PacketLight Networks PL-1000RO 3.3 Manual

PL-1000RO 3.3 INSTALLATION AND
CONFIGURATION MANUAL

PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED.
PL-1000RO 3.3 Installation and Configuration Manual
The information and content contained in this document is proprietary and copyrighted to © 2013
PacketLight Networks, Ltd. All Rights Reserved. The information shall not be used, copied,
reproduced, or disclosed in whole or in part without the written consent of PacketLight Networks, Ltd.
PacketLight Networks, Ltd. reserves the right, without prior notice or liability, to make changes in
equipment design or specifications. Information supplied by PacketLight Networks, Ltd. is believed to
be accurate and reliable. However, no responsibility is assumed by PacketLight Networks, Ltd. for the
use thereof, nor for the rights of third parties which may be affected in any way by the use thereof.
Any representation(s) in this document concerning performance of PacketLight Networks, Ltd.’s
product(s) are for informational purposes only and are not warranties of future performance, either
express or implied.
IN NO EVENT WILL PACKETLIGHT BE LIABLE FOR ANY LOST REVENUE, PROFIT, OR DATA, OR FOR
SPECIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL, OR PUNITIVE DAMAGES HOWEVER CAUSED
AND REGARDLESS OF THE THEORY OF LIABILITY ARISING OUT OF THE USE OF OR INABILITY TO USE
HARDWARE OR SOFTWARE EVEN IF PACKETLIGHT HAD BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. In no event shall PacketLight's liability to Customer, whether in contract, tort
(including negligence), or otherwise, exceed the price paid by Customer. The foregoing limitations
shall apply even if the above-stated warranty fails of its essential purpose. BECAUSE SOME STATES
OR JURISDICTIONS DO NOT ALLOW LIMITATION OR EXCLUSION OF CONSEQUENTIAL OR
INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE I
Contents
1INTRODUCTION............................................................................................. 1
1.1 OVERVIEW ................................................................................................. 1
1.1.1 MAIN FEATURES................................................................................. 1
1.1.2 TYPICAL APPLICATION.......................................................................... 2
1.1.3 PHYSICAL DESCRIPTION ....................................................................... 4
1.2 PL-1000RO CONFIGURATIONS ........................................................................ 5
1.2.1 MUX/DEMUX MODULE CONFIGURATIONS ................................................. 5
1.2.2 WSS MODULE CONFIGURATIONS ............................................................ 8
1.2.3 EDFA MODULE CONFIGURATIONS............................................................ 9
1.2.4 POWER SUPPLY UNIT CONFIGURATIONS ....................................................10
1.2.5 FAN UNIT CONFIGURATION ..................................................................10
1.3 PL-1000RO MANAGEMENT............................................................................10
1.3.1 MANAGEMENT PORTS..........................................................................11
1.3.2 MANAGEMENT FUNCTIONALITY ...............................................................12
1.3.3 MANAGEMENT PROTOCOLS ...................................................................12
1.4 TECHNICAL SPECIFICATIONS ...........................................................................13
1.4.1 GENERAL SPECIFICATIONS....................................................................13
1.4.2WSS SPECIFICATIONS ........................................................................17
2INSTALLATION............................................................................................ 19
2.1 SAFETY PRECAUTIONS...................................................................................19
2.1.1 GENERAL SAFETY PRECAUTIONS .............................................................19
2.1.2 ELECTRICAL SAFETY PRECAUTIONS..........................................................19
2.1.3 PROTECTION AGAINST ELECTROSTATIC DISCHARGE ......................................21
2.2 SITE REQUIREMENTS ....................................................................................21
2.2.1 PHYSICAL REQUIREMENTS ....................................................................21
2.2.2 POWER REQUIREMENTS .......................................................................21
2.2.3 AMBIENT REQUIREMENTS .....................................................................21
2.2.4 ELECTROMAGNETIC COMPATIBILITY CONSIDERATIONS ...................................22
2.3 INSTALLING THE PL-1000RO UNIT ..................................................................22
2.3.1 PACKAGE CONTENTS ..........................................................................22
2.3.2 REQUIRED EQUIPMENT ........................................................................23
2.3.3 CABLE CONNECTIONS .........................................................................23
2.3.4 CABLING EXAMPLES ...........................................................................26

