Oxygen 8 NOVA Series User manual

INSTALLATION
MANUAL
NOVA SERIES

Table of Contents
1. General Information 3
2. Installation 4
2.1 Unwrapping the Product 4
2.2 Assembly 4
2.3 Weights 5
2.4 Horizontal Installation 6
2.4.1 Front Doors 6
2.4.2 Side Doors 8
2.5 Vertical Installation 8
2.6 Installation of Accessories 10
2.6.1 Horizontal Coupled Accessories 10
2.6.2 Vertical Coupled Accessories 11
2.6.3 Decoupled Accessories 12
2.7 External Sensors 13
2.7.1 Supply Air Temperature Sensor 13
2.7.2 Pressure Sensor 13
2.7.3 CO2/VOC Sensor 14
2.7.4 Combination Temperature 15
/Humidity Sensor
3. Access Requirements 16
4. Lifting Requirements 16
5. Electrical Hook-Ups 17
5.1 Electrical Information 17
5.2 1PH Electrical Hook Up (2 Fans) 18
5.3 3PH Electrical Hook Up (2 Fans) 19
5.4 3PH Electrical Hook Up (4 Fans) 20
5.5 3PH Electrical Hook Up (6 Fans) 21
5.6 1PH Lite Electrical Hook Up (2 Fans) 22
5.7 3PH Lite Electrical Hook Up (2 Fans) 23
5.8 3PH Lite Electrical Hook Up (4 Fans) 24
5.9 3PH Lite Electrical Hook Up (6 Fans) 25
5.10 Fan Connection - 1PH 26
5.11 Fan Connection - 3PH 27
6.0 Wiring Diagrams 28
6.1 Nova 240V, Single Phase, S1 29
6.2 Nova 240V, Single Phase S2 30
6.3 Nova, Three Phase, S1 31
6.4 Nova, Three Phase, S2 32
6.5 Field Wiring, DX Coil, EKE 33
6.6 Field Wiring, DX Coil, Electric Reheat, EKE 34
6.7 Field Wiring, Electric Preheat, DX Coil 35
Electric Reheat, EKE
6.8 Field Wiring, Electric Preheat, DX Coil, EKE 36
6.9 Field Wiring, Damper Wiring 37
6.10 Field Wiring, Electric Reheat Wiring 38
6.11 Field Wiring, Electric Preheat, 39
Electric Reheat Wiring
6.12 Field Wiring, Electric Preheat Wiring 40
6.13 Field Wiring, Cooling Water Coil 41
6.14 Field Wiring, Humidity Control 42

Installation Manual Nova Series
3
This manual includes important instructions for safe
connection of the Heat Recovery Ventilator (HRV) or
Energy Recovery Ventilator (ERV). Before connecting
the unit, please read carefully and follow all of the
instructions below! The manufacturer reserves the
right to make changes, including changes in the
technical documentation, without previous notification.
Please keep this manual for future reference.
Consider this manual a permanent part of the product.
This manual will show the manufacturers'
recommended installation method. Please note that
local codes and regulations may override these
recommendations. The installation must follow local
codes and standards.
The National Electric Code (NEC), the National
Fire Protection Agency (NFPA), and the Canadian
Electrical Code (CEC) must be followed. Installation
of this product must be performed by a qualified and
accredited professional in conformance with local and
national codes, standards and licensing requirements.
Warnings and Caution
Warnings and cautions appear at the appropriate
sections throughout this manual. Please read these
sections carefully.
Warning
This sign indicates a potentially hazardous situation,
which could result in death or serious injury if not
avoided.
Caution
This sign indicates a potentially hazardous situation,
which may result in minor or moderate injury if not
avoided. It may also alert against unsafe practices.
Caution
This label indicates a situation that may result in
equipment or property damage only accidents.
1.0 General Information

