Panasonic CQ-C7413U? CQ-C7113U User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Tone Controls (Bass/Treble) Bass: ±12dB at 60Hz
Treble: ±12dB at 16kHz
Equlizer Center Frequency 60, 160, 400, 1k, 3k, 6k, 16k Hz
(CQ-C7413U)
Equlizer Center Frequency Band 1 (60, 80, 100, 200 Hz)
Band 2 (500, 1k, 2k, 3k Hz)
Band 3 (10k, 12k, 15k, 18k Hz)
(CQ-C7113U)
Variable Range of Equalizer -12dB to 12dB (2dB step)
Current Consumption Less than 2.2A
(CD mode; 0.5W × 4-speaker)
Maximum Power Output 50W × 4(at 1kHz)
Speaker Impedance 4-8Ω
Pre-amp Output Voltage
<CQ-C7413U> 5V
(CD mode; 1kHz, 0dB)
<CQ-C7113U> 2V
(CD mode; 1kHz, 0dB)
Subwoofer Output Voltage
<CQ-C7413U> 5V
(CD mode; 1kHz, 0dB)
<CQ-C7113U> 2V
(CD mode; 1kHz, 0dB)
Pre-amp Output Impedance
<CQ-C7413U> 60Ω
<CQ-C7113U> 200Ω
Subwoofer Output Impedance
© 2005 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-C7413U
CQ-C7113U
WMA MP3 CD Player/Receiver
<CQ-C7413U> 60Ω
<CQ-C7113U> 200Ω
FM Stereo Radio
Frequency Range 87.9MHz - 107.9MHz
Usable Sensitivity 10.2dBf (0.9µV, 75Ω)
50dB Quieting Sensitivity 15.2dBf (1.6µV, 75Ω)
Frequency Response 30Hz-15kHz (±3dB)
Alternate Channel Selectivity 75dB
Stereo Separation 35dB (at 1kHz)
Image Response Ratio 75dB
IF Response Ratio 100dB
Signal to Noise Ratio 62dB
AM Radio
Frequency Range 530kHz - 1,710kHz
Usable Sensitivity 27dB/µV (S/N 20dB)
CD Player
Sampling Frequency 8 Times Oversampling
DA Converter 4 DAC System
Pick-up Type Astigma 3-Beam
Light Source Semiconductor Laser
Wave Length 790 nm
Frequency Response 20 Hz-20kHz (±1dB)
Signal to Noise Ratio 96dB
Total Harmonic Distortion 0.01% (1kHz)
Wow and Flutter Below Measurable Limits
Channel Separation 75dB
Dimensions (W×H×D)** 7”×1-15/16”×6-1/8”
(178×50×155mm)
Weight** 3 lbs. 8oz (1.6 kg)
AUTOMOTIVE AFTERMARKET
Specifications*
ORDER NO. ACED051232C7
C4

* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
** Above specifications comply with EIA standards.
1 ABOUT LEAD FREE SOLDER (PbF) 3
2 FEATUERS 3
3 REPLACEING THE FUSE 3
4 MAINTENANCE 3
5 NOTES 3
6 DIMENSIONS 3
7 LASER PRODUCTS 3
8 WIRING CONNECTION 4
9 DISASSEMBLY INSTRUCTIONS 6
10 TERMINALS DESCRIPTION 9
11 IC BLOCK DIAGRAM 14
12 PACKING PARTS LIST 16
13 REPLACEMENT PARTS LIST [CQ-C7413U] 17
14 EXPLODED VIEW (Unit) [CQ-C7413U] 23
15 REPLACEMENT PARTS LIST [CQ-C7113U] 24
16 EXPLODED VIEW (Unit) [CQ-C7113U] 30
17 CD PLAYER PARTS LIST 31
18 EXPLODED VIEW (CD PLAYER) 34
19 WIRING DIAGRAM 35
20 SCHEMATIC DIAGRAM-1 42
21 SCHEMATIC DIAGRAM-2 43
22 BLOCK DIAGRAM 49
CONTENTS
Page Page
2
CQ-C7413U / CQ-C7113U