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE II
3OPERATION AND PRELIMINARY CONFIGURATION ...................................... 29
3.1 OPERATING INSTRUCTIONS.............................................................................29
3.1.1 CONNECTING AND CONFIGURING THE TERMINAL ..........................................29
3.1.2 TURNING ON THE PL-1000RO..............................................................30
3.2 PERFORMING PRELIMINARY CONFIGURATION.........................................................30
3.3 ACCESSING THE WEB APPLICATION ...................................................................31
3.3.1 WEB BROWSER REQUIREMENTS .............................................................31
3.3.2 PREREQUISITES FOR ACCESSING THE WEB APPLICATION ................................32
3.3.3 LOGGING IN TO THE WEB APPLICATION ....................................................32
3.4 NAVIGATING THE WEB APPLICATION..................................................................33
3.4.1 ITEM BUTTONS .................................................................................33
3.4.2 SIDEBAR BUTTONS ............................................................................34
3.4.3 TABS.............................................................................................35
3.5 LOGGING OUT OF THE WEB APPLICATION ............................................................36
4SECURITY MANAGEMENT............................................................................. 37
4.1 USER ACCESS LEVELS...................................................................................37
4.2 USER AUTHENTICATION METHODS ....................................................................37
4.2.1 LOCAL AUTHENTICATION......................................................................38
4.2.2 REMOTE AUTHENTICATION....................................................................38
4.3 SECURITY SETTINGS.....................................................................................40
4.3.1 USERS TAB (ADMINISTRATOR) ..............................................................41
4.3.2 USERS TAB (NON-ADMINISTRATOR)........................................................43
4.3.3 RADIUS TAB (ADMINISTRATOR) .............................................................45
5FAULT MANAGEMENT................................................................................... 47
5.1 FAULT VIEWS.............................................................................................47
5.1.1 ALARMS .........................................................................................47
5.1.2 EVENTS..........................................................................................47
5.1.3 CONFIGURATION CHANGES ...................................................................48
5.2 GENERAL FAULT VIEWING PROCEDURE ...............................................................48
5.3 SYSTEM FAULTS..........................................................................................49
5.3.1 ALARMS TAB....................................................................................50
5.3.2 EVENTS TAB ....................................................................................52
5.3.3 CONFIGURATION CHANGES TAB .............................................................54
5.4 ALL FAULTS...............................................................................................55
5.4.1 ALARMS TAB....................................................................................56
5.4.2 EVENTS TAB ....................................................................................58

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE III
5.4.3 CONFIGURATION CHANGES TAB .............................................................60
5.5 WSS FAULTS.............................................................................................61
5.5.1 ALARMS TAB....................................................................................62
5.5.2 EVENTS TAB ....................................................................................64
5.5.3 CONFIGURATION CHANGES TAB .............................................................66
5.6 MANAGEMENT PORT FAULTS............................................................................67
5.6.1 ALARMS TAB....................................................................................68
5.6.2 EVENTS TAB ....................................................................................70
5.6.3 CONFIGURATION CHANGES TAB .............................................................71
5.7 ETHERNET PORT FAULTS ................................................................................73
5.7.1 ALARMS TAB....................................................................................74
5.7.2 EVENTS TAB ....................................................................................76
5.7.3 CONFIGURATION CHANGES TAB .............................................................77
5.8 EDFA FAULTS............................................................................................79
5.8.1 ALARMS TAB....................................................................................80
5.8.2 EVENTS TAB ....................................................................................82
5.8.3 CONFIGURATION CHANGES TAB .............................................................83
5.9 PSU FAULTS..............................................................................................85
5.9.1 ALARMS TAB....................................................................................86
5.9.2 EVENTS TAB ....................................................................................88
5.9.3 CONFIGURATION CHANGES TAB .............................................................89
6CONFIGURATION MANAGEMENT.................................................................. 91
6.1 CONFIGURATION OPTIONS..............................................................................91
6.2 GENERAL CONFIGURATION PROCEDURE ..............................................................92
6.3 SYSTEM CONFIGURATION ...............................................................................93
6.3.1 GENERAL TAB ..................................................................................94
6.3.2 INVENTORY TAB................................................................................96
6.3.3 LICENSE TAB ...................................................................................97
6.3.4 TIME TAB .......................................................................................97
6.3.5 IP TAB ..........................................................................................99
6.3.6 SNMP TAB ...................................................................................102
6.3.7 SYSLOG TAB..................................................................................104
6.4 WSS CONFIGURATION................................................................................105
6.4.1 GENERAL TAB ................................................................................106
6.4.2 PROVISIONING TAB..........................................................................107
6.5 MANAGEMENT PORT CONFIGURATION...............................................................109
6.5.1 MNG TAB.....................................................................................110
6.5.2 SFP TAB ......................................................................................112

