Senco DuraSpin DS200-14v User manual

Applications:
For drywallers and remodelers, DuraSpin is the ideal tool for drywall
(to wood or steel studs), floor sheathing, and underlayment.
Features and Benefits:
• 14.4 volt battery provides the optimum balance of power,
weight and run-time across the full range of screws
• 2,300 RPM high-torque motor drives screws without
bogging down
• Patented clutch design means long-lasting durability
• One-hour charger and extra battery ensures a backup battery
with a full charge
• Easy depth-of-drive adjustment regulates the precise
amount of countersink
• Easy bit change — from phillips to square
• Wide range of collated screws to speed production
• Belt hook — DuraSpin goes where you go
• One full year warranty
Fastener Specifications:
Screw Lengths: 1" (25 mm) to 2" (50 mm)
Screw Diameters: #6, #7, #8
DuraSpin™Cordless Screw Driver
NEW!
Application:
Drive/Head:
Thread:
Point:
Finish:
Screw:
Drywall
to Wood Drywall to Light Gauge Steel Drywall to Heavy Gauge Steel Wood to Wood
#2 Phillips #2 Phillips #2 Phillips #2 Square
Bugle Bugle Bugle Flat
Coarse Fine Fine Coarse 2/3
with Wax
Sharp Sharp Drill Sharp
Grey
Phosphate Grey Phosphate Clear Zinc Yellow Zinc
#6 X 11 /4" #6 X 11 /4"
#8 X 13/4"
#8 X 11 /2"
#6 X 11 /4"
#6 X 15 /8"
#7 X 2"
DuraSpin, the collated screw fastening system from SENCO®,
is designed to maximize efficiency in a wide variety of screw-
fastening applications. Engineered for comfort and convenience,
the DS200-14v cordless screw driver drives 1" to 2" screws.
Tool Specifications:
Voltage: 14.4 volts
Battery Ampacity: 1700 mAh
RPM: 2300 rev/min
Weight: 4.9 lbs. (2.2 kg)
Height: 10 inches (254 mm)
Length: 13.8 inches (350 mm)
Width: 2.8 inches (70 mm)
Recharge Time: 1 hour
Screw Drives/Charge: see chart on reverse side
Fastener Capacity: 50 screws (one strip)
Torque Delivered: 37 in-lbs
Generated Noise: 74 dBA
Vibration: less than 2.5m/sec2
Model DS200-14v

For additional information on how Senco fastening systems will save you time, reduce costs and increase quality, call your nearest
Authorized Senco Dealer or Distributor listed in the Yellow Pages under “Staples,” or call our toll-free Action Line: 1-800-543-4596.
www.senco.com
DuraSpin™Cordless Screw Driver
Powerful 14.4 volt battery
Provides optimum balance of power,
weight and run-time across the full
range of screws
Each tool comes complete with:
Two 14.4 volt batteries,
one-hour battery charger,
2 spare drive bits, and a
rugged carrying case.
Screw guard
Guides screws while protecting
hands and clothing
Battery charger
Provides full charge in one
hour—increases productivity
and decreases downtime
Comfortable grip and
cushioned trigger
Ergonomically designed for extra
comfort and better productivity
with less exertion
Second-hand grip
Helps combat worker fatigue
Super-tough drive bits
The longest-lasting drive
bits available
Belt hook
Lets DuraSpin go where you go
Quick-bit release
No chuck—bits pop out and pop in
Adjustable nose piece
With easy-to-read length markings,
adjusts to screw lengths of 1 to 2 inches
2300 RPM high-torque motor
Specially designed to torque screws in
without bogging down
Adjustable depth-of-screw drive
For flush drive or countersink
Patented clutch design
Extends motor and bit life by disengaging
when drive is completed
©2000 by Senco Products, Inc. Order MK394 Litho in U.S.A.
Typical Applications and
Screws Used Average Number of Screws Driven Per Charge Screw Reorder Code
Drywall to Wood
Drywall to Light Gauge Steel
Drywall to Heavy Gauge Steel
Subfloor to Wood
#6 X 1
1
/ 4 " Screws 650
#6 X 1
5
/ 8 " Screws 450
#7 X 2" Screws 300
#6 X 1
1
/ 4 " Screws
700 (25 GAUGE)
600 (20 GAUGE)
#6 X 1
1
/ 4 " Screws 300 (18 GAUGE)
#6 X 1
5
/ 8 " Screws 350
#8 X 1
1
/ 2 " Screws 250
#8 X 1
3
/ 4 " Screws 200
06A125P
06A162P
07A200P
06B125P
06C125C
06A162P
08F150Y
08F175Y
These are representative averages. Your results may vary based on specific work conditions.
Model DS200-14v
