Basic Operating Instructions
Wearable Camera
Model No. HX-A1M
More detailed operating instructions are available in “Operating Instructions (PDF format)”. To
read it, download it from the website.
https://eww.pavc.panasonic.co.jp/hdw/oi/A1/
≥Click the desired language.
* You will need Adobe Reader to browse or print the Operating Instructions (PDF format).
You can download and install a version of Adobe Reader that you can use with your OS from
the following website. (As of March 2015)
http://www.adobe.com/products/acrobat/readstep2.html
SQT0886
until
2015/4/20
Please read these instructions carefully before using
this product, and save this manual for future use.
HX-A1M-SQT0886_mst.book 1 ページ ２０１５年４月６日 月曜日 午前９時４６分

2
SQT0886 (ENG)
For Europe only
∫EMC Electric and magnetic
compatibility
This symbol (CE) is located on the rating plate.
∫Cautions for use
Keep this unit as far away as possible from
electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
≥If you use this unit on top of or near a TV, the
pictures and/or sound on this unit may be
disrupted by electromagnetic wave radiation.
≥Do not use this unit near cell phones because
doing so may result in noise adversely
affecting the pictures and/or sound.
≥Recorded data may be damaged, or pictures
may be distorted, by strong magnetic fields
created by speakers or large motors.
≥Electromagnetic wave radiation generated by
microprocessors may adversely affect this
unit, disturbing the pictures and/or sound.
≥If this unit is adversely affected by
electromagnetic equipment and stops
functioning properly, press the reset button.
Do not use this unit near radio transmitters
or high-voltage lines.
≥If you record near radio transmitters or
high-voltage lines, the recorded pictures and/
or sound may be adversely affected.
About connecting to a PC
≥Do not use any other USB cables except the
supplied one.
Information for Your Safety
WARNING:
To reduce the risk of fire, electric shock or
product damage,
≥Do not let water or other liquids drip or
splash inside the unit.
≥Do not expose accessories (battery pack,
battery charger, AC adaptor, SD memory
card and etc.) to rain, moisture, dripping or
splashing.
≥Do not place objects filled with liquids,
such as vases, on accessories.
≥Use only the recommended accessories.
≥Do not remove covers.
≥Do not repair this unit by yourself. Refer
servicing to qualified service personnel.
CAUTION!
To reduce the risk of fire, electric shock or
product damage,
≥Do not install or place this unit in a
bookcase, built-in cabinet or in another
confined space. Ensure this unit is well
ventilated.
≥Do not obstruct this unit’s ventilation
openings with newspapers, tablecloths,
curtains, and similar items.
≥Do not place sources of naked flames,
such as lighted candles, on this unit.
This unit and the microSD card become
warm during use. This is not a
malfunction.
HX-A1M-SQT0886_mst.book 2 ページ ２０１５年４月６日 月曜日 午前９時４６分

3
(ENG) SQT0886
Make sure to use the supplied cable.
Do not extend the cable.
Do not spray insecticides or volatile
chemicals onto this unit.
≥If this unit is sprayed with such chemicals, its
body may be marred and the surface finish
may peel off.
≥Do not leave rubber or plastic products in
contact with this unit for a long time.
Cleaning
≥Before cleaning, pull the USB cable from the
PC, and then wipe this unit with a soft, dry
cloth.
≥If this unit is very dirty, dip a cloth in water and
squeeze firmly, and then wipe this unit with
the damp cloth. Next, dry this unit with a dry
cloth.
≥Use of benzine, paint thinner, alcohol, or
dishwashing liquid may alter the camera body
or peel the surface finish. Do not use these
solvents.
≥When using a chemical dust cloth, follow the
instructions that came with the cloth.
When you are not going to use this unit for
an extended time
≥Store this unit in a cool place with minimal
humidity, and with a constant temperature
where possible (recommended temperature:
15 oC to 25 oC, recommended humidity:
40%RH to 60%RH).
≥Always remove the card from this unit.
≥When storing this unit for an extended time, it
is recommended that you charge it once
every year.
≥The battery discharges slowly even if this unit
is not used. The remaining battery level will
decrease when this unit is not used for an
extended time.
≥When storing this unit in a cupboard or
cabinet, it is recommended that you place a
desiccant (silica gel) in with it.
About the battery
The battery used in this unit is a
rechargeable lithium-ion battery. It is
susceptible to humidity and temperature
and the effect increases the more the
temperature rises or falls.
Due to the waterproof, dustproof, and anti-
shock design of this product, it is not
possible to replace the built-in battery.
If the operating time is very short even after
the battery has been recharged, the battery
has worn out.
About the microSD card
When the microSD card is being accessed
(when the access lamp is lit or flashing), do
not perform the following:
jRemove the microSD card
jTurn the unit off
jInsert and remove the USB cable
jExpose the unit to vibrations or shock
≥Keep the glasscover (night mode),
glasscover (normal shooting), terminal cover
(waterproof) and terminal cover (USB
connection) out of reach of children to
prevent swallowing.
HX-A1M-SQT0886_mst.book 3 ページ ２０１５年４月６日 月曜日 午前９時４６分