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE IV
6.5.3 ALS TAB......................................................................................113
6.6 ETHERNET PORT CONFIGURATION ...................................................................115
6.6.1 ETHERNET TAB ...............................................................................115
6.7 MUX/DEMUXCONFIGURATION.....................................................................117
6.7.1 MUX/DEMUX TAB..........................................................................117
6.8 EDFA CONFIGURATION ...............................................................................118
6.8.1 EDFA TAB....................................................................................119
6.9 PSU CONFIGURATION .................................................................................121
6.9.1 PSU TAB......................................................................................122
6.10 FAN UNIT CONFIGURATION ..........................................................................123
6.10.1 FAN UNIT TAB...............................................................................123
7PERFORMANCE MONITORING.................................................................... 126
7.1 OPTICAL INFORMATION ...............................................................................126
7.1.1 OPTICAL INFORMATION TAB................................................................127
7.2 WSS MONITORING ....................................................................................128
7.2.1 WSS MONITORING TAB ....................................................................129
7.3 MANAGEMENT PORT PERFORMANCE MONITORING.................................................130
7.3.1 VIEWING OPTICAL PERFORMANCE MONITORING.........................................131
7.4 EDFA PERFORMANCE MONITORING .................................................................133
7.4.1 VIEWING OPTICAL PERFORMANCE MONITORING.........................................134
8MAINTENANCE........................................................................................... 137
8.1 SYSTEM MAINTENANCE................................................................................137
8.1.1 RESTART TAB.................................................................................138
8.1.2 LOG FILES TAB...............................................................................139
8.1.3 CONFIGURATION TAB........................................................................141
8.1.4 SOFTWARE TAB ..............................................................................144
8.2 EXTERNAL ALARM MAINTENANCE ....................................................................146
8.2.1 EXTERNAL ALARM MAINTENANCE TAB.....................................................147
9TOPOLOGY MANAGEMENT.......................................................................... 149
9.1 NETWORK TOPOLOGY..................................................................................149
9.1.1 NETWORK TOPOLOGY TAB ..................................................................150
9.1.2 ZOOMING IN AND OUT OF THE TOPOLOGY DISPLAY.....................................153
9.1.3 BROWSING OTHER NODES .................................................................153
9.1.4DEFINING MULTIPLE NODES AS MULTI-CHASSIS........................................153
10 REMOTE MANAGEMENT CONFIGURATION.................................................. 157
10.1 REMOTE MANAGEMENT CONFIGURATION EXAMPLE ................................................157

