PAJ GPS VEHICLE Finder 1.0 4G User manual

4G
V EHICLE
FINDER
1.0

3
1.1 Scope of delivery
1.1 Scope of delivery............................................................................. 3
1.2 Product description ......................................................................... 4
1.3 Activation ....................................................................................... 5
1.4 Connection to vehicle....................................................................... 6
1.5 Installation...................................................................................... 7
1.6 Start-up .......................................................................................... 8
1.7 Use................................................................................................. 9
1.8 Short description FINDER-Portal......................................................10
1.9 Meaning of the LED lights................................................................12
1.10 Alerts ..........................................................................................13
1.11 Technical data ..............................................................................14
1.12 Safety Instructions........................................................................15
1.13 Disposal of used batteries.............................................................21
1.14 Disposal of electric devices...........................................................22
Thank you for purchasing our FINDER!
Before starting:
Read the instructions carefully, before using the FINDER for the first time.
Please keep this user manual in a safe place in case you may need it in the
future.
Table of contents
VEHICLE Finder 4G 1.0 von PAJ V 2.0 EN
© PAJ UG (haftungsbeschränkt)
NOTE!
We update our user manuals on a regular basis, in order to keep up to date. The
latest version can be viewed at any time at:
paj-gps.com/finder
Your delivery will include:
• PAJ VEHICLE Finder 4G 1.0
• User manual
• M2M SIM card*
*the M2M SIM card is already inside your
FINDER and is not replaceable.

45
1.2 Product description 1.3 Activation
LED signals
Wiring harness
NOTE!
To activate, you need the device ID. Please make a note of it before
installing your FINDER!
In order to use your VEHICLE Finder 4G 1.0, you will need to previously activate it online.
Enter the following link and follow the instructions:
start.nder-portal.com
NOTE!
For a detailed explanation of the activation process,
you can simply click on the following link or scan the
QR code:
paj-gps.de/registrierung/

67
1.4 Connection to vehicle 1.5 Installation
1.
2.
• SIM card already placed in the VEHICLE Finder 4G 1.0
• The VEHICLE Finder 4G 1.0 should not be attached to gasoline lines or other
flammable components
• No other components on your vehicle should be damaged by the attachment
By installing the VEHICLE Finder 4G 1.0 on the vehicle battery, it is possible that
this will be discharged to power the VEHICLE Finder 4G 1.0. If you regularly use
your vehicle, this should not be a problem with a functioning battery, as it is cons-
tantly recharged by driving. If this is not the case, please check before connec-
tion whether your battery has a discharge protection and, if necessary, retrot
this. In idle state, the FINDER requires about 10-20 mAh
•
Please note the following points, before connecting to the vehicle:
NOTE!
Please always observe the manufacturer‘s specifications for your
vehicle. Claims for damages for improper connections are excluded.
Connect the FINDER to the battery.
Connectthe red cable withthe fuse
toPLUS(+).Connecttheblack cable
to Minus (-)
Mount the FINDER with the help
of the adhesive strip in the engine
compartment

89
1.7 Use
1.6 Start-up
Red cable
Black cable
-
+
-
+
Battery
9-75 V
NOTE!
By connecting to the power supply, the FINDER turns on immediately and the
LED lights give a signal. If the device is not connected to the vehicle battery but
to another location (e.g., fuse box), this may cause the ignition on/off function
to be not accurately recognized.
WARNING! The poles must not be swapped under any circumstances.
If the activation was successful, you can start the VEHICLE Finder 4G 1.0.
When connected to the power supply, the FINDER will switch on.
NOTE!
After you have successfully installed the VEHICLE Finder 4G 1.0 in your vehicle,
it is advisable to move the vehicle for some time. For example, drive the car
briefly to go shopping. This allows the device to log into the correct network
faster and establish a first connection.
As soon as your device has been successfully activated, started up and has sent and
logged data for the rst time, you can place it wherever you choose and use your
phone, tablet or PC to start tracking it! You will be able to do this in our App or enter
the following link to the desktop version:
v2.nder-portal.com

