Panasonic CQ-C7402W User manual

ORDER NO. ACED060609C3
AUTOMOTIVE AFTERMARKET
CQ-C7402W
WMA MP3 CD Player/Receiver with Full Dot Matrix Display
SPECIFICATIONS
Specifications*
General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Tone Controls (Bass/
Treble)
Bass: ±12dB at 60Hz / Treble: ±
12dB at 16kHz
Equalizer Center Frequency 60, 160, 400, 1k, 3k, 6k, 16k (Hz)
Variable Range of Equalizer -12dB to 12dB (2dB step)
Current Consumption Less than 2.2A / (CD mode; 0.5W × 4
-speaker)
Maximum Power Output 50W × 4(at 4 )
Speaker Impedance 4 - 8
Pre-amp Output Voltage 5V
Subwoofer Output Voltage 5V
Pre-amp Output Impedance 60
Subwoofer Output
Impedance
60
CD Player
Sampling Frequency 8 Times Oversampling
Pick-up Type Astigma 3-Beam
Light Source Semiconductor Laser
Wave Length 790 nm
Frequency Response 20Hz-20kHz (±1dB)
Signal to Noise Ratio 96dB
1

Total Harmonic Distortion 0.01% (1kHz)
Wow and Flutter Below Measurable Limits
Channel Separation 75dB
FM Stereo Radio
Frequency Range 87.5MHz - 108MHz
Usable Sensitivity 6dB/ V (S/N 30dB)
Stereo Separation 35dB (at 1kHz)
AM Radio
Frequency Range 531kHz - 1,602kHz
Usable Sensitivity 28dB/ V (S/N 20dB)
Dimensions (W×H×D)** 178×50×155mm
Weight** 1.6Kg
* Specifications and the design are subject to possible
modification without notice due to improvements.
** Dimensions and Weight shown are approximate.
** Above specifications comply with EIA standards.
2006 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
1. ABOUT LEAD FREE SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF stamp on the PCB.
Caution :
2

- Pb free solder has a higher melting point than standard solder; Typically
the melting point is 50 - 70°F (30 - 40°C) higher. Please use a soldering
iron with temperature control and adjust it to 700 ± 20°F (370 ± 10°C). In
case of using high temperature soldering iron, please be careful not to
heat too long.
- Pb free solder will tend to splash when heated too high (about 1100°F/
600°C)
- This lead free solder will be used for the products after serial No.
1,000,001.
2. FEATURES
- MP3/WMA Playback from CD-R/RW
- Fully Motorized Front Panel
- Six Preset Modes (FLAT, ROCK, POP, VOCAL, JAZZ, CLUB)
- SQ7 (7 Bands Sound Quality)
- DVD Changer Control
- Delightful sound space thanks to system buildup
- Maximum Power Output 50W
- Pre Out Fix Tipe (Silver)
3. REPLACEING THE FUSE
Use fuses of the same specified rating 15 amps. Using different substitutes or fuses with higher ratings,
or connecting the unit directly without a fuse, could cause fire or damage to the stereo unit.
4. MAINTENANCE
Your products is designed and manufactured to ensure a minimum of maintenance. Use a soft cloth for
routine exterior cleaning. Never use benzine, thinner or other solvent.
5. NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package block is necessary, it will be supplied already
aligned at the factory.
[CD DECK BLOCK]
This model has no servo alignment points because microcomputer controls the servo circuit
6. DIMENSIONS
3

7. LASER PRODUCTS
8. WIRING CONNECTION
4

9. DISASSEMBLY INSTRUCTIONS
9.1. How to Remove the Flexible PCB(AP2)
5

9.2. How to Install the Main P.C.B. of the Electric Display
10. TERMINALS DESCRIPTION
10.1. Main Block
IC601 : C2CBJG000589
6

