Panasonic Viera Link HX-WA10 User manual

1AG6P1P6313--(S)
Owner’s Manual
Dual Camera
Model No.HX-WA10
Before connecting, operating or adjusting this product, please read the instructions completely.
For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,
contact us via the web at: http://www.panasonic.com/contactinfo
PVQT3P35

2VQT3P35
Things You Should
Know
Thank you for choosing Panasonic!
You have purchased one of the most
sophisticated and reliable products on
the market today. Used properly, we’re
sure it will bring you and your family
years of enjoyment. Please take time
to fill in the information on the right.
The serial number is on the tag
located on the battery holder of your
camera. Be sure to retain this
manual as your convenient camera
information source.
Safety Precautions
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT
DAMAGE,
iDO NOT EXPOSE ACCESSORIES (AC ADAPTOR, USB CABLE,
BATTERY PACK, SD MEMORY CARD AND ETC.) TO RAIN,
MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON
THEM.
iUSE ONLY THE RECOMMENDED ACCESSORIES.
iDO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS
WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR
FIRE HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS
AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE
VENTILATION VENTS.

VQT3P35 3
FCC Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
iReorient or relocate the receiving antenna.
iIncrease the separation between the equipment and receiver.
iConnect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
iConsult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, follow the attached
installation instructions and use only shielded
interface cables with ferrite core when connecting to
computer or peripheral devices.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
Declaration of Conformity
Trade Name: Panasonic
Model No.: HX-WA10
Responsible party: Panasonic Corporation of North America One
Panasonic Way, Secaucus, NJ 07094
Support Contact: Panasonic Consumer Electronics Company 1-800-
211-PANA (7262)
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
HX-WA10

4VQT3P35
kConcerning the battery
AC adaptor
This AC adaptor operates on AC between 100V and 240V.
But
iIn the U.S.A. and Canada, the AC adaptor must be connected to a
120V AC power supply only.
iWhen connecting to an AC supply outside of the U.S.A. or Canada,
use a plug adaptor to suit the AC outlet configuration.
THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE
EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.
Battery pack (Lithium ion battery pack)
iUse the specified unit to recharge the battery pack.
iDo not use the battery pack with equipment other than the specified
unit.
iDo not get dirt, sand, liquids, or other foreign matter on the terminals.
iDo not touch the plug terminals (+ and -) with metal objects.
iDo not disassemble, remodel, heat or throw into fire.
If any electrolyte should come into contact with your hands or clothes,
wash it off thoroughly with water.
If any electrolyte should come into contact with your eyes, never rub the
eyes. Rinse eyes thoroughly with water, and then consult a doctor.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 °C
(140 °F) or incinerate.

VQT3P35 5
kProduct Identification Marking
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer’s instructions.
Product Location
Dual Camera Battery holder
A lithium ion battery that is recyclable powers
the product you have purchased. Please call 1-800-8-
BATTERY for information on how to recycle this battery.
U.S.A./CANADA CONSUMERS: ATTENTION:

6VQT3P35
Precautions
USE & LOCATION
iTO AVOID SHOCK HAZARD ...
Your camera and power supply
should not be exposed to rain or
moisture. Do not connect the
power supply or operate your
camera if it gets wet. Your
camera has been designed for
outdoor use, however it is not
designed to sustain direct
exposure to water, rain, sleet,
snow, sand, dust, or a direct
splashing from a pool or even a
cup of coffee. This action could
permanently damage the internal
parts of your camera. Do not
attempt to disassemble this unit.
There are no user serviceable
parts inside. Unplug your camera
from the power supply before
cleaning.
iAS WITH ANY SMALL OBJECT,
SD CARDS CAN BE
SWALLOWED BY YOUNG
CHILDREN. DO NOT ALLOW
CHILDREN TO HANDLE THE
SD CARD.
iDO NOT AIM YOUR CAMERA
AT THE SUN OR OTHER
BRIGHT OBJECTS
iDO NOT LEAVE THE CAMERA
WITH THE EVF AIMED
DIRECTLY AT THE SUN AS
THIS MAY CAUSE DAMAGE TO
THE INTERNAL PARTS OF THE
EVF
iDO NOT EXPOSE YOUR
CAMERA TO EXTENDED HIGH
TEMPERATURE ... Such as, in
direct sunlight, inside a closed
car, next to a heater, etc... This
action could permanently
damage the internal parts of your
camera.
iAVOID SUDDEN CHANGES IN
TEMPERATURE ... If the unit is
suddenly moved from a cold
place to a warm place, moisture
may form on the SD card and
inside the unit.
iDO NOT LEAVE YOUR
CAMERA OR THE POWER
SUPPLY TURNED ON WHEN
NOT IN USE.
iSTORAGE OF YOUR CAMERA
... Store and handle your camera
in a manner that will not subject it
to unnecessary movement (avoid
shaking and striking). Your
camera contains a sensitive pick-
up device which could be
damaged by improper handling
or storage.
CARE
iTO CLEAN YOUR CAMERA ...
Do not use strong or abrasive
detergents when cleaning your
camera body.
iTO PROTECT THE LENS ... Do
not touch the surface of the lens
with your hand. Use a
commercial camera lens solution
and lens paper when cleaning
the lens. Improper cleaning can
scratch the lens coating.
WARNING
CAUTION