Installation Manual Nova Series
4
2.1 Unwrapping the Product
When removing the shrink wrap, be cautious with
knives and sharp tools to prevent scratching the
paint.
The HMI, pressure sensor, external duct pressure
sensor and all other optional field components will be
found in the electrical box or fan compartment. They
are secured there for transport and to easily find
them on the job site.
2.2 Assembly
On the C-Series cabinets, it is possible to remove
the fan section from the core section for ease of
installation and maneuverability in tight locations.
Use the following steps to disassemble the fan
section from the core section.
1. Remove the cover from the fan.
2. Undo the screw terminals that are holding the
power wires and the communication wires.
*See back of manual for electrical drawings.
3. Loosen the cable glands and pull the wires out of
the motor.
4. Pull the pressure tube from the nozzle port on
the fan bell mouth.
5. Push the pressure tube and all cables back into
the core section, through the rubber grommets
that are on the fan wall.
6. Repeat steps 1 ― 5 for the other fan.
7. Remove bolts for each corner and top shelf.
8. Pull apart the two sections.
9. Reverse actions for assembly (contractor is
responsible for correct assembly).
2.0 Installation
1 2 4 3
7 7 8
5
Unit Wrapped
for Shipping
4x Corner
2x Shelf

Installation Manual Nova Series
5
2.3 Weights
Model Fan
Section
(A) lbs.
Core
Section
(B) lbs.
Fan
(C)
lbs.
Core
(D)
lbs.
Indoor
Total
Weight
(H/V) lbs.
Outdoor
Total
Weight*
lbs.
A16 Shipped as 1 Piece 27 x 2 28 320/330
A18 Shipped as 1 Piece 27 x 2 28 380/390 490
B20 Shipped as 1 Piece 29 x 2 45 425/435
B22 Shipped as 1 Piece 29 x 2 45 470/480 610
C20 215 360 38 x 2 72 550/575
C20 - Bypass 260 470 38 x 2 72 695
C22 Shipped as 1 Piece 38 x 2 72 600/615 770
C22 - Bypass Shipped as 1 Piece 38 x 2 72 770 960
C24 255 390 51 x 2 88 630/645
C26 Shipped as 1 Piece 51 x 2 88 675/690 860
C26 - Bypass Shipped as 1 Piece 51 x 2 88 880 1100
C30 325 450 75 x 2 55 x 2 755/775
C32 Shipped as 1 Piece 75 x 2 55 x 2 810 1000
C32 - Bypass Shipped as 1 Piece 75 x 2 55 x 2 1030 1275
C40 Shipped as 1 Piece 38 x 4 72 x 2 905 1120
C40 - Bypass Shipped as 1 Piece 38 x 4 72 x 2 1225 1490
C48 Shipped as 1 Piece 51 x 4 88 x 2 1055 1300
C48 - Bypass Shipped as 1 Piece 51 x 4 88 x 2 1395 1690
C58 Shipped as 1 Piece 38 x 6 72 x 3 1265 1530
C70 Shipped as 1 Piece 51 x 6 88 x 3 1495 1790
A
B
C
D
*Outdoor total weights include dampers in casing, hoods, roof and base rail.
Outdoor Unit with
Hoods, Base Rail
and Dampers

Installation Manual Nova Series
6
2.4 Horizontal Installation
2.4.1 Front Doors
The hanging brackets are supplied loose with the
necessary hardware to install them. They are not
shipped assembled due to the variability of installation
access on job sites.
Each hanging bracket is composed of two pieces: an
inner component and an outer component. The units
are designed to have four sets of brackets to support
the unit.
Note Depending on the ducted opening location
selected during the design phase, the location of
the brackets will vary. Please consult your submittal
drawings for specific locations.
Outer
Bracket
Inner
Bracket
Unit with 1A Opening Unit with 1A and 3A Openings
Warning
The unit must be installed with both the inner and outer bracket. Each unit must also have all four brackets installed
to meet these guidelines.

Installation Manual Nova Series
7
Assembly of Hanging Brackets
1. Locate the position of the brackets on the outside
of the unit.
2. Mark the 8 hole locations and drill to allow for
the ¼" bolt. 32 - ¼" bolts, 32 - ¼" lock nut, 32 - ¼"
washers and 64 - ¼" washers have been provided
with the unit.
3. Assemble the hanging bracket by aligning the 8
holes of the outer bracket through the unit and
with the inner bracket. Note: the inner component
should be oriented so that its flange is pointing to
the ceiling, and the outer bracket has the single
hole pointing to the ceiling.
4. Install the 8 bolts. Caution - Do not over tighten
and crush the panel.
5. Install 4 tek-screws in the flange portion of the
inner bracket and secure it to the top casing of the
unit.
6. Install 4 tek-screws in the lower flange of the outer
bracket to secure it to the bottom frame of the unit.
7. Repeat steps 1 through 6 for the remainder of the
brackets.
8. The hole in the outer brackets are designed for a
½" threaded rod to hang the units by.
Bracket Alignment