Pin
No.
Port Description (I/
O)
(V)
FM AM CD
1 PANEL
OPEN
PANEL OPEN
detection
I 0 5.2 5.2
2 PANEL
CLOSE
PANEL CLOSE
detection
I 0 0 5.2
3 NC No Connection - - - -
4 BATT BATT detection I 4.8 5 5
5 ACC ACC detection I 4.8 5 5
6 SDA Electronic VOL
data
I/O 4.9 4.9 4.9
7 SCLK Electronic VOL
clock
O 4.9 4.9 4.9
8 NC No Connection - - - -
9 Vss Power supply GND I 0 0 0
10 ST FM ST detection I 5.1 5.2 5.2
11 PLL DI(MO) PLL data output O 0.6 0 0
12 PLL DO(MI) PLL data input I 5.2 5.2 5.2
13 PLL CLK PLL clock output O 4.9 4.9 4.9
14 PLL CE PLL chip enable
output
O 0 0 0
15 CD RST CD deck reset
output
O 4.9 4.9 4.9
16 SUB SI SUB u-com Data
trans
SO 0.6 0.6 0.8
17 NC No Connection - - - -
18 SUB SO SUB u-com data
recept
SI 4.4 4.4 4.4
19 CH DATA Changer; data
transmission from
XM; FLASH W SO
SI 1.6 1.6 1.6
20 CH CLK Clock
transmission from
the changer;
FLASH W CLK
SCK 4.9 4.9 4.9
21 Vdd Power supply I 4.9 4.9 4.9
22 XM SI DATA
transmission to XM
; FLASH W SI
S0 0 0 0
23 CD SI CD DATA
transmission
S0
24 CD SCK CD Clock
transmission
SCK 0 0.4 0
25 CONDENSOR Capacitor for
power supply
- 3.3 3.3 3.3
26 CDC SO CD DATA
transmission
SI 0 0 0
27 CDC STB Changer stororb
signal input
INT 0 0 0
28 CD IN DISC in detect I 4.9 4.9 0.4
7

Pin
No.
Port Description (I/
O)
(V)
FM AM CD
29 DECK V
CONT
DECK power
supply control
output
O 4.9 4.9 4.9
30 CD STB CD frame sink O 3.7 3.7 3.7
31 NC No Connection - - - -
32 Avdd Power supply of D/
A converter
I 5.1 5.1 5.1
33 AVREF Reference voltage
for D/A converter
I 5.1 5.1 5.1
34 AVGND Reference GND for
D/A converter
I 0 0 0
35 AVSS Grand for A/D and
D/A converter
I 0 0 0
36 SD FM/AM signal
meter signal input
A/
D
0.2 0 0.3
37 INIT A Initializ A A/
D
0 0 0
38 INIT B Initializ B A/
D
0 0 0
39 A IN SPE.ANA A.IN A/
D
0 0 0
40 Vss GND I 0 0 0
41 CD MUTE CD deck mute
detection
I 0 0 5.1
42 NC No Connection - - - -
43 NC No Connection - - - -
44 NC No Connection - - - -
45 CD SW1 CD disc in
detection
I - - -
46 CD SW2 CD disc in
detection
I - - -
47 MOD0 Operating mode
input 0
I 5.1 5.1 5.1
48 MOD1 Operating mode
input 1
I 5.1 5.1 5.1
49 MOD2 Operating mode
input 2
I 0 0 0
50 H
STANDBY
External standby
input
I 5 5 5
51 DC DC
CNT
DC/DC control for
60W (CQ-C8401W)
O 0 0 0
NC No Connection
(CQ-C7401W)
- - - -
52 FP
MOTOR1
Front open/close
control 1
O 4.9 5 4.9
53 FP
MOTOR2
Front open/close
control 2
O 4.9 5 4.9
8

Pin
No.
Port Description (I/
O)
(V)
FM AM CD
54 V CNT1 Panel driving
voltage control 1
O 0 0 5
55 V
CNT2(NC)
No Connection - - - -
56 SA CLK Control for Speana
acquisition
O 5 5 4.9
57 EXT MUTE TEL/NAVI MUTE
input
I 5.3 5.2 5.2
58 AMP CONT External AMP
control
O 4.9 5 4.9
59 BZ-OUT Buzzer output PPG 0 0 0
60 ANT CONT Motor antenna
control
O 4.9 5 0
61 DIM1 Dimmer control
output 1
O 0 0 0
62 DIM2 Dimmer control
output 2
O 0 0 0
63 CDC REM
OUT
Remote control
code output to
Changer
O 5 5 5
64 CDC SENS CDC 1/2 detection I 5.1 5.1 5.1
65 CDC 1/2 CDC 1/2 change
output
O 0 0 0
66 NC No Connection - - - -
67 M W UP MAIN.WAKE.UP.REQ
input
I 5 4.9 5
68 NC No Connection - - - -
69 NC No Connection - - - -
70 NC No Connection - - - -
71 NC No Connection - - - -
72 MAIN
CONT
MAIN power
supply control
output
O 4.9 4.9 4.9
73 INV CONT INV power supply
control output
O 5 5 5
74 AF MUTE Tr-MUTE control O/I 5 5 5
75 RESET Reset input I 5 5 5
76 NC No Connection - - - -
77 NC No Connection - - - -
78 NC GND I 0 0 0
79 Vss GND I 0 0 0
80 X1 Crystal oscillator
input
I 2 2 2
81 X2 Crystal oscillator
output
O 2.5 2.5 2.5
82 Vdd Power supply I 5 5 5
83 P00 Pldaun port for
writing
I 0 0 0
9

