Panasonic Palmcorder PV-L672 User manual

Basic Operation Special Features For Your Information
Getting Started
Camcorder
Operating Instructions
Please read these instructions carefully before attempting to operate this product.
Please save this manual.
Guía para rápida consulta en español está incluida.
Model No.
LSQT0607
P -L672
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
01.L672 Getting p01-08 02.2.19, 0:49 PM1

2
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Things You Should Know
Thank you for choosing Panasonic!
You have purchased one of the most
sophisticated and reliable products on the
market today. Used properly, it will bring
you years of enjoyment. Please take time
to fill in the information to the right.
The serial number is on the tag located on
the rear side of your Camcorder. Be sure
to retain this manual as your convenient
Camcorder information source.
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
1 pc. C daptor (PV- 20)
with DC Power Cable
(page 10)
1 pc. CR2025 Clock Battery
(VSBW0004)
(installed in Camcorder)
(page 51)
1 pc. Shoulder Strap
(LSFC0012) (page 12)
1 pc. udio/Video Cable
(LSJ 0390) (pages 21, 22) 1 pc. Battery Pack (PV-BP18) (pages 9, 10)
These accessories are provided in order to set up or use your Camcorder.
Unpack your Camcorder
1 pc. Digital PhotoShot Disk
for Windows 95/98/Me/2000
(LSFT0490) (page 42)
1 pc. PC Connection Cable
(RS232C-2.5P)
(LSJ 0276) (page 42)
SD is a trademark of the SD Card ssociation.
MultiMediaCard is a registered trademark of the MultiMediaCard ssociation.
Microsoft and Windows are registered trademarks of Microsoft in the United States and
other countries.
ll product/brand names are trademarks or registered trademarks of the respective holders.
1 pc. Lens Cap (LSYK0817)
with Lens Cap Strap
(LSGQ0049) (page 12)
1 pc. VHS PlayPak
(PV-P1/VYMW0009) and
one “ ” battery (page 21)
01.L672 Getting p01-08 02.2.19, 0:49 PM2

3
Getting Started
Safety Precautions
WARNING:TO PRE ENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
Your Compact VHS Camcorder is designed to record and play back in Standard Play (SP)
and Super Long Play (SLP) modes. You can also play a Compact VHS Camcorder
recording on your VHS VCR using the supplied VHS PlayPak.
This Camcorder is equipped with the HQ System to provide excellent video pictures, and
is compatible with standard VHS equipment.
It is recommended that only cassette tapes that have been tested and inspected for use in
VCR machines with the and/or mark be used.
This symbol warns the user that
uninsulated voltage within the unit may
have sufficient magnitude to cause
electric shock. Therefore, it is dangerous
to make any kind of contact with any
inside part of this unit.
This symbol alerts the user that important
literature concerning the operation and
maintenance of this unit has been included.
Therefore, it should be read carefully in
order to avoid any problems.
The above markings are located on the appliance’s bottom cover.
Note: This equipment has been tested and found to comply with Part 15 and part 18 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when
operated in a residential environment.
If this equipment does cause interference to radio or television reception, which can be determined by
turning the equipment off and on, use the equipment in another location and/or utilize an electrical
outlet different from that used by the receiver.
If necessary, consult the dealer or an experienced radio/TV technician for help. You may find the
booklet, ‘Something bout Interference’ available from FCC local regional offices helpful.
This product may cause interference to radio equipment and should not be installed near maritime
safety communications equipment or other critical navigation or communication equipment operating
between 0.45-30 MHz.
FCC Warning : To assure continued FCC compliance, the user must use only provided
shielded interfacing cable with ferrite cores when connecting to
computer. lso, any unauthorized changes or modifications to this
equipment would void the users authority to operate.
Things You Should Know
Declaration of Conformity
Model Number : P -L672
Trade Name : Panasonic
Responsibility Party : Matsushita Electric Corporation of merica
ddress : One Panasonic Way Secaucus New Jersey 07094
Telephone Number : 1-800-211-P N (7262)
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
01.L672 Getting p01-08 02.2.19, 0:49 PM3