Installation Manual Nova Series
8

Installation Manual Nova Series
9
2.4.2 Side Doors
When a Nova unit is ordered with side doors, there is no access to install hanging brackets and the unit must
be supported from below as seen in the image. The sizing of the supports is to be designed by the installing
contractor.
2.5 Vertical Installation
A floor mounted Nova unit will ship with an installed base rail. These units can be installed directly on the floor or a
housekeeping pad.
Unit with Side Doors and Unistrut
Vertical Unit with Base Rails
on Housekeeping Pad

Installation Manual Nova Series
10
2.6 Installation of Accessories
2.6.1 Horizontal Coupled Accessories

Installation Manual Nova Series
11
2.6.2 Vertical Coupled Accessories
Base mounted accessories that are connect to a duct connection in the lower position of the unit will come with
matching base rails.
Accessories that are to be connected to a duct connection in the upper position will need to be supported
externally. This can also be done with Unistrut or similar.
1 2

Installation Manual Nova Series
12
2.6.3 Decoupled Accessories
Ceiling hung decoupled accessories will not come with hanging brackets and can be supported in the ceiling with
Unistrut and threaded rod or equivalent.
Accessory modules can come with base rails for floor mounting.

Installation Manual Nova Series
13
2.7 External Sensors
2.7.1 Supply Air Temperature Sensor
TTH-6202 sensors are installed in the ventilation
duct using the accompanying bracket, which must
be attached to a firm, level surface by means of
two screws. The supply voltage is provided via the
Modbus connection. TTH-6202 has a pre-fitted cable,
which is equipped with a standard RJ12 connector.
The cable may be extended up to 50 m using a
Category 3 extension cable. The sensor must be
mounted according to, and must be aligned parallel to
the air flow in the center of the duct.
5'*
*Sensor must be installed a minimum of 5' from the heating or cooling module.
2.7.2 Pressure Sensor
Sensor must be installed ⅔ of the way
down the duct in the duct path that
would result in the most pressure drop.
Sensor must be installed ⅔ of the way
down the duct in the duct path that
would result in the most pressure drop.
Supply Air Return Air
Exhaust Air Outside Air
Supply Air
Return Air

Installation Manual Nova Series
14
2.7.3 CO/VOC Sensor
VTH-6202 sensors are installed in the ventilation
duct using the accompanying bracket, which must
be attached to a firm, level surface by means of
two screws. The 18-30 V DC supply voltage (24 V
DC nominal voltage) is provided via the Modbus
connection. VTH-6202 has a pre-fitted 7000 mm cable,
which is equipped with a standard RJ12 connector. The
cable may be extended to as much as 50 m without
any negative eects on measuring accuracy. The
surrounding EMC environment must, however, be taken
into account and must be capable of being defined as
low. To extend the cable, use a crossover Category 3
extension cable, RJ12-RJ12, 6P6C. The sensor should
be installed in such a way that the air flow in the duct
can pass unhindered through the measuring hole
at the end of the sensor, which should be aligned
parallel to the air flow. Although the VTH-6202 is not
aected by the position in which it is installed, it should
not be installed in an upright position with the cable
downwards as this may cause moisture to accumulate
in the sensor.
The enclosure is opened without the use of tools
by pressing the snap lock at the side of the tube
connectors. PTH-6202 is attached onto a level
surface by 2 screws, which are screwed into a solid
surface. PTH-6202 can be fitted in all directions
without accuracy being aected. PTH-6202 also
functions with only one tube fitted to the connectors
(+ or -). However, two tubes should always be fitted to
ensure a suitable enclosure rating, if the connectors
do not face downwards. Pressure is supplied to the
measurement unit by tubes, the highest pressure
being connected to the ‘+ connector’ and the lowest
pressure to ‘- connector’. The pressure tubes must be
as short as possible and must be secured in position to
prevent vibration. To obtain the best possible results,
pressure must be measured where there is least risk
of turbulence, i.e. in the center of the ventilation duct
and at a distance of at least twice the width of the duct
from bends and six times the width from branches. If
there is a risk of condensation forming in connection
tubes, PTH-6202 is to be located in such a way that
condensate fluids cannot flow back into the pressure
transmitter.
Supply Air
Return Air
In duct view

