pagertec ZEN User manual

ZEN
Outdoor Mobile
Charging Locker
A. Installation Guide
1
1. Locate ZEN to the proper location.Mark the
holes on wall.Drill 4 x Ø6mm holes on wall
according to the Mark. Fix 4 x screw studs and
4 x screws on wall (not included).
Ø8mm Ø8mm
350 mm
784
620
72
132
350
350 49
457
58
680

B. Replace Cable
1. Open the control box
door with key provided.
2. Unlock the door by
pressing the button on
the lock.
3.Open the cable clip.
4. Unplug USB Cable.
5. Take out the cable through the hole.
13
4
2
2

- Input : AC 100 - 240V / 50~60Hz
- Material (Housing) : Cold Rolled Steel
- Dimensions:
785mm (H) x 457mm (W) x80mm (D)
Regular version
Model No.: PL-ZN06-Y2
- Output (per locker box) : 5V/2.4A Max
PD version
Model No.: PD-ZN06-Y2
- Output (per locker box) : 20W Max
Type C Cable - 20W Max
Lightning Cable - 20W Max
Micro USB Cable - 10W Max
F. Specifications
C. Emergency
To enter the Administrator Mode, tap the hidden Gear
Icon at the top right corner of the main screen.
Administrative Mode
Enter 4-digit password
Enter 8-digit password
Administrator
1
2
3
4
5
6
7
8
9
0
Administrator
Reset Locker Box
Factory Reset
Modify Password
Volume
10.Open the front door by using the key
provided.
D. Reset to factory admin password
Reset to factory
admin password
- To Prevent fire on shock hazard.
- To avoid electric shock, please do not disassemble the
device.
- If trouble occurs,immediately disconnected the device
from wall socket.
Maintenance
- Wipe the device with a soft dry cloth to prevent dust
build up.
- keep the device away from strong volatile solvents or
chemicals, such as thinner,benzene,alcohol, pesticide,
rubber or vinyl plastic etc,which may lead to deterioration
or damage to your devices.
G. Notes on use

Replace UVC Light Bulb
1. Open the locker box door and unscrew
the M3 screw at the UVC light bulb case.
2. take off the UVC basket by unscrewing
the 2 x Screw.
4. twist the UVC light bulb to replace a new
one.
3.take off the UVC unit by unscrewing 2
screws on the unit.
UVC light bulb: 10V3W
Specifications of UVC light