VQT3P35 7
iTO PROTECT THE FINISH OF
YOUR CAMERA ... Before
handling your camera,make sure
your hands and face are free
from any chemical products, such
as sunblock, as it may damage
the finish.
-If you see this symbol-
Information on Disposal in other
Countries outside the European
Union
This symbol is only
valid in the
European Union.If
you wish to discard
this product, please
contact your local
authorities or
dealer and ask for
the correct method
of disposal.

8VQT3P35
IMPORTANT! PLEASE READ
kAbout handling the camera
iOpening and closing the battery cover or terminal cover in a sandy or
dusty environment may cause water to get inside the camera and
result in malfunction, so be especially careful in these environments.
iDo not touch the lens or terminals with dirty hands.
iDo not open or close the battery cover or terminal cover near or in
water, or with wet hands.
iIf there is moisture inside the battery cover or terminal cover, wipe it
completely dry, and use the supplied brush to remove any foreign
matter.
iIf there is water on the surface of the camera, use a soft dry cloth to wipe it
completely dry before opening the camera.
iAvoid dropping or hitting the camera, or subjecting it to strong
vibrations or shocks. Do not apply strong pressure to it.
hThe camera may malfunction or lose the ability to record images,
or the LCD monitor and/or exterior case may be damaged.
hThe waterproof capability may deteriorate.
iDo not sit with the camera in a pants pocket, or force it into a full briefcase
or bag.
iBe careful of accessories etc. dangling from the strap, which may press
against the LCD monitor and break it.
kCondensation (when the lens is cloudy)
iChanges in temperature or humidity may cause water to form on the
camera surfaces (condensation). Recorded images may appear
washed out. Some possible causes to be aware of are the following.
hUsing the camera in the water immediately after moving from a very
warm waterside setting, for example.
hMoving from cold surroundings, such as a ski slope, to warm
surroundings.
hOpening the battery cover or terminal cover in a humid environment.
iIf condensation has formed, try the following countermeasures.
hTurn off the camera and leave it with the battery door open it in a
location with a stable ambient temperature for about 2 hours. The
cloudiness will dissipate naturally when the camera adjusts to the
ambient temperature.
hIf cloudiness persists, open the battery cover and terminal cover in a
location away from heat and humidity, and leave the camera for
about 2 hours. (Do not open and close the covers near the
waterside.)

VQT3P35 9
kBe sure to take some test pictures beforehand
Before those important events, be sure to take some trial pictures to confirm
that the images and audio are being properly recorded.
kIndemnity about recorded content
Panasonic does not accept any responsibility for damages directly or
indirectly due to any type of problems that result in loss of recording or edited
content, and does not guarantee any content if recording or editing does not
work properly. Likewise, the above also applies in a case where any type of
repair is made to the unit (including any other non-built-in memory/HDD
related component).
kBe aware of copyrights
Under copyright law, your video and audio recordings cannot be used without
permission of the owner except for your personal use.
Note that photography may be restricted even if the purpose is for your
personal use only.
kPlease also read the “CAUTIONS FOR USE” (page 186).
kHandling of built-in memory
This unit is equipped with a 80 MB (approx.) built-in memory. When using this
component, pay attention to the following points.
iThe status indicator (page 32) illuminates while the SD card or built-in
memory is being accessed (reading, recording, playback, deleting etc.). Do
not perform the following operations when the lamp illuminates. It may
damage the built-in memory or cause a malfunction in the unit.
hTurn the unit off (remove the battery)
hEject the SD card from the camera
hInsert or remove the USB cable
hExpose the unit to vibrations or shock
iFor disposing of or transferring this unit, please see page 187.
Back up data periodically.
The built-in memory is temporary storage. In order to avoid erasing data
due to static electricity, electromagnetic waves, breakage, and failures,
back up the data to a computer or DVD disc. (page 141)