10 11
1.8 Short description FINDER-Portal
Update interval
Device position
Distance travelled
1. 2. 3. 4. 5.
Application menu
View statistics,
device settings,
application settings,
alert summary,
extra features e.g.
logbook etc.
Alert notications
View unread notications
PAJ Logo
Update page/refresh
Device list
Overview devices,
alert settings,
travelled routes,
customize device display
Options
Map view options
Detailed instructions for the FINDER-Portal
can be found on: paj-gps.de/portal-anleitung
or scan this QR-Code.
1.
2.
3.
4.
5.
Menu Alerts Devices Options
30
sec

12 13
1.9 Meaning of the LED lights 1.10 Alerts
Orange LED - Network
Blue LED - GPS Status
Signal Meaning
The blue LED is on GPS signal available
The blue LED flashes No GPS signal available
The blue LED is off The GPS tracker is in standby mode or
switched off
Signal Meaning
The orange LED is on Signal available
The orange LED flashes No signal available
The orange LED is off The GPS tracker is in standby mode or
switched off
Power cut alert
Receive a notication as soon as the GPS tracker is
disconnected from the external power supply.
Ignition alert
Receive a notication as soon as your car is started or
turned off.
Voltage alert
Alert notication, as soon as the voltage of the vehicle
battery deviates from the dened threshold. You can set the
voltage threshold in the FINDER Portal.
Movement/Shock alert
Receive a notication as soon as your GPS tracker is either
moved or shaken.
Geofence alert
Receive a notication as soon as your GPS tracker leaves
your determined perimeter.
Speed alert
Receive a notication as soon as your GPS tracker exceeds
a certain speed (you can set the speed limit in the FINDER
Portal).
NOTE!
All alerts must be activated and deactivated
via the FINDER-Portal. Once the alert is
active you will receive anotification via the PAJ
App and/or via email.

14 15
1.12 Safety Instructions
1.11 Technical data
Weight 116 g
Dimensions
106 x 66 x 16 mm
123 x 66 x 16 mm (including eyelet)
length of connection cable: 40 cm
Battery time*approx. 12 hours (Standby)
Battery type (internal) 3,6 V 200 mAh NiMH
Charger fixed connection to vehicle battery: 9-75 V
Time to start cold start: 30 s
standby: 30 s / in operation: 1 s
Network/Bands
LTE-FDD:
B1/B2/B3/B4/B5/B7/B8/B12/B13/ B18/B19/B20/
B25/B26/B28/B66
LTE-TDD:
B34/B38/B39/B40/B41
GSM/GPRS/EDGE:
850/900/1800/1900 MHz
Network module SIMCOM A7670G
GPS chip AT6558R
GPS reception -162 dBm
GPS accuracy up to 5 meters
Storage temperature from -30°C up to +80°C
Operating environment from -20°C up to +75°C
Humidity 10% up to 85%
Water protection waterproof according to IP67
*Emergency battery, when the FINDER is disconnected from the power supply.
Signal words
The following signal words are used in these operating instructions:
NOTE!
This is a warning about possible damage to property.
WARNING!
This classies a hazard of medium risk level. Failure to comply with the warning
may result in serious injury.
Proper use
Please read the safety instructions for this PAJ FINDER, hereinafter only referred
to as GPS tracker, carefully before use in order to be able to deploy it properly. The
intended use is to employ the GPS tracker only as described in this manual to locate
an object or a living being. Please bear in mind that it is a criminal offence to monitor
third parties using a GPS tracker without their consent. If you use it in any other way,
this is considered improper use and can lead to damage to property or even personal
injury. Please note that the GPS tracker is not a toy for children. In other countries
and regions there are different laws on digital positioning and localization of people,
animals and/or objects. PAJ UG is not responsible if such laws or regulations are
violated, this is the sole responsibility of the user.
NOTE!
The manufacturer and dealer accept no liability for damage caused by improper or
incorrect use.

