Ozito LHD-7100 User manual

CORDLESS
HAMMER
DRILL
18V Li-ion
INSTRUCTION MANUAL
LHD-7100
WHAT’S IN THE BOX
Hammer Drill
ozito.com.au
SPECIFICATIONS
Input: 18V
Chuck Size: 13mm Keyless
No Load Speed: 0-350 / 0-1,200 /min
Impacts: 0-5,600 / 0-17,000bpm
Torque Setting: 19
Max. Torque: 30Nm
Drilling Capacity: Timber 25mm
Steel 10mm
Masonry 10mm
Battery: 1.3Ah Lithium Ion
Charge time: 3 - 5 Hours
Weight with Battery: 1.65kg Charging Adaptor
2 x 18V Battery
Drill Bits x 9
Charging Cradle
50mm Screwdriver Bit

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
KNOW YOUR PRODUCT SETUP & PREPARATION
1. BATTERY
1 Keyless Chuck
2 Torque Adjustment Collar
3 LED Light
4 Variable Speed Trigger
5 Forward/Reverse Lever
6 Battery 18V
7 Battery Release Button
8 Gear Selector
HAMMER DRILL
This charger is recommended for use with a residual current
device with a rated residual current of 30mA or less.
ACCESSORIES
9 Charging Jack
10 Charging Adaptor
11 Charging Cradle
12 50mm Screwdriver Bit
13 Steel Drill Bits x 3
14 Masonry Drill Bits x 3
15 Wood Drill Bits x 3
Installing and Removing
Slide the battery into the drill
base until it clicks into place.
Charging
Hold down the battery release
buttons and slide the battery
out.
Battery Indicator
1. Depress the battery
indicator button.
2. Observe which lights illuminate for a reading on your battery’s
charge.
Charged Flat
Low Charge
2. Slide cradle onto the battery.
Only the red light will be
illuminated when properly
connected and charging.
1. Plug charging jack into
charging cradle. Both
lights will illuminate when
connected.
Note: Once fully charged, both the red and green lights will
illuminate.

2. CHUCK 3. CONTROLS
1. To start drilling squeeze the
variable speed trigger.
2. To stop drilling release
the trigger.
1. Open the chuck jaws.
3. Tighten the chuck jaws.
2. Insert the drill bit,
making sure it is
centred in the jaws.
OPERATION
1. To set the drill to forward rotation, move fwd/rev lever to the
right. For reverse rotation, move fwd/rev lever to the left.
Variable Speed Trigger
Forward/Reverse Lever
Keyless Chuck
3. For faster speeds, squeeze
the trigger rmly. For slower
speeds, apply less pressure
to the trigger.
Speed Control
1. Slide the switch backward
to select rst gear.
2. Slide the switch forward to
select second gear.
4. Pull on the bit to
ensure it is rmly
secured.
The gear selector controls the speed of the drill. First gear allows
slower drilling with more torque, while second gear is suitable when
less power but more speed is required.
Caution: Do not handle drill bits or other accessories without
gloves as they are sharp and can become hot after use, potentially
causing personal injury.
6
7
8
FWD
REV
Slower Faster

LHD-7100
3. FUNCTIONS 4. DRILLING
1. Depress and release the
variable speed trigger to
ensure it is not locked on.
3. Secure the material to be
drilled in a vice or clamp to
stop it turning whilst drilling.
4. Hold the drill rmly and
place the bit at the point to
be drilled.
2. Check the forward/reverse
lever for the correct setting.
Before starting to drill, perform a few simple checks.
1. To select, turn the torque
collar to align the arrow
on the housing with the
hammer icon.
5. Depress the variable
speed trigger to start the
drill.
6. Move the drill bit into the workpiece.
Note: Do not force the drill or apply side pressure to elongate the
hole. Let the drill do the work.
Hammer Drilling
Screwdriving to Preset Depth
Turn torque ring to the desired
setting.
Hammer drilling is required when drilling into concrete, brick or
masonry
Drilling
1. To drill into wood, metal or
plastic, turn the torque collar
to align the arrow on the
housing with the drill icon.
1. Set the torque collar to
lowest setting and tighten
the rst screw.
To determine the appropriate setting:
2. If the clutch rachets and
makes a clicking sound
before screw is ush,
increase the collar setting
and continue tightening.
3. Repeat until you reach the
correct setting/ screw depth.
Use this setting for the
remaining screws.

Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
MAINTENANCE
DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
TROUBLESHOOTING
WARNING! Wear ear protectors when impact drilling Exposure to noise
can cause hearing loss.
Use auxiliary handle(s), if supplied with the tool. Loss of control can cause
personal injury.
Hold power tool bi insulated gripping surfaces, when performing an operation
where the cutting accessory may contact hidden wiring or its own cord. Cutting
accessory contacting a “live” wire may make exposed metal parts of the power tool
“live” and could give the operator an electric shock.
Before drilling into walls, ceilings etc, ensure that there are no concealed power
cables or pipes in the cavity.
WARNING! Some dust created by power sanding, sawing, grinding,
drilling and other construction activities contain chemicals known to cause
cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products
• Arsenic and chromium from chemically treated timber
Your risk from exposure to these chemicals varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals: work in a well
ventilated area and work with approved safety equipment, such as dust masks that
are specially designed to lter out microscopic particles.
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
HAMMER DRILL SAFETY WARNINGS
Warning
Wear eye protection Wear ear protection
Read instruction manual
ø Diameter
mA Milliamperes
Recycle battery Do not put in the rubbish
Polarity
Do not incinerate Do not get battery wet
Thermal cut-out protection
Transformer Energy
Rating (MEPS)
Double insulated
/min Revolutions or
reciprocation per minute
Ah Amp hour
Indoor use only
Lithium Ion battery Do not use or store battery in
temperatures exceeding 50ºC
Electrical Emissions
Conformity (EMC)
IPM Impacts per minute Nm Newton Meters
no No load speed
VVolts Hz Hertz
ac/~ Alternating current WWatts
Direct current
dc/
1. When not in use, the hammer drill should be stored in a dry,
frost free location, keep out of children’s reach.
2. Keep ventilation slots of the hammer drill clean at all times
and prevent anything from entering.
3. If the housing of the hammer drill requires cleaning, do not
use solvents. Use of a cloth only is recommended.
4. Blow out the ventilation slots with compressed air
periodically .
Note: Ozito Industries will not be responsible for any damage or
injuries caused by repair of the drill by an unauthorised person
or by mishandling.
LED lights do not illuminate on charger
Check the charging adaptor is securely plugged into the wall out let.
Check the battery is rmly connected to the charging cradle.
Check that the charging jack is securely connected to the charging cradle.
The battery has a short run time
Ensure the battery is properly charged. It will take 4-5 charging cycles
before the battery reaches optimum charge and run time. On the initial
charge, the battery requires 5 hours of charging. Subsequent charging
only requires 3-5 hours.
Variable speed trigger is locked
Ensure that the forward / reverse lever is in the correct position; pressed
left for forwards direction, pressed right for backwards direction. If it is in
between the two settings the variable speed trigger will be locked.
The drill is stripping the screw head
Ensure you are not applying to much force to the screw. Hold the drill
more lightly against the screw and lower the torque setting.
Drill has cut out during use
Use the battery indicator button to check if the battery has gone at. If the
indicator does not work or indicates that the battery still has charge, it is
likely that the battery’s themal voltage protection has been activated. This
can happen when the drill has been used for extended periods or worked
hard with large drill bits or accessories.
Place the battery on the charging cradle for 3-5 hours. It will need this
time to cool down and for the protection circuits to be reset.
Sparking visible through the housing air vents
A small amount of sparking may be visible through the housing vents.
This is normal and does not indicate a problem.
18V Li-ion Battery Pack SPLCD5000-16
Charging Adaptor SPLCD5000-17
Charging Stand SPLCD5000-18

SPARE PARTS Tool: 18V Li-ion Hammer Drill
Model No. LHD-7100
Item
No. Description Part No.
How To Order
16 18V Li-ion Battery
Charging Cradle & Adaptor
SPLCD5000-16
SPLCD5000-17A
Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you
have any further questions, please contact Ozito Customer Service on:
Australia: 1800 069 486
New Zealand: 0508 069 486
[email protected]
The following is a list of spare parts carried by Ozito.
Please contact Customer Service for any parts not
listed.
1 2 3 4
10
14
15
16
11
12
13
5
6
7
8
9
Item
No. Description Part No.

WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
This tool is double insulated in accordance with AS/NZS 60335-1;
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid
a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitable for the power input of the tool or which is damaged or defective may result in a risk of re and electric
shock.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your nger on
the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Battery tool use and care
a. Recharge only with the charger specied by the manufacturer. A charger that is suitable for one
type of battery pack may create a risk of re when used with another batery pack.
b. Use power tools only with specically designated battery packs. Use of any other battery packs may
create a risk of injury and re.
c. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a re.
d. Under abusive conditions, liquid may be ejected from the battery; aviod contact. If contact
accidentally occurs, ush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritationor burns.
6. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
BATTERY AND CHARGER SAFETY WARNINGS
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR
BATTERY CHARGER.
1. Before using the charger read all instructions and cautionary markings on the charger, battery pack
and the product using the battery pack.
1. This charger is not intended for any uses other than charging rechargeable batteries. Any other use
may result in risk of re, electric shock or electrocution.
2. Do not place any object on top of the charger or place the charger on a soft surface that may result
in excessive internal heat. Place the charger in a position away from any heat source.
3. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when
disconnecting the charger.
4. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected
to damage or stress.
5. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord
could result in the risk of re, electric shock or electrocution.
6. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in
any way. Have it checked by an electrician or power tool repairer.
7. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is
required. Incorrect reassembly may result in a risk of electric shock, electrocution or re.
8. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning.
Removing the battery pack will not reduce this risk.
9. Never attempt to connect 2 chargers together.
10. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed
40ºC (such as inside sheds or metal buildings in summer).
11. The charger is designed to operate on standard household electrical power (240 volts). Do not
attempt to use it on any other voltage!
12. The battery pack is not fully charged out of the carton. First read the safety instructions and then
follow the charging notes and procedures.
13. The longest life and best performance can be obtained if the battery pack is charged when the air
temperature is between 18 - 24ºC. Do not charge the battery pack in an air temperature below 10ºC
or above 40ºC. This is important and will prevent damage to the battery pack.
14. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery
can explode in a re.
15. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or
cracks, immediately discontinue use and do not recharge.
16. During charging, the battery must be placed in a well ventilated area.

OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0113
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase and is intended for DIY (Do It
Yourself) use only. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: included
accessories, etc.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