4
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
1. Read Instructions – ll the safety and
operating instructions should be read before
the unit is operated.
2. Retain Instructions – The safety and
operating instructions should be retained for
future reference.
3. Heed Warnings – ll warnings on the unit
and in the operating instructions should be
adhered to.
4. Follow Instructions – ll operating and
maintenance instructions should be followed.
5. Cleaning – Unplug this video unit from the
wall outlet before cleaning. Do not use liquid
or aerosol cleaners. Use a dry cloth for
cleaning.
6. Attachments – Do not use attachments not
recommended by the video product
manufacturer as they may be hazardous.
7. Water and Moisture – Do not use this video
unit near water – for example near a bath tub,
wash bowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, and
the like.
8. Accessories – Do not place this video unit
on an unstable cart, stand, tripod, bracket, or
table. The video unit may fall, causing serious
injury to a child or adult, and serious damage
to the unit. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer, or sold with the video unit. ny
mounting of the unit should follow the
manufacturer’s instructions and should use a
mounting accessory recommended by the
manufacturer. n appliance and cart
combination should be moved
with care. Quick stops,
excessive force, and uneven
surfaces may cause the
appliance and cart combination
to overturn.
9. entilation – Slots and openings in the
cabinet are provided for ventilation and to
ensure reliable operation of the video unit
and to protect it from overheating. These
openings must not be blocked or covered.
Never place the video unit on a bed, sofa,
rug, or other similar surface, or near or over a
radiator or heat register. This video unit
should not be placed in a built-in installation
such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s
instructions have been adhered to.
10. Power Sources – This video unit should be
operated only from the type of power source
indicated on the marking label. If you are not
sure of the type of power supply to your
home, consult your appliance dealer or local
power company. For video units intended to
be operated from battery power, or other
sources, refer to the operating instructions.
Important Safeguards
11. Grounding or Polarization – This video unit
may be equipped with either a polarized
2-wire C ( lternating Current) line plug (a
plug having one blade wider than the other)
or 3-wire grounding type plug, a plug having a
third (grounding) pin.
The 2-wire polarized plug will fit into the
power outlet only one way. This is a safety
feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If
the plug still fails to fit, contact your electrician
to replace your obsolete outlet.
Do not defeat the safety purpose of the
polarized plug.
The 3-wire grounding type plug will fit into a
grounding type power outlet. This is a safety
feature. If you are unable to insert the plug
into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat
the safety purpose of the grounding type plug.
12. Power-Cord Protection – Power-supply
cords should be routed so that they are not
likely to be walked on or pinched by items
placed upon or against them. Paying
particular attention to cords of plugs,
convenience receptacles, and the point where
they exit from the unit.
13. Outdoor Antenna Grounding – If an outside
antenna or cable system is connected to the
video unit, be sure the antenna or cable
system is grounded so as to provide some
protection against voltage surges and built-up
static charges. Part 1 of the Canadian
Electrical Code, in US Section 810 of the
National Electrical Code, provides information
with respect to proper grounding of the mast
and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size
of grounding conductors, location of antenna
discharge unit, connection to grounding
electrodes, and requirements for the
grounding electrode.
14. Lightning – For added protection of this
video unit receiver during a lightning storm, or
when it is left unattended and unused for long
periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system.
This will prevent damage to the video unit due
to lightning and power-line surges.
01.L672 Getting p01-08 02.2.19, 0:49 PM4

