDOW
MISC
END INIT DEMO ↑UNLOCK
2. AWB—Conventional white balance
3. PTL—Push to lock white balance
4. Manual—Manual white balance
5. Preset—Fixed color temperature for Indoor,
Outdoor, Fluorescent, User setting.
6.4. DAY/NIGHT CONTROL
Move cursor to D/N CNTL then press ENTER key to enter D/N MENU
Press RIGHT or LEEFT key to select item, then Press the ENTER to enter
Item sub menu
LUX/DELAY →SCHEDULE →EXTERNAL →DAY MODE → NIGHT
MODE
1. LUX/DELAY
Press RIGHT or LEFT key to set the item.
LUX LEVEL – Sets the color and mono-
chrome switching level. You can select
LOW LVL, MID LVL, HI LVL.
DELAY TIME – Sets the detecting time. The
Color/monochrome mode switches if the brightness level change specified
You can select 10 sec, 30 sec or 60 sec
PRESET MENU
WB FIX INDOOR
3200K
RETURN
MENU WHITE BAL MENU
;R GAIN STD
;B GAIN STD
RETURN
PUSH TO LOCK MENU
PTL PUSH
RETURN
ENTER
D/N MENU
D/N TYPE LUX/DELAY
RETURN
LUX/DELAY MENU
LUX LEVEL LOW LVL
DELAY TIME 10 SEC
RETURN

-12 -
2. SCHEDULE (D/N SWITCH TIME)
This function can set the time to change the
Day/Night mode.
CHOICE D/N TYPE: Press ENTER key to
switch D or N mode to conform to your setting
time.
※If N→D time same with other, camera will plus 1 minute by itself.
3. EXTERNAL
This function allow use external device to
control camera switch to Night mode by HI
(+5V) potential or LOW (0V) potential.
※Function 1~3 will action when back to first menu
(SETUP MENU)
4. DAY MODE
Switch to DAY mode.
5. NIGHT MODE
Switch to NIGHT mode.
6.5. PICTURE CONTROL
Menu item: VIDEO→PATTERN→APERTURE→GAMMA
VIDEO MENU
1. Chroma Gain setting
Move the cursor to CHROMA position, while
observing the monitor or vector scope, move the “I” bar
to adjust the color level.
2. HUE gain setting
Move the cursor to HUE position, while observing the monitor or vector scope, move
the “I” bar to adjust the TINT phase.
3. Brightness level setting
Move the cursor to BRIGHT position, while observing the color video monitor or
waveform monitor / oscilloscope , press LEFT/RIGHT key to adjust the brightness
level. Press ENTER key back to default brightness setting value.
VIDEO MENU
CHROMA |•••|•••|
HUE |•••|•••|
;BRIGHT 90
PEDESTAL 7.5 IRE
SPRS EFCT 120
SPRS GAIN 48
RETURN
SCHEDULE MENU
D →N TIME HOUR : 00
MIN : 00
N →D TIME HOUR : 00
MIN : 01
CHOICE D/N TYPE
RETURN
EXTERNAL D→N MENU
INPUT SIGNAL HI
RETURN

-13 -
4. Pedestal level setting
Move the cursor to PESESTAL position, while observing the color video monitor or
waveform monitor / oscilloscope , press LEFT/RIGHT key to adjust the pedestal
level.
5. Chroma suppress effect level setting
This parameter is for control the timing of minimal lighting level when the camera
picture swaps from color into monochrome.
Increase the parameter value toward late swap at lower lighting level, the default
setting is around 2 Lux.
Move the cursor to SPRS EFCT position, adjust the value by LEFT/RIGHT key.
6. Chroma suppress gain
This parameter control the color gain when the picture swap from color into
monochrome under low light, set the value to “0” for completely black and
white picture effect, set the value to maximum for no color suppress effect.
PATTERN MENU
This function is good for quick color monitor
calibration and cable signal condition checking.
Move the cursor to PATTERN position to turn ON
or OFF the pattern generator.
Move the cursor to TYPE to select the pattern
type.
Move the cursor to COLOR for different color display selection.
APERTURE MENU
Move the cursor to AP GAIN L for horizontal low
frequency aperture correction. (00-03)
Move the cursor to AP GAIN H for horizontal low
frequency aperture correction. (00-03)
Move the cursor to V AP GAIN for vertical aperture
correction. (00-15)
GAMMA MENU
1.Move the cursor to Y GAMMA ADJ to turn on or
off the gamma correction.
Turn off the Y gamma ADJ for gamma = 1.
Off1 for gamma=1 with no knee effect.
Off2 for gamma=1 with knee on effect.
PATTERN MENU
PATTERN OFF
TYPE HSR
COLOR BLUE
RETURN
APERTURE MENU
AP GAIN L 02
AP GAIN H 02
V AP GAIN 10
RETURN
GAMMA MENU
Y GAMMA ADJ ON
Y GAMMA 04
Y KNEE 00
C GAMMA ADJ ON
C GAMMA 04
C KNEE 07
RETURN

