Ozito SDL-4000 User manual

CORDLESS
SCREWDRIVER
3.6V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage: 3.6V
Chuck Size: 6.35mm Keyless
No Load Speed: 200/min
Torque Settings: 8
Max Torque: 3Nm
Battery: 1.3Ah Li-ion
Charge Time: 3-5 Hours
Weight (tool only): 0.42kg
SDL-4000
WHAT’S IN THE BOX
Cordless Screwdriver
Driver Bits x 15
Charging Adaptor
Docking Station
ozito.com.au

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
2. Plug charging adaptor into
power socket.
4. Place the Screwdriver on the
docking station for charging.
1 Bit Holder
2 Quick Connect Chuck
3 Torque Collar
4 LED Worklight
5 Charge Check Indicator
6 Charge Check Button
7 Handle Lock Button
8 On/off Trigger
9 Charging Socket on Driver
10 Forward/ Reverse Lever
CORDLESS SCREWDRIVER
KNOW YOUR PRODUCT
1. CHARGING
1. Remove charging adaptor from
the base of docking station.
3. Insert the charging jack into the
charging socket on the docking
station.
Charge Check LED Indicator
1. Depress the charge check button.
2. Observe which charge check LED illuminates for a reading on your
battery’s charge.
11 Docking Station
12 Docking Station Storage
Cover
13 Charging Adaptor
14 Charging Socket on Dock
15 Charging Jack
16 CRV Bits x 15
ACCESSORIES
SETUP & PREPARATION
To reduce the risk of electric shock, a residual current device
(rated 30mA or less) must be used.
Flat Battery Low Charge Full Charge
NOTE: A RED LIGHT ON TOP OF THE SCREWDRIVER WILL
ILLUMINATE WHEN PROPERLY CONNECTED AND CHARGING.

2. CHANGING DRIVER BITS 3. SWIVEL HANDLE
Installing CRV Bits
1. Insert the CRV bit directly into the bit holder until it clicks into place.
Removing CRV Bits
1. Pull the quick connect chuck back to release the CRV bit.
2. Whilst holding the chuck back, pull the CRV bit to remove from the
bit holder.
Inline Position
1. Hold the handle locking
button down.
2. Rotate the handle clockwise until it clicks into position.
Angled Position
1. Hold the handle locking
button down.
2. Rotate the handle anti-clockwise until it clicks into position.

On / Off Trigger
Forward / Reverse Lever
1. For forward rotation, push the lever hard left. For reverse rotation
push lever to the right.
Adjusting the Torque Collar
1. Locate the arrow on the front of torque collar.
2. Rotate the torque collar to the desired setting (the higher the
number, the higher the torque or twisting action the screwdriver will
produce).
Note: When using your screwdriver for various driving applications, it
becomes necessary to increase and decrease the power and torque
in order to prevent the possibility of damaging screw heads, threads
or the work piece.
3. Hold the screwdriver rmly and place the bit on the screw to be
fastened.
Note: Do not force the screwdriver or apply side pressure to elongate
the hole. Let the screwdriver do the work.
SDL-4000
4. CONTROLS 5. SCREWDRIVING
FWD REV
FWD REV
OPERATION
1. To start driving squeeze the
on/off trigger.
2. To stop driving release the on/
off trigger.
1. Select the desired handle
position.
2. Check the forward/reverse
lever is on desired setting.
4. Squeeze the on/off trigger to
start the screwdriver.
5. Fasten the screw into the
workpiece.