16 17
A faulty electrical installation or a mains voltage that is too high can lead to
an electric shock.
• Before use, make sure that the mains voltage of the socket corresponds with
the information on the type plate.
• To be able to disconnect the charging cable from the mains as quickly as
possible in the event of a failure, connect the power supply unit where it is
easily accessible.
• If you notice any visible damage to your GPS tracker or charging cable, do
not use it.
• Use only the original parts supplied to charge the GPS tracker. If the charging ca-
ble is damaged, replace it only with original accessories from the manufacturer.
• Never place the GPS tracker near an open re or hot surfaces.
• The GPS tracker is not protected against humidity and water. Please use and
store it only in a dry environment.
• The charging cable should only be used indoors. Keep it away from humidity
and do not kink it.
• Do not open the housing of the GPS tracker. Leave the repair to qualied
specialists. However, if you carry out repairs yourself, connect the GPS tracker
incorrectly or operate it incorrectly, liability and warranty claims are excluded.
Hazards for children and vulnerable people
Safety
WARNING! RISK OF ELECTRIC SHOCK!
WARNING! DANGER OF SUFFOCATION!
Please do not let people (including children) with limited physical, sensory or
mental abilities use the GPS tracker. It is considered an exception if they have
previously received instructions from a person responsible for their safety on
how to use the device.
NOTE!
Inform your child about the dangers and use of the GPS tracker.
Please be sure that they not play with small parts (e.g. accessories, etc.). These
may be swallowed, leading to suffocation.
Below you will nd information and instructions on how to use the battery:
• The GPS tracker runs by a lithium ions battery. It is not exchangeable and must
not be removed or opened.
• Make sure that the GPS tracker (also when charging the battery) is kept away
from heat sources and high temperatures, such as direct sunlight in a vehicle.
Disregard of this instruction may result in destruction of the battery and over-
heating, explosion and re.
• Only use the original accessories for the charging process. If the battery is char-
ged otherwise, this may result in overheating, explosion or re.
• Do not burn or pierce the GPS tracker. Protect it from mechanical damage.
• If a child swallows the battery, seek medical aid immediately!
Removing or replacing the battery:
• Contact our support if the battery needs to be removed or replaced.
• Send the machine to us to remove or replace the battery.
WARNING! EXPLOSION AND FIRE HAZARD!
The battery

18 19
• For safety reasons, do not attempt to remove the battery. Failure to remove the
battery properly may result in damage to the battery and unit, personal injury
and/or compromise the safety of the unit.
• PAJ GPS shall not be liable for any damage or loss (whether in contract or tort,
including negligence) arising from your failure to comply with these warnings
and instructions.
Batteries that leak due to damage can cause burns if they come into contact with
the skin. Therefore, never open the battery. However, if the battery leaks, please
wear protective gloves.
WARNING! RISK OF CHEMICAL BURNS!
NOTE!
Failure to observe these recommendations may result in malfunctions or
damage to the GPS tracker.
Electromagnetic compatibility
Please observe all rules and prohibitions and switch off the GPS tracker immediately
in danger areas and if it might cause interference. Furthermore, it should not be used
in the vicinity of, for example, medical equipment, fuels and chemicals, or in blasting
areas. With mobile devices, malfunction due to interference may occur and affect per-
formance. Transformers and very strong magnetic elds must be avoided. Otherwise
there may be deviations in the transmission.
Below you will nd information and instructions on how to clean the GPS tracker:
• Do not use aggressive cleaning agents or brushes for cleaning. Do not clean
the GPS tracker with metallic cleaning objects (e.g. knife, metal sponge). This
may damage the surface.
• Never put the GPS tracker in water, in a dishwasher (or the like) and do not
use a steam cleaner.
WARNING! RISK OF DAMAGE!
Cleaning
Storage
If you are not using the GPS tracker for a lengthy period of time, turn it off. Place the
tracker in its original packaging or in a carton of the same size. Protect the tracker
from dirt and humidity.
NOTE!
Keep the FINDER away of children’s reach in order to avoid possible damage to
property or personal injury.
Correct cleaning:
• The surface may be wiped clean with a slightly damped cloth.
• The GPS tracker should then be wiped dry completely.