10 VQT3P35
kConcerning this unit’s recording method and compatibility
<Video compatibility>
iThis camera is an MP4 standard (MPEG-4AVC/H.264 format) digital movie
camera that records high-definition HDTV video.
The AVCHD and MPEG2 video formats are different and are therefore not
compatible.
iThis camera may degrade or be unable to play back videos recorded or
created with other products, and other products may degrade or not be
able to play back videos recorded with this camera, even if the products
support the MP4 format.
<Photo compatibility>
iThis unit is compliant with the unified standard DCF (Design rule for
Camera File system) established by JEITA (Japan Electronics and
Information Technology Industries Association) and with Exif
(Exchangeable Image File Format). Files which do not comply with the
DCF standard cannot be played back.
iThe file format of images supported by this unit is JPEG. (Not all JPEG
format files will be played back.)
iThis unit may degrade or not play back images recorded or created on
other products, and other products may degrade or not play back images
recorded on this unit.
kAbout the battery pack
iNever place the battery pack within the reach of infants. In the event that
the battery pack is swallowed, consult a doctor immediately.
kAbout the photos and illustrations in this manual
iThe product images, illustrations, menu displays etc. in this manual may
differ slightly from the actual product.
kFor the purposes of these owner’s manual
iSD Memory Card, SDHC Memory Card and SDXC Memory Card are
referred to as the “SD card”.
iPages for reference are indicated by parentheses, for example: (page 00).

VQT3P35 11
IMPORTANT: ABOUT THE
WATERPROOF PERFORMANCE OF
THE CAMERA
iThis camera is qualified JIS protection grade 8 (JIS IPX8) for waterproof
performance. It is waterproof up to a depth of 3 meters (10 feet) for at least
60 minutes.*
iThe supplied accessories are not waterproof (excluding handstrap).
*This means that the camera can be used underwater for a specified time in
a specified pressure in accordance with the handling method established by
Panasonic. It does not guarantee against destruction or malfunction, or
guarantee waterproofing, in all conditions.
Observe the following precautions and avoid using under water pressure
exceeding the guaranteed performance, or in an environment with excessive
dust or sand.
The waterproof capability is not guaranteed if the camera is subjected to an
impact as a result of being hit or dropped, etc.
If an impact to the camera occurs, consult with the store where it was
purchased or a service center, and have it inspected (subject to a fee) to
verify that the waterproof capability has not been compromised.
Any damage due to water leakage that was caused by customer misuse or
mishandling is not covered by the warranty.
kHandling of the camera
iDo not leave the camera for a long period of time in places where the
temperature is very low (ski resort etc.) or very high (above 35 °C [95 °F]),
especially in strong sunlight, in a car sitting outside, close to a heater, on
the beach, etc. (The waterproof capability may be degraded.)
iThe inside of the camera is not waterproof. Do not open or close the
battery cover or terminal cover when you are close to the sea, a lake or a
river, or with wet hands.
iThe waterproof function of the camera applies only to sea water and fresh
water.
iOperation may not be possible, or the audio volume may be low, if snow or
water freezes on the zoom switch, speaker or microphone in cold
environments such as at a ski resort.

12 VQT3P35
MAINTENANCE AND
WATERPROOF PERFORMANCE
kBefore using the camera in water, please check the following
jCheck that there is no foreign matter adhering to the inside of any of
the covers.
hIf lint, hair, sand or the like is present, water may leak into the camera
in seconds and damage it.
hIf any liquid is adhering to the camera, wipe it off with a soft dry cloth.
Liquid on the camera may leak inside and damage the camera.
hIf there is any foreign matter adhering to the
camera, use the supplied brush to remove it.
hTake particular care to remove all traces of
foreign matter from the sides and corners of
the rubber seals, where minute particles of
sand or dust may adhere.
hUse the brush end with the short (hard) bristles to remove larger
foreign matter or damp sand from the camera.
kCare of the brush
iBefore using the brush, check that there is no foreign matter adhering to it.
iAfter using the brush, shake off any foreign matter and keep it where it will
stay clean.
Do not open or close any of the covers in sandy or dusty environments,
near the waterside, or with wet hands. Sand or dust adhering to the
camera can result in water getting inside.
Brush (supplied)
Terminal cover
Battery cover
Battery cover
Terminal cover