5
Getting Started
USE & LOCATION
•TO A OID SHOCK HAZARD ... Your Camcorder and power supply should not be exposed to rain or moisture.
Do not connect the power supply or operate your Camcorder if it gets wet. Your Camcorder has been designed for
outdoor use, however it is not designed to sustain direct exposure to water, rain, sleet, snow, sand, dust, or a direct
splashing from a pool or even a cup of coffee. This action could permanently damage the internal parts of your
Camcorder. Do not attempt to disassemble this unit. There are no user serviceable parts inside. Unplug your
Camcorder from the power supply before cleaning.
•DO NOT AIM YOUR CAMCORDER AT THE SUN OR OTHER BRIGHT OBJECTS.
•DO NOT LEA E THE CAMCORDER WITH THE E F AIMED DIRECTLY AT THE SUN AS THIS MAY CAUSE
DAMAGE TO THE INTERNAL PARTS OF THE E F.
•DO NOT EXPOSE YOUR CAMCORDER TO EXTENDED HIGH TEMPERATURE ... Such as, in direct sunlight,
inside a closed car, next to a heater, etc... This action could permanently damage the internal parts of your
Camcorder.
•A OID SUDDEN CHANGES IN TEMPERATURE ... If the unit is suddenly moved from a cold place to a warm
place, moisture may form on the tape and inside the unit.
•DO NOT LEA E YOUR CAMCORDER OR THE POWER SUPPLY TURNED ON WHEN NOT IN USE.
•STORAGE OF YOUR CAMCORDER ... Store and handle your Camcorder in a manner that will not subject it to
unnecessary movement (avoid shaking and striking). Your Camcorder contains a sensitive pick-up device which
could be damaged by improper handling or storage.
CARE
•TO CLEAN YOUR CAMCORDER ... Do not use strong or abrasive detergents when cleaning your Camcorder
body.
•TO PROTECT THE LENS ... Do not touch the surface of the lens with your hand. Use a commercial camcorder
lens solution and lens paper when cleaning the lens. Improper cleaning can scratch the lens coating.
•TO PROTECT THE FINISH OF YOUR CAMCORDER ... Before handling your Camcorder, make sure your hands
and face are free from any chemical products, such as suntan lotion, as it may damage the finish.
Important Safeguards
15. Power Lines – n outside antenna system
should not be located in the vicinity of overhead
power lines or other electric light or power
circuits, or where it can fall into such power
lines or circuits. When installing an outside
antenna system, extreme care should be taken
to keep from touching such power lines or
circuits as contact with them might be fatal.
16. Overloading – Do not overload wall outlets
and extension cords as this can result in a
risk of fire or electric shock.
17. Objects and Liquids – Never push objects
of any kind into this video unit through
openings as they may touch dangerous
voltage points or short out parts that could
result in a fire or electric shock. Never spill
liquid of any kind onto the video unit.
18. Servicing – Do not attempt to service this
video unit yourself as opening or removing
covers may expose you to dangerous voltage
or other hazards. Refer all servicing to
qualified service personnel.
19. Damage Requiring Service – Unplug this
video unit from the wall outlet and refer
servicing to qualified service personnel under
the following conditions:
a. When the power-supply cord or plug is
damaged.
b. If any liquid has been spilled into, or
objects have fallen onto, the video unit.
c. If the video unit has been exposed to rain
or water.
d. If the video unit does not operate normally
by following the operating instructions.
djust only those controls that are covered
by the operating instructions, as an improper
adjustment of other controls may result in
damage and will often require extensive
work by a qualified technician to restore the
video unit to its normal operation.
e. If the video unit has been dropped or the
cabinet has been damaged.
f. When the video unit exhibits a distinct
change in performance – this indicates a
need for service.
20. Replacement Parts – When replacement
parts are required, be sure the service
technician has used replacement parts
specified by the manufacturer or have the
same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock or other hazards.
21. Safety Check – Upon completion of any
service or repairs to this video unit, ask the
service technician to perform safety checks
to determine that the video unit is in safe
operating order.
Precautions
01.L672 Getting p01-08 02.2.19, 0:49 PM5

6
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Table of Contents
iewfinder/LCD Monitor Indications .......................................................47~49
Operation Notes (Cleaning EVF) ...........................................................................50
Notice ...............................................................................................................50
Replacing Clock Battery.................................................................................51
Palmcorder Accessory System .....................................................................52
Palmcorder Accessory Order Form ..............................................................53
Specifications..................................................................................................54
Before Requesting Service (Video Head Cleaning, Self Diagnostic System) .........55~56
Request for Service Notice ............................................................................56
Limited Warranty .............................................................................................57
Customer Services Directory.........................................................................58
Spanish Quick Use Guide/Guía Para Uso Rápido........................................59
Index.................................................................................................................60
Things You Should Know.............................................................................2~3
Important Safeguards ...................................................................................4~5
Precautions........................................................................................................5
Self Demo Mode ................................................................................................7
Quick Operation Guide .....................................................................................8
Supplying Power (Battery Charge/Use/Refresh/Care, C daptor, Car Battery Cord)....9~10
Cassette Information ......................................................................................11
Before Using (Using the Shoulder and Hand Straps, Lens Cap) ....................................12
Using MENU Mode ..........................................................................................13
Setting the Clock (Time Zone, uto Daylight Saving Time) ...................................14~15
Built-in Auto Light (Using the Light, Rplacing the Bulb).............................................16
Camera Recording (Basic, Stand-by, Programmed Recording) .............................17~19
Playing Back Recordings
(Basic Playback, Visual Search, Still Picture, Tracking, TV/VCR Playback) .................20~21
Copying your Tapes (dubbing) ......................................................................22
Four-Speed Power Zoom............. 23
Backlight ....................................... 23
MagicPix™ Images....................... 24
Focus ( uto/Manual Focus) ................. 25
High Speed Shutter ( uto/Manual Shutter) 26
Auto Fade...................................... 27
Color Digital Fade ........................ 28
Color Digital Filter ........................ 29
Digital Zoom ................................. 30
Digital Electronic Image
Stabilization (E.I.S.).................... 31
Still/Strobe/Wide........................... 32
MotionSensor ............................... 33
Digital Still Camera ..................34~41
• Memory Card (optional)
Insertion/Removal ........................34
• Recording ..................................... 36
• Using the Light .............................37
• Playback........................................ 37
• Displayed Directry/Image Number ... 38
• Delete Specific Images ................39
• Picture in Picture Wipe Title........ 40
• Digital Wipe Mode ........................ 41
PC Connection .........................42~45
Using a SD PCMCIA Adaptor
(optional) ........................................ 46
Basic Operation Special Features For Your Information
Getting Started
01.L672 Getting p01-08 02.2.19, 0:49 PM6

