Panasonic Viera HX-DC1 User manual

1AG6P1P6280--(S)
Owner’s Manual
Dual Camera
Model No.HX-DC10
HX-DC1
Before connecting, operating or adjusting this product, please read the instructions completely.
For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,
contact us via the web at: http://www.panasonic.com/contactinfo
PVQT3M88

2VQT3M88
Things You Should
Know
Thank you for choosing Panasonic!
You have purchased one of the most
sophisticated and reliable products on
the market today. Used properly, we’re
sure it will bring you and your family
years of enjoyment. Please take time
to fill in the information on the right.
The serial number is on the tag
located on the battery holder of your
camera. Be sure to retain this
manual as your convenient camera
information source.
Safety Precautions
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT
DAMAGE,
iDO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE,
DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED
WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE
APPARATUS.
iUSE ONLY THE RECOMMENDED ACCESSORIES.
iDO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS
WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR
FIRE HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS
AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE
VENTILATION VENTS.

VQT3M88 3
FCC Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
iReorient or relocate the receiving antenna.
iIncrease the separation between the equipment and receiver.
iConnect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
iConsult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, follow the attached
installation instructions and use only shielded
interface cables with ferrite core when connecting to
computer or peripheral devices.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
Declaration of Conformity
Trade Name: Panasonic
Model No.: HX-DC10/HX-DC1
Responsible party: Panasonic Corporation of North America One
Panasonic Way, Secaucus, NJ 07094
Support Contact: Panasonic Consumer Electronics Company 1-800-
211-PANA (7262)
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
HX-DC10 HX-DC1

4VQT3M88
kConcerning the battery
AC adaptor
This AC adaptor operates on AC between 100V and 240V.
But
iIn the U.S.A. and Canada, the AC adaptor must be connected to a
120V AC power supply only.
iWhen connecting to an AC supply outside of the U.S.A. or Canada,
use a plug adaptor to suit the AC outlet configuration.
THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE
EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.
Battery pack (Lithium ion battery pack)
iUse the specified unit to recharge the battery pack.
iDo not use the battery pack with equipment other than the specified
unit.
iDo not get dirt, sand, liquids, or other foreign matter on the terminals.
iDo not touch the plug terminals (+ and -) with metal objects.
iDo not disassemble, remodel, heat or throw into fire.
If any electrolyte should come into contact with your hands or clothes,
wash it off thoroughly with water.
If any electrolyte should come into contact with your eyes, never rub the
eyes. Rinse eyes thoroughly with water, and then consult a doctor.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 °C
(140 °F) or incinerate.

VQT3M88 5
kProduct Identification Marking
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer’s instructions.
Product Location
Dual Camera Battery holder
A lithium ion battery that is recyclable powers the product
you have purchased. Please call 1-800-8-BATTERY for
information on how to recycle this battery.
U.S.A./CANADA CONSUMERS: ATTENTION:

6VQT3M88
Precautions
USE & LOCATION
iTO AVOID SHOCK HAZARD ...
Your camera and power supply
should not be exposed to rain or
moisture. Do not connect the
power supply or operate your
camera if it gets wet. Your
camera has been designed for
outdoor use, however it is not
designed to sustain direct
exposure to water, rain, sleet,
snow, sand, dust, or a direct
splashing from a pool or even a
cup of coffee. This action could
permanently damage the internal
parts of your camera. Do not
attempt to disassemble this unit.
There are no user serviceable
parts inside. Unplug your camera
from the power supply before
cleaning.
iAS WITH ANY SMALL OBJECT,
SD CARDS CAN BE
SWALLOWED BY YOUNG
CHILDREN. DO NOT ALLOW
CHILDREN TO HANDLE THE
SD CARD.
iDO NOT AIM YOUR CAMERA
AT THE SUN OR OTHER
BRIGHT OBJECTS
iDO NOT LEAVE THE CAMERA
WITH THE EVF AIMED
DIRECTLY AT THE SUN AS
THIS MAY CAUSE DAMAGE TO
THE INTERNAL PARTS OF THE
EVF
iDO NOT EXPOSE YOUR
CAMERA TO EXTENDED HIGH
TEMPERATURE ... Such as, in
direct sunlight, inside a closed
car, next to a heater, etc... This
action could permanently
damage the internal parts of your
camera.
iAVOID SUDDEN CHANGES IN
TEMPERATURE ... If the unit is
suddenly moved from a cold
place to a warm place, moisture
may form on the SD card and
inside the unit.
iDO NOT LEAVE YOUR
CAMERA OR THE POWER
SUPPLY TURNED ON WHEN
NOT IN USE.
iSTORAGE OF YOUR CAMERA
... Store and handle your camera
in a manner that will not subject it
to unnecessary movement (avoid
shaking and striking). Your
camera contains a sensitive pick-
up device which could be
damaged by improper handling
or storage.
CARE
iTO CLEAN YOUR CAMERA ...
Do not use strong or abrasive
detergents when cleaning your
camera body.
iTO PROTECT THE LENS ... Do
not touch the surface of the lens
with your hand. Use a
commercial camera lens solution
and lens paper when cleaning
the lens. Improper cleaning can
scratch the lens coating.
WARNING
CAUTION

VQT3M88 7
iTO PROTECT THE FINISH OF
YOUR CAMERA ... Before
handling your camera, make sure
your hands and face are free
from any chemical products, such
as sunblock, as it may damage
the finish.
-If you see this symbol-
Information on Disposal in other
Countries outside the European
Union
This symbol is only
valid in the
European Union. If
you wish to discard
this product, please
contact your local
authorities or
dealer and ask for
the correct method
of disposal.

8VQT3M88
IMPORTANT! PLEASE READ
kAbout the models covered by this owner’s manual
iThis manual pertains to models HX-DC10 and HX-DC1.
iWhere passages refer to a specific model(s), the model number is
indicated.
kBe sure to take some test pictures beforehand
Before those important events, be sure to take some trial pictures to confirm
that the images and audio are being properly recorded.
kIndemnity about recorded content
Panasonic does not accept any responsibility for damages directly or
indirectly due to any type of problems that result in loss of recording or edited
content, and does not guarantee any content if recording or editing does not
work properly. Likewise, the above also applies in a case where any type of
repair is made to the unit (including any other non-built-in memory/HDD
related component).
kHandling of built-in memory
This unit is equipped with an built-in memory (HX-DC10: Approx. 80 MB, HX-
DC1: Approx. 80 MB). When using this component, pay attention to the
following points.
iThe status indicator (page 21) illuminates while the SD card or built-in
memory is being accessed (reading, recording, playback, deleting etc.). Do
not perform the following operations when the lamp illuminates. It may
damage the built-in memory or cause a malfunction in the unit.
hTurn the unit off (remove the battery)
hEject the SD card from the camera
hInsert or remove the USB cable
hExpose the unit to vibrations or shock
iFor disposing of or transferring this unit, please see page 118.
Back up data periodically.
The built-in memory is temporary storage. In order to avoid erasing data
due to static electricity, electromagnetic waves, breakage, and failures,
back up the data to a computer or DVD disc. (page 129)