VQT3P35 13
kTo prevent water leaking into the camera, please observe the
following precautions before using it.
kCheck that there is sufficient battery power and card memory
remaining.
kDo not open or close the battery cover or terminal cover in places
with sand and dust, or with wet hands.
kAt the time of purchase, the battery cover lock is in the locked
position. When opening the battery cover, first release the lock.
1 Check that there is no foreign matter on the inner side of the battery
cover or terminal cover (where the rubber seal 1contacts the
camera body 2).
hIf the rubber seal inside the battery cover or terminal cover is cracked
or deformed, consult the store where the camera was purchased or a
nearby service center.
Battery cover lock
Red part
(colored label)
Terminal cover lock
1
1
2
2
Terminal cover
Battery cover
Hair, lint
Liquid
Crack,
deformation
Sand, dust

14 VQT3P35
2 If there is foreign matter adhering to the camera, use the supplied
brush to remove it.
hIf there is any foreign matter, such as lint, hair,
sand, etc., on the parts indicated by the text
balloons in the illustration, water will leak
inside within seconds and may damage the
camera.
kExample of foreign matter inside the battery cover
kExample of foreign matter inside the terminal cover
Brush (supplied)
Rubber seal
Where the rubber seal
contacts the camera
body
Rubber seal Where the rubber seal
contacts the camera body

VQT3P35 15
iIf there is liquid on the surface, wipe it off with a soft dry cloth.
iThe integrity of the rubber seals decreases after about 1 year. It is strongly
recommended that you have the seals replaced (subject to a fee) at least
once a year at the store where the camera was purchased or at nearby
service center.
3 1With the battery cover lock released, press the battery cover to
close it.
hTo prevent water seeping into the camera, make sure that foreign
matter such as liquids, sand, hair or dust is trapped between the
cover and the camera body.
2Push the battery cover lock to the left to lock it.
hThe colored label is visible when the battery cover lock is not
completely closed. Be sure to close the lock completely so that the
colored label is not visible.
3Close the terminal cover firmly until you hear it “click” shut and
the red part of the terminal cover lock is no longer visible.
hIf the camera is used without the covers securely closed, they may
open on their own. 1
32
Terminal cover lock
Battery cover lock

16 VQT3P35
HINT
iIf there is any foreign matter on the camera, use the supplied brush to
remove it.
iIf the camera is used in the following environments, foreign matter such as
sand or dust may inadvertently get caught in the gap between the battery
cover or terminal cover and the body.
hIn the sea or in waters in which sand is suspended.
hIn places with a lot of sand or dust, such as at the beach or in a
sandbox.
kUsing the camera underwater
iUse the camera underwater at a depth of up to 3 meters (10 feet), water
temperature from 0 °C to 35 °C (32 °F to 95 °F), and for not longer than
60 minutes continuously. Before using the camera in water again, make
sure that it has been sufficiently dried.
iIf there is water or dirt on the camera, wipe it dry with a soft dry cloth and
leave it to dry in a well ventilated spot before using again.
iDo not open and close the battery cover or terminal cover while
underwater.
iDo not subject the camera to shock underwater. (The waterproof
performance may become impaired, and water may seep into the camera.)
iDo not dive into the water holding the camera. Do not use the camera in a
location where it might be impacted by forceful splashing, such as in a
strong current or a waterfall. (Strong water pressure may cause the
camera to malfunction.)
iThe camera will sink in water. Take care not to drop the camera and lose it
underwater, for example by making sure the hand strap is secured or by
some other measure.
iDo not use the camera in water warmer than 35 °C (95 °F) (in the bath or
spa).
iIf the camera is splashed with detergent, soap, hot water, bath salts,
tanning oil, sun screen, chemicals, etc., wipe it off immediately.
iThe card and battery are not waterproof. Do not handle them with wet
hands. Also, do not insert a wet card or battery in the camera.