7
Getting Started
Self Demo Mode
E F or LCD Monitor
Note:
• Self Demo stops automatically if battery
is attached (page 9) and cassette tape is
inserted (page 11).
• Inserting a tape alone (or attaching a
partially charged battery) only temporarily
stops Self Demo.
• Self Demo stops for 30 seconds when the
Light is pressed.
To turn Self Demo back on:
• Set to SELF DEMO : ON in MENU screen.
Before you begin...
• Connect Camcorder to power source.
Self Demo mode is on when the screen
below appears. To turn it off, follow
steps 1-4 below.
1Set POWER to CAMERA.
2Press MENU for
MENU mode.
Press UP or DOWN
to select
SELF DEMO .
3Press DISPLAY to select OFF.
4Press MENU to exit.
1
2, 3, 4
01.L672 Getting p01-08 02.2.19, 0:49 PM7

8
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Quick Operation Guide
See page 20.
1Press LCD-OPEN to unlock the LCD monitor.
Swing it fully open and adjust the angle.
2Set POWER to CAMERA.
3Press RECORD/PAUSE
to start recording.
Press RECORD/PAUSE
again to pause recording.
See page 17.
1Attach fully
charged Battery
(page 9).
2Slide TAPE
EJECT to open
door.
3Insert cassette
(page 11).
4Press here to
close door.
1Press LCD-OPEN to unlock the LCD monitor.
Swing it fully open and adjust the angle (see above).
Charging the Battery Pack
Charge Battery Pack fully before
operation (page 9).
1Plug in AC
Adaptor.
Camera Recording
Playback using the LCD Monitor
Insert Cassette
3Press REWIND/SEARCH
to rewind tape.
4Press PLAY to start
playback.
5Press STOP to stop
playback.
2Insert Battery. CH RGE Lamp
flashes, then stays lit when
charging is complete.
Protection Film
Note:
• Remove the Protection Film before use.
2Set POWER
to CR.
01.L672 Getting p01-08 02.2.19, 0:49 PM8

9
Getting Started
Supplying Power
To use battery refresh, insert Battery on AC
Adaptor (see steps 1~2 above), then press
BATTERY REFRESH.
The REFRESH Lamp lights, then goes out when
discharge is complete. Battery charging will then
start automatically.
If B TTERY REFRESH is pressed by mistake,
remove Battery from C daptor and reinsert it
for normal charging.
Note:
• Charging takes about 7 and 1/2 hours when
Battery Refresh is used.
• Battery will not operate in extremely high
temperatures.
Note:
• Charging takes about 1 and 1/2 hours.
• While the DC Power Cable (supplied) is connected
to the C daptor, the Battery cannot be charged.
• fter charging 5 times, use Battery Refresh feature
as explained below.
• Battery life gradually decreases after repeated use
and recharging. If operation time becomes very
short even after a sufficient charge, discard Battery
properly (pages 10, 50).
Charge Battery Pack fully before use. 1Plug in AC Adaptor.
POWER Lamp lights.
2Insert Battery.
Align left side of Battery with left edge of
C daptor.
BPress Battery down and slide in direction
of arrow.
The CH RGE Lamp flashes, then stays lit
when charging is complete.
3Remove Battery.
Slide Battery to the left and lift off.
Charging the Battery Pack
Battery Refresh
This feature completely discharges
Battery before recharging begins.
Use after every 5 charges for optimum
Battery performance.
fully charged Battery provides a maximum of about 2 hours of continuous use (LCD
monitor off) or about 1.5 hours (LCD monitor on). ctual time may vary due to operating
conditions. Using the Built-in Light decreases operating time.
Using the Battery Pack
A Attach Battery.
aInsert top of Battery into top of mounting
surface.
bPress and snap into place.
B Remove Battery.
Slide BATTERY RELEASE and remove
Battery.
b
A
B
a
POWER
Lamp
CHARGE
Lamp
1
23
A
(Top iew)
B
BATTERY
REFRESH
REFRESH
Lamp
02.L672 Getting p09-16 02.2.19, 0:49 PM9