4
SQT0886 (ENG)
For Europe and Australia only
∫Disposal of Old Equipment and
Batteries
Only for European Union and
countries with recycling systems
These symbols on the
products, packaging, and/
or accompanying
documents mean that used
electrical and electronic
products and batteries
must not be mixed with
general household waste.
For proper treatment,
recovery and recycling of
old products and used
batteries, please take them
to applicable collection
points in accordance with
your national legislation.
By disposing of them correctly, you will
help to save valuable resources and
prevent any potential negative effects on
human health and the environment.
For more information about collection and
recycling, please contact your local
municipality.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
Note for the battery
symbol (bottom symbol):
This symbol might be used
in combination with a
chemical symbol. In this
case it complies with the
requirement set by the Directive for the
chemical involved.
For Singapore only
For Thailand only
For India only
For Korea only
This wireless product may cause propagation
interference, so it cannot be used for life-saving
services.
Declaration of Conformity (DoC)
Hereby, “Panasonic Corporation” declares that
this product is in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC.
Customers can download a copy of the original
DoC to our R&TTE products from our DoC
server:
http://www.doc.panasonic.de
Contact to Authorized Representative:
Panasonic Marketing Europe GmbH,
Panasonic Testing Centre, Winsbergring 15,
22525 Hamburg, Germany
This product is intended for general consumer.
(Category 3)
This product on purpose to connect to access
point of 2.4 GHz WLAN.
This telecommunication equipment conforms
to NTC/NBTC technical requirement.
The specifications are exempted for any
licensing requirement by Ministry of
Communications and Information Technology,
G.S.R. 45 (E)., dated 28th January, 2005.
Complies with
IDA Standards
DB01017
HX-A1M-SQT0886_mst.book 4 ページ ２０１５年４月６日 月曜日 午前９時４６分

5
(ENG) SQT0886
Information for Your Safety......................2
Preparation
(Important) About the Waterproof/
Dustproof and Anti-shock Performance
of this unit..................................................6
When using in a cold climate or at low
temperatures .............................................9
Read this first ..........................................10
Accessories............................................. 11
Power supply...........................................13
Charging the battery ......................... 13
Charging and recording time............. 14
Recording to a card ................................ 15
Cards that you can use with
this unit.............................................. 15
Inserting/removing a
microSD card .................................... 15
Turning this unit on/off...........................16
About overheat detection .................. 16
About battery level indications .......... 16
Wi-Fi® function........................................ 17
Install the “Image App” ...................... 18
Connecting to a smartphone .................19
Setting up a Wi-Fi connection to a
smartphone ....................................... 19
Setting up this unit .................................19
Setting date and time ........................ 20
Initialising the network settings ......... 20
Attaching this unit to a Multi Mount or
Tripod Mount ........................................... 21
Using a Multi Mount .......................... 21
Using a Tripod Mount ........................ 24
Basic
Recording ................................................26
Check before recording..................... 26
Recording with this unit ..................... 27
Playback ..................................................28
Others
Troubleshooting ..................................... 29
Requests when disposing of this unit .... 30
Specifications ......................................... 32
About copyright ...................................... 33
Limited Warranty
(ONLY FOR AUSTRALIA) ....................... 35
Contents
HX-A1M-SQT0886_mst.book 5 ページ ２０１５年４月６日 月曜日 午前９時４６分