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE V
10.1.1 SETTING UP POINT-TO-POINT MANAGEMENT............................................157
10.1.2 CONFIGURING MANAGEMENT FOR PL-1000RO A......................................158
10.1.3 CONFIGURING MANAGEMENT FOR PL-1000RO B......................................159
10.1.4 ACCESSING THE WEB APPLICATION FROM MANAGEMENT A TO PL-1000RO A.....161
10.1.5 ACCESSING THE WEB APPLICATION FROM MANAGEMENT A TO PL-1000RO B.....161
10.1.6 ACCESSING THE WEB APPLICATION FROM MANAGEMENT B TO PL-1000RO B.....162
10.1.7 ACCESSING THE WEB APPLICATION FROM MANAGEMENT B TO PL-1000RO A.....162
11 CLI............................................................................................................. 165
11.1 GENERAL FEATURES ...................................................................................165
11.2 ACCESSING THE CLI ..................................................................................165
11.2.1 USING A SERIAL PORT ......................................................................166
11.2.2 USING TELNET ...............................................................................166
11.2.3 USING SSH ..................................................................................167
11.3 CLI COMMAND TYPES .................................................................................168
11.4 RUNNING CLI COMMANDS............................................................................169
11.4.1 GENERAL COMMANDS .......................................................................170
11.4.2 PING COMMAND..............................................................................172
11.4.3 INTERFACE COMMANDS .....................................................................173
11.4.4 IP SETTING COMMANDS ....................................................................174
11.4.5 LOG COMMANDS .............................................................................176
11.4.6 SHOW COMMANDS...........................................................................176
11.4.7 SYSTEM RESTART COMMAND...............................................................178
APPENDIX A: CONNECTION DATA................................................................. 179
A.1 CONTROL CONNECTOR..............................................................................179
A.2 ALARM CONNECTOR..................................................................................179
A.3 ETH CONNECTOR......................................................................................182
A.4 OPTICAL PL-1000RO CONNECTORS ...............................................................182
A.4.1 DATA PORTS..................................................................................182
A.4.2 MNG PORTS..................................................................................183
A.4.3 MUX/DEMUX PORT ........................................................................183
A.5 POWER SUPPLY COMBINATIONS .....................................................................183
A.6 POWER CONNECTORS .................................................................................184
A.7 PROTECTIVE GROUND TERMINAL ....................................................................185
A.8 FIBER SHELF............................................................................................186
APPENDIX B: ALARM AND EVENT MESSAGES................................................ 187
B.1 ALARM MESSAGES .....................................................................................187
B.2 CONFIGURATION EVENT MESSAGES.................................................................189
B.3 OTHER EVENT MESSAGES ............................................................................189

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE VI
APPENDIX C: TROUBLESHOOTING CHART .................................................... 191
C.1 TROUBLESHOOTING CHART...........................................................................191
INDEX............................................................................................................. 193

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE VII
List of Figures
Figure 1: Typical Application for PL-1000RO Devices.................................................. 3
Figure 2: Example Application................................................................................. 4
Figure 3: PL-1000RO Unit without MUX/DEMUX......................................................... 4
Figure 4: PL-1000RO Front Panel without MUX/DEMUX............................................... 5
Figure 5: PL-1000RO Data Ports without MUX/DEMUX................................................ 6
Figure 6: PL-1000RO without MUX/DEMUX inside a Ring (Example)............................. 7
Figure 7: PL-1000RO Data Ports with MUX/DEMUX .................................................... 7
Figure 8: PL-1000RO with MUX/DEMUX inside a Ring (Example).................................. 8
Figure 9: WSS Architecture..................................................................................... 9
Figure 10: PL-1000RO Management Ports................................................................11
Figure 11: Class 3B Laser Warning .........................................................................20
Figure 12: Cabling of a Ring PL-1000RO without MUX/DEMUX (Example) ....................27
Figure 13: Cabling of a Ring PL-1000RO with MUX/DEMUX (Example).........................27
Figure 14: Login Window.......................................................................................32
Figure 15: System Configuration Window ................................................................33
Figure 16: PL-1000RO Item Buttons (Example)........................................................33
Figure 17: PL-1000RO Sidebar Buttons ...................................................................34
Figure 18: PL-1000RO Tabs (Example)....................................................................35
Figure 19: PL-1000RO Users Tab............................................................................36
Figure 20: Security Settings Window.......................................................................40
Figure 21: Users Tab (Administrator)......................................................................41
Figure 22: Confirm Changes ..................................................................................42
Figure 23: Confirm Changes ..................................................................................43
Figure 24: Confirm Delete .....................................................................................43
Figure 25: Users Tab (Non-Administrator) ...............................................................43
Figure 26: Confirm Changes ..................................................................................44
Figure 27: Radius Tab (Administrator).....................................................................45
Figure 28: Confirm Configuration............................................................................45
Figure 29: System Fault Window ............................................................................49
Figure 30: Alarms Tab...........................................................................................50
Figure 31: Events Tab...........................................................................................52
Figure 32: Configuration Changes Tab.....................................................................54
Figure 33: All Fault Window ...................................................................................55
Figure 34: Alarms Tab...........................................................................................56
Figure 35: Events Tab...........................................................................................58
Figure 36: Configuration Changes Tab.....................................................................60
Figure 37: WSS Fault Window................................................................................61
Figure 38: Alarms Tab...........................................................................................62
Figure 39: Events Tab...........................................................................................64
Figure 40: Configuration Changes Tab.....................................................................66
Figure 41: Management Port Fault Window..............................................................67