Installation Manual Nova Series
15
2.7.4 Combination Temperature/
Humidity Sensor
HTH-6202 sensors are installed in the ventilation
duct using the accompanying bracket, which must
be attached to a firm, level surface by means of
two screws. The 18-30 V DC supply voltage (24 V
DC nominal voltage) is provided via the Modbus
connection. HTH-6202 has a pre-fitted 7000 mm
cable, which is equipped with a standard RJ12
connector. The cable may be extended to as much
as 50 m without any negative eects on measuring
accuracy. The surrounding EMC environment must,
however, be taken into account and must be capable
of being defined as low. To extend the cable, use a
crossover Category 3 extension cable, RJ12-RJ12,
6P6C. The sensor should be installed in such a way
that the air flow in the duct can pass unhindered
through the measuring hole at the end of the sensor,
which should be aligned parallel to the air flow.
Although HTH-6202 is not aected by the position
in which it is installed, it is advisable not to install
the sensor in an upright position with the cable
downwards as this may cause moisture to accumulate
in the sensor. It is important that HTH-6202 is installed
in such a way that the measuring hole is positioned at
the center of the duct.
5'*
*Sensor must be installed a minimum of 5' from the heating or cooling module.
In duct view
Supply Air Return Air
Exhaust Air Outside Air

Installation Manual Nova Series
16
3.0 Access Requirements
Top of Unit
The National Electrical Code (NEC) stipulates that there must be a minimum of 36 inches of clearance from an
electrical connection. The installing contractor must ensure there is at least 36 inches of clearance perpendicular to
the top of the electrical box.
Front of Unit
In order to open the doors of the unit, the installing contractor must leave 48 inches perpendicular to the doors.
If there is no intention to open the doors fully, they can be removed for servicing, by removing the hinge pins and
lifting o the doors.
4.0 Lifting Requirements
Horizontally Installed Units
Once the mounting angles have been installed, the unit can be lifted by the
angles.
Vertically Installed Units
A vertically installed unit that is delivered with base rails, can be lifted from
the base rail with the use of a spreader bar to prevent damage to the unit.
Door with removed hinge pinUnit with doors open
Unit with Spreader Bars