VQT3M88 9
kConcerning this unit’s recording method and compatibility
<Video compatibility>
iThis camera is an MP4 standard (MPEG-4AVC/H.264 format) digital movie
camera that records high-definition HDTV video.
The AVCHD and MPEG2 video formats are different and are therefore not
compatible.
iThis camera may degrade or be unable to play back videos recorded or
created with other products, and other products may degrade or not be
able to play back videos recorded with this camera, even if the products
support the MP4 format.
<Photo compatibility>
iThis unit is compliant with the unified standard DCF (Design rule for
Camera File system) established by JEITA (Japan Electronics and
Information Technology Industries Association) and with Exif
(Exchangeable Image File Format). Files which do not comply with the
DCF standard cannot be played back.
iThe file format of images supported by this unit is JPEG. (Not all JPEG
format files will be played back.)
iThis unit may degrade or not play back images recorded or created on
other products, and other products may degrade or not play back images
recorded on this unit.
kAbout the battery pack
iNever place the battery pack within the reach of infants. In the event that
the battery pack is swallowed, consult a doctor immediately.
kAbout the photos and illustrations in this manual
iThe product images, illustrations, menu displays etc. in this manual may
differ slightly from the actual product.
iUnless noted otherwise, the screen and camera illustrations are those of
Model HX-DC10.
kFor the purposes of this owner’s manual
iSD Memory Card, SDHC Memory Card and SDXC Memory Card are
referred to as the “SD card”.
iPages for reference are indicated by parentheses, for example: (page 00).

10 VQT3M88
WHAT YOU CAN DO WITH YOUR
DIGITAL MOVIE CAMERA
Easy shooting/playback (Basic features)
Intelligent Auto Mode
(HX-DC10)
... (page 48)
Just point the camera at the subject, and
it automatically ascertains the scene
and captures the images with the
optimum settings.
Shoot movies
... (page 53)
Take photos
... (page 54)
Play back videos and
photos
... (page 59)
353 000:15:53
16 M
-
S
1080-30 p
1080-30 p
000:00:09
000:00:09
000:00:09
2 M
16 M
-
S
F3.5
F3.5
1/30
1/30
F3.5
1/30
DEC.20
DEC.20.
2011
2011
DEC.20.2011

VQT3M88 11
Using the convenient features (Practical
applications)
Image stabilizer... (pages 43, 74)
Subject tracking... (pages 45, 80)
Scene mode... (pages 41, 72, 171 to 173)
HINT
User guide on the Internet
When this camera is connected to an Internet-connected VIERA via an HDMI
mini cable (sold separately), you can press the VIERA’s remote control Menu
button and from the resulting menu select “User guide on the Internet” to see
easy-to-understand explanations of the camera’s operation and convenient
functions on the VIERA screen.
iApplicable to VIERA units sold from December 2010.
iTo connect the camera to the VIERA via an HDMI mini cable, please see
pages 150 to 152.

12 VQT3M88
Keeping recorded videos (Copy/dubbing)
From built-in memory to SD
card...
(page 47)
DVD recorder and video deck...
(page 154)
* It is not possible to directly insert in the card slot
an SD card recorded with this camera and play
back or dub from it.
* It is not possible to connect the camera to the
USB connector and play back or dub from it.
* Recording with HD image quality on a Blu-ray
disc recorder is not possible.
On a computer...
(pages 123 to 148)

VQT3M88 13
CONTENTS
CHECKING THE INCLUDED ACCESSORIES ....................................17
ABOUT THE CARD ..............................................................................18
Media cards that can be used with this camera
(as of February 2011) ...............................................................18
SETUP
PARTS NAMES ....................................................................................20
CHARGING THE BATTERY PACK ......................................................23
About the temperature alert icon ............................................29
INSTALLING THE CARD .....................................................................30
TURNING THE CAMERA ON AND OFF ..............................................32
Turning on the camera ..................................................................32
Turning off the camera ..................................................................33
Turning on the camera when it is in the sleep mode .....................33
DATE AND TIME SETTING .................................................................34
Date and time backup ...................................................................36
SWITCHING BETWEEN THE RECORDING MODE AND PLAYBACK
MODE ...............................................................................................37
MENU SCREEN ...................................................................................38
Accessing/exiting the Menu Screen ..............................................38
Using the Menu .............................................................................39
Overview of the Menu Screen .......................................................40
INTELLIGENT AUTO MODE (HX-DC10) .............................................48
BASIC OPERATION
SHOOTING
BEFORE TAKING PICTURES .............................................................51
For best results ..............................................................................51
How to use the accessories ..........................................................52
VIDEO RECORDING ............................................................................53
TAKING PHOTOS ................................................................................54
Shoot a photo while recording a video ..........................................56
MACRO-PHOTOGRAPHY (ZOOM) .....................................................57
PLAYBACK
PLAYING BACK VIDEOS AND PHOTOS ............................................59
How to save one frame from a video as a photo ...........................62
DELETING FILES .................................................................................63
Delete single/delete all/delete folder .............................................63
Delete selected ..............................................................................64