VQT3P35 17
kCauses of water leak
iIf the camera is used in any of the following conditions, a gap may appear
betweenthe camerabody and the battery cover or terminal cover, resulting
in water seeping in and causing the camera to malfunction.
hWhen there is foreign matter, such as lint, hair, sand, etc., between the
battery cover or terminal cover and the camera body.
hWhen the rubber seal has deteriorated.
hWhen the lock on the battery cover and/or terminal cover is not closed.
kCare of the camera after using underwater
1 With the battery cover and
terminal cover closed, rinse
the camera with water; or, if it
was used in the sea, soak it in
a shallow container filled with
fresh water for about 10
minutes.
hLeaving the camera with
foreign objects or saline
matter on it may cause
damage, discoloration,
corrosion, unusual odor, or
deterioration.
The camera must be cleaned after it has been used underwater.
iRinse the camera in water, and do not open the battery cover or
terminal cover until all sand and dust have been removed.
iDo not soak the camera in water for more than 60 minutes.
Battery cove
r
Water can leak
inside through the
gap
Terminal
cover
Rubber seal
Where the
rubber seal
contacts the
camera body
Rubber seal Where the rubber seal contacts the camera body

18 VQT3P35
2 Wipe off the water,place the camera on a dry cloth and leave it to dry
for a while in a well-ventilated shaded spot.
3 Check that there is no water on
the camera, and open the
battery cover and terminal
cover.
hMoisture may easily
accumulate in the grooves
inside the covers, so take care
that no water gets inside.
4 Wipe off any water or sand
inside the battery cover and
terminal cover with the
supplied brush or a soft dry cloth.
iAfter the camera has been used underwater or soaked in fresh water,
moisture may collect in the grooves around the card/battery compartment
and connection terminals. In addition, water droplets may adhere to the
card or battery if the battery cover is opened without sufficiently drying the
camera. Be sure to wipe off the water with a soft dry cloth in such cases.
iDo not open or close the battery cover or terminal cover with water
droplets still on the camera. The water droplets may seep into the camera,
causing condensation and malfunction.
<Wiping moisture from the camera>
iIf there is moisture inside the battery cover, wipe every crevice completely
clear of moisture.
*This moisture is not due to exposure to water.
Moisture
here

VQT3P35 19
kAbout the water draining design
This camera is designed so that water that entered the gaps around the zoom
switch etc. drains out. For this reason, bubbles may appear when the camera
is immersed in water, but this is not a malfunction.
<Draining water from the camera>
iDrainage holes are found at two points on the bottom of the camera. Hold
the camera vertically, as shown, to drain off the water.
When draining, attach the hand strap to the camera and secure the hand
strap to your wrist to prevent the camera from dropping.
HINT
iUse a soft dry cloth to wipe water and dirt from the camera.
iAfter use at the seaside or underwater, make sure that the battery cover
and terminal cover are securely closed, and soak the camera in a shallow
container filled with fresh water for about 10 minutes.
iIf the zoom switch does not operate smoothly, it may be due to the
adhesion of foreign matter. Using the camera in this condition may cause a
malfunction such as locking up, so wash off any foreign objects by soaking
the camera in fresh water and rinsing it. After cleaning, check that the
zoom switch operates smoothly.
iAfter soaking or washing the camera, wipe the water from it with a soft dry
cloth and dry it in a well ventilated shaded spot.
iAfter soaking the camera in water, place it on a dry cloth and leave it to dry
for a while, and check to make sure that the water has drained from it.
iDo not use hot air from a hairdryer or the like to dry the camera. The
waterproof capability will deteriorate due to deformation.
iDo not use chemicals such as benzine, paint thinner, alcohol or cleanser;
do not use soap or detergents.
Drainage
holes

20 VQT3P35
WHAT YOU CAN DO WITH YOUR
DIGITAL MOVIE CAMERA
Easy shooting/playback (Basic features)
Intelligent Auto Mode
... (page 58)
Just point the camera at the subject, and
it automatically ascertains the scene
and captures the images with the
optimum settings.
Shoot movies
... (page 63)
Take photos
... (page 64)
Play back videos and
photos
... (page 71)
353 000:15:53
16 M
-
S
1080-30 p
1080-30 p
000:00:09
000:00:09
000:00:09
2 M
16 M
-
S
F3.5
F3.5
1/30
1/30
F3.5
1/30
DEC.20
DEC.20.
2011
2011
DEC.20.2011
