Oxygen 8 VENTUM Series User manual

INSTALLATION
MANUAL
VENTUM SERIES

Table of Contents
1. General Information 3
2. Installation 4
2.1 Unwrapping the Product 4
2.2 Assembly 4
2.3 Weights 5
2.4 Installation 5
2.4.1 Ceiling Mount 5
2.5 Installation of Accessories 7
2.5.1 Coupled Accessories 7
2.5.2 Decoupled Accessories 9
2.6 External Sensors 10
2.6.1 Supply Air Temperature Sensor 10
2.6.2 Pressure Sensor 10
2.6.3 CO2/VOC Sensor 11
2.6.4 Combination Temperature 12
/Humidity Sensor
3. Access Requirements 13
4. Lifting Requirements 13
5. Electrical Hook-Ups 14
5.1 Electrical Information 15
5.2 1PH Electrical Hook Up (2 Fans) 16
5.3 3PH Electrical Hook Up (2 Fans) 17
5.6 1PH Lite Electrical Hook Up (2 Fans) 18
5.7 3PH Lite Electrical Hook Up (2 Fans) 19
6.0 Wiring Diagrams 20
6.1 Ventum 240V, Single Phase, S1 21
6.2 Ventum 240V, Single Phase S2 22
6.3 Ventum, Three Phase, S1 23
6.4 Ventum, Three Phase, S2 24
6.5 Field Wiring, DX Coil, EKE 25
6.6 Field Wiring, DX Coil, Electric Reheat, EKE 26
6.7 Field Wiring, Electric Preheat, DX Coil 27
Electric Reheat, EKE
6.8 Field Wiring, Electric Preheat, DX Coil, EKE 28
6.9 Field Wiring, Damper Wiring 29
6.10 Field Wiring, Electric Reheat Wiring 30
6.11 Field Wiring, Electric Preheat, 31
Electric Reheat Wiring
6.12 Field Wiring, Electric Preheat Wiring 32
6.13 Field Wiring, Cooling Water Coil 33
6.14 Field Wiring, Humidity Control 34
6.15 Field Wiring, Combi Coil 35
6.16 Field Wiring, Hydronic Preheat 36
6.17 Field Wiring, Occupancy Mode 37
6.18 Field Wiring, Hydronic Reheat 38
6.19 Field Wiring, Fire Alarm 39
6.20 Field Wiring, DX Coil, Hydronic Reheat 40
EKE, Bypass
6.21 Field Wiring, CO2 Control, 41
External Bypass

Installation Manual Ventum Series
3
This manual includes important instructions for safe
connection of the Heat Recovery Ventilator (HRV) or
Energy Recovery Ventilator (ERV). Before connecting
the unit, please read carefully and follow all of the
instructions below! The manufacturer reserves the
right to make changes, including changes in the
technical documentation, without previous notification.
Please keep this manual for future reference.
Consider this manual a permanent part of the product.
This manual will show the manufacturers'
recommended installation method. Please note that
local codes and regulations may override these
recommendations. The installation must follow local
codes and standards.
The National Electric Code (NEC), the National
Fire Protection Agency (NFPA), and the Canadian
Electrical Code (CEC) must be followed. Installation
of this product must be performed by a qualified and
accredited professional in conformance with local and
national codes, standards and licensing requirements.
Warnings and Caution
Warnings and cautions appear at the appropriate
sections throughout this manual. Please read these
sections carefully.
Warning
This sign indicates a potentially hazardous situation,
which could result in death or serious injury if not
avoided.
Caution
This sign indicates a potentially hazardous situation,
which may result in minor or moderate injury if not
avoided. It may also alert against unsafe practices.
Caution
This label indicates a situation that may result in
equipment or property damage only accidents.
1.0 General Information

Installation Manual Ventum Series
4
2.1 Unwrapping the Product
When removing the shrink wrap, be cautious with
knives and sharp tools to prevent scratching the
paint.
The HMI, pressure sensor, external duct pressure
sensor and all other optional field components will be
found in the electrical box or fan compartment. They
are secured there for transport and to easily find
them on the job site.
2.2 Assembly
Remove the middle panel for wiring access. Fans
and filters are accessible via the bottom doors. Fans
should be pre-wired and no assembly is required.
Use the following steps to disassemble the fan
section from the core section.
1. Remove the cover from the fan.
2. Undo the screw terminals that are holding the
power wires and the communication wires.
*See back of manual for electrical drawings.
3. Loosen the cable glands and pull the wires out of
the motor.
4. Pull the pressure tube from the nozzle port on
the fan bell mouth.
5. Push the pressure tube and all cables back into
the core section, through the rubber grommets
that are on the fan wall.
6. Repeat steps 1 ― 5 for the other fan.
2.0 Installation
1 2 4 3 5
Unit Wrapped
for Shipping
4x Corner