14 VQT3M88
PLAYBACK MODES ............................................................................ 66
21-image display playback ........................................................... 66
Magnifying (zooming in) the image (photos only) ......................... 67
ADVANCED OPERATION
SHOOTING
RECORDING MENU 1 ......................................................................... 68
Recording mode setting (page 40) ............................................... 68
Recorded pixels (page 40) ............................................................ 71
Scene mode setting (page 41) ...................................................... 72
Self-timer setting (page 41) .......................................................... 73
RECORDING MENU 2 ......................................................................... 74
Motion compensation (image stabilizer) setting (page 43) ........... 74
Focus setting (page 43) ................................................................ 75
ISO sensitivity setting (page 43) ................................................... 76
White balance setting (page 43) ................................................... 77
RECORDING MENU 3 ......................................................................... 78
Exposure setting (HX-DC10) (page 45) ........................................ 78
Subject tracking settings (page 45) .............................................. 80
Shortcut setting (page 45) ............................................................ 82
Exposure compensation ............................................................... 85
PLAYBACK
PLAYBACK MENU 1 ........................................................................... 86
Slideshow settings (page 46) ........................................................ 86
File protect setting (page 46) ........................................................ 87
Rotate (page 46) ........................................................................... 89
Resize (page 46) .......................................................................... 89
PLAYBACK MENU 2 ........................................................................... 90
Correcting red-eye (page 47) ........................................................ 90
Editing videos (page 47) ............................................................... 91
Copy (page 47) ........................................................................... 100
FILE INFO DISPLAY .......................................................................... 102
OPTION SETTINGS
DISPLAY THE OPTION SETTING MENU ......................................... 103
INTRODUCTION TO THE OPTION SETTING MENU ...................... 104
TV output setting (page 107) ...................................................... 110
Storage folder setting (page 109) ............................................... 114
Playback folder setting (page 109) ............................................. 115
File No. continued setting (page 109) ......................................... 116
Formatting (initializing) (page 107) ............................................. 118

VQT3M88 15
CHECKING THE REMAINING CARD MEMORY ...............................119
Checking the remaining number of images and
video recording time ................................................................119
Check the available audio recording time ...................................120
CHECKING THE REMAINING BATTERY PACK CHARGE ..............121
OTHER DEVICES AND CONNECTIONS
CONNECTING TO A COMPUTER
SETTING THE CONNECTION MODE ...............................................123
USING AS A CARD READER ............................................................125
ABOUT THE CONTENTS OF THE CARD .........................................126
Configuration of directories in the card ........................................126
File formats ..................................................................................126
When using as a card reader ......................................................127
Selecting which medium to access .............................................128
USING AS A WEBCAM ......................................................................130
Operating environment ................................................................130
Using as a webcam .....................................................................131
WHAT YOU CAN DO WITH A COMPUTER ......................................132
Contents of the supplied CD-ROM ..............................................132
End User License Agreement .....................................................134
OPERATING ENVIRONMENT ...........................................................136
Operating environment for HD Writer VE 1.0 ..............................136
To use the HD Writer VE 1.0 .......................................................139
Operating environment for the card reader function
(mass storage) ........................................................................140
INSTALLATION ..................................................................................141
Uninstalling HD Writer VE 1.0 .....................................................144
STARTING HD WRITER VE 1.0 ........................................................145
Reading the owner’s manual of the software applications ..........146
IF USING Mac ....................................................................................147
Operating environment ................................................................147
Copying photos on a computer ...................................................147
To disconnect USB cable safely ..................................................148
CONNECTING TO A TV
CONNECTING TO A TV .....................................................................149
Connecting to a video input terminal ...........................................150
Connecting to the HDMI terminal ................................................150
PLAYING BACK ON A TV ..................................................................151
Playback using VIERA Link™ (HDAVI Control™) .......................151