Installation Manual Nova Series
5.0 Electrical Hook Ups
Warning
Hazardous voltage, disconnect all electrical power, including remote disconnects and discharge all motor start/run
capacitors before servicing. Follow proper lockout/tagout procedures to ensure the power cannot be accidentally
re-engaged.
5.1 Electrical Information
Model Airflow Nom. V. Motor
kW
SA
Fan
Qty.
SA
Fan
FLA
SA Fan
FLA
Total
RA
Fan
Qty.
SA
Fan
FLA
SA Fan
FLA
Total
Tnsfmr
FLA
Fuse
Size
FLA MCA MROP
D
Rcmd
Fuse
A16/A18 775 240 0.5 1 2.50 2.50 1 2.50 2.50 0.29 3/10 5.29 5.91 8.41 15A
B20/B22 1300 240 0.78 1 3.90 3.90 1 3.90 3.90 0.29 3/10 8.09 9.06 12.96 15A
B20/B22 1300 208 2.00 1 6.00 6.00 1 6.00 6.00 0.33 4/10 12.33 13.83 19.83 15A
B20/B22 1300 460 2.50 1 4.00 4.00 1 4.00 4.00 0.14 3/16 8.14 9.14 13.14 15A
C20/C22 2200 208 2.00 1 6.00 6.00 1 6.00 6.00 0.33 4/10 12.33 13.83 19.83 15A
C20/C22 2200 460 2.50 1 4.00 4.00 1 4.00 4.00 0.14 3/16 8.14 9.14 13.14 15A
C24/C26 2700 208 2.7 1 8.60 8.60 1 8.60 8.60 0.33 4/10 17.53 19.68 28.28 25A
C24/C26 2700 460 3.7 1 5.80 5.80 1 5.80 5.80 0.14 3/16 11.74 13.19 18.99 15A
C30/C32 3500 208 3 1 9.00 9.00 19.00 9.00 0.33 4/10 18.33 20.58 29.58 25A
C30/C32 3500 460 3.3 1 5.40 5.40 1 5.40 5.40 0.14 3/16 10.94 12.29 17.69 15A
C40 4400 208 2.00 2 6.00 12.00 2 6.00 12.00 0.33 4/10 24.33 27.33 39.33 35A
C40 4400 460 2.50 2 4.00 8.00 2 4.00 8.00 0.14 3/16 16.14 18.14 26.14 25A
C48 5400 208 2.7 2 8.60 17.20 2 8.60 17.20 0.33 4/10 34.73 39.03 56.23 50A
C48 5400 460 3.7 2 5.80 11.60 2 5.80 11.60 0.14 3/16 23.34 26.24 37.84 35A
C58 6600 208 2.00 3 6.00 18.00 3 6.00 18.00 0.33 4/10 36.33 40.83 58.83 50A
C58 6600 460 2.50 3 4.00 12.00 3 4.00 12.00 0.14 3/16 24.14 27.14 39.14 35A
C70 8100 208 2.7 3 8.60 25.80 3 8.60 25.80 0.33 4/10 51.93 58.38 84.18 80A
C70 8100 460 3.7 3 5.80 17.40 3 5.80 17.40 0.14 3/16 34.94 39.29 56.69 50A

Installation Manual Nova Series
18
5.2 Single-Phase Electrical Hook Up (2 Fans)
Attention: Single phase electrical consists of single 240V hot, neutral and ground. Dual 120V feeds will not work.
1 phase, 3 wire, 240V -10% ― +15%, 60Hz
Pieces:
2021-02-11
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
PM
FAN
MOTOR
FAN
MOTOR
DATA CABLEDATA CABLE
0-10V
0-10V
L1 L2 L3GND
tt
tt
t
ENCLOSURE
4/10A for 208V
3/16A for 460V
208V or 460V
24V
1/L1
3/L2
5/L3
2/T1
4/T2
6/T3
I> I> I>
1/L1
3/L2
5/L3