Installation Manual Ventum Series
5
2.3 Weights
Model Fan (A) lbs. Core (B) lbs. Total Weight lbs.
H05 27 13 450
H10 28.7 13 620
H15 37.5 22 720
H20 37.5 22 820
H25 48.5 64 1130
H30 48.5 64 1300
A
B
2.4 Installation
2.4.1 Ceiling Mount
Ventum is available exclusively for ceiling mount/
horizontal applications with inner and outer brackets
only. The hanging brackets are supplied loose with
the necessary hardware to install them. They are not
shipped assembled due to the variability of installation
access on job sites. The front panel of the unit must be
removed to slide the core into the unit.
Each hanging bracket is composed of two pieces: an
inner component and an outer component. The units
are designed to have four sets of brackets to support
the unit.
Note Depending on the ducted opening location
selected during the design phase, the location of
the brackets will vary. Please consult your submittal
drawings for specific locations.
Inner
Bracket
Outer
Bracket
Warning
The unit must be installed with both the inner and outer
bracket. Each unit must also have all four brackets
installed to meet these guidelines. Ceiling Mounted Unit

Installation Manual Ventum Series
6
Assembly of Hanging Brackets
1. Locate the position of the brackets on the outside
of the unit.
2. Mark the 8 hole locations and drill to allow for
the ¼" bolt. 32 - ¼" bolts, 32 - ¼" lock nut, 32 - ¼"
washers and 64 - ¼" washers have been provided
with the unit.
3. Assemble the hanging bracket by aligning the 8
holes of the outer bracket through the unit and
with the inner bracket. Note: the inner component
should be oriented so that its flange is pointing to
the ceiling, and the outer bracket has the single
hole pointing to the ceiling.
4. Install the 8 bolts. Caution - Do not over tighten
and crush the panel.
5. Install 4 tek-screws in the flange portion of the
inner bracket and secure it to the top casing of the
unit.
6. Install 4 tek-screws in the lower flange of the outer
bracket to secure it to the bottom frame of the unit.
7. Repeat steps 1 through 6 for the remainder of the
brackets.
8. The hole in the outer brackets are designed for a
½" threaded rod to hang the units by.
Bracket Alignment

Installation Manual Ventum Series
7
2.5 Installation of Accessories
2.5.1 Coupled Accessories
Coupled Accessory with Ceiling
Mounted Unit
Mounted Coupled Accessory

Installation Manual Ventum Series
8
Corner brackets come pre-installed with each Ventum unit. Accessories should be independently supported with
Unistrut on the end farthest from the unit. Base mounted accessories that are connect to a duct connection in the
lower position of the unit will come with matching base rails.
Accessories that are to be connected to a duct connection in the upper position will need to be supported
externally.
12

Installation Manual Ventum Series
9
2.5.2 Decoupled Accessories
Ceiling hung decoupled accessories will not come with hanging brackets and can be supported in the ceiling with
horizontal brackets and threaded rod or equivalent.

Installation Manual Ventum Series
10
2.6 External Sensors
2.6.1 Supply Air Temperature Sensor
TTH-6202 sensors are installed in the ventilation
duct using the accompanying bracket, which must
be attached to a firm, level surface by means of
two screws. The supply voltage is provided via the
Modbus connection. TTH-6202 has a pre-fitted cable,
which is equipped with a standard RJ12 connector.
The cable may be extended up to 50 m using a
Category 3 extension cable. The sensor must be
mounted according to, and must be aligned parallel to
the air flow in the center of the duct.
*Sensor must be installed a minimum of 5' from the heating or cooling module.
2.6.2 Pressure Sensor
Sensor must be installed ⅔ of the way down the duct in the
duct path that would result in the most pressure drop.
Supply Air
Return Air
5'*
Supply Air