6
SQT0886 (ENG)
This does not guarantee no destruction, no malfunction, or waterproofing in all conditions.
*1 This means that this unit can be used underwater for specified time in specified pressure in
accordance with the handling method established by Panasonic.
*2 “MIL-STD 810F Method 516.5-Shock” is the test method standard of the U.S. Defense
Department, which specifies performing drop tests from a height of 122 cm, at 26 orientations
(8 corners, 12 ridges, 6 faces) using 5 sets of devices, and passing the 26 orientation drops
within 5 devices. (If failure occurs during the test, a new set is used to pass the drop orientation
test within a total of 5 devices.)
Panasonic’s test method is based on the above “MIL-STD 810F Method 516.5-Shock”.
However, the drop height was changed from 122 cm to 150 cm dropping onto 3 cm thick
plyboard. This drop test was passed.
(Disregarding appearance change such as loss of paint or distortion of the part where drop
impact is applied.)
∫Handling of this unit
≥The waterproof performance may be degraded due to the strong water pressure when this unit is
used deeper than 1.5 m underwater.
≥When this unit is splashed with detergent, soap, hot spring, bath additive, sun oil, sun screen,
chemical, etc., wipe it off immediately.
≥Do not rinse with running water, such as tap water.
≥Waterproof function of this unit is for sea water and fresh water only.
≥Any malfunction caused by customer misuse, or mishandling will not be covered by the warranty.
≥
Cards are not waterproof. Do not handle with a wet hand. Also, do not insert wet card into this unit.
≥Do not attach/remove the terminal cover (waterproof) or glasscover when your hands are wet or
water droplets are present on this unit. If water droplets get inside this unit, the terminals may rust
and cause malfunctions. Other types of damage may also result.
≥
If you attach/remove the terminal cover (waterproof) or glasscover in a sandy or dusty place,
sand or other foreign objects may adhere to the internal components, threaded portions
(portions of this unit, terminal cover (waterproof) and glasscover with helical threads), rubber
seals or other parts of this unit. Be extra careful when attaching parts to this unit. If foreign
objects are caught in it, water may leak in and cause malfunctions and other problems.
Preparation
(Important) About the Waterproof/
Dustproof and Anti-shock
Performance of this unit
Waterproof/Dustproof Performance
This unit’s waterproof/dustproof rating complies with the “IP68” rating. Provided the care
and maintenance guidelines described in this document are strictly followed, this unit
can operate underwater, to a depth not exceeding 1.5 m for a time not exceeding
30 minutes. *1
Anti-shock Performance
This unit has cleared a test conducted by Panasonic, which complies with MIL-STD 810F
Method 516.5-Shock (a drop test performed from a height of 1.5 m onto 3 cm thick
plywood). *2
Waterproofing is not guaranteed if the unit is subject to an impact as a result of being hit or
dropped etc. If an impact to this unit occurs, it should be inspected (subject to a fee) by a
Panasonic’s Service Centre to verify that the waterproofing is still effective.
HX-A1M-SQT0886_mst.book 6 ページ ２０１５年４月６日 月曜日 午前９時４６分

