Panasonic DMP-BD60GN User manual

©Panasonic Corporation 2009.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.CHM0903012CE
Blu-ray Disc Player
Model No. DMP-BD60GN
DMP-BD60GA
DMP-BD60GZ
DMP-BD60GC
DMP-BD60PU
DMP-BD80GN
Vol. 2
Colour
(K).......................Black Type

2
TABLE OF CONTENTS PAGE PAGE
1 Safety Precautions -----------------------------------------------3
1.1. General guidelines-----------------------------------------3
2Warning--------------------------------------------------------------4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatic Sensitive (ES) Devices---------------4
2.2. Service caution based on legal restrictions----------5
3 Service Navigation------------------------------------------------6
3.1. Caution when Replacing EEPROM or
DIGITAL P.C.B. ---------------------------------------------6
4 Specifications------------------------------------------------------7
5 Service Mode-------------------------------------------------------9
5.1. Self-Diagnosis and Special Mode Setting------------9
6 Service Fixture & Tools ---------------------------------------18
7 Measurements and Adjustments --------------------------19
7.1. Service Positions-----------------------------------------19
7.2. Adjustment of BDP/Digital P.C.B. Module----------20

3
1 Safety Precautions
1.1. General guidelines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
1.1.1. Leakage current cold check
1. Unplug the AC cord and connect a jumper between the
two prongs on the plug.
2. Measure the resistance value, with an ohmmeter,
between the jumpered AC plug and each exposed metal-
lic cabinet part on the equipment such as screwheads,
connectors, control shafts, etc. When the exposed metal-
lic part has a return path to the chassis, the reading
should be between 1MΩand 5.2MΩ.
When the exposed metal does not have a return path to
the chassis, the reading must be .
1.1.2. Leakage current hot check
(See Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use
an isolation transformer for this check.
2. Connect a 1.5kΩ, 10 watts resistor, in parallel with a
0.15μF capacitors, between each exposed metallic part
on the set and a good earth ground such as a water pipe,
as shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more sensi-
tivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the volt-
age at each point.
5. Reverse the AC plug in the AC outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed 0.75 volts
RMS. A leakage current tester (Simpson Model 229 or
equivalent) may be used to make the hot checks, leakage
current must not exceed 1/2 milliampere. In case a mea-
surement is outside of the limits specified, there is a pos-
sibility of a shock hazard, and the equipment should be
repaired and rechecked before it is returned to the cus-
tomer.
Figure 1

4
2Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive
(ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec-
trostatic Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistor-sand semi-
conductor chip components. The following techniques should be used to help reduce the incidence of component damage caused
by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alumi-
num foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as anti-static (ESD protected) can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or compara-
ble conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity sufficient
to damage an ES device).

5
2.2. Service caution based on legal restrictions
2.2.1. General description about Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this
equipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin
(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30 degrees C (86°F) more than that
of the normal solder.
Definition of PCB Lead Free Solder being used
Service caution for repair work using Lead Free Solder (PbF)
• The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of PbF is printed on the PCB using the lead free solder.)
• To put lead free solder, it should be well molten and mixed with the original lead free solder.
• Remove the remaining lead free solder on the PCB cleanly for soldering of the new IC.
• Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt the
lead free solder.
• Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30 degrees
C (662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
• The following 3 types of lead free solder are available through the service parts route.
RFKZ03D01KS-----------(0.3mm 100g Reel)
RFKZ06D01KS-----------(0.6mm 100g Reel)
RFKZ10D01KS-----------(1.0mm 100g Reel)
Note
* Ingredient: tin (Sn), 96.5%, silver (Ag) 3.0%, Copper (Cu) 0.5%, Cobalt (Co) / Germanium (Ge) 0.1 to 0.3%
The letter of PbF is printed either foil side or components side on the PCB using the lead free solder.
(See right figure)

6
3 Service Navigation
3.1. Caution when Replacing EEPROM or DIGITAL P.C.B.
When replacing EEPROM (IC51601) or DIGITAL P.C.B. only, change the destination as following the steps below mentioned.
1. Select the destination and Model No. from the latest version of “DIGA Repair Support Navi PAL”.
2. Select “Serial Remote” function.
After performing above steps, update to the latest firmware.