Installation Manual Ventum Series
11
2.6.3 CO/VOC Sensor
VTH-6202 sensors are installed in the ventilation
duct using the accompanying bracket, which must
be attached to a firm, level surface by means of
two screws. The 18-30 V DC supply voltage (24 V
DC nominal voltage) is provided via the Modbus
connection. VTH-6202 has a pre-fitted 7000 mm cable,
which is equipped with a standard RJ12 connector. The
cable may be extended to as much as 50 m without
any negative eects on measuring accuracy. The
surrounding EMC environment must, however, be taken
into account and must be capable of being defined as
low. To extend the cable, use a crossover Category 3
extension cable, RJ12-RJ12, 6P6C. The sensor should be
installed in such a way that the air flow in the duct can
pass unhindered through the measuring hole at the end
of the sensor, which should be aligned parallel to the
air flow. Although the VTH-6202 is not aected by the
position in which it is installed, it should not be installed
in an upright position with the cable downwards as this
may cause moisture to accumulate in the sensor.
The enclosure is opened without the use of tools
by pressing the snap lock at the side of the tube
connectors. PTH-6202 is attached onto a level
surface by 2 screws, which are screwed into a solid
surface. PTH-6202 can be fitted in all directions
without accuracy being aected. PTH-6202 also
functions with only one tube fitted to the connectors
(+ or -). However, two tubes should always be fitted to
ensure a suitable enclosure rating, if the connectors
do not face downwards. Pressure is supplied to the
measurement unit by tubes, the highest pressure
being connected to the ‘+ connector’ and the lowest
pressure to ‘- connector’. The pressure tubes must be
as short as possible and must be secured in position to
prevent vibration. To obtain the best possible results,
pressure must be measured where there is least risk
of turbulence, i.e. in the center of the ventilation duct
and at a distance of at least twice the width of the duct
from bends and six times the width from branches. If
there is a risk of condensation forming in connection
tubes, PTH-6202 is to be located in such a way that
condensate fluids cannot flow back into the pressure
transmitter.
Supply Air
Return Air
In duct view

Installation Manual Ventum Series
12
2.6.4 Combination Temperature/
Humidity Sensor
HTH-6202 sensors are installed in the ventilation
duct using the accompanying bracket, which must
be attached to a firm, level surface by means of
two screws. The 18-30 V DC supply voltage (24 V
DC nominal voltage) is provided via the Modbus
connection. HTH-6202 has a pre-fitted 7000 mm
cable, which is equipped with a standard RJ12
connector. The cable may be extended to as much
as 50 m without any negative eects on measuring
accuracy. The surrounding EMC environment must,
however, be taken into account and must be capable
of being defined as low. To extend the cable, use a
crossover Category 3 extension cable, RJ12-RJ12,
6P6C. The sensor should be installed in such a way
that the air flow in the duct can pass unhindered
through the measuring hole at the end of the sensor,
which should be aligned parallel to the air flow.
Although HTH-6202 is not aected by the position
in which it is installed, it is advisable not to install
the sensor in an upright position with the cable
downwards as this may cause moisture to accumulate
in the sensor. It is important that HTH-6202 is installed
in such a way that the measuring hole is positioned at
the center of the duct.
5'*
*Sensor must be installed a minimum of 5' from the heating or cooling module.
In duct view
Supply Air

Installation Manual Ventum Series
13
3.0 Access Requirements
Top of Unit
The National Electrical Code (NEC) requires 36 inches of clearance from an electrical connection. For Ventum, with
a front-mounted electrical box, the 3’ must be measured from the front of the box. The unit should be mounted such
that the bottom doors remain accessible.
4.0 Lifting Requirements
Units can be lifted by mounting angles. Lifting directly from the frame is not recommended.
Door with removed hinge pinUnit with doors open

Installation Manual Ventum Series
14
Installation Manual Ventum Series
5.0 Electrical Hook Ups
Warning
Hazardous voltage, disconnect all electrical power, including remote disconnects and discharge all motor start/run
capacitors before servicing. Follow proper lockout/tagout procedures to ensure the power cannot be accidentally
re-engaged.
3 phase, 4 wire, 208V, 460V -10% - +15%, 60Hz
Recommended fuse diagram
1 phase, 3 wire, 240V -10% - +15%, 60Hz
Recommended fuse diagram
Unit Size 208V 460V
C24-ERV 25A 15A
C30-ERV 25A 15A
C24-FC 15A 15A
C30-FC 20A 15A
Unit Size 208V
A16-ERV 15A
B20-ERV 15A
A16-FC 15A
B20-FC 15A