7
(ENG) SQT0886
≥Do not leave this unit for a long period of time in places where temperature is very low (at high
altitude etc.) or very high (inside a car under strong sunlight, close to a heater, on the beach, etc.)
waterproof performance may be degraded.
≥The inside of this unit is not waterproof. Water leakage will cause malfunction.
≥If any foreign objects are found on the internal components, threaded portions, rubber
seals or other parts of this unit, remove them with a soft dry cloth.
≥If any liquid such as water droplets are found on the internal components, threaded
portions, rubber seals or other parts of this unit, wipe it off with a soft dry cloth. Do not
attach/remove the terminal cover (waterproof) or glasscover near water, underwater, with
wet hands or when this unit is wet. Doing so may cause water to leak in.
≥The alert sound and shutter sound may be lowered when using this unit. This is for ensuring the
waterproof performance of this unit, and not a malfunction. Attaching/removing the terminal cover
(waterproof) or glasscover will restore the original volume.
≥This unit is not waterproof when the terminal cover (USB connection) is in use. In this case, do
not use this unit underwater or touch it with wet hands.
∫About Condensation (When the lens is fogged up)
Condensation occurs when there is a change in temperature or humidity, such as when the unit is
taken from outside or a cold room to a warm room. Please be careful, as it may cause the lens to
become soiled, moldy, or damaged.
When taking the unit to a place which has a different temperature, if the unit is accustomed to the
room temperature of the destination for about one hour, condensation can be prevented. (When the
difference in temperature is severe, place the unit in a plastic bag or the like, remove air from the
bag, and seal the bag.)
When condensation occurs, turn off this unit, remove the terminal cover (waterproof) and
glasscover, and leave this unit for approximately 2 hours. Once this unit adjusts to the ambient
temperature, the condensation will disappear naturally.
1 Rotate the terminal cover (waterproof) and glasscover in the directions of the
arrows to remove them.
2 Check that no foreign objects are found on the internal components,
threaded portions and rubber seals of this unit.
≥If there are any foreign objects, such as lint, hair, sand, etc., water will leak within a few seconds
causing malfunction.
3 If there is foreign objects adhering to the unit, remove it with a soft dry cloth.
≥Check to see if any foreign objects such as lint is adhering to this unit.
≥Wipe it off with a dry soft cloth if there is any liquid. It may cause water leaks and malfunction if
you use this unit with liquid adhered.
≥Use a blower (commercially available) to remove foreign objects that cannot be removed with a
dry soft cloth.
Check before using underwater
Do not attach/remove the terminal cover (waterproof) or glasscover in sandy or dusty
locations, near water or with wet hands. If sand or dust adheres to this unit, water may leak
in.



HX-A1M-SQT0886_mst.book 7 ページ ２０１５年４月６日 月曜日 午前９時４６分

8
SQT0886 (ENG)
4 Check that the terminal cover (waterproof), glasscover and rubber seals are
neither cracked nor deformed.
≥Be sure to read the supplied leaflet about the rubber seals.
5 Rotate the terminal cover (waterproof) and glasscover until they are attached
firmly.
≥Rotate them in the opposite directions of Step 1.
≥Tighten them firmly to ensure that they are not loose.
≥To prevent water seeping into this unit, be careful not to trap foreign objects such as liquids, sand,
hair or dust etc.
≥Use this unit underwater at a depth of down to 1.5 m with the water temperature between 0 oC
and 35 oC.
≥Do not use this unit at a depth of over 1.5 m.
≥Do not use it in hot water over 35 oC (in a bath or hot spring).
≥Do not use this unit underwater not longer than 30 minutes continuously.
≥Do not attach/remove the terminal cover (waterproof) or glasscover.
≥Do not apply shock to this unit underwater. (Waterproof performance may not be maintained, and
there is a chance of water leak.)
≥Do not dive into the water holding this unit. Do not use this unit in a location where the water will
splash strongly, such as rapid flow or waterfall. (Strong water pressure may be applied, and it may
cause malfunction.)
≥This unit will sink in the water. Take care not to drop this unit.
1 Rinse this unit without removing the terminal cover (waterproof) and
glasscover.
≥After use at the seaside or underwater, soak the unit in fresh water pooled in a shallow container
for about 10 minutes.
2 Drain water by holding this unit and shaking it lightly a few times.
≥After using this unit at the seaside or underwater, or after washing it, water will remain at the mic
site of this unit for a while and it may cause lower sound or sound distortion.
≥Pay careful attention to prevent this unit from dropping.
3 Wipe off water drops on this unit with a soft dry cloth and dry this unit in a
shaded area that is well ventilated.
≥Dry this unit 1 hour or more.
≥Dry this unit on a dry cloth.
≥Do not dry this unit with hot air from dryer or similar. It will deteriorate the waterproof performance
or cause failure due to deformation.
≥Do not use chemicals such as benzine, thinner, alcohol or cleanser, soap or detergents.
4 After checking that there are no water droplets, remove the terminal cover
(waterproof) and glasscover, and wipe off any water droplets or sand left
inside with a soft, dry cloth.
Using this unit underwater
Caring for this unit after using it underwater
Do not attach/remove the terminal cover (waterproof) or glasscover until you remove the
sand and dust by rinsing this unit.
Make sure to clean the camera after using it.
≥Thoroughly wipe off any water droplets, sand, and saline matter on your hands, body, hair, etc.
≥
It is recommended to clean the camera indoors, avoiding places where water spray or sand may fall.
Do not leave this unit uncared for longer than 60 minutes after using it underwater.
≥Leaving this unit with foreign objects or saline matter on it may cause damage, discolouration,
corrosion, unusual odour, or deterioration of the waterproof performance.
HX-A1M-SQT0886_mst.book 8 ページ ２０１５年４月６日 月曜日 午前９時４６分