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE VIII
Figure 42: Alarms Tab...........................................................................................68
Figure 43: Events Tab...........................................................................................70
Figure 44: Configuration Changes Tab.....................................................................71
Figure 45: Ethernet Port Fault Window....................................................................73
Figure 46: Alarms Tab...........................................................................................74
Figure 47: Events Tab...........................................................................................76
Figure 48: Configuration Changes Tab.....................................................................77
Figure 49: EDFA Fault Window...............................................................................79
Figure 50: Alarms Tab...........................................................................................80
Figure 51: Events Tab...........................................................................................82
Figure 52: Configuration Changes Tab.....................................................................83
Figure 53: PSU Fault Window.................................................................................85
Figure 54: Alarms Tab...........................................................................................86
Figure 55: Events Tab...........................................................................................88
Figure 56: Configuration Changes Tab.....................................................................89
Figure 57: System Configuration Window ................................................................93
Figure 58: General Tab..........................................................................................94
Figure 59: Inventory Tab.......................................................................................96
Figure 60: License Tab..........................................................................................97
Figure 61: Time Tab..............................................................................................97
Figure 62: IP Tab - Dual Networks..........................................................................99
Figure 63: IP Tab - Single Network.......................................................................100
Figure 64: Confirm Changes ................................................................................101
Figure 65: SNMP Tab ..........................................................................................102
Figure 66: Syslog Tab.........................................................................................104
Figure 67: Confirm Configuration..........................................................................104
Figure 68: Confirm Configuration..........................................................................105
Figure 69: WSS Configuration Window ..................................................................105
Figure 70: General Tab........................................................................................106
Figure 71: Provisioning Tab .................................................................................107
Figure 72: Management Port Window....................................................................109
Figure 73: MNG Tab............................................................................................110
Figure 74: Confirm Changes ................................................................................110
Figure 75: Confirm Changes ................................................................................111
Figure 76: SFP Tab.............................................................................................112
Figure 77: ALS Tab.............................................................................................113
Figure 78: Ethernet Port Window..........................................................................115
Figure 79: Ethernet Tab ......................................................................................115
Figure 80: MUX/DEMUX Configuration Window.......................................................117
Figure 81: MUX/DEMUX Tab.................................................................................117
Figure 82: EDFA Configuration Window .................................................................118
Figure 83: EDFA Tab...........................................................................................119
Figure 84: Confirm Changes ................................................................................119
Figure 85: Confirm Changes ................................................................................120

