Ozito PowerXchange PXBP-150 User manual

1.5AH BATTERY
18V Lithium Ion
2
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING
INSTRUCTIONS FOR YOUR BATTERY CHARGER.
1. Before using the charger read all instructions and cautionary markings on the
charger, battery pack and the product using the battery pack.
2. This charger is not intended for any uses other than charging rechargeable bat-
teries. Any other use may result in risk of re, electric shock or electrocution.
3. Do not place any object on top of the charger or place the charger on a soft sur-
face that may result in excessive internal heat. Place the charger in a position
away from any heat source.
4. To reduce risk of damage to the electric plug and cord, pull by the plug rather
than the cord when disconnecting the charger.
5. Make sure the cord is located so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
6. An extension cord should not be used unless absolutely necessary. Use of an
improper extension cord could result in the risk of re, electric shock or electrocution.
7. Do not operate the charger if it has received a sharp blow, been dropped or
otherwise damaged in any way. Have it checked by an electrician or power tool
repairer.
8. Do not disassemble charger. Take it to an electrician or power tool repairer
when service or repair is required. Incorrect reassembly may result in a risk of
electric shock, electrocution or re.
9. To reduce risk of electric shock, unplug the charger from the outlet before at-
tempting any cleaning. Removing the battery pack will not reduce this risk.
10. Never attempt to connect 2 chargers together.
11. DO NOT store or use the tool and battery pack in locations where the temperature
may reach or exceed 40ºC (such as inside sheds or metal buildings in summer).
12. The charger is designed to operate on standard household electrical power
(240 volts). Do not attempt to use it on any other voltage!
13. The battery pack is not fully charged out of the carton. First read the safety
instructions and then follow the charging notes and procedures.
14. The longest life and best performance can be obtained if the battery pack is
charged when the air temperature is between 18 - 24ºC. Do not charge the
battery pack in an air temperature below 10ºC or above 40ºC. This is important
and will prevent damage to the battery pack.
15. Do not incinerate the battery pack even if it is seriously damaged or is completely
worn out. The battery can explode in a re.
16. Never attempt to open the battery pack for any reason. If the plastic housing of the
battery pack breaks or cracks, immediately discontinue use and do not recharge.
17. During charging, the battery must be placed in a well ventilated area.
BATTERY SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! When using mains-powered tools, basic safety
precautions, including the following, should always be followed to
reduce risk of re, electric shock, personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off
in an emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future
reference.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia
and New Zealand.
This tools charger is double insulated in accordance with AS/NZS 60335.1
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid hazard.
Note: Double insulation does not take the place of normal safety precautions when
operating this tool. The insulation system is for added protection against injury
resulting from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool.
Before use, inspect the extension lead for signs of damage, wear and ageing.
Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of
an extension lead not suitable for the power input of the tool or which is damaged or
defective may result in a risk of re and electric shock.
To reduce the risk of electric shock, we recommend the use of a residual current
device (rated 30mA or less).
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
PXBP-150
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
Battery Power: 1.5Ah Li-ion
Compatible Chargers: PXCG-030 (Fast Charger)
PXCG-120 (Eco Charger)
Charge Times: 30min Fast Charger
2Hr Eco Charger
Weight: 0.35kg
1. Battery
2. Battery Release Button
3. Charge Indicator Button
ozito.com.au
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
DESCRIPTION OF SYMBOLS
Warning
Do not use or store battery in
temperatures exceeding 50ºC
Volts Hertz
Alternating Current
Direct Current
Milliamperes
Watts
Amp Hour
Ah
W
HzV
ac/~
mA
Lithium Ion Battery
Do not put in the rubbish
Do not get battery wet
Recycle Battery
Do not incinerate
dc
31

BATTERY CHARGE
INDICATOR
The purchased battery is equipped
with a battery charge indicator to
show the state of the battery charge.
Press the charge indicator button and
look to see which LED lights.
Battery requires immediate charging
Low state of charge, requires charging soon.
Mid state of charge
Full state of charge.
Note: The battery needs to be removed from the tool to check the state
of charge.
BATTERY PROTECTION SYSTEM
The tool is equipped with a battery protection system, which helps to
ensure longevity of the battery.
The output power automatically cuts off during operation when the tool
and/or battery are placed under the following situations:
• When the tool is overloaded:
If this occurs, release the trigger switch and remove causes of
overload, then pull the switch trigger again to restart.
• When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the
tool.
Note: The indicated capacity may be lower than the actual level during
use or immediately after using the tool.
PXBP-150
1. OPERATION WARRANTY
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE
RELATING TO THE WARRANTY POLICY OR
PROCEDURE.
The benefits provided under this warranty are in addition to other rights
and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You
are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount
to a major failure.
Generally you will be responsible for all costs associated with a claim
under this warranty, however, where you have suffered any additional
direct loss as a result of a defective product you may be able to claim
such expenses by contacting our customer service helpline above.
36 MONTH REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the original
date of purchase and is intended for DIY (Do It Yourself) use only. If a
product is defective it will be replaced in accordance with the terms of
this warranty. Warranty excludes consumable parts.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other than that
specified on the tool.
• If the tool shows signs of damage or defects caused by or
resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction
manual.
• If the tool is disassembled or tampered with in any way.
OZITO Australia/New Zealand (Head Office)
1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
CHARGING YOUR LITHIUM ION BATTERY
This battery has been shipped in a low charge condition, and requires
charging prior to use. Allow several cycles of charging and discharging
(through use with a compatible tool) for the battery to reach its optimum
performance / runtime.
This battery has two compatible Ozito chargers available through your
local Bunnings Warehouse:
• PXCG-030 Fast Charger
• PXCG-120 Eco Charger
Only use the battery pack with Ozito Power X Change 18V cordless
products.
1. Insert the power plug of the charger into the mains socket outlet.
The green LED will begin to ash when properly connected to
power supply.
2. Insert the battery pack into the battery charger .
3. Remove battery from the charger once fully charged. Disconnect
the charger from the power supply.
Note: The battery pack can become a little warm during the charging.
This is normal
If the battery pack fails to charge, check:
if there is voltage at the socket outlet
that the battery and charger are properly connected.
If the battery pack still fails to charge, please contact our customer
service center.