writing
Pin
No.
Port Description (I/
O)
(V)
FM AM CD
84 P01 Pull-up port for
writing
I 5.1 5 5.1
85 OFFSET
DET
PWR-IC OFFSET
detection
I 0 0 0
86 STBY PWR-IC STBY
control output
O 5 5 5
87 AMP MUTE PWR-IC MUTE
control output
O 0 0 0
88 ILL SENS External dimmer
control input
I 5 5 5
89 SUBM CNT 3.3V control for
SUB
microcomputer
O 5 5 5
90 NC No Connection - - - -
91 NC No Connection - - - -
92 NC No Connection - - - -
93 SUB W U
REQ
SUB.WAKE.UP.REQ O 4.9 5 4.9
94 DISPM
CNT
Power supply
control output of
display 5V
O/I 0 0 0
95 EJE
ILL(NC)
No Connection - - - -
96 NC No Connection - - - -
97 NC No Connection - - - -
98 S LED Security LED
control output
O 0 0 5
99 PANEL IN PANEL detect I 5.2 5.2 5.2
100 EP CS(NC) No Connection - - - -
10.2. Display Block
IC900 C2CBJH000095
10

Pin
No.
Port Part Name &
Description
I/O (V)
1 A18 FLASH A17 O 1.5
2 A19 FLASH A18 O 1.7
3 A20 FLASH A19 O 1.3
4 NC No Connection - -
5 NC No Connection - -
6 NC No Connection - -
7 A0 LCD driver data or
command distinction
O 1.3
8 A1 FLASH A0 O 0.3
9 VSS Ground potential - 0
10 A2 FLASH A1 O 0.4
11 A3 FLASH A2 O 0.4
12 A4 FLASH A3 O 0.4
13 A5 FLASH A4 O 1.3
14 A6 FLASH A5 O 0.4
15 A7 FLASH A6 O 0
16 A8 FLASH A7 O 1.3
17 A9 FLASH A8 O 0
18 A10 FLASH A9 O 0
19 A11 FLASH A10 O 1.5
20 A12 FLASH A11 O 1.7
21 VCC Positive power
supply terminal
- 3.5
22 A13 FLASH A12 O 1.4
23 A14 FLASH A13 O 1.6
24 A15 FLASH A14 O 1.7
25 SUB SI UP
SO
MAIN-u-com
communication data
input and external
flash rewritting
- 0.5
26 SUB SO/UP
SI
MAIN-u-com
communication data
output and external
flash rewritting
O 1.8
27 UP CLK External flash
rewritting switch
I 3.5
28 NC No Connection - -
29 FLASH
RESET
FLASH reset control
output
O 3.5
30 KS1 Key scan signal 1
output
I 0
31 NC No Connection - -
32 NC No Connection - -
33 AVCC Positive power
supply for A/D
converter
- 3.5
34 AVRH A/D converter
standard voltage input
- 3.5
11

Pin
No.
Port Part Name &
Description
I/O (V)
35 AVSS/AVRL A/D converter ground
potential
- 0
36 TH DETECT Temperature
detection input
I 1.3
37 KS2 Key scan signal 2
output
I 0
38 KS3 Key scan signal 3
output
I 0
39 NC No Connection - -
40 VSS Ground potential - 0
41 KI5 Key return signal 5
input
I 0
42 KI4 Key return signal 4
input
I 0
43 KI3 Key return signal 3
input
I 0
44 KI2 Key return signal 2
input
I 0
45 NC FLASH writing
program starter
I 0
46 NC FLASH writing
program starter
I 3.5
47 MD0 Mode setting terminal I 3.5
48 MD1 Mode setting terminal I 3.5
49 MD2 Mode setting terminal I 0
50 S W U REQ SUB-u-com wake up
request
INT 3.0
51 ROTARY.1 Rotary encoder signal
1(VOL UP)
I 2.5
52 ROTARY.2 Rotary encoder signal
2 (VOL DOWN)
I 2.5
53 KI1(SOURCE) Key return signal 1 INT
/I
0
54 REMO INT Remote control signal
interference
INT 3.7
55 NC/WP/ACC No Connection O 0
56 NC/A21 No Connection O 0
57 NC/A22 No Connection O 0
58 FLASH CE FLASH chip enable O 3.4
59 LCD CS LCD driver chip select O 3.4
60 NC No Connection - -
61 NC No Connection - -
62 REMO 1 Remote control signal I 3.7
63 NC No Connection - -
64 VLCD CONT VLCD 16V control O 3.4
65 M W U REQ MAIN-u-com wake up
request
O 0
66 LED ON P.LED control output O 3.4
12