10
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Supplying Power
Caution:
• Charge only with specified charger.
• Battery can be charged within a temperature range of
10 °C (50 °F) and 35 °C (95 °F).
• Battery is normally warm after charging or just after use.
• Do not use an insufficiently charged or worn-out Battery.
Safety precautions:
• Do not get Battery near, or dispose of in, fire.
• Do not directly connect (short circuit) the positive (+)
and negative (–) terminals.
• Never attempt to disassemble or reassemble Battery.
To avoid Battery damage:
• Do not drop or jar Battery.
• Use Battery with specified units only.
• If Battery is used in extremely high
temperatures, a safety device will
automatically prevent operation.
To prolong Battery life:
• While not in use, remove Battery from
the Camcorder and C daptor, and
store in a cool, dark, dry place.
• Keep Battery terminals clean.
Note:
• While the DC Power Cable (supplied) is
connected to the C daptor, the Battery
cannot be charged.
• When not in use, unplug C daptor from
C outlet. ( daptor uses 1.2 W of electricity
while plugged in.)
1Connect AC Adaptor DC OUT to
Camcorder DC IN with supplied DC
Power Cable.
2Plug in AC Adaptor.
POWER Lamp lights.
DC IN
Connector
DC Power Cable
POWER Lamp
DC OUT
Connector
DC IN
Connector
This unit will operate on 110/120/220/240 V C 50/60 Hz. n C plug adaptor may be required
for voltages other than 120 V C. Please contact either a local or foreign electrical parts
distributor for assistance in selecting an alternate C plug. We recommend using the accessory
power plug adaptor (VJSS0070) in an area which has special C outlets.
CAUTION:
1Connect P -C16 Car Battery Cord
(optional) to Camcorder DC IN.
2A Start engine first.
B Plug Car Battery Cord into
Cigarette lighter socket.
• If Car Battery cord fuse needs replacing,
use exact current rating (in amps).
Note:
• This cord only works in vehicles equipped
with DC 12 (negative ground) battery.
Check with your car/truck dealer. Use only
specified car battery cord.
• To avoid blowing the car battery cord fuse,
do step 2 in the proper order.
• Running vehicles must be well ventilated.
• When not in use, disconnect cigarette
lighter plug.
• For personal safety the driver of the vehicle
should not attempt to operate the
camcorder while driving.
Battery Care
AC Adaptor
Cigarette
Lighter
Socket (12 )
Car Battery Cord
(optional) Cigarette Lighter Plug
Car Battery Cord (Optional)
02.L672 Getting p09-16 02.2.19, 0:49 PM10

11
Getting Started
Cassette Information
1Turn Tape Wheel in direction of arrow
until there is no slack.
2Attach Battery (page 9).
3Slide TAPE EJECT to open door.
4Insert cassette as shown.
5Press here to close door.
12
3
4• To remove the cassette, slide the TAPE
EJECT switch.
5
1To prevent accidental erasing,
break off tab with screwdriver.
(Or, slide tab open.)
2To record again,
cover hole with adhesive tape.
(Or, slide tab closed.)
Protects tapes from being accidentally
erased.
Erase Protection Tab
Cassette Insertion/Removal
Slide tab type
12
• SLP playback may contain more picture noise.
SLP
(Super Long Play)
SP
(Standard Play)
Cassette type
Tape Speed
Selector Position TC-20
20 minutes
1 hour
30 minutes
TC-30 TC-40
40 minutes
1 hour
30 minutes 2 hours
Use tapes with the mark in this unit.
Record/Playback Time
02.L672 Getting p09-16 02.2.19, 0:49 PM11

12
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Before Using
Remove Battery Pack before doing steps.
1Undo strap ends
from buckles.
Attaching Shoulder Strap Adjust the Length of the
Shoulder Strap
Pull a loop of strap from buckle, then pull
strap tight to shorten or lengthen.
djust Hand Strap length to fit your hand as
shown.
2Thread strap ends through Strap
Rings on Camcorder.
3Re-insert the strap
ends into buckles.
Hand Strap
1
2
3
min. 25.4 mm (1 inch)
Attaching the Lens Cap
Strap:
Thread the Strap through
the Lens Cap attachment
ring as illustrated at left.
Lens Cap
Attaching the Lens Cap Cord to the Hand Strap:
Remove the Hand Strap from the front clasp and thread
the Strap through the loop in the Lens Cap Cord.
Reattach the Hand Strap.
02.L672 Getting p09-16 02.2.19, 0:49 PM12