1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
• • •
• Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
• • •
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
• • •
• This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATUERS
• • •
• Hands Free Phone System. (The optional Bluetooth hands-
free kit: CY-BT100U)
• • •
• Expansion Module (The optional Hub unit: CY-EM100U)
• • •
• The optional adapter allows you to connect the optional
Panasonic DVD changer unit (CX-DH801U).
• • •
• The optional adapter allows you to connect the optional
Panasonic CD changer unit (CX-DP880).
• • •
• The optional adapter allows you to connect the optional
iPod®series.
• • •
• XM Satellite Radio. (The optional XM receiver: XMD-1000)
• • •
• Sirius Satellite Radio. (The optional Sirius Satellite receiver:
SIR-PAN1)
• • •
• SQ (Sound Quality).
• • •
• SQ7 (7-Band Sound Quality) [CQ-C7413U].
• • •
• SQ3 (3-Band Sound Quality) [CQ-C7113U].
• • •
• D.M(Direct Memory)
• • •
• Customize the Display (Customize Function)
• • •
• MP3/WMA Playback from CD-R/RW.
• • •
• This manual is for 2 models CQ-C7413U and CQ-C7113U.
The following table describes the differences between 2
models.
3 REPLACEING THE FUSE
Use fuses of the same specified rating 15 amps. Using different
substitutes or fuses with higher ratings, or connecting the unit
directly without a fuse, could cause fire or damage to the stereo
unit.
4 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvent.
5 NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the
factory.
[CD DECK BLOCK]
This model has no servo alignment points because
microcomputer controls the servo circuit
6 DIMENSIONS
7 LASER PRODUCTS
3
CQ-C7413U / CQ-C7113U