Pin
No.
Port Part Name &
Description
I/O (V)
67 NC No Connection - -
68 NC No Connection - -
69 FLASH OE/
LCD RD
FLASH output enable
and LCD driver lead
strobe
O 3.4
70 LCD WR LCD driver light
strobe signal
O 3.4
71 FLASH WE FLASH light enable
signal
O 3.4
72 NC No Connection - -
73 LCD RESET LCD driver reset
control
O 3.4
74 FLASH RY/BY FLASH ready/busy
input
I 3.4
75 /RST System reset signal
input
I 3.5
76 NC No Connection - -
77 X1A No Connection - -
78 X0A Not used I 0
79 VSS Ground - 0
80 X0 MAIN system clock
input (12.5MHz)
I 1.3
81 X1 MAIN system clock
output (12.5MHz)
O 1.5
82 VCC Positive power supply - 3.5
83 D0 FLASH D0/LCD D0 I 0.9
84 D1 FLASH D1/LCD D1 I 0.9
85 D2 FLASH D2/LCD D2 I 1.1
86 D3 FLASH D3/LCD D3 I 0.9
87 D4 FLASH D4/LCD D4 I 1.0
88 D5 FLASH D5/LCD D5 I 1.1
89 D6 FLASH D6/LCD D6 I 1.1
90 D7 FLASH D7/LCD D7 I 0.8
91 D8 FLASH D8 I/O 0.9
92 D9 FLASH D9 I/O 0.9
93 D10 FLASH D10 I/O 0.9
94 D11 FLASH D11 I/O 0.8
95 D12 FLASH D12 I/O 0.8
96 D13 FLASH D13 I/O 0.7
97 D14 FLASH D14 I/O 0.7
98 D15 FLASH D15 I/O 0.7
99 A16 FLASH A15 O 3.0
100 A17 FLASH A16 O 1.7
10.3. CD Servo Block
IC401 : YESAM275
13

Pin
No.
Port Descriptions I/O (V)
1 CVSS1 GND - 0
2 A22 TP407 - 0
3 CVSS2 GND - 0
4 DVDD1 I/O system (3.3V) power
supply
- 3.1
5 A10 Address bus of FLASH ROM O 3.1
6 - - - -
7 A11 Address bus of FLASH ROM O 0
8 A12 O 3.1
9 A13 O 3.1
10 A14 O 3.1
11 A15 O 0
12 /
CVDD1
CORE CPU system (1.6V)
power supply
- 1.6
13 - - - -
14 DVSS1 GND - 0
15 CVSS3 GND - 0
16 /
CVDD2
I/O system (3.3V) power
supply
- 1.6
17 - - - -
18 - - - -
19 READY - - 3.1
20 /PS FLASH ROM selection
signal
O 3.1
21 - - - -
22 - - - -
23 R/W Lead/light signal to FLASH
ROM
O 3.1
24 /
MSTRB
Memory access signal O 3.1
25 - - - -
26 /MSC - - 3.1
27 MUTE Mute signal output (H:Mute
on)
O 0
28 - - - -
29 - - - -
30 /HOLD - - 3.1
31 BIO SUBO input I 0
32 MP/MC Operation mode setting
(external pull-up)
I 3.1
33 DVDD2 I/O system (3.3V) power
supply
- 3.1
34 CVSS4 GND - 0
35 BD R1 GND I 0
36 - - - -
37 CVSS5 GND - 0
38 - - - -
14