13
Getting Started
Using MENU Mode
Before you begin...
• Connect Camcorder to power source.
• Set POWER to CAMERA or CR.
1Press MENU for MENU mode.
The C MER or VCR MENU screen (see below
left) appears when Menu mode is entered.
2Press UP or DOWN to highlight the
desired menu item.
3Press DISPLAY to set selection.
4Press MENU to exit.
Note:
• The Menu mode is canceled if UP/DOWN,
DISPL Y, or MENU are not pressed within 5
minutes when Self Demo mode is off.
• The Menu mode is canceled if UP/DOWN,
DISPL Y, or MENU are not pressed within 30
seconds when Self Demo mode is on.
MENU Mode ( CR) Screen
MENU Mode (CAMERA) Screen 1PROGRAMMED REC (page 19).
Camcorder starts and stops recording at a
preset time.
2DISPLAY (page 47).
ON :On-screen Display (OSD) screens are
displayed.
3SHUTTER (page 26).
Select desired shutter speed.
4STAND-BY RELEASE (page 18).
ON :Enables quick resumption of recording
from Stand-by mode.
5CLOCK SET (pages 14, 15).
Select to set clock.
6LIGHT MODE (page 16).
ON/OFF :Light can be set ON or OFF.
ON/OFF/ UTO: Light can be set ON, OFF, or UTO.
7SELF DEMO (page 7).
ON :SELF DEMO screen is displayed.
8DIGITAL WIPE (pages 40, 41).
ON :Digital wipe mode can be used.
9MAGICPIX (page 24).
ON :Picture sensitivity is increased.
10MOTIONSENSOR (page 33).
ON :Enables MotionSensor recording.
11 IDEO EFFECTS (pages 27~29).
UTO F DE :BL CK or WHITE
DIGIT L F DE :TYPE 7 types
COLOR 8 colors
DIGIT L FILTER :COLOR 5 colors
5
2
1, 2, 3, 4
1
2
3
4
5
6
7
8
9
10
11
02.L672 Getting p09-16 02.2.19, 0:49 PM13

14
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Setting the Clock
Before you begin...
• Connect Camcorder to power source.
• Set POWER to CAMERA or CR.
Set the following items in order: Time
Zone, Daylight Saving Time, Date,
and Time.
1Press MENU for MENU mode.
Press UP or DOWN to select CLOCK SET .
2Press DISPLAY for
CLOCK SET menu.
Press UP or DOWN to
select TIME ZONE, DST,
or DATE/TIME.
3Press DISPLAY for menu of item selected in
step 2.
To change the setting:
TIME ZONE ➔Go to step 3a on page 15.
D.S.T. ➔Go to step 3b on page 15.
DATE/TIME ➔Go to step 3c on page 15.
4Press MENU twice to exit.
[ CR MODE ][ CAMERA MODE ]
1, 2, 3, 4
(continued on next page)
02.L672 Getting p09-16 02.2.19, 0:49 PM14

15
Getting Started
Date and time including leap year are
calculated up to DEC 31, 2099.
Spring (First Sunday in April) :
ahead one hour.
Autumn (Last Sunday in October) :
back one hour.
Clock will auto-adjust to daylight saving time (DST).
Setting the Time Zone
•When traveling, repeat this operation and
select one of the 8 listed time zones to
set the clock to local time.
Press UP or DOWN to
select OFF or UTO.
Press DISPLAY to
confirm entry.
Press UP or DOWN to
select local time zone.
Press DISPLAY to
confirm entry.
DST: AUTO
Press or hold down UP or
DOWN to select hour, then
press DISPLAY to fix.
Repeat for minute, month, day,
and year.
Clock starts when year is
entered and DISPLAY is
pressed.
EXAMPLE :
Note:
•uto DST does not function if time zone
is set to Hawaii or Samoa (see “Setting
the Time Zone” above).
Note :
•Clock may lose or gain up to 2 minutes
per month.
• When traveling outside the listed time
zones, set clock to local time manually.
• To adjust or set clock, see “Setting Date
and Time” bottom of page.
The Camcorder is preset to DST: AUTO .
If DST is not observed in your area, set
to OFF by doing the following.
[ Time Zone chart ]
The Camcorder is preset to Eastern time.
Auto Daylight Saving Time
Setting Date and Time
Setting the Clock
3a
3b
3c
02.L672 Getting p09-16 02.2.19, 0:49 PM15