9
(ENG) SQT0886
≥If you remove the terminal cover (waterproof) or glasscover without thoroughly drying this unit,
water droplets may form on the card or other parts. Also, water may accumulate in the gap
around the card slot or the terminal connector. Be sure to wipe any water off with a soft, dry cloth.
≥If you attach the terminal cover (waterproof) or glasscover while still wet, water droplets may seep
into this unit and cause condensation or malfunctions.
≥If the Multi Mount or Tripod Mount are exposed to seawater, rinse off the salt water with fresh
water. When the Multi Mount or Tripod Mount are exposed to water, wipe them off with a dry towel
or something similar, and dry them thoroughly in the shade.
≥It may cause injury to the skin if you directly touch the metal parts of the unit in places
where temperature is very low (environments under 0 oC, such as ski resorts or places at
high altitude) for a long period of time.
Keep this point in mind when using this unit for a long period of time.
≥The performance of the battery (recording time/operating time) may decrease temporarily when
using in a temperature between j10 oC and 0 oC (cold places such as ski resorts or places at
high altitude). (Charge the battery sufficiently before use.)
≥The battery cannot be recharged at temperatures lower than 0 oC. (The power lamp flashes fast
when the battery cannot be recharged.) Charge the battery sufficiently in a place where the
ambient temperature is between 10 oC and 30 oC.
≥If the unit is used in cold places such as ski resorts or places at high altitude with snow or water
droplets adhered to the unit, some parts of the unit may become hard to move or the sound may
become dim with snow or water droplets freezing in the gap of the buttons and microphone. This
is not a malfunction.
≥If the Wi-Fi® function is used in cold places such as ski resorts or places at high altitude, playback
may not be performed correctly.
In case water enters this unit, stop the use and consult your dealer.
Malfunctions resulting from water leakage due to wrong handling by customers are not subject to
compensation.
Preparation
When using in a cold climate or at low
temperatures
HX-A1M-SQT0886_mst.book 9 ページ ２０１５年４月６日 月曜日 午前９時４６分

10
SQT0886 (ENG)
∫About recording formats and compatibility of this unit
≥This unit is an MP4 format (MPEG-4 AVC file standard) Wearable Camera for recording high-
definition motion pictures.
≥AVCHD and MPEG2 motion pictures are different formats, and are not therefore supported by
this unit.
∫About the portrait rights
Be sure to pay special attention to the privacy, the portrait rights, etc. of the subject when you use
this unit. Use it at your own risk.
∫About the “Image App”
Install the smartphone application “Image App” on your smartphone.
You can change this unit’s settings and record and play back images by setting up a Wi-Fi
connection between this unit and a smartphone.
≥For information about the installation of the “Image App”, refer to page 18.
∫About the clock setting
Make sure to set date and time before recording. (l20)
∫For the purposes of these operating instructions
≥Pictures may be slightly different from the original.
≥Depending on the firmware version you are using, captured screens described in these operating
instructions may differ from the actual screens.
≥Names, icons, contents and services of applications may be changed with no prior notice. Please
note that they may differ from the descriptions of these operating instructions.
≥microSD card, microSDHC card and microSDXC card are referred to as the “microSD card”.
≥Smartphone and tablet computer are referred to as the “smartphone”.
≥Pages for reference are indicated by an arrow, for example: l00
≥Smartphone operations are described as follows:
Preparation
Read this first
∫Indemnity about recorded content
Panasonic does not accept any responsibility for damages directly or indirectly due to any type
of problems that result in loss of recording or edited content, and does not guarantee any
content if recording or editing does not work properly. Likewise, the above also applies in a case
where any type of repair is made to this unit.
Tap
Touch the screen
lightly and release
your finger.
Drag
Move your finger
while still touching
the screen.
Drag and Drop
Move your finger
while still touching
the screen, and
release the finger.
HX-A1M-SQT0886_mst.book 10 ページ ２０１５年４月６日 月曜日 午前９時４６分