8 WIRING CONNECTION
8.1. CQ-C7413U
4
CQ-C7413U / CQ-C7113U

8.2. CQ-C7113U
5
CQ-C7413U / CQ-C7113U

9 DISASSEMBLY INSTRUCTIONS
9.1. How to Remove the Flexible PCB(AP2)
6
CQ-C7413U / CQ-C7113U

9.2. How to Install the Main P.C.B. of the Electric Display
7
CQ-C7413U / CQ-C7113U

8
CQ-C7413U / CQ-C7113U

10.1. Main Block [CQ-C7413U]
IC601 : C2CBKG000035
Pin
No. Port Part Name & Description I/O FM AM CD
1 PANEL OPEN Panel open detection I 0 5.2 5.2
2 PANEL CLOSE Panel close detection I 0 0 5.2
3 SUBM CNT 3.3V power control for
Display O 5 - -
4 BATT Battery power check I 4.8 5 5
5 ACC Acc. power check I 4.8 5 5
6 SDA Serial data for
electronic volume I/O 4.9 4.9 4.9
7 SCLK Serial clock for
electronic volume O 4.9 4.9 4.9
8 CD MUTE Signal mute from CD
deck I 5 5 5
9 Vss GND - 0 0 0
10 ST FM stereo detection I 5.1 5.2 5.2
11 PLL DI (MO) Serial data to PLL O 0.6 0 0
12 PLL DO (MI) Serial data from PLL I 5.2 5.2 5.2
13 PLL CLK Serial clock for PLL O 4.9 4.9 4.9
14 PLL CE Chip enable for PLL O 0 0 0
15 CD RESET Reset for CD deck O 4.9 4.9 4.9
16 SUB SI Serial data to Display
CPU O 0.6 0.6 0.8
17 CD IN Disc-in detection I 5 5 5
18 SUB SO Serial data from
Display CPU I 4.4 4.4 4.4
19 CH DATA/ UP
SO XM SO/UP SO Serial data from Changer I 1.6 1.6 1.6
20 CH CLK/ UP
CLK Serial clock for Changer or Flash
writer
I 4.9 4.9 4.9
21 Vdd +5V power supply - 4.9 4.9 4.9
22 XM SI (MO)/ UP
SI Serial data to Satellite or Flash writer O 0 0 0
23 CD SI (MO) Serial data to CD deck O 0 0 0
24 CD SCLK Serial clock for CD
deck I/O 0 0.4 0
25 CONDENSOR Capacitor connection
for power - 3.3 3.3 3.3
26 CD SO (MI) Serial data from CD
deck I 0 0 0
27 CH STB Strobe from Changer I 0 0 0
28 CH REM OUT Remote control codes
to Changer O 4.9 4.9 0.4
29 DECK V CONT Power control for CD
deck O 4.9 4.9 4.9
30 REMO INT Interrupt for remote
control I 3.7 3.7 3.7
31 CD FS Frame sync. for CD
deck O - - -
32 Avdd +5V power supply - 5.1 5.1 5.1
33 AVREF +5V power supply - 5.1 5.1 5.1
34 AVGND GND - 0 0 0
35 AVSS GND - 0 0 0
36 SD FM/AM signal level
meter I 0.2 0 0.3
37 INIT A Model setting A by
voltage level I 0 0 0
38 INIT B Model setting B by
voltage level I 0 0 0
39 AIN Spectrum analyzer
data I 0 0 0
40 Vss GND - 0 0 0
41 SYS ID1 Hub connection device
detection ID 1 I 0 0 0
42 SYS ID2 Hub connection device
detection ID 2 I 5.2 5.2 5.2
Pin
No. Port Part Name & Description I/O FM AM CD
43 HUB EVENT Bluetooth incoming
detection I 5.2 5.2 5.2
44 HUB CNT Request of hub
connection check O 0 0 0
45 CD SW1 Disc detection switch 1 I 0 0 0
46 CD SW2 Disc detection switch 2 I 0 0 0
47 MOD0 Operating mode
control 0 from Flash
writer
I 5.1 5.1 5.1
48 MOD1 Operating mode
control 1: pulled up to
H
- 5.1 5.1 5.1
49 MOD2 Operating mode
control 2 from Flash
writer
I 0 0 0
50 H STANDBY Standby control from
external I 5 5 5
51 DCDC CONT Not connected - - - -
52 FP MOTOR1 Open/Close of Front
panel 1 O 4.9 5 4.9
53 FP MOTOR2 Open/Close of Front
panel 2 O 4.9 5 4.9
54 V CONT1 Reference voltage
control for motor driver O 0 0 5
55 REMO 1 Remote control data I 5 5 5
56 SA CLK Spectrum analyzer
clock O 5 5 4.9
57 EXT MUTE Pulled up to H I 5.3 5.2 5.2
58 AMP CONT Power control for
external Amplifier O 4.9 5 4.9
59 BZ OUT Buzzer signal O 0 0 0
60 OEL VCONT Not connected - - - -
61 WOW MODE1 SRS WOW mode 1 O 0 0 0
62 WOW MODE2 SRS WOW mode 2 O 0 0 0
63 WOW MODE3 SRS WOW mode 3 O 0 0 0
64 DIM1 Not connected - - - -
65 DIM2 Not connected - - - -
66 MAIN CNT2 Power control for Hub O 5 5 5
67 SRC KEY SOURCE key
detection I 5 4.9 5
68 PANEL IN Panel attachment
detection I - - -
69 RDS CLK Not connected - - - -
70 NC Not connected - - - -
71 RDS DATA Not connected - - - -
72 MAIN CONT Main power control O 4.9 4.9 4.9
73 INV CONT Dimmer power control O 5 5 5
74 AF MUTE Audio mute O 5 5 5
75 RESET Reset I 5 5 5
76 FOCUS ELV Focus elevation for
SRS WOW O - - -
77 X1A Oscillator clock O 2.1 2.1 2.1
78 X0A Oscillator clock I 1.6 1.6 1.6
79 Vss GND - 0 0 0
80 X1 Crystal oscillator clock I 2 2 2
81 X2 Crystal oscillator clock O 2.5 2.5 2.5
82 Vdd +5V power supply - 5 5 5
83 P00 Pulled down to L - 0 0 0
84 P01 Pulled up to H - 5.1 5 5.1
85 OFFSET DET Audio clipping level
detection from Power
amp.
I 0 0 0
86 STBY Standby for Power
amp. O 5 5 5
87 MUTE Mute for Power amp. O 0 0 0
88 ILL SENS Pulled up to H - 5 5 5
89 NC Not connected - - - -
10 TERMINALS DESCRIPTION
9
CQ-C7413U / CQ-C7113U