Installation Manual Ventum Series
15
5.1 Electrical Information
Model Airflow Nom. V. Motor
kW
SA
Fan
Qty.
SA
Fan
FLA
SA Fan
FLA
Total
RA
Fan
Qty.
SA
Fan
FLA
SA Fan
FLA
Total
Tnsfmr
FLA
Fuse
Size
FLA MCA MROP
D
Rcmd
Fuse
H05 600 240 0.5 2.5 2.5 0.29 5.39 5.91 8.41 15A 3/10 5.29 5.91 8.41 15A
H10 1000 240 0.78 3.9 3.9 0.29 8.09 9.06 12.96 15A 3/10 8.09 9.06 12.96 15A
H15 1350 208 2.0 6.0 6.0 0.33 12.33 13.83 19.83 15A 4/10 12.33 13.83 19.83 15A
H15 1350 460 2.5 4.0 4.0 0.14 8.14 9.14 13.14 15A 3/16 8.14 9.14 13.14 15A
H20 1800 208 2.0 6.0 6.0 0.33 12.33 13.83 19.83 15A 4/10 12.33 13.83 19.83 15A
H20 1800 460 2.5 4.0 4.0 0.14 8.14 9.14 13.14 15A 3/16 8.14 9.14 13.14 15A
H25 2250 208 2.7 8.6 8.6 0.33 17.53 19.68 28.28 25A 4/10 17.53 19.68 28.28 25A
H25 2250 460 3.7 5.8 5.8 0.14 11.74 13.19 18.99 15A 3/16 11.74 13.19 18.99 15A
H30 3000 208 2.7 8.6 8.6 0.33 17.53 19.68 28.28 25A 4/10 18.33 20.58 29.58 25A
H30 3000 460 3.7 5.8 5.8 0.14 11.74 13.19 18.99 15A 3/16 10.94 12.29 17.69 15A