2/T1
4/T2
6/T3
I> I> I>
O28-05-0003-23
NOVA WIRING LAYOUT 3-PHASE
Pieces:
2021-02-11
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
PM
L1 240V
O28-05-0003-24
NOVA WIRING LAYOUT SINGLE PHASE
FAN
MOTOR
FAN
MOTOR
DATA CABLEDATA CABLE
0-10V
0-10V
GND
tt
tt
t
ENCLOSURE
3/10A
24V
N
FAN I/0 R/A
BOTTOM
FAN I/0 S/A
TOP
6
5
3
4
1
7
8
POSITION PCs
TYPE
1
2
3
4
61
5
COLOUR PART No.
1
1
1
3
4
22/6 COMMUNICATION MODBUS
7
81
1
22/6 COMMUNICATION MODBUS
18/4 (3 PHASE/GRD) POWER
18/4 (3 PHASE/GRD) POWER
18/2 (0-10V, GRD) COMMNS.
18/2 (0-10V, GRD) COMMNS.
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-01A
PM ELE. BOX WIRING LAYOUT - 208V
3-PHASE
1
FAN R/A
(BOTTOM)
FAN S/A
(TOP)
BLACK
BLACK
GRAY
GRAY
BLACK
BLACK
BLACK
BLACK
L
CL C
24V
TRANSFORMER
T1
T2
T3 SWITCH BODY
T1 T2
MMP1 MMP2
GREEN GREEN
WHITE
BLACK
RED
WHITE
BLACK
RED
FOR T1, T2 CONNECTION
SEE 208V TRANSFORMER
WIRING DIAGRAM
T1 BLACK T2 BLACK
C
T1 T2 T3
2
2
2
1
1
SINGLE WIRE 10Ga, L=9"
SINGLE WIRE 10Ga, L=14"
9
9
92
FAN JUMPER 18Ga
BLACK
WIP0010
WIP0010
WIP0017
WIP0018
WIP0022
WIP0021
WIP0019
WIP0020
WIP0023
FOR WIRES CONNECTION
SEE 208V TRANSFORMER
WIRING DIAGRAM
Pre-heat
temperature sensor
is placed in top or
bottom core bracket.
17-WHITE
16-BLACK2-BLUE
1-RED
3-PHASE 208V POWER SOURCE
24V
TRANSFORMER
T1
18/3 (HOT, NEUTRAL, GROUND)
WHITE 1 WHITE 2
GREEN 1
GREEN 2
BLACK 1 BLACK 2
M9F
1
M9F
2
FOR T1
CONNECTION
SEE 240V
TRANSFORMER
WIRING
DIAGRAM
POWER BOX
POSITION PCsTYPE
1
3
41
COLOUR A16
1
1
2
1
1
22/6 COMMUNICATION MODBUS
5
6
7
8
91
1
1
1
22/6 COMMUNICATION MODBUS
18/2 0-10V, GRD COMMUNICATION
18/2 0-10V, GRD COMMUNICATION
2
4
5
18
9
18/3 (HOT, NEUTRAL, GROUND)
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-02A
PM ELE. BOX WIRING LAYOUT - 240V SINGLE
PHASE
6
7
T1
C
SWITCH BODY
SINGLE WIRE 10Ga L=9"
2BLACK SINGLE WIRE 10Ga L=11"
BLACK
BLACK
BLACK
BLACK
BLACK
33
BLACK SINGLE WIRE 10Ga L=8"
GREY
GREY
10 2
SINGLE WIRE 18Ga, 1.5-Inch
BLACK WIP0023
10
10
FOR WIRES
CONNECTION
AND JUMPER
SETTING, SEE
240V
TRANSFORMER
WIRING
DIAGRAM
DRAWING No.
B20
WIP0004
WIP0003
WIP0015
WIP0001
WIP0002
WIP0010
WIP0010
WIP0010
WIP0014
WIP0003
WIP0015
WIP0012
WIP0011
WIP0010
WIP0010
WIP0010
FAN I/0 R/A
BOTTOM
FAN I/0 S/A
TOP
FAN R/A
(BOTTOM)
FAN S/A
(TOP)
17-WHITE
16-BLACK Pre-heat
temperature sensor
is placed in top or
bottom core bracket.
2-BLUE
1-RED
WIP00021WIP00021