Pin
No. Port Part Name & Description I/O FM AM CD
90 PE DO(MI) - - - - -
91 NC Not connected - - - -
92 NC Not connected - - - -
93 SUB RESET Reset for display CPU O 4.9 5 4.9
94 DISPM CONT 5V power control for
Display O 0 0 0
95 NC Not connected - - - -
96 NC Not connected - - - -
97 NC Not connected - - - -
98 S LED Security LED drive O 0 0 5
99 ANT CONT Power control for
antenna motor O 5.2 5.2 5.2
100 EP CS Not connected - - - -
10.2. Main Block [CQ-C7113U]
IC601 : C2CBKG000035
Pin
No. Port Part Name & Description I/O FM AM CD
1 PANEL OPEN Panel open detection I 0 5.2 5.2
2 PANEL CLOSE Panel close detection I 0 0 5.2
3 SUBM CNT 3.3V power control for
Display O 5 - -
4 BATT Battery power check I 4.8 5 5
5 ACC Acc. power check I 4.8 5 5
6 SDA Serial data for
electronic volume I/O 4.9 4.9 4.9
7 SCLK Serial clock for
electronic volume O 4.9 4.9 4.9
8 CD MUTE Signal mute from CD
deck I 5 5 5
9 Vss GND - 0 0 0
10 ST FM stereo detection I 5.1 5.2 5.2
11 PLL DI (MO) Serial data to PLL O 0.6 0 0
12 PLL DO (MI) Serial data from PLL I 5.2 5.2 5.2
13 PLL CLK Serial clock for PLL O 4.9 4.9 4.9
14 PLL CE Chip enable for PLL O 0 0 0
15 CD RESET Reset for CD deck O 4.9 4.9 4.9
16 SUB SI Serial data to Display
CPU O 0.6 0.6 0.8
17 CD IN Disc-in detection I 5 5 5
18 SUB SO Serial data from
Display CPU I 4.4 4.4 4.4
19 CH DATA/ UP
SO XM SO/UP SO Serial data from Changer I 1.6 1.6 1.6
20 CH CLK/ UP
CLK Serial clock for Changer or Flash
writer
I 4.9 4.9 4.9
21 Vdd +5V power supply - 4.9 4.9 4.9
22 XM SI (MO)/ UP
SI Serial data to Satellite or Flash writer O 0 0 0
23 CD SI (MO) Serial data to CD deck O 0 0 0
24 CD SCLK Serial clock for CD
deck I/O 0 0.4 0
25 CONDENSOR Capacitor connection
for power - 3.3 3.3 3.3
26 CD SO (MI) Serial data from CD
deck I 0 0 0
27 CH STB Strobe from Changer I 0 0 0
28 CH REM OUT Remote control codes
to Changer O 4.9 4.9 0.4
29 DECK V CONT Power control for CD
deck O 4.9 4.9 4.9
30 NC Not connected - - - -
31 CD FS Frame sync. for CD
deck O - - -
32 Avdd +5V power supply - 5.1 5.1 5.1
33 AVREF +5V power supply - 5.1 5.1 5.1
34 AVGND GND - 0 0 0
35 AVSS GND - 0 0 0
36 SD FM/AM signal level
meter I 0.2 0 0.3
37 INIT A Model setting A by
voltage level I 0 0 0
38 INIT B Model setting B by
voltage level I 0 0 0
39 AIN Spectrum analyzer
data I 0 0 0
40 Vss GND - 0 0 0
41 SYS ID1 Hub connection device
detection ID 1 I 0 0 0
42 SYS ID2 Hub connection device
detection ID 2 I 5.2 5.2 5.2
43 HUB EVENT Bluetooth incoming
detection I 5.2 5.2 5.2
10
CQ-C7413U / CQ-C7113U