Pin
No.
Port Descriptions I/O (V)
39 - - - -
40 DVSS2 GND - 0
41 CLK C
M
AUDIO bit clock input I 1.6
42 SCK Clock input I 3.0
43 LRCK
C M
AUDIO L/R identifying
signal input
I 1.6
44 CDFS Serial frame sink signal
input
I 2.4
45 DATA
CM
AUDIO serial data input I 1.6
46 - - - -
47 SI Serial data input I 0
48 CLK M
C
AUDIO bit clock output O 1.6
49 SCK Clock input I 3.0
50 CVSS6 GND - 0
51 - - - -
52 CVDD3 CORE CPU system (1.6V)
power supply
- 1.6
53 LRCK
M C
AUDIO L/R identifying
signal output
O 1.5
54 CDFS Serial frame sink signal
input
I 2.4
55 - - - -
56 DVDD3 I/O system (3.3V) power
supply
- 3.1
57 DVSS3 GND - 0
58 REST
SW
Mechanics deck REST SW
input
I 3.1
59 DATA
M C
AUDIO serial data output O 1.6
60 SO Serial data output O 1.1
61 - - - -
62 - - - -
63 /NMI - - 3.1
64 /INT0 - - 3.1
65 /INT1 - - 3.1
66 BLKCK Subcode block clock pulse
input
I 0
67 /INT3 - - 3.1
68 CV
DD4
CORE CPU system (1.6V)
power supply
- 1.6
69 SW1 Mechanics deck SW1 input I 0
70 CVSS7 GND - 0
71 MCLK Clock output (To Servo
DSP)
O 3.1
72 DVSS4 GND - 0
15

Pin
No.
Port Descriptions I/O (V)
73 MLD Command load signal
output (To Servo DSP)
I 3.1
74 MDATA Command data output (To
Servo DSP)
O 3.1
75 DVDD4 I/O system (3.3V) power
supply
- 3.1
76 DVSS5 GND - 0
77 CLK
MD1
Clock mode setting (L
fixation)
I 0
78 CLK
MD2
Clock mode setting (H
fixation)
I 3.1
79 CLK
MD3
Clock mode setting (L
fixation)
I 0
80 - - - -
81 SW2 Mechanics deck SW2 input I 0.2
82 - - - -
83 EMU0 - - 3.1
84 EMU/
OFF
- - 3.1
85 TDO - - 0
86 TDI - - 3.1
87 /TRST - - 0
88 TCK - - 3.1
89 TMS - - 3.1
90 CVSS8 GND - 0
91 CVDD5 CORE CPU system (1.6V)
power supply
- 1.6
92 HPIENA GND I 0
93 DVSS6 GND - 0
94 - - - -
95 CLKENA Oscillation output Cainabl
signal
O 0
96 X1 Crystal Connection O 0.7
97 X2/
CLKIN
Crystal Connection I 1.0
98 RS Reset signal input I 3.1
99 D0 Data base of FLASH ROM I/O 0
100 D1 I/O 0
101 D2 I/O 0
102 D3 I/O 0
103 D4 I/O 0
104 D5 I/O 0
105 A16 Address bus of FLASH ROM O 3.1
106 DVSS7 GND - 0
107 A17 Address bus of FLASH ROM O 3.1
108 A18 Address bus of FLASH ROM O 0
109 A19 TP419 O 0
16

Pin
No.
Port Descriptions I/O (V)
110 A20 TP416 O 0
111 CVSS9 GND - 0
112 DVDD5 I/O system (3.3V) power
supply
- 3.1
113 D6 Data bus of FLASH ROM I/O 0
114 D7 I/O 0
115 D8 I/O 0
116 D9 I/O 0
117 D10 I/O 0
118 D11 Data bus of FLASH ROM I/O 0
119 D12 I/O 0
120 STAT Status signal input I 3.0
121 D13 Data path of FLASH ROM I/O 3.1
122 D14 I/O 0
123 D15 I/O 0
124 - - - -
125 CVDD6 CORE CPU system (1.6V)
power supply
- 1.6
126 CVSS10 GND - 0
127 - - - -
128 DVSS8 I/O system (3.3V) power
supply
- 0
129 - - - -
130 DVDD6 I/O system (3.3V) power
supply
- 3.1
131 A0 Address bus of FLASH ROM O 3.1
132 A1 O 0
133 A2 O 0
134 A3 O 0
135 /RST Reset signal output(To
Servo DSP)
O 3.1
136 A4 Address bus of FLASH ROM O 0
137 A5 O 3.1
138 A6 O 3.1
139 A7 O 0
140 A8 O 3.1
141 A9 O 3.1
142 CVDD7 CORE CPU system (1.6V)
power supply
- 1.6
143 A12 TP406 - 0
144 DVSS9 GND - 0
11. IC BLOCK DIAGRAM
11.1. Main Block
IC201 : C1BB00000796
17

IC241 : C1BB00001047
18

IC251 : C1BB00001046
IC401 : C1BB00001045
19

IC670 : YEAMC14584BE
IC271 : C1EA00000043
20