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE IX
Figure 86: PSU Configuration Window ...................................................................121
Figure 87: PSU Tab.............................................................................................122
Figure 88: FAN Unit Configuration Window.............................................................123
Figure 89: FAN Unit Tab......................................................................................123
Figure 90: Optical Information Window .................................................................126
Figure 91: Optical Information Tab .......................................................................127
Figure 92: WSS Monitoring Window ......................................................................128
Figure 93: WSS Monitoring Tab............................................................................129
Figure 94: Management Port Performance Monitoring Window..................................130
Figure 95: Optical Level Performance Monitoring ....................................................131
Figure 96: EDFA Performance Monitoring Window...................................................133
Figure 97: Optical Level Performance Monitoring ....................................................134
Figure 98: System Maintenance Window................................................................137
Figure 99: Restart Tab ........................................................................................138
Figure 100: Confirm Changes...............................................................................138
Figure 101: Confirm Changes...............................................................................139
Figure 102: Confirm Changes...............................................................................139
Figure 103: Log Files Tab ....................................................................................139
Figure 104: System Log Files (Example)................................................................140
Figure 105: Configuration Tab..............................................................................141
Figure 106: Opening .cfg Dialog Box.....................................................................142
Figure 107: Update System Configuration: Configuration File...................................143
Figure 108: Confirm System Overwrite..................................................................143
Figure 109: System Updating and Restarting Message ............................................143
Figure 110: Software Tab....................................................................................144
Figure 111: Software Download Message...............................................................145
Figure 112: Software Download Status Window......................................................145
Figure 113: Confirm Changes...............................................................................145
Figure 114: Confirm Changes...............................................................................146
Figure 115: External Alarm Maintenance Window ...................................................146
Figure 116: External Alarm Tab............................................................................147
Figure 117: Network Topology Window..................................................................149
Figure 118: Network Topology Tab .......................................................................150
Figure 119: Linear Topology (Example).................................................................151
Figure 120: Ring Topology (Example) ...................................................................152
Figure 121: General Tab......................................................................................154
Figure 122: Multi-Chassis Nodes...........................................................................155
Figure 123: Point-to-Point Remote Management (Example) .....................................157
Figure 124: IP Addresses: PL-1000RO A (Example) ................................................158
Figure 125: SNMP Traps Table (Example)..............................................................159
Figure 126: IP Addresses: PL-1000RO B (Example) ................................................160
Figure 127: Static Routing Table (Example)...........................................................160
Figure 128: SNMP Traps Table (Example)..............................................................161
Figure 129: CLI Command Tree............................................................................169
Figure 130: External ALARM Diagram....................................................................180

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE X
Figure 131: DC Connector Wiring Diagram.............................................................184
Figure 132: Protective Ground Terminal Wiring Diagram..........................................185
Figure 133: Fiber Shelf Diagram...........................................................................186

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE XI
List of Tables
Table 1: General Specifications ..............................................................................13
Table 2: WSS Specifications...................................................................................17
Table 3: Configure Interface Ethernet IP Command Options.......................................31
Table 4: User Access Levels...................................................................................37
Table 5: Attributes Used........................................................................................38
Table 6: Users Tab Parameters (Administrator)........................................................41
Table 7: Users Tab Parameters (Non-Administrator) .................................................44
Table 8: Radius Tab Parameters (Administrator).......................................................46
Table 9: Alarms Tab Parameters.............................................................................51
Table 10: Events Tab Parameters ...........................................................................53
Table 11: Configuration Changes Tab Parameters.....................................................55
Table 12: Alarms Tab Parameters...........................................................................57
Table 13: Events Tab Parameters ...........................................................................59
Table 14: Configuration Changes Tab Parameters.....................................................61
Table 15: Alarms Tab Parameters...........................................................................64
Table 16: Events Tab Parameters ...........................................................................65
Table 17: Configuration Changes Tab Parameters.....................................................67
Table 18: Alarms Tab Parameters...........................................................................69
Table 19: Events Tab Parameters ...........................................................................71
Table 20: Configuration Changes Tab Parameters.....................................................72
Table 21: Alarms Tab Parameters...........................................................................75
Table 22: Events Tab Parameters ...........................................................................77
Table 23: Configuration Changes Tab Parameters.....................................................78
Table 24: Alarms Tab Parameters...........................................................................81
Table 25: Events Tab Parameters ...........................................................................83
Table 26: Configuration Changes Tab Parameters.....................................................84
Table 27: Alarms Tab Parameters...........................................................................87
Table 28: Events Tab Parameters ...........................................................................89
Table 29: Configuration Changes Tab Parameters.....................................................90
Table 30: General Tab Parameters..........................................................................94
Table 31: Inventory Tab Parameters.......................................................................96
Table 32: Time Tab Parameters..............................................................................98
Table 33: IP Tab Parameters................................................................................101
Table 34: SNMP Tab Parameters...........................................................................103
Table 35: Syslog Tab Parameters .........................................................................105
Table 36: General Tab Parameters........................................................................107
Table 37: Provisioning Tab Parameters..................................................................108
Table 38: MNG Tab Parameters............................................................................111
Table 39: SFP Tab Parameters .............................................................................112
Table 40: ALS Tab Parameters .............................................................................114
Table 41: Ethernet Tab Parameters.......................................................................116
Table 42: MUX/DEMUX Tab Parameters.................................................................118

