Ozito SDL-5000 User manual

CORDLESS
SCREWDRIVER
TORCH
3.6V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage: 3.6V
Chuck Size: 6.35mm Magnetic
No Load Speed: 180/min
Torque Settings: 9
Max Torque: 3.5Nm
Battery: 1.5Ah Li-ion
Charge Time: 3 - 5Hours
Weight (tool only): 0.4kg
SDL-5000
WHAT’S IN THE BOX
Cordless Screwdriver
Driver Bits x 24
USB Charging Cable
Docking Station
ozito.com.au

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1 Bit Holder
2 Torque Collar
3 LED Work Light
4 Forward / Reverse Lever
5 Handle Lock Button
6 Rotating Rear Handle
7 On / Off Trigger
8 USB Charging Point
9 Charge Indicator
10 Torch On/Off Switch
11 Torch LED
CORDLESS SCREWDRIVER / TORCH
KNOW YOUR PRODUCT
1. CHARGING
12 Drill Bit Storage
13 Docking Station
14 Charge Check Indicator
15 USB Charger Compartment
16 Clear Case Lock
17 USB Charging Cable
18 CRV Bits x 24
ACCESSORIES
SETUP & PREPARATION
1
12 13 14 15 16 17 18
2 3 7 8 9 10 11
5 64
Charging the Screwdriver / Torch
1 Remove the USB charging
adaptor from the base of the
docking station.
3 Plug the charging jack into
the charging point on the
screwdriver.
5 The charge indicator will
illuminate green once the tool
is completely charged.
2 Plug the USB
charging cable
into a USB
portable charge
pack (not
included) or USB
port.
4 The charge
indicator will
illuminate red
indicating
the battery is
charging.

2. DOCKING STATION 3. CHANGING DRIVER BITS
Charging with the Docking Station
1 Remove the USB charging
adaptor from the base of
docking station.
The docking station allows neat and tidy storage of the screwdriver bits,
while ensuring your screwdriver is always charged and ready to go.
3 Plug the charging jack into the
charging point on the docking
station.
5 The docking station indicator
lights illuminate in sequence,
indicating the tool is charging.
2 Plug the USB charging cable
into a USB portable charge
pack (not included) or USB
port.
4 Place the screwdriver / torch
onto the docking station to
allow the tool to charge.
6 When the tool is completely
charged, all 4 indicator lights
will illuminate.
Inserting Driver Bits
Removing Driver Bits
1 Insert the CRV bit directly into
the magnetic bit holder.
1 Pull the CRV bit out of
the magnetic bit holder to
remove.
2 Pull gently on the
CRV bit to ensure
it is properly
secured.

4. CONTROLS
OPERATION
On/Off Trigger Screwdriving LED Worklight
Using the Torch Function
Forward / Reverse Lever
Adjusting the Torque
1 To start driving, squeeze the
on/off trigger.
The screwdriver features a
worklight that will help brighten
the work area. This light will
automatically turn on once the on/
off trigger is pressed.
1 To turn the torch on, press
torch on/off switch into the on
position.
2 To stop driving,
release the on/off
trigger.
2 To turn the torch
off, press torch on/
off switch into the
off position.
1 Push the forward/reverse
lever left, for forward rotation.
2 For reverse rotation push the
lever to the right of the tool.
Align the arrow at the top of the
tool with the desired setting by
rotating the torque collar.
Note: A higher number will result
in higher torque or twisting
action.
Note: To avoid damaging screw heads, start with a low torque setting
and increase until the screw head is ush with the work piece.
FWD
REV
FWD

SDL-5000
5. SWIVEL HANDLE 6. SCREWDRIVING
In-line Position
Angled Position
1 Hold the handle locking button
down.
The screwdriver / torch features a rotating handle to suit a range of
applications. You can operate the screwdriver of torch in either handle
position.
1 Select the desired handle
position.
4 Squeeze the on/off trigger to
start the screwdriver.
3 Hold the screwdriver rmly and place the bit on the screw to be
fastened.
1 Hold the handle locking button
down.
2 Rotate the handle
clockwise until it
clicks into position.
2 Check the
forward/reverse
lever is in the
desired setting.
5 Fasten the screw
into the work
piece.
Note: Do not force the screwdriver or apply side pressure to elongate
the hole. Let the screwdriver do the work.
2 Rotate the handle
anti-clockwise
until it clicks into
position.
FWD
REV
FWD

