PAJ GPS POWER Finder User manual

POWER FINDER

USER MANUAL- PAJ GPS Finder WITH ONLINE-TRACKING
Thank you for purchasing a PAJ FINDER. Before using your
FINDER please read the instructions carefully. It will introduce
you to the handling and operation of the product. Please keep
the manual for future reference.
MANUAL DE INSTRUCCIONES - PAJ GPS Finder CON
LOCALIZACIÓN ONLINE
Muchas gracias comprar nuestro PAJ FINDER. Antes del
primer uso: Lea el manual de instrucciones atentamente antes
de utilizar el FINDER. Por favor guarde el manual para
consultas en el futuro.

This manual includes the languages
Este manual incluye los idiomas
1 English........................4
2 Spanish.....................20

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
4
Table of contents
1English
1.1 What's included ............................................. 5
1.2 Product graphics ........................................... 5
1.3 Loading.......................................................... 6
1.4 How do I activate the FINDER? ...................... 6
1.5 Turning on/off ............................................... 6
1.6 How do I track my vehicle with
the FINDER?................................................... 7
1.7 LED lights ...................................................... 8
1.8 Technical data............................................... 9
1.9 Safety instructions ...................................... 10
1.10 Note on the disposal of
used batteries.............................................. 17
1.11 Note on the disposal of
electric appliances ...................................... 18

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
5
1.1 What's included
In the delivery:
POWER Finder 4G by PAJ
M2M SIM card (is already inserted/ do not replace)
USB charging cable
Adhesive magnet (attach the red adhesive strips to the
desired object - do not stick on the FINDER!)
The latest version of this manual always can be downloaded
for free at
www.paj-gps.us/finder
The PAJ-GPS team wishes you lots of fun with your PAJ GPS
FINDER!
1.2 Product graphics
LED signal
Battery terminal
Button for the
battery indicator
Battery indicator

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
6
1.3 Loading
Before first using, the GPS Tracker should be charged for
approx. 8-12 hours. Connect the supplied charging cable to the
charging port of the GPS tracker. Then attach the USB port to
the socket adapter. As soon as none of the bars on the battery
display are flashing, the FINDER is charged.
The POWER Finder 4G offers you a running time of approx.
90 days without charging! However, it should be noted that
the duration depends on the load. The more PAJ's POWER
Finder 4G is moved and the more alerts are sent, the higher
the utilization.
1.4 How do I activate the FINDER?
In order to be able to use the PAJ GPS FINDER, it is necessary to
first activate the device online.
Note: To activate the device you need the ID of your FINDER.
These can be found on the barcode stuck on the device.
Please follow
www.finder-portal.us/go
for activation.
1.5 Turning on/off
Recommended first step: To receive the best GPS signal
place the POWER Finder 4G outside and make sure it is not
covered. Avoid garages, basements and similar.
If the activation has been carried out successfully, the FINDER
can be switched on. please follow these instructions:

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
7
1) Open the housing cover
2) Remove the rubber cover
Please do not remove or change the SIM card!
3) Slide the slider to "ON"
4) Put the rubber cover
back into the device
5) Click the housing cover back
into the device
The button next to the charging socket is only used to
display the battery. Just press the button once!
How do I see if the FINDER is on?
Please briefly press the battery button once.
BEHAVIOR
STATUS
The red LED and battery
indicator light up for
approx. 20 seconds
FINDER is switched on
Red LED and battery indicator
remain switched off
FINDER is switched off
1.6 How do I track my vehicle with the FINDER?
Once the activation and connection processes have been
successful, and the FINDER already has sent its first data, you
can go ahead with tracking your protected vehicle. Use the app

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
8
for IOs or Android, your tablet or computer. For online tracking
please visit:
www.finder-portal.us
The tracking service explains all functions online. Download
the app for free for IOS and Android here:
1.7 LED lights
Red LED
SIGNAL
MEANING
The red LED is off
Standby mode or FINDER is
switched off.
If the GPS tracker is not moved
(anymore), the GPS signal
switches off. As soon as the
GPS tracker is moved again,
the GPS signal automatically
switches on again.
The red LED flashes quickly
Reception available
The red LED flashes slowly
No signal available.
FINDER is looking for a signal.
Battery indicator
SIGNAL
MEANING
The battery indicator and the
red LED light up for approx. 10
seconds (if the FINDER is
connected to a cable)
FINDER is charging

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
9
(briefly press the ON / OFF
button to display the battery)
All bars of the battery indicator
are displayed constantly
FINDER is fully charged
1.8 Technical data
Dimensions
4,33 x 2,76 x 0,47 inch (109 ×
61 × 30,5mm)
GPS accuracy
Up to 3 meters
Standby time
About 90 days
Battery
3,7V 10.000mAh Li-Polymer
Weight
302g
Time to start
Cold start: 40 seconds
In Operation: 1 second
Network/Band
LTE Cat-M1/NB2: B1/B2/
B3/B4/B5/B8/B12/B13/B18/
B19/B20/B26/B28/B66
EGPRS:
GSM 850 MHz (max. 2W)
GSM 900 MHz (max. 2W)
DCS 1800 MHz (max. 1W)
PCS 1900 MHz (max. 1W)
GPS chip
MTK high sensitivity chip
GSM-/LTE-/GPRS-Modul
SIM7600E
GPS reception
-165dBm
Charger
110-290V, AC 50 Hz input 5V,
DC output
Storage
temperature
from -20°C to +50°C
Operating environment
from -10°C to +70°C
Air humidity
10%-70%