20 21
1.13 Disposal of used batteries
Declaration of conformity
Hereby, PAJ UG (haftungsbeschränkt) declares that the tracker, VEHICLE Finder 4G 1.0,
is in conformity with the Directive 2014/53/EU. The complete text of the EU Declaration
of Conformity can be found at the following Internet address:
paj-gps.de/konformitaetserklaerung/
Packaging disposal
Dispose of the packaging according to type. Throw cardboard and paper to the
corresponding container. Foil belongs in the recyclables collection.
The following note is addressed to those who use batteries or products with
products with built-in batteries and who will not resell them in the form in which
they were supplied to them (end users).
Free recall of used batteries
Batteries must not be disposed of with waste. You are legally obliged to return used
batteries so that proper disposal can be guaranteed. You can return used batteries to
a local collection point or to your local retailer. As a distributor of batteries, we are also
to take back used batteries, although our obligation to take back used is limited to the
type which we carry or have carried as batteries in our range. Used batteries of the
aforementioned type can therefore either be returned to us with sufcient postage or
handed in directly to our dispatch warehouse at the following address free of charge:
PAJ UG (haftungsbeschränkt)
Hohe Straße 61
51570 Windeck
Germany
E-Mail: [email protected]
Meaning of the battery symbols
Batteries are marked with the symbol of a crossed-out dustbin (see illustration). This
symbol indicates that batteries must not be disposed of in household waste. Batteries
containing more than 0.0005% mercury by mass, more than 0.002% cadmium by mass
or more than 0.004% lead by mass are also marked with the chemical name of the
pollutant below the dustbin symbol. The abbreviation „Cd“ stands for cadmium, „Pb“
for lead and „Hg“ for mercury.

23
22
1.14 Disposal of electric devices
The Electrical and Electronic Equipment Act (ElektroG) contains a large number of
requirements for the handling of electrical and electronic equipment. The most im-
portant ones are summarised here:
1. Separate collection of WEEE
Waste Electrical and Electronic Equipment that has become waste is referred to as
WEEE. Owners of WEEE must dispose of it separately from unsorted local waste. In
particular, WEEE does not belong in household waste, but in special collection and
return systems.
2. Batteries and accumulators
As a rule, owners of WEEE must separate spent batteries and accumulators that are
not enclosed in the WEEE before handing them over at a collection point. This does
not apply if the WEEE is handed over to public waste management authorities and
separated from other WEEE there for the purpose of preparation for reuse.
3. Options for returning old appliances (WEEE)
Owners of WEEE from private households can hand it in to public waste management
authorities or at the collection points set up by manufacturers or distributors as dened
by the ElektroG. An online directory of collection and collection points can be found here:
https://www.ear-system.de/ear-verzeichnis/sammel-und-ruecknahmestellen.jsf
4. Data protection
Old equipment often contains sensitive personal data. This applies in particular to in-
formation and telecommunication technology devices such as computers and smart-
phones. For your own sake, please note that each end-user is responsible for deleting the
data on the old equipment to be disposed of.
5. Meaning of the „crossed-out dustbin“ symbol
The symbol of a crossed-out dustbin regularly displayed on electrical and elec-
tronic equipment indicates that the respective device must be separated from
unsorted local waste at the end of its service life.
6. Manufacturer registration number
As a manufacturer, within the meaning of the ElektroG, we are registered with the respon-
sible foundation Elektro-Altgeräte Register (Benno-Strauß-Str. 1, 90763 Fürth) under the
following registration number: DE33887550
In this case, please contact us
and we will be delighted to help you!
PAJ UG (haftungsbeschränkt)
Hohe Straße 61
51570 Windeck
Germany
Mail: [email protected]
Phone: [phone]
Web: paj-gps.com
The PAJ GPS Team wishes you to enjoy your
VEHICLE Finder 4G 1.0!
DO YOU HAVE ANY QUESTIONS?

PAJ UG (haftungsbeschränkt)
Hohe Straße 61, 51570 Windeck
Germany