Installation Manual Ventum Series
16
Pieces:
2021-02-11
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
PM
FAN
MOTOR
FAN
MOTOR
DATA CABLEDATA CABLE
0-10V
0-10V
L1 L2 L3GND
tt
tt
t
ENCLOSURE
4/10A for 208V
3/16A for 460V
208V or 460V
24V
1/L1
3/L2
5/L3
2/T1
4/T2
6/T3
I> I> I>
1/L1
3/L2
5/L3
2/T1
4/T2
6/T3
I> I> I>
O28-05-0003-23
NOVA WIRING LAYOUT 3-PHASE
Pieces:
2021-02-11
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
PM
L1 240V
O28-05-0003-24
NOVA WIRING LAYOUT SINGLE PHASE
FAN
MOTOR
FAN
MOTOR
DATA CABLEDATA CABLE
0-10V
0-10V
GND
tt
tt
t
ENCLOSURE
3/10A
24V
N
FAN I/0 R/A
BOTTOM
FAN I/0 S/A
TOP
6
5
3
4
1
7
8
POSITION PCs
TYPE
1
2
3
4
61
5
COLOUR PART No.
1
1
1
3
4
22/6 COMMUNICATION MODBUS
7
81
1
22/6 COMMUNICATION MODBUS
18/4 (3 PHASE/GRD) POWER
18/4 (3 PHASE/GRD) POWER
18/2 (0-10V, GRD) COMMNS.
18/2 (0-10V, GRD) COMMNS.
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-01A
PM ELE. BOX WIRING LAYOUT - 208V
3-PHASE
1
FAN R/A
(BOTTOM)
FAN S/A
(TOP)
BLACK
BLACK
GRAY
GRAY
BLACK
BLACK
BLACK
BLACK
L
CL C
24V
TRANSFORMER
T1
T2
T3 SWITCH BODY
T1 T2
MMP1 MMP2
GREEN GREEN
WHITE
BLACK
RED
WHITE
BLACK
RED
FOR T1, T2 CONNECTION
SEE 208V TRANSFORMER
WIRING DIAGRAM
T1 BLACK T2 BLACK
C
T1 T2 T3
2
2
2
1
1
SINGLE WIRE 10Ga, L=9"
SINGLE WIRE 10Ga, L=14"
9
9
92
FAN JUMPER 18Ga
BLACK
WIP0010
WIP0010
WIP0017
WIP0018
WIP0022
WIP0021
WIP0019
WIP0020
WIP0023
FOR WIRES CONNECTION
SEE 208V TRANSFORMER
WIRING DIAGRAM
Pre-heat
temperature sensor
is placed in top or
bottom core bracket.
17-WHITE
16-BLACK2-BLUE
1-RED
3-PHASE 208V POWER SOURCE
24V
TRANSFORMER
T1
18/3 (HOT, NEUTRAL, GROUND)
WHITE 1 WHITE 2
GREEN 1
GREEN 2
BLACK 1 BLACK 2
M9F
1
M9F
2
FOR T1
CONNECTION
SEE 240V
TRANSFORMER
WIRING
DIAGRAM
POWER BOX
POSITION PCsTYPE
1
3
41
COLOUR A16
1
1
2
1
1
22/6 COMMUNICATION MODBUS
5
6
7
8
91
1
1
1
22/6 COMMUNICATION MODBUS
18/2 0-10V, GRD COMMUNICATION
18/2 0-10V, GRD COMMUNICATION
2
4
5
18
9
18/3 (HOT, NEUTRAL, GROUND)
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-02A
PM ELE. BOX WIRING LAYOUT - 240V SINGLE
PHASE
6
7
T1
C
SWITCH BODY
SINGLE WIRE 10Ga L=9"
2BLACK SINGLE WIRE 10Ga L=11"
BLACK
BLACK
BLACK
BLACK
BLACK
33
BLACK SINGLE WIRE 10Ga L=8"
GREY
GREY
10 2
SINGLE WIRE 18Ga, 1.5-Inch
BLACK WIP0023
10
10
FOR WIRES
CONNECTION
AND JUMPER
SETTING, SEE
240V
TRANSFORMER
WIRING
DIAGRAM
DRAWING No.
B20
WIP0004
WIP0003
WIP0015
WIP0001
WIP0002
WIP0010
WIP0010
WIP0010
WIP0014
WIP0003
WIP0015
WIP0012
WIP0011
WIP0010
WIP0010
WIP0010
FAN I/0 R/A
BOTTOM
FAN I/0 S/A
TOP
FAN R/A
(BOTTOM)
FAN S/A
(TOP)
17-WHITE
16-BLACK Pre-heat
temperature sensor
is placed in top or
bottom core bracket.
2-BLUE
1-RED
WIP00021WIP00021
5.2 Single Phase Electrical Hook-Up (2 Fans)
Attention: Single phase electric consists of single Line, Neutral and Ground OR two hot lines and Ground (Line 1,
Line 2 and Ground) based on voltage availability.

