Panasonic HDC-SD600P User manual

until
2010/5/17
For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,
contact us via the web at: http://www.panasonic.com/contactinfo
Operating Instructions
High Definition Video Camera
Model No.HDC-SD600P
Before connecting, operating or adjusting this product, please read the instructions completely.
Spanish Quick Use Guide is included.
Guía para rápida consulta en español está incluida.
VQT2U72