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
10
1.9 Safety instructions
Signal words
The following signal words are used in this manual:
WARNING! This classifies a hazard of medium risk level. Failure
to comply with the warning may result in serious injury.
Please note: This is a warning about possible damage to
property.
Proper use
Please read the safety instructions for this model, POWER Finder
4G, hereinafter only referred to as GPS tracker, carefully before
use in order to be able to deploy it properly. The intended use is
to employ the GPS tracker only as described in this manual to
locate a vehicle. Please bear in mind that it is a criminal offence
to monitor third parties using a GPS tracker without their
consent. If you use it in any other way, this is considered
improper use and can lead to damage to property or even
personal injury. Please note that the GPS tracker is not a toy for
children.
Please be aware in other countries and regions there are
different laws on digital positioning and localization of people,
animals and/or objects. PAJ GPS is not responsible if such laws
or regulations are violated, this is the sole responsibility of the
user.
Please note: Please note that changes or modifications not
expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Please note: The manufacturer and dealer accept no liability
for damage caused by improper or incorrect use.

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
11
Safety
WARNING! RISK OF ELECTROCUTION!
Please note: Please ensure that the installation is carried out
only by a specialist and competent person. Incorrect
installation may invalidate the operating permit.
A faulty electrical installation or an excessive mains voltage
may cause an electric shock.
Before use, adjust the mains voltage of the socket with the
information on the type plate.
Before use, make sure that the mains voltage of the socket
corresponds with the information on the type plate.
To be able to disconnect the charging cable or respectively
the cable harness from the mains as quickly as possible in
the event of a failure, connect the power supply unit where
it is easily accessible.
If you notice any visible damage to your GPS tracker or
charging cable or respectively the cable harness, do not use
it.
Use only the original parts supplied to charge the GPS
tracker. If the charging cable or respectively the cable
harness is damaged, replace it only with original
accessories from the manufacturer.
Never place the GPS tracker near an open fire or hot
surfaces.
The GPS tracker is not protected against humidity and
water. Please use and store it only in a dry environment.

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
12
Keep the charging cable or respectively the cable harness
away from humidity and do not kink it.
Do not open the housing of the GPS tracker. Leave the repair
to qualified specialists. However, if you carry out repairs
yourself, connect the GPS tracker incorrectly or operate it
incorrectly, liability and warranty claims are excluded.
WARNING! The charging cable or respectively the cable harness
represents a danger of choking hazard and strangulation.
Battery mode
WARNING! DANGER OF EXPLOSION AND FIRE!
Below you will find information and instructions on how to use
the battery:
The GPS tracker runs by a lithium ions battery. It is not
exchangeable and must not be removed or opened.
Make sure that the GPS tracker is kept away from heat
sources and high temperatures, such as direct sunlight in a
vehicle. Disregard of this instruction may result in
destruction of the battery and overheating, explosion and
fire.
Only use the original accessories for the charging process.
If the battery is charged otherwise, this may result in
overheating, explosion or fire.
Do not burn or pierce the GPS tracker. Protect it from
mechanical damage.
Do not remove the battery with sharp or pointed objects. Do
not drop, disassemble or modify it.
If a child or any other person swallows the battery, seek
medical aid immediately!

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
13
If you want to have the battery replaced, then please contact
our support.
In special cases it is possible to disconnect the battery from
the device. To do this, the cover of the FINDER must be
removed and the ON / OFF switch must be set to OFF.
The FINDER must not be charged permanently via an
external power supply.
WARNING! DANGER OF A CHEMICAL BURN!
Batteries that leak due to damage may cause burns in contact
with the skin. Therefore, never open the battery. However, if the
battery leaks, please wear protective gloves.
Electromagnetic compatibility
Please note all rules and prohibitions. Immediately switch off
the GPS tracker in dangerous areas and if it might cause
interference. Furthermore, it should not be used in the vicinity of,
for example, medical equipment, fuels and chemicals, or in
blasting areas. With mobile devices, malfunction due to
interference may occur and affect performance. Transformers
and very strong magnetic fields must be avoided. Otherwise
there may be deviations in the transmission. Disregard of these
instructions may cause interference or damage to the GPS
tracker.
Cleaning
WARNING! RISK OF DAMAGE!
Below you will find information and instructions on how to clean
the GPS tracker:
Do not use aggressive cleaning agents or brushes for
cleaning. Do not clean the GPS tracker with metallic

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
14
cleaning objects (e.g. knife, metal sponge). This may
damage the surface.
Never put the GPS tracker in water, in a dishwasher (or the
like) and do not use a steam cleaner.
Correct cleaning:
1. The surface may be wiped clean with a slightly damped
cloth.
2. The GPS tracker should then be wiped dry completely.
Please note: Improper use of the tracker may result in
damage.
Dangers for children and people in need of help
Please do not let people (including children) with limited
physical, sensory or mental abilities use the GPS tracker. It is
considered an exception if they have previously received
instructions from a person responsible for their safety on how
to use the device. Please be sure that they not play with small
parts (e.g. accessories, etc.). These may be swallowed, leading
to suffocation. Inform your child about the dangers and about
how to use the GPS tracker.
Storage
If you are not using the GPS tracker for a lengthy period of time,
turn it off. Place the tracker in its original packaging or in a
carton of the same size. Protect the tracker from dirt and
humidity. Keep out of the reach of children.