7
4 Specifications

8

9
5 Service Mode
5.1. Self-Diagnosis and Special Mode Setting
5.1.1. Self-Diagnosis Functions
Self-Diagnosis Function provides information for errors to service personnel by Self-Diagnosis Display when any error has
occurred.
U**, H** and F** are stored in memory and held.
You can check latest error code by transmitting [0] [1] of Remote Controller in Service Mode.
Automatic Display on FL will be cancelled when the power is turned off or AC input is turned off during self-diagnosis display is ON.
Error Code Diagnosis contents Description Monitor Display Automatic FL display
U30 Remote control code error Display appears when main unit and remote
controller codes are not matched. No display
*is remote controller code of the
main unit.
Display for 5 seconds.
U59 Abnormal inner temperature
detected Display appears when the drive temperature exceeds 70°C.
The power is turned off forcibly.
For 30 minutes after this, all key entries are
disabled. (Fan motor operates at the highest
speed for the first 5 minutes. For the remain-
ing 25 minutes, fan motor is also stopped.)
The event is saved in memory as well.
No display
U59 is displayed for 30 minutes.
U71 HDMI incompatible error
(HDCP incompatible) Display this error when the equipment (com- patible with DVI such as TV, amplifier etc.)
connected to the unit by HDMI is incompatible
with HDCP.
*HDCP = High-bandwidth Digital Content Pro-
tection
No display
U72 HDMI connection error
(communication error) This error is displayed when there are any communication problems with the unit and the
equipments (TV, amplifier etc.) connected to
the unit by HDMI. (or when there is a problem
with the HDMI cable)
No display
U72 display disappears when
error has been solved by Power
OFF/ON of connecting equipment
or by inserting/removing of HDMI
cable.
U73 HDMI connection error
(authentication error) when authentication error occurs while the equipments (TV, amplifier etc.) are connected
by HDMI. (or when there is a problem with the
HDMI cable)
No display
U73 display disappears when
error has been solved by Power
OFF/ON of connecting equipment
or by inserting/removing of HDMI
cable.
F99 Hang-up Displayed when communication error has
occurred between Main microprocessor and
Timer microprocessor.
No display
Displayed is left until the [POWER]
key is pressed.
H19 02 Inoperative fan motor When inoperative fan motor is detected after
powered on, the power is turned off
automatically.
The event is saved in memory.
No display No display
F00 No error information Initial setting for error code in memory
(Error code Initialization is possible with error
code initialization and main unit initialization.)
No display No display
F34 Initialization error When initialization error is detected after
starting up main microprocessor, the power is
turned off automatically.
The event is saved in memory.
No display No display
F58 Drive hardware error When drive unit error is detected, the event is
saved in memory. No display No display