16
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Note:
• Using Light reduces battery operating time.
• Provide proper ventilation when using
Light extensively in a hot environment.
• Using Light when the Camcorder is
powered by a car battery may shorten
bulb life.
• Set Light to OFF when not in use.
For recording in dim lighting.
Using the Light
Built-in Auto Light
1, 2
CAUTION:
Light becomes hot.
Never cover Light while on.
Before you begin...
• Connect Camcorder to power source.
• Set POWER to CAMERA.
E F or LCD Monitor
A : Light is on.
A : Light mode is auto.
1Press MENU for
MENU mode. Press
UP or DOWN to
select LIGHT MODE .
2Press DISPLAY to set OFF/ON or
OFF/ON/ UTO. Press MENU to exit.
3Press LIGHT repeatedly for Light ON,
OFF, or UTO.
• In UTO, light turns itself on/off
according to lighting conditions.
Replacing the Bulb Before you begin...
• Order Part No. LLW0015 for replacement
bulb.
• Set POWER to OFF.
1
2
3
DANGER:
Use only replacement bulb (P RT NO. VLLW0015) supplied by Panasonic to reduce risk
of fire.
Handle new bulb with cloth or tissue as skin oils will decrease bulb life.
Remove lens cover and allow bulb to cool before replacing to avoid possible burn hazard.
1Slightly raise portion A of lens cover
to unhook, and slide portion B
forward to remove.
2Using Tweezers or needle-nose pliers,
carefully remove bulb.
• Take unit to service center if you need
assistance.
3Replace bulb using a clean cloth or
tissue. (Do not touch with fingers.)
4Replace lens cover.
Note:
• Handle bulb gently. Excessive force may
cause bulb to crack.
B
A
3
02.L672 Getting p09-16 02.2.19, 0:49 PM16

17
Basic Operation
Camera Recording
Before you begin...
• Connect Camcorder to power source.
• Insert cassette with record tab (page 11).
View recording scene on EVF (Electronic
Viewer Finder) or LCD (Liquid Crystal
Display) monitor.
Recording via E F or LCD
Monitor
1Press LCD-OPEN to unlock the LCD
monitor. Swing LCD monitor fully open
and adjust viewing angle.
• If you want to record using EVF, close
and lock LCD monitor.
2Set POWER to
CAMERA.
• Be sure POWER
is fully turned to
C MER position.
• EVF or LCD monitor
turns on/off by the POWER switch.
• Both EVF and LCD monitor turn on
when LCD is at 180° (see above left).
This allows both you and the subject to
view the recording.
3LCD: Press BRIGHT
ADJUSTMENT
to adjust LCD
monitor
brightness level.
E F : Look into E F and adjust
ISION ADJUSTMENT to your
eyesight.
4Hold down TAPE SPEED for about 1
second to change tape speed to SP/SLP
(page 11).
5Press RECORD/
PAUSE to start or
pause recording.
6Set POWER to
OFF when finished.
• To remove the cassette, slide the
T PE EJECT switch (page 11).
Note:
• When Camcorder is aimed at excessively
bright objects, or bright lights, a vertical
bar may appear in the picture. This is
normal for the CCD pick-up. Try to avoid
this when possible.
• Using LCD monitor reduces battery
operation time. Return LCD monitor to
locked position when not in use.
E F or LCD Monitor
(Record/Pause mode)
E F or LCD Monitor
(Record mode)
Tape speed
1
3
BRIGHT
ADJUSTMENT
CAUTION :
Rotating partially open LCD
monitor may block cassette door
and damage Camcorder body.
ISION
ADJUSTMENT
3
4
Built-in
Microphone
2, 6
5
03.L672 Basic p17-19 02.2.19, 0:49 PM17