Installation Manual Nova Series
19
5.3 Three-Phase Electrical Hook Up (2 Fans)
3 phase, 4 wire, 208V, 460V -10% ― +15%, 60Hz
Pieces:
2021-02-11
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
PM
FAN
MOTOR
FAN
MOTOR
DATA CABLEDATA CABLE
0-10V
0-10V
L1 L2 L3GND
tt
tt
t
ENCLOSURE
4/10A for 208V
3/16A for 460V
208V or 460V
24V
1/L1
3/L2
5/L3
2/T1
4/T2
6/T3
I> I> I>
1/L1
3/L2
5/L3
2/T1
4/T2
6/T3
I> I> I>
O28-05-0003-23
NOVA WIRING LAYOUT 3-PHASE
Pieces:
2021-02-11
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
PM
L1 240V
O28-05-0003-24
NOVA WIRING LAYOUT SINGLE PHASE
FAN
MOTOR
FAN
MOTOR
DATA CABLEDATA CABLE
0-10V
0-10V
GND
tt
tt
t
ENCLOSURE
3/10A
24V
N
FAN I/0 R/A
BOTTOM
FAN I/0 S/A
TOP
6
5
3
4
1
7
8
POSITION PCs
TYPE
1
2
3
4
61
5
COLOUR PART No.
1
1
1
3
4
22/6 COMMUNICATION MODBUS
7
81
1
22/6 COMMUNICATION MODBUS
18/4 (3 PHASE/GRD) POWER
18/4 (3 PHASE/GRD) POWER
18/2 (0-10V, GRD) COMMNS.
18/2 (0-10V, GRD) COMMNS.
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-01A
PM ELE. BOX WIRING LAYOUT - 208V
3-PHASE
1
FAN R/A
(BOTTOM)
FAN S/A
(TOP)
BLACK
BLACK
GRAY
GRAY
BLACK
BLACK
BLACK
BLACK
L
CL C
24V
TRANSFORMER
T1
T2
T3 SWITCH BODY
T1 T2
MMP1 MMP2
GREEN GREEN
WHITE
BLACK
RED
WHITE
BLACK
RED
FOR T1, T2 CONNECTION
SEE 208V TRANSFORMER
WIRING DIAGRAM
T1 BLACK T2 BLACK
C
T1 T2 T3
2
2
2
1
1
SINGLE WIRE 10Ga, L=9"
SINGLE WIRE 10Ga, L=14"
9
9
92
FAN JUMPER 18Ga
BLACK
WIP0010
WIP0010
WIP0017
WIP0018
WIP0022
WIP0021
WIP0019
WIP0020
WIP0023
FOR WIRES CONNECTION
SEE 208V TRANSFORMER
WIRING DIAGRAM
Pre-heat
temperature sensor
is placed in top or
bottom core bracket.
17-WHITE
16-BLACK2-BLUE
1-RED
3-PHASE 208V POWER SOURCE
24V
TRANSFORMER
T1
18/3 (HOT, NEUTRAL, GROUND)
WHITE 1 WHITE 2
GREEN 1 GREEN 2
BLACK 1 BLACK 2
M9F
1
M9F
2
FOR T1
CONNECTION
SEE 240V
TRANSFORMER
WIRING
DIAGRAM
POWER BOX
POSITION PCsTYPE
1
3
41
COLOUR A16
1
1
2
1
1
22/6 COMMUNICATION MODBUS
5
6
7
8
91
1
1
1
22/6 COMMUNICATION MODBUS
18/2 0-10V, GRD COMMUNICATION
18/2 0-10V, GRD COMMUNICATION
2
4
5
18
9
18/3 (HOT, NEUTRAL, GROUND)
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-02A
PM ELE. BOX WIRING LAYOUT - 240V SINGLE
PHASE
6
7
T1
C
SWITCH BODY
SINGLE WIRE 10Ga L=9"
2BLACK SINGLE WIRE 10Ga L=11"
BLACK
BLACK
BLACK
BLACK
BLACK
33
BLACK SINGLE WIRE 10Ga L=8"
GREY
GREY
10 2
SINGLE WIRE 18Ga, 1.5-Inch
BLACK WIP0023
10
10
FOR WIRES
CONNECTION
AND JUMPER
SETTING, SEE
240V
TRANSFORMER
WIRING
DIAGRAM
DRAWING No.
B20
WIP0004
WIP0003
WIP0015
WIP0001
WIP0002
WIP0010
WIP0010
WIP0010
WIP0014
WIP0003
WIP0015
WIP0012
WIP0011
WIP0010
WIP0010
WIP0010
FAN I/0 R/A
BOTTOM
FAN I/0 S/A
TOP
FAN R/A
(BOTTOM)
FAN S/A
(TOP)
17-WHITE
16-BLACK Pre-heat
temperature sensor
is placed in top or
bottom core bracket.
2-BLUE
1-RED
WIP00021WIP00021

Installation Manual Nova Series
20
5.4 Three-Phase Electrical Hook Up (4 Fans)
3 phase, 4 wire, 208V, 460V -10% ― +15%, 60Hz
Pieces:
2021-02-11
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
PM
FAN
MOTOR
DATA CABLE DATA CABLE
0-10V
0-10V
L1 L2 L3GND
tt
tt
t
ENCLOSURE
4/10A for 208V
3/16A for 460V
208V or 460V
24V
1/L1
3/L2 5/L3
2/T1
4/T2
6/T3
I> I> I>
1/L1
3/L2 5/L3
2/T1
4/T2
6/T3
I> I> I>
O28-05-0004-03
NOVA ELECTRICAL LAYOUT 4-FANS;
3-PHASE
1/L1
3/L2 5/L3
2/T1
4/T2
6/T3
I> I> I>
1/L1
3/L2 5/L3
2/T1
4/T2
6/T3
I> I> I>
FAN
MOTOR
FAN
MOTOR
FAN
MOTOR
0-10V
0-10V
REVERSE FEED