MAINTENANCE
TROUBLESHOOTING
On/Off Trigger is Locked
Ensure that the forward / reverse lever is in the correct position; pressed left for
forwards direction, pressed right for backwards direction. If it is in between the two
settings the on/off trigger will be locked.
LED Torch is Not Working
The tools battery may be depleted. Charge the tool using the USB charger
provided.
The Handle Is Not Rotating
Ensure you are holding the handle lock button down while rotating the handle.
Ensure you are rotating the handle in the correction direction. Clockwise rotation
into in-line position or anti-clockwise for angled position.
Tool is Not Charging When Placed Onto The Docking
Station
Ensure that you have connected the docking station to a suitable USB port using
the USB charging cable provided.
Ensure the tool is correctly seated in the docking station.
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
1. When not in use, the screwdriver should be stored in a dry, frost
free location, keep out of children’s reach.
2. Keep ventilation slots of the screwdriver clean at all times and
prevent any debris from entering.
3. If the housing of the screwdriver requires cleaning, do not use
solvents but cloth only.
4. Blow out the ventilation slots with compressed air periodically .
Note: Ozito Industries will not be responsible for any damage or
injuries caused by repair of the screwdriver by an unauthorised
person or by mishandling of the tool.

SPARE PARTS
How To Order
Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any
further questions, please contact Ozito Customer Service on:
Australia: 1800 069 486
New Zealand: 0508 069 486
[email protected]
Tool: 3.6V Li-Ion Screwdriver
Model No. SDL-5000
12
45679
8
10
11
18
19
20
21
22
23
24
25
12
13
14
15
16 17
3-1 3-2 3-3 3-4 3-5 3-6 3-7 3-8 3-9
3-16 3-17 3-18 3-19
3-10 3-11 3-12 3-13 3-14 3-15

DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR
BATTERY CHARGER.
• To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when
disconnecting the charger.
• Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected
to damage or stress.
• DO NOT store or use the tool in locations where the temperature may reach or exceed 40ºC (such as
inside sheds or metal buildings in summer).
• The tool is not fully charged out of the carton. First read the safety instructions and then follow the
charging notes and procedures.
• The longest life and best performance can be obtained if the tool is charged when the air tempera-
ture is between 18 - 24ºC. Do not charge the tool in an air temperature below 10ºC or above 40ºC.
This is important and will prevent damage to the tool.
• Do not incinerate the tool even if it is seriously damaged or is completely worn out. The battery can
explode in a re.
• Never attempt to open the tool for any reason. If the plastic housing of the tool breaks or cracks, im-
mediately discontinue use and do not recharge.
• During charging, the tool must be placed in a well ventilated area.
BATTERY AND CHARGER SAFETY WARNINGS
Warning Read instruction manual
mA Milliamperes
Polarity
Thermal cut-out protection
Transformer Energy
Rating (MEPS)
/min Revolutions or
reciprocation per minute
Ah Amp hour
Indoor use only
Electrical Emissions
Conformity (EMC)
Nm Newton Meters
no No load speed
V Volts Hz Hertz
ac/~ Alternating current W Watts
Direct current
dc/
Isolation transformer

SCREWDRIVER SAFETY WARNINGS
GENERAL POWER TOOL SAFETY WARNINGS - PERSONAL SAFETY
WARNING! Some dust created by power sanding, sawing, grinding,
drilling and other construction activities contain chemicals known to cause
cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products
• Arsenic and chromium from chemically treated timber
Your risk from exposure to these chemicals varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals: work in a well
ventilated area and work with approved safety equipment, such as dust masks that
are specially designed to lter out microscopic particles.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Donotoperatepowertoolsinexplosiveatmospheres,suchasinthepresenceofammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
notuseapowertoolwhileyouaretiredorundertheinuenceofdrugs,alcoholormedication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Battery tool use and care
a. Rechargeonlywiththechargerspeciedbythemanufacturer.A charger that is suitable for one
type of battery pack may create a risk of re when used with another batery pack.
b. Usepowertoolsonlywithspecicallydesignatedbatterypacks.Use of any other battery packs
may create a risk of injury and re.
c. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects, that can make a connection from one terminal
to another. Shorting the battery terminals together may cause burns or a re.
d. Under abusive conditions, liquid may be ejected from the battery; aviod contact. If contact
accidentallyoccurs,ushwithwater.Ifliquidcontactseyes,additionallyseekmedicalhelp.
Liquid ejected from the battery may cause irritation or burns.
6. Service
a. Haveyourpowertoolservicedbyaqualiedrepairpersonusingonlyidenticalreplacement
parts. This will ensure that the safety of the power tool is maintained.

IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
0316
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the
original date of purchase and is intended for DIY (Do It Yourself)
use only. If a product is defective it will be replaced in accordance
with the terms of this warranty. Lithium Ion batteries are covered
by a 12 month warranty. Warranty excludes consumable parts, for
example: driver bits, etc.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