CONTENTS
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE XII
Table 43: EDFA Tab Parameters ...........................................................................120
Table 44: PSU Tab Parameters.............................................................................122
Table 45: FAN Unit Tab Parameters ......................................................................124
Table 46: Optical Information Tab Parameters........................................................127
Table 47: WSS Monitoring Tab Parameters ............................................................129
Table 48: Management Port Optical Level PM Parameters ........................................132
Table 49: EDFA Optical Level PM Parameters .........................................................135
Table 50: External Alarm Maintenance Tab Parameters ...........................................147
Table 51: CONTROL Connector Wiring...................................................................179
Table 52: ALARM Interface, Pin Function ...............................................................181
Table 53: ETH Port Connector, Pin Functions..........................................................182
Table 54: Data Ports Specifications.......................................................................182
Table 55: MNG Ports Specifications.......................................................................183
Table 56: MUX/DEMUX Port Specifications .............................................................183
Table 57: Alarm Messages...................................................................................187
Table 58: Configuration Event Messages................................................................189
Table 59: Other Event Messages ..........................................................................189
Table 60: Troubleshooting Chart...........................................................................191

INTRODUCTION
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE 1
1Introduction
This chapter provides an overview of the PL-1000RO.
In this Chapter
Overview...............................................................................................1
PL-1000RO Configurations.......................................................................5
PL-1000RO Management .......................................................................10
Technical Specifications.........................................................................13
1.1 Overview
The PL-1000RO provides reconfigurable Optical Add-Drop Multiplexer (ROADM)
functionality based on the wavelength-selective switch (WSS) technology.
ROADM based network architecture simplifies configuration and management of
complex DWDM network infrastructure. PL-1000RO's ROADM solution offers
flexible wavelength routing capabilities suitable for ring, linear add/drop, core
and edge DWDM network topologies.
The PL-1000RO ROADM can be configured dynamically to add/drop selected
wavelengths at any site in the network and seamlessly change the network node
capacity as needed. In addition, it automatically maintains the equalization and
power balance of the added and bypassed wavelengths. It can integrate Erbium
Doped Fiber Amplifier (EDFA) modules for amplifying the wavelengths and
delivering effective long distance DWDM solutions.
The PL-1000RO is a highly integrated device that can incorporate a DWDM
MUX/DEMUX module in addition to the EDFA modules.
The PL-1000RO is fully interoperable with PacketLight's family of products.
1.1.1 Main Features
The PL-1000RO combines the following key functionalities:
•Flexible wavelengths add/drop
•Variable optical attenuator (VOA) for optical power equalization
•44 DWDM C-Band channels with 100 GHz spacing or
88 DWDM C-Band channels with 50 GHz spacing
•Manual or automatic channel equalization
•Supports 40 Gbps and 100 Gbps signal rates
•Supports linear add/drop and ring topologies
•Two 100M management ports based on SFP optics for local or remote
management using an Optical Supervisory Channel (OSC)
•Automatic Laser Shutdown (ALS) on management ports