10
5.1.2. Special Modes Setting
UNSUP-
PORT Unsupported disc error *An unsupported format disc was played, although the drive starts normally.
*The data format is not supported, although
the media type is supported.
*Exceptionally in case of the disc is dirty.
This disc is
incompatible. Display for 5 seconds.
The character indication flows
sideways.
NO READ Disc read error *A disc is flawed or dirty.
*A poor quality failed to start.
*The track information could not be read.
Cannot read.
Please check the
disc.
HARD
ERR Drive error The drive detected a hard error. DVD drive error. Display for 5 seconds.
The character indication flows
sideways.
SELF
CHECK Restoration operation Since the power cord fell out during a power failure or operation, it is under restoration
operation.
*It will OK, if a display disappears automati-
cally. If a display does not disappear, there is
the possibility that defective Digital P.C.B. /
BDP drive.
No display
The character indication flows
sideways.
PLEASE
WAIT Unit is in termination process Unit is in termination process now. BYE is displayed and power will be turned off. No display
The character indication flows
sideways.
UNFOR-
MAT Unformatted disc error You have inserted an unformatted BD-RE/ BD-R/DVD-RAM/DVD-RW or raw +R/+R DL,
or DVD-RW of DVD-Video format.
This disc is not for-
matted properly.
Cannot be played.
The character indication flows
sideways.
No PLAY When there is a viewing restric-
tion on a BD-Video or DVD-
Video.
Rating password is set. No display
Item FL display Key operation
Mode name Description Front Key
Rating password The audiovisual level setting password is ini-
tialized to Level 8.Open the tray, and press [SKIP REV (Remote Controller)] and [PLAY]
simultaneously for 5 seconds.
Service Mode Setting every kind of modes for servicing.
*Details are described in 5.1.3. Service Mode
at a glance.
When the power is off, press
[PAUSE], [PLAY] and [SETUP
(Remote Controller)] keys simulta-
neously for 5 seconds.
BD-ROM history cleaning < Persistent Storage> of BD-ROM standard is
cleaned.
Screen display: [The history has been
cleared] is displayed for five seconds. Same display as before execution.
When the power is on, disc is not in
tray, press [STOP] and [POWER
(Remote Controller)] keys simulta-
neously for 5 seconds.
Forced disc eject Removing a disc that cannot be ejected.
The tray will open and unit will shift to P-off
mode.
While Demonstration Lock is being set, this
Forced disc eject function is not accepted.
The display before execution
leaves. When the power is off, press [PAUSE] and [OPEN/CLOSE] keys
simultaneously for 5 seconds.
NTSC/PAL system select To switch PAL/NTSC alternately. The display before execution
leaves. When the power is on (SS mode),
press [STOP] and [OPEN/CLOSE]
simultaneously for 5 seconds.
Forced power-off When the power button is not effective while
power is ON, turn off the power forcibly. Display in P-off mode. Press [POWER] key over than 4 seconds.
Error Code Diagnosis contents Description Monitor Display Automatic FL display

11
Aging Perform sequence of modes as * Aging
Description shown below continually. Display following the then mode. When the power is ON, press [PAUSE], [PLAY] and [OPEN/
CLOSE] simultaneously for over 5
seconds and less than 10 seconds.
NOTE1:
If the unit has hung-up because of
pressing keys for over 10 seconds,
once turn off the power, and re-exe-
cute this command.
*When releasing Aging mode, press
[POWER] key over 4 seconds.
Demonstration lock/
unlock Ejection of the disc is prohibited. The lock setting is effective until unlocking the
tray and not released by Main unit
initialization of service mode.
*When lock the tray.
LOCK is displayed for 3 seconds.
When the power is on (SS mode),
press [PLAY] and [OPEN/CLOSE]
keys simultaneously for 5 seconds.
Note:
When a disc is not in tray, this
setting is not effective.
*When unlock the tray.
UNLOCK is displayed for 3 sec-
onds.
When the power is on (SS mode),
press [PLAY] and [OPEN/CLOSE]
keys simultaneously for 5 seconds.
*When press OPEN/CLOSE key
while the tray being locked.
Display LOCK for 3 seconds.
Press [OPEN/CLOSE] key while the
tray is being locked.
Progressive initialization The progressive setting is initialized to Inter-
lace. The display before execution leaves. When the power is on (SS mode), press [STOP] and [PLAY] simulta-
neously for 5 seconds.
Item FL display Key operation
Mode name Description Front Key

12
Default setting The date of Menu, Mode and EEPROM set-
ting, etc. is set to the default condition in fac-
tory.
HELLO, BYE are displayed.
When the power is off, press
[PAUSE], [POWER] and [OPEN/
CLOSE] simultaneously for 5 sec-
onds.
Item FL display Key operation
Mode name Description Front Key

13
5.1.3. Service Modes at a glance
Service mode setting: While the power is off, press [PAUSE], [PLAY] and [SETUP (Remote Controller)] simultaneously for five
seconds.
Item FL display Key operation
Mode name Description (Remote controller key)
Release Items Item of Service Mode executing is cancelled. Press [0] [0] in service mode.
Error Code Display Last Error Code of U/H/F held by Timer is dis-
played on FL.
*Details are described in 5.1.1. Self-Diagno-
sis Functions.
If any error history dose not exist,
[F00] is displayed.
Press [0] [1] in service mode
ROM Version Display 1. Region code (displayed for 5 sec.)
2. Main firm version (displayed for 5 sec.)
3. Timer firm version (displayed for 5 sec.)
4. Drive firm version (displayed for 5 sec.)
5. ROM correction version (displayed for 5
sec.)
6. B002 version (displayed for 5 sec.)
7. B003 version (left displayed)
*are version displays.
Press [0] [2] in service mode
Drive application check Checking whether the drive is applicable drive
or not. Press [0] [3] in service mode.
Drive check Simple quality of BD drive. Press [3] [8] in service mode.