Installation Manual Ventum Series
17
Pieces:
2021-02-11
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
PM
FAN
MOTOR
FAN
MOTOR
DATA CABLEDATA CABLE
0-10V
0-10V
L1 L2 L3GND
tt
tt
t
ENCLOSURE
4/10A for 208V
3/16A for 460V
208V or 460V
24V
1/L1
3/L2
5/L3
2/T1
4/T2
6/T3
I> I> I>
1/L1
3/L2
5/L3
2/T1
4/T2
6/T3
I> I> I>
O28-05-0003-23
NOVA WIRING LAYOUT 3-PHASE
Pieces:
2021-02-11
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
PM
L1 240V
O28-05-0003-24
NOVA WIRING LAYOUT SINGLE PHASE
FAN
MOTOR
FAN
MOTOR
DATA CABLEDATA CABLE
0-10V
0-10V
GND
tt
tt
t
ENCLOSURE
3/10A
24V
N
FAN I/0 R/A
BOTTOM
FAN I/0 S/A
TOP
6
5
3
4
1
7
8
POSITION PCs
TYPE
1
2
3
4
61
5
COLOUR PART No.
1
1
1
3
4
22/6 COMMUNICATION MODBUS
7
81
1
22/6 COMMUNICATION MODBUS
18/4 (3 PHASE/GRD) POWER
18/4 (3 PHASE/GRD) POWER
18/2 (0-10V, GRD) COMMNS.
18/2 (0-10V, GRD) COMMNS.
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-01A
PM ELE. BOX WIRING LAYOUT - 208V
3-PHASE
1
FAN R/A
(BOTTOM)
FAN S/A
(TOP)
BLACK
BLACK
GRAY
GRAY
BLACK
BLACK
BLACK
BLACK
L
CL C
24V
TRANSFORMER
T1
T2
T3 SWITCH BODY
T1 T2
MMP1 MMP2
GREEN GREEN
WHITE
BLACK
RED
WHITE
BLACK
RED
FOR T1, T2 CONNECTION
SEE 208V TRANSFORMER
WIRING DIAGRAM
T1 BLACK T2 BLACK
C
T1 T2 T3
2
2
2
1
1
SINGLE WIRE 10Ga, L=9"
SINGLE WIRE 10Ga, L=14"
9
9
92
FAN JUMPER 18Ga
BLACK
WIP0010
WIP0010
WIP0017
WIP0018
WIP0022
WIP0021
WIP0019
WIP0020
WIP0023
FOR WIRES CONNECTION
SEE 208V TRANSFORMER
WIRING DIAGRAM
Pre-heat
temperature sensor
is placed in top or
bottom core bracket.
17-WHITE
16-BLACK2-BLUE
1-RED
3-PHASE 208V POWER SOURCE
24V
TRANSFORMER
T1
18/3 (HOT, NEUTRAL, GROUND)
WHITE 1 WHITE 2
GREEN 1 GREEN 2
BLACK 1 BLACK 2
M9F
1
M9F
2
FOR T1
CONNECTION
SEE 240V
TRANSFORMER
WIRING
DIAGRAM
POWER BOX
POSITION PCsTYPE
1
3
41
COLOUR A16
1
1
2
1
1
22/6 COMMUNICATION MODBUS
5
6
7
8
91
1
1
1
22/6 COMMUNICATION MODBUS
18/2 0-10V, GRD COMMUNICATION
18/2 0-10V, GRD COMMUNICATION
2
4
5
18
9
18/3 (HOT, NEUTRAL, GROUND)
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-02A
PM ELE. BOX WIRING LAYOUT - 240V SINGLE
PHASE
6
7
T1
C
SWITCH BODY
SINGLE WIRE 10Ga L=9"
2BLACK SINGLE WIRE 10Ga L=11"
BLACK
BLACK
BLACK
BLACK
BLACK
33
BLACK SINGLE WIRE 10Ga L=8"
GREY
GREY
10 2
SINGLE WIRE 18Ga, 1.5-Inch
BLACK WIP0023
10
10
FOR WIRES
CONNECTION
AND JUMPER
SETTING, SEE
240V
TRANSFORMER
WIRING
DIAGRAM
DRAWING No.
B20
WIP0004
WIP0003
WIP0015
WIP0001
WIP0002
WIP0010
WIP0010
WIP0010
WIP0014
WIP0003
WIP0015
WIP0012
WIP0011
WIP0010
WIP0010
WIP0010
FAN I/0 R/A
BOTTOM
FAN I/0 S/A
TOP
FAN R/A
(BOTTOM)
FAN S/A
(TOP)
17-WHITE
16-BLACK Pre-heat
temperature sensor
is placed in top or
bottom core bracket.
2-BLUE
1-RED
WIP00021WIP00021
5.3 Three-Phase Electrical Hook-Up (2 Fans)

Installation Manual Ventum Series
18
5.10 Fan Connection - Single Phase
WHITE
BLACK
BLACK
FAN BODY
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-10
PM
240V FAN WIRING DIAGRAM
SINGLE PHASE
GREEN
WHITE
BLACK
10V
GND
E1 D1
L1
NPE

Installation Manual Ventum Series
19
5.11 Fan Connection - Three Phase
WHITE
BLACK
WHITE
BLACK
RED
GREEN*
BLACK
FAN BODY
Pieces:
2020-04-02
Scale:
Drawn by:
Approved by:
Date:
Material:
Weight:
Name:
Drawing number:
O28-05-0003-09
PM 208V, 460V FAN WIRING DIAGRAM
3-PHASE
24V
GND
E1
L3
L2
L1
D1
* GROUND TERMINAL POSITION VARY. FOLLOW THE GROUND MARK

Installation Manual Ventum Series
20
Wiring Diagrams