INTRODUCTION
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE 2
•Optional one or two Booster and/or Pre-Amp EDFA modules for optical power
amplification
•Optional MUX/DEMUX module
•The following management protocols are available for configuration,
monitoring, and provisioning:
CLI over a serial or Telnet/SSH connection
Web-based HTTP/HTTPS management
SNMP management interface
Remote Authentication Dial In User Service (Radius) protocol for
centralized remote user authentication
Syslog protocol
Simple Network Time Protocol (SNTP) for network timing
TFTP and FTP for file transfer
Rapid Spanning Tree Protocol (RSTP)
•Supports Operations, Administration, and Maintenance (OAM) functions:
Alarm and Event fault management
Optical channel monitoring (OCM) for all channels
Performance monitoring (PM)
External alarms
•Pluggable FAN unit
•AC and DC, single or dual pluggable power supply units (PSUs)
1.1.2 Typical Application
The PL-1000RO can be managed using Command Line Interface (CLI) over a
serial or Telnet/Secure Shell (SSH) connection, Web management over
HTTP/HTTPS, or SNMP.
As with other PacketLight devices, the PL-1000RO can be managed with
PacketLight’s LightWatch™ NMS/EMS (network management system). For
information about LightWatch, see the LightWatch Getting Started Guide.
The PL-1000RO can be used to:
•Expand existing fiber capacity regardless of service type
•Build scalable, high-capacity, pay-as-you-grow optical networks
•Converge existing networks and new services over existing infrastructure
•Provide a fully optical layer solution, transparent to service rate and type
•Build cost-effective add and drop networks

INTRODUCTION
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE 3
•Integrate with third-party DWDM optical solutions and colored optics
Typically the PL-1000RO may be used in a ring or linear add/drop topology.
The following figure illustrates a ring with four sites connected with PL-1000RO
devices.
Figure 1: Typical Application for PL-1000RO Devices

INTRODUCTION
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE 4
1.1.2.1 Example Application
The following figure illustrates a typical application that shows four sites
connected in a DWDM ring of six wavelengths. Each site has two PL-1000RO
units, one PL-300 device, and two PL-1000 devices. Using the PL-1000RO node,
the user is able to dynamically change the route of the 10G services between the
PL-1000 devices by defining the provisioning of add/drop and express channels in
each site.
Figure 2: Example Application
1.1.3 Physical Description
The PL-1000RO is a compact unit intended for installation in a 19-inch or 23-inch
rack or placed on a desktop or shelf.
The PL-1000RO unit is a 19-inch/1U ETSI compliant unit with single or dual
field-replaceable AC and/or DC power supplies and a pluggable FAN unit.
Figure 3: PL-1000RO Unit without MUX/DEMUX

INTRODUCTION
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE 5
All connections are made to the front panel. The PL-1000RO front panel also
includes indicator LEDs that show its operating status.
The following figure shows the function of the connectors on the front panel.
Figure 4: PL-1000RO Front Panel without MUX/DEMUX
1.2 PL-1000RO Configurations
This section describes some of the available configurations of the PL-1000RO.
1.2.1 MUX/DEMUX Module Configurations
The PL-1000RO has two basic configurations:
•Without a MUX/DEMUX module
•With a MUX/DEMUX module

INTRODUCTION
PACKETLIGHT NETWORKS PL-1000RO 3.3 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION.ALL RIGHTS RESERVED. PAGE 6
1.2.1.1 PL-1000RO without MUX/DEMUX
The following figure shows the front panel of the PL-1000RO without a
MUX/DEMUX module.
Figure 5: PL-1000RO Data Ports without MUX/DEMUX
1.2.1.1.1 Data Ports without MUX/DEMUX
The following are the data ports of a PL-1000RO without a MUX/DEMUX module:
•COM: The common network port connected to the line.
•EXP: The express channels.
•A/D: The add/drop channels.
•OSC: The optical supervisory channel.