14
Laser Used Time
Indication Check laser used time (hours) of drive.
l(****) is the used time display in
hour.
lLaser used time of BD/ DVD/ CD in
Playback/Recording mode is
counted.
Press [4] [1] in service mode.
Item FL display Key operation
Mode name Description (Remote controller key)

15
BD drive last error BD drive error code display. 1. Error Number is displayed for 5
seconds.
2. Please ignore this display.
3. Last drive error (1/2) is displayed
for 5 seconds.
00 : Bad disc
03 : Bad disc
04 : Bad disc or drive malfunction
4. Last drive error (2/2) is displayed
for five seconds.
5. Error occurring disc type is dis-
played for 5 seconds.
Press [4] [2] in service mode.
Item FL display Key operation
Mode name Description (Remote controller key)

16
6. Disc maker ID is displayed for 5
seconds.
7. Factor of drive error (hexadeci-
mal) occurring is left displayed.
In case that the maker cannot be
identified, display is black out.
Item FL display Key operation
Mode name Description (Remote controller key)

17
CEC (H) output Check of the CEC terminal high output of
HDMI. Press [5] [5] in service mode.
CEC (L) output Check of the CEC terminal low output of
HDMI. Press [5] [6] in service mode.
Tray OPEN/CLOSE Test The BD drive tray is opened and closed
repeatedly.
*is number of open/close cycle
times.
Press [9] [1] in service mode
*When releasing this mode, press
the [POWER] button of Remote
Controller more than 4 seconds.
Delete the Laser Used
Time Laser used time stored in the memory of the unit is deleted. Press [9] [5] in service mode.
Delete the Last Drive
Error Delete the Last Drive Error information stored on the BD Drive. Press [9] [6] in service mode.
Delete the Error History Delete Error History information stored on the
unit. Press [9] [7] in service mode.
Error code initialization Initialization of the last error code held by
timer (Write in F00) Press [9] [8] in service mode.
Initialize Service Last Drive Error, Error history and Error
Codes stored on the unit are initialized to fac-
tory setting.
Press [9] [9] in service mode.
Finishing service mode Release Service Mode. Display in STOP (SS) mode. Press power button on the front
panel or Remote controller in ser-
vice mode.
Item FL display Key operation
Mode name Description (Remote controller key)

18
6 Service Fixture & Tools
Part Number Description Pcs Compatibility
RFKZ0216 Extension Cable (AV Out P.C.B. - Digital P.C.B. / 23 Pin) (only BD80) 1 Same as EH55 Series
RFKZ0168 Extension Cable (Power P.C.B. - Fan Motor / 3 Pin) 1 Same as EH55 Series
RFKZ0239 Extension Cable (Front P.C.B. - Digital P.C.B. / 10 Pin) 1 Same as EH55 Series
RFKZ0367 Extension Cable (Power P.C.B. - Front P.C.B. / 6 Pin) 1 Same as EH55 Series
JZS0484 Eject Pin 1 Same as ES15/ E50 Series
RFKZ03D01KS Lead Free Solder (0.3mm/100g Reel) - Same as EH55 Series
RFKZ06D01KS Lead Free Solder (0.6mm/100g Reel) - Same as EH55 Series
RFKZ10D01KS Lead Free Solder (1.0mm/100g Reel) - Same as EH55 Series
RFKZ0316 Solder Remover (Lead free low temperature Solder/50g) - Same as EH55 Series
RFKZ0328 Flux - Same as EH55 Series

19
7 Measurements and Adjustments
7.1. Service Positions
Note:
For description of the disassembling procedure, see the section 9.
7.1.1. Checking and Repairing of BDP/Digital P.C.B. Module

20
7.2. Adjustment of BDP/Digital P.C.B. Module
7.2.1. Repair Flowchart