18
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Before you begin...
• Connect Camcorder to power source.
• Insert cassette with record tab (page 11).
Camera Recording
1Set POWER to
CAMERA.
2Press MENU for
MENU mode.
Press UP or DOWN
to select STAND-BY RELEASE .
3Press DISPLAY to select ON/OFF.
ON : From Stand-by mode, press
RECORD/P USE two times to
resume recording.
OFF : From Stand-by mode, set
POWER to OFF, then to
C MER . Press RECORD/
P USE to record.
4Press MENU to exit.
Stand-by Quick Release
If left in RECORD/P USE mode for 5
minutes, Camcorder switches to Stand-by
mode to conserve battery. When set to ON,
Stand-by Quick Release lets you resume
recording by pressing RECORD/P USE two
times. Stand-by Quick Release is set to OFF
at the factory.
aPress RECORD/PAUSE to stop
recording.
bSet POWER to OFF and leave cassette
in Camcorder.
cTo resume recording, set POWER to
CAMERA.
dPress RECORD/PAUSE to resume
recording.
Note:
• Use Manual Easy Edit (left) if more than 24
hours before recording is resumed.
Manual Easy Editing For a smooth transition between scenes if
recording is stopped, and then started within
24 hours.
For proper continuity when taping from
Stop mode or after attaching a new
Battery.
Easy Edit Stand-by
ASet POWER to CR.
BaPress REWIND/SEARCH to rewind
a few seconds of tape.
bPress PLAY to review recording.
cPress STILL where you want to
continue recording.
CSet POWER to CAMERA.
DPress RECORD/PAUSE to resume
recording.
2, 3, 4
B
b
1, b, c,
A , C
a, d, D
ac
03.L672 Basic p17-19 02.2.19, 0:49 PM18

19
Basic Operation
Before you begin...
• Connect Camcorder to power source.
Use AC Adaptor for longer recordings.
• Insert cassette with record tab (page 11).
• Set POWER to CAMERA.
Camera Recording
1Press MENU for MENU
mode. Press UP or
DOWN to select
PROGRAMMED REC .
2Press DISPLAY.
(Current time is
displayed.)
Each additional press
of DISPLAY increases
start time by 30 minutes.
3Press DOWN to select
REC TIME .
Press DISPLAY
repeatedly to select one
of the options shown at
left.
To cancel the setup, press MENU twice.
4Press RECORD/PAUSE
to place Camcorder in
stand-by mode.
Recording will be done as scheduled.
Note:
• Start time may not be set over 24 hours from
current time.
• Camcorder shuts off at tape end, or 12 hours
after Interval Recording starts.
• To cancel, set POWER to OFF.
Set a recording start and stop time. Or,
set a 5 or 10 second interval recording
to be done each minute.
*1 Record 5 seconds each minute.
*2 Record 10 seconds each minute.
REC TIME :
Programmed Recording
4
1, 2, 3
03.L672 Basic p17-19 02.2.19, 0:49 PM19

20
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Playing Back Recordings
Before you begin...
• Connect Camcorder to power source.
• Insert recorded tape.
Tracking Control
Quick isual Search
Search Speed
• SP (Standard Play) : 3 times normal.
• SLP (Super Long Play) : 9 times normal.
During playback, press:
•FF : fast forward search
•REW : rewind search
Press again or press PL Y for normal play.
Still Picture
Press STILL to freeze picture.
Press again for normal play.
This feature works best in SLP mode (page 11).
Special Effects
Note:
•During search, horizontal noise bars will appear.
udio is muted.
•To protect video heads and tape, operating
modes will revert as follows after 5 minutes:
Still Stand-by
Stand-by Power off (when Battery Pack is
used).
• Tape auto-rewinds if played or fast forwarded to end.
Note:
• Using LCD monitor reduces battery operating
time. Return LCD monitor to locked position
when not in use.
1Press LCD-OPEN and swing LCD
monitor fully open.
• If you want to playback on EVF, close
and lock LCD monitor.
2Set POWER to CR.
• If tape has no record tab, auto
playback begins.
• EVF or LCD monitor turns on/off by
the POWER switch.
3Playback function buttons.
AREW :Rewind tape.
BPLAY :Play tape.
CSTOP :Stop tape.
DBRIGHT : djust LCD monitor brightness.
EOLUME:During playback, adjust
volume of speaker.
Press “T” :Volume
up (+).
Press “W” :Volume
down (-).
Playback on E F or LCD Monitor
Auto Tracking
Continuously analyzes each recording for
optimum picture quality.
Manual Tracking
Some recordings require manual
adjustment to reduce noise.
Press UP or DOWN until Playback picture
clears up.
Press DISPLAY to return to uto Tracking.
Speaker
1
3
BRIGHT
ADJUSTMENT
D
2
3B
A
C
E
STILL
04.L672 Basic p20-22 02.2.19, 0:49 PM20