MAINTENANCE
DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
TROUBLESHOOTING
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
On/off trigger is locked
Ensure that the forward / reverse lever is in the correct position; pressed left for
forwards direction, pressed right for backwards direction. If it is in between the two
settings the on/off trigger will be locked.
Charging Adaptor SPSDL4000-26
Base Assembly SPSDL4000-27A
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR
BATTERY CHARGER.
1. Before using the charger read all instructions and cautionary markings on the charger, battery pack and
the product using the battery pack.
2. This charger is not intended for any uses other than charging rechargeable batteries. Any other use may
result in risk of re, electric shock or electrocution.
3. Do not place any object on top of the charger or place the charger on a soft surface that may result in
excessive internal heat. Place the charger in a position away from any heat source.
4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when discon-
necting the charger.
5. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to
damage or stress.
6. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord could
result in the risk of re, electric shock or electrocution.
7. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any
way. Have it checked by an electrician or power tool repairer.
8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is
required. Incorrect reassembly may result in a risk of electric shock, electrocution or re.
9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning.
Removing the battery pack will not reduce this risk.
10. Never attempt to connect 2 chargers together.
11. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 40ºC
(such as inside sheds or metal buildings in summer).
12. The charger is designed to operate on standard household electrical power (240 volts). Do not attempt to
use it on any other voltage!
13. The battery pack is not fully charged out of the carton. First read the safety instructions and then follow
the charging notes and procedures.
14. The longest life and best performance can be obtained if the battery pack is charged when the air tem-
perature is between 18 - 24ºC. Do not charge the battery pack in an air temperature below 10ºC or above
40ºC. This is important and will prevent damage to the battery pack.
15. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery can
explode in a re.
16. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or
cracks, immediately discontinue use and do not recharge.
17. During charging, the battery must be placed in a well ventilated area.
BATTERY AND CHARGER SAFETY WARNINGS
Warning Read instruction manual
mA Milliamperes
Polarity
Thermal cut-out protection
Transformer Energy
Rating (MEPS)
Double insulated
/min Revolutions or
reciprocation per minute
Ah Amp hour
Indoor use only
Electrical Emissions
Conformity (EMC)
Nm Newton Meters
no No load speed
V Volts Hz Hertz
ac/~ Alternating current W Watts
Direct current
dc/
Isolation transformer
1. When not in use, the screwdriver should be stored in a dry, frost
free location, keep out of children’s reach.
2. Keep ventilation slots of the screwdriver clean at all times and
prevent any from entering.
3. If the housing of the screwdriver requires cleaning, do not use
solvents but cloth only.
4. Blow out the ventilation slots with compressed air periodically .
Note: Ozito Industries will not be responsible for any damage or
injuries caused by repair of the screwdriver by an unauthorised
person or by mishandling of the tool.

SPARE PARTS Tool:
Model No.
Item
No. Description Part No.
How To Order
Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any
further questions, please contact Ozito Customer Service on:
Australia: 1800 069 486
New Zealand: 0508 069 486
[email protected]
The following is a list of spare parts carried by Ozito.
Please contact Customer Service for any parts not
listed.
Tool: 3.6V Li-ion Screwdriver with Charging Base
Model No. SDL-4000
24
25
19
16
15
26
28
29
30
31
27
18
17
14 13
10 11
8
9
12
20 23
21
22
1
7
5
6
4
3
2
Item
No. Description Part No.
26 Charging Adaptor SPSDL4000-26
27 Base Assembly SPSDL4000-27A

SCREWDRIVER SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
This tools charger is double insulated in accordance with AS/NZS 60745-1;
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid
a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitable for the power input of the tool or which is damaged or defective may result in a risk of re and electric
shock.
To reduce the risk of electric shock, this product must be used with a residual current device (rated at 30mA
or less).
GENERAL POWER TOOL SAFETY WARNINGS - PERSONAL SAFETY
ELECTRICAL SAFETY
WARNING! Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory may contact hidden
wiring or its own cord. Cutting accessory contacting a “live” wire may make
exposed metal parts of the power tool “live” and could give the operator an electric
shock. Before drilling into walls, ceilings etc, ensure that there are no concealed
power cables or pipes in the cavity.
WARNING! Some dust created by power sanding, sawing, grinding,
drilling and other construction activities contain chemicals known to cause
cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products
• Arsenic and chromium from chemically treated timber
Your risk from exposure to these chemicals varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals: work in a well
ventilated area and work with approved safety equipment, such as dust masks that
are specially designed to lter out microscopic particles.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Battery tool use and care
a. Recharge only with the charger specied by the manufacturer. A charger that is suitable for one
type of battery pack may create a risk of re when used with another batery pack.
b. Use power tools only with specically designated battery packs. Use of any other battery packs
may create a risk of injury and re.
c. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects, that can make a connection from one terminal
to another. Shorting the battery terminals together may cause burns or a re.
d. Under abusive conditions, liquid may be ejected from the battery; aviod contact. If contact
accidentally occurs, ush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
6. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.

IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
0513
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the
original date of purchase and is intended for DIY (Do It Yourself)
use only. If a product is defective it will be replaced in accordance
with the terms of this warranty. Lithium Ion batteries are covered
by a 12 month warranty. Warranty excludes consumable parts, for
example: driver bits, etc.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