-14 -
2. Move the cursor to Y GAMMA for different gamma correction, set the value
to 04 equal to gamma .45, the value of 01 around gamma = 0.9, Value 07
equal to 0.1.
3.The default setting for Y KNEE is 00, there are 6 knee curve selectable.
4. C GAMMA ADJ ON/OFF
Off1 with no knee effect.
Off2 with knee on effect.
5. Chroma gamma curve 00-07(default=04)
6. Chroma knee curve 00-07(default=07)
POSITIVE/NEGATIVE
Display sequence:
COLOR POSITIVE→COLOR NEG→MONO POS→MONO NEG
OPTICAL DETECT WINDOWS SETTING
Enter this menu for detecting window size and
position setting.
Press ENTER for detection windows size and
position adjustment, after setting press ENTER
key again back to previous menu.
6.6 MISC
This function is to adjust the camera’s Synchronization and lens applications.
Move the cursor to MISC and press enter.
6.6.1. EXTSYNC
Press LEFT/RIGHT key to select the type of
camera’s synchronization, press ENTER key to
enter external sync phase adjusting menu.
Align sync phase by press LEFT/RIGHT key.
6.6.2. AUTO IRIS
Press LEFT/RIGHT key to select the type of auto-iris lens: DC lens / Video lens.
6.6.3. IRIS WINDOWS
Press LEFT/RIGHT to adjust the level for auto-iris lens (for both DC type and Video
type). Ranging from 0 to 19.
6.6.3. SYSTEM HOUR
Setting hour of current time (0 to 24)
OPD WINDOW MENU
OPD WINDOW POSITION
OPD WINDOWS SIZE
RETURN
MISC MENU
EXT SYNC INT
AUTO IRIS DC LENS
IRIS WINDOWS 13
SYSTEM HOUR : 08
MIN : 00
SYSTEM TIME : DISPLAY
RETURN

-15 -
6.6.4. SYSTEM MIN
Setting minute of current time (0 to 60)
6.4.5. SYSTEM TIME (DISPLAY/HIDE)
Show or Hide current time on screen when the camera working.
7. SPECIFICATIONS
Image device 1/2” or 1/3” interline transfer Super/Exview HAD CCD
Signal system PAL or NTSC standard
Picture elements PAL: 542(H) x 582(V), NTSC: 542(H) x 492(V)
PAL: 795(H) x 596(V), NTSC: 811(H) x 508(V)
Scanning system PAL: 625 lines, NTSC: 525 lines, 2:1 interlace
Sync system Internal/Line lock sync
Horizontal resolution Color: 500TV-Lines, B/W: 540TV-Line
Minimum illumination: Exview HAD: 0.1Lux at F1.2 (Color), 0.01Lux at F1.2 (B/W)
Super HAD: 0.5Lux at F1.2 (Color), 0.05Lux at F1.2(B/W)
Aperture correction H aperture and V aperture-gain adjustable
Gain Super AGC 0- 36dB;Min gain 0-20dB; MGC
S/N ratio Better than 50dB
Auto exposure system 1. CCD iris mode : 1/50(1/60) - 1/100,000 sec.
2. Flickerless mode : NTSC 1/100 sec. PAL 1/120 sec.
3. AES low shutter mode : 1/100(1/125) – 1/100,000 sec
4. Auto iris mode : 1/50(1/60) sec.
5. Auto iris with shutter mode: 1/50(1/60) to 1/10,000 sec.
Auto Exposure Av./Pk level: 1:12 to 12:1
Auto Exposure response speed: 0.5 to 20 sec
Manual exposure system Shutter speed: 1/50(1/60), 1/120,1/250,1/500,1/1000,1/2000,1/5000,1/10000 sec.
Gain: 0, 6, 12, 18 dB
White balance ATW: Max 2000°K- 18000°K, speed, detect window adjustable
AWB: conventional
Push to Lock: gain memory
PRESET: Indoor mode 3200°K, Fluorescent mode 4200°K, Outdoor mode 6300°K
User memory mode:
MWB: R gain, B gain adjustable
Back light compensation 1. Histogram detect: level can be adjusted from 0 to 15 times.
2. Windows weighting: 225 divisions on screen, each window compensation
weighting can be adjusted
3. Histogram and windows weighting can be set on/off individually.
BLC function activated for auto iris lens also
Day& Night 1. Auto detect: D/N switch illumination level, Delay times
2. D/N by Schedule: Day to Night time, Night to Day time
3. D/N by External: Hi, Low
4. Day mode
5. Night mode
Video output signal Composite: 1.0 Vp-p at 75Ωload
Y/C: Y= 1.0 Vp-p at 75Ωload C= 0.286 Vp-p at 75Ω
Gamma correction 0.1 –1.0, Y/ C gamma curve selectable
Knee effect Y / C knee selectable
OSD presentable function 1. Camera ID : up to 20 characters alphanumeric, position, brightness, contrast
2. Light control : Exposure mode, BLC, AGC maximum or minimum, AE
response speed, AE Average/Peak, shutter limit
3. White balance : ATW , AWB, PTL, MWB Preset, ATW speed, detect area

-16 -
4. Sync system selection, phase adjustment
5. Picture Chroma, Hue, Brightness, gamma, aperture correction, color suppress
6. Color -Negative, Positive, Monochrome – Negative, Positive.
7. Color pattern generator
8. OSD menu lock
9. Auto Demo
10. D&N Filters Removable: Auto Detect, Day/Night, D/N by Schedule, D/N by
External
11. System Time Display
Auto iris lens Accepts video or DC drive iris lens
Lens mount C & CS mount
Operating temperature -10°C to 50°C
Power source DC 12V
AC 24V /DC 12V
AC 85 ~ 265 V
Power consumption: 4.8 W (DC type)
6.0 W (AC type)
Dimensions (W x H x D): 71 x 52 x 128 mm