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
15
Disposal of packaging
Dispose of the packaging according to type. Add
cardboard to the paper bank, plastics to the recyclables
collection.
Disregard of these instructions may shorten the life of the
built-in battery or cause damage to the GPS tracker in
general.
FCC Radiation Exposure Statement
The transmitter must not be colocated or operated in
conjunction with any other antenna or transmitter. This
equipment complies with the FCC RF radiation exposure limits
set forth for an uncontrolled environment. This equipment
should be installed and operated with a minimum distance of
20cm from any part of your body.
Information to Users
According to the FCC Part 15.19, 15.21, and 15.105 rules, for this
EUT, the instructions or operation manual furnished the user
shall include the following or similar statement, placed in a
prominent location in the text of the manual:
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
16
NOTE 1: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
NOTE 2: Any changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.
FCC ID: 2ASPJPAJGPS319

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
17
1.10 Note on the disposal of used batteries
The following instruction is aimed at those who use batteries
or products with built-in batteries and do not resell them in
the form supplied to them (end users).
Acceptance of returned used batteries free of charge
Batteries must not be disposed of with household waste. You
are legally obliged to return used batteries so that proper
disposal can be guaranteed. You can dispose of used batteries
at a municipal collection point or at a local retailer. As a
distributor of batteries, we are also obliged to take back used
batteries, whereby our obligation to take back only applies to the
type of used batteries that we have or had as new batteries in
our range. Used batteries of the above type can therefore either
be returned to us with sufficient prepayment or directly to our
shipping warehouse at the following address free of charge:
PAJ GPS Inc.
444 Brickell Ave, Suite 700
Miami, FL 33131
USA
e-mail: [e-mail]
Meaning of the battery symbols
Batteries are marked with the symbol of a crossed-out dustbin
(see following illustration). This symbol indicates that batteries
must not be disposed of with household waste. Batteries
containing more than 0.0005 mass percent of mercury, more
than 0.002 mass percent of cadmium or more than 0.004 mass
percent of lead additionally bear the chemical name
of the pollutant they contain below the waste bin
symbol. The abbreviation "Cd" stands for cadmium,
"Pb" stands for lead and "Hg" stands for mercury.

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
18
1.11 Note on the disposal of electric appliances
1. Separate collection of old appliances
Electrical and electronic equipment that has become waste is
referred to as old appliances. Owners of WEEE must have it
collected separately from unsorted municipal waste. In
particular, old appliances must not be disposed of with
household waste, but in special collection and return systems.
2. Batteries and accumulators
Owners of WEEE must normally separate used batteries and
accumulators which are not enclosed by the WEEE from WEEE
before returning them to a collection point. This does not apply
if the old appliances are handed over to public waste
management authorities and separated from other old
appliances for the purpose of preparation for reuse.
3. Data protection notice
WEEE often contains sensitive personal data. This applies in
particular to information and telecommunications technology
devices such as computers and smartphones. In your own
interest, please note that each end user is responsible for
deleting the data on the old devices to be disposed of.
4. Meaning of the symbol „crossed-out dustbin“
The crossed-out dustbin symbol regularly displayed
on electrical and electronic equipment indicates that
the respective device must be collected separately
from unsorted municipal waste at the end of its service
life.

POWER Finder 4G by PAJ GPS V.1.0 US
© PAJ GPS Inc.
19
Do you have any questions?
Just contact us,
we are happy to help you!
PAJ GPS Inc.
444 Brickell Ave, Suite 700
Miami, FL 33131
USA
E-Mail: [email protected]
Facebook: facebook.com/pajgps.us
Web: www.paj-gps.us
Best wishes,
your PAJ team

POWER Finder 4G by PAJ GPS V.1.0 ES
© PAJ GPS Inc.
20
Contenido
2Spanish
2.1 Volumen de entrega .................................... 21
2.2 Gráficas del producto .................................. 21
2.3 Cargar.......................................................... 22
2.4 Activación.................................................... 22
2.5 Encender/ apagar ........................................ 22
2.6 Uso .............................................................. 24
2.7 Significado luces LED.................................. 24
2.8 Datos técnicos............................................. 25
2.9 Instrucciones de seguridad ......................... 26
2.10 Indicación para el desecho
de baterías viejas ........................................ 33
2.11 Indicación para el desecho
de dispositivos electrónicos........................ 34