16 VQT3M88
COPYING/DUBBING
COPYING/DUBBING ......................................................................... 154
Dubbing in standard picture quality ............................................ 154
IMPORTANT MESSAGES AND ALERTS
COMMONLY ASKED QUESTIONS ................................................... 156
TROUBLESHOOTING ....................................................................... 164
Camera ....................................................................................... 164
Restrictions concerning the Scene Mode and
Color Mode features ............................................................... 171
ABOUT COPYRIGHT ........................................................................ 174
CAUTIONS FOR USE ....................................................................... 175
RECORDING MODES/APPROXIMATE RECORDABLE TIME ......... 181
APPROXIMATE NUMBER OF RECORDABLE PICTURES .............. 183
SPECIFICATIONS ............................................................................. 185
OPTIONAL ACCESSORIES .............................................................. 191
Limited Warranty (ONLY FOR U.S.A. AND PUERTO RICO) ............ 193
Spanish Quick Use Guide/Guía española para el uso rápido ............ 196

VQT3M88 17
CHECKING THE INCLUDED ACCESSORIES
Check the accessories before using this unit.
Product numbers correct as of February, 2011.
These may be subject to change.
Battery pack
VW-VBX070
AC adaptor
VSK0750
USB cable
VFA0544
AV cable
VFA0543
Lens cap
VFC4701
Lens cap strap
VFC4702
CD-ROM
Software
Handstrap
* To prevent the camera from
dropping, be sure to attach the
handstrap (page 52).
VFC4627
iPlease dispose of packing materials properly.
iKeep the battery pack and the lens cap out of reach of children to
prevent swallowing.

18 VQT3M88
ABOUT THE CARD
Media cards that can be used with this camera
(as of February 2011)
Use SD cards conforming to Class 4 or higher of the SD Speed Class Rating*
for video recording.
* The SD Speed class Rating is the speed standard for successive writes.
See the card label to confirm the rating.
(Example)
This camera is compatible with SDXC devices (SD Memory Card/SDHC
Memory Card/SDXC Memory Card compatible devices). If using an
SDHC memory card/SDXC memory card in different device, please
confirm that it is compatible with the respective memory card.
Card type Capacity Video recording Photo
shooting
SD Memory
Card
8 MB/16 MB/
32 MB/64 MB/
128 MB/256 MB
Operation is not
guaranteed.
Operation
is not
guaranteed.
512 MB/
1 GB/ 2 GB
Can be used. Can be used.
SDHC Memory
Card
4 GB/6 GB/
8 GB/12 GB/
16 GB/
24 GB/32 GB
SDXC Memory
Card 48 GB/64 GB
Please confirm which of our SD Memory Cards/SDHC Memory Cards/
SDXC Memory Cards can be used with this product by visiting the
support web site at the address below.
http://panasonic.jp/support/global/cs/e_cam
(This website is in English only.)

VQT3M88 19
i4 GB or more Memory Cards that do not have the SDHC logo or 48 GB or
more Memory Cards that do not have the SDXC logo are not based on SD
Memory Card specifications.
iCards with capacity larger than 64 GB cannot be used.
iWhen the write-protect switch on the SD card is locked, no recording,
deletion or editing will be possible on the card.
iKeep the Memory Card out of reach of children to prevent swallowing.
Write-protect switch

20 VQT3M88
SETUP
SETUP
SETUP
PARTS NAMES
Front
Flash
Lens
Monitor unit
Internal stereo
microphone
iThe flash unit
becomes very
hot and may
cause a burn.
Avoid touching
the flash unit
when shooting.
Status indicator
* The tripod mounting
hole is on the bottom.
Speaker
Attaching to a tripod
having a screw length
longer than 5.5 mm
(0.22”) may damage the
camera.