Pin
No. Port Part Name & Description I/O FM AM CD
44 HUB CNT Request of hub
connection check O 0 0 0
45 CD SW1 Disc detection switch 1 I 0 0 0
46 CD SW2 Disc detection switch 2 I 0 0 0
47 MOD0 Operating mode
control 0 from Flash
writer
I 5.1 5.1 5.1
48 MOD1 Operating mode
control 1: pulled up to
H
- 5.1 5.1 5.1
49 MOD2 Operating mode
control 2 from Flash
writer
I 0 0 0
50 H STANDBY Standby control from
external I 5 5 5
51 DCDC CONT Not connected - - - -
52 FP MOTOR1 Open/Close of Front
panel 1 O 4.9 5 4.9
53 FP MOTOR2 Open/Close of Front
panel 2 O 4.9 5 4.9
54 V CONT1 Reference voltage
control for motor driver O 0 0 5
55 REMO 1 Remote control data I 5 5 5
56 SA CLK Spectrum analyzer
clock O 5 5 4.9
57 EXT MUTE Pulled up to H I 5.3 5.2 5.2
58 AMP CONT Power control for
external Amplifier O 4.9 5 4.9
59 BZ OUT Buzzer signal O 0 0 0
60 NC Not connected - - - -
61 WOW MODE1 Not connected - - - -
62 WOW MODE2 Not connected - - - -
63 WOW MODE3 Not connected - - - -
64 DIM1 Not connected - - - -
65 DIM2 Not connected - - - -
66 MAIN CNT2 Power control for Hub O 5 5 5
67 SRC KEY SOURCE key
detection I 5 4.9 5
68 PANEL IN Panel attachment
detection I - - -
69 NC Not connected - - - -
70 NC Not connected - - - -
71 NC Not connected - - - -
72 MAIN CONT Main power control O 4.9 4.9 4.9
73 INV CONT Dimmer power control O 5 5 5
74 AF MUTE Audio mute O 5 5 5
75 RESET Reset I 5 5 5
76 FOCUS ELV Not connected - - - -
77 X1A Oscillator clock O 2.1 2.1 2.1
78 X0A Oscillator clock I 1.6 1.6 1.6
79 Vss GND - 0 0 0
80 X1 Crystal oscillator clock I 2 2 2
81 X2 Crystal oscillator clock O 2.5 2.5 2.5
82 Vdd +5V power supply - 5 5 5
83 P00 Pulled down to L - 0 0 0
84 P01 Pulled up to H - 5.1 5 5.1
85 OFFSET DET Audio clipping level
detection from Power
amp.
I 0 0 0
86 STBY Standby for Power
amp. O 5 5 5
87 MUTE Mute for Power amp. O 0 0 0
88 ILL SENS Pulled up to H - 5 5 5
89 NC Not connected - - - -
90 NC Not connected - - - -
91 NC Not connected - - - -
92 NC Not connected - - - -
93 SUB RESET Reset for display CPU O 4.9 5 4.9
Pin
No. Port Part Name & Description I/O FM AM CD
94 DISPM CONT 5V power control for
Display O 0 0 0
95 EJE IU Not connected - - - -
96 NC Not connected - - - -
97 NC Not connected - - - -
98 S LED Security LED drive O 0 0 5
99 ANT CONT Power control for
antenna motor O 5.2 5.2 5.2
100 EP CS Not connected - - - -
11
CQ-C7413U / CQ-C7113U

10.3. Display Block
IC900 : C2CBJH000133 [CQ-C7413U]
IC900 : C2CBJH000134 [CQ-C7113U]
Pin
No. Port Part Name & Description I/O (V)
1 A18 A18 in Address bus O 1.5
2 A19 A19 in Address bus O 1.7
3 A20 A20 in Address bus O 1.3
4 NC Not connected - -
5 LED G - - -
6 LED B - - -
7 A0 A0 in address bus for LCD O 1.3
8 A1 A1 in Address bus O 0.3
9 VSS GND - -
10 A2 A2 in Address bus O 0.4
11 A3 A3 in Address bus O 0.4
12 A4 A4 in Address bus O 0.4
13 A5 A5 in Address bus O 1.3
14 A6 A6 in Address bus O 0.4
15 A7 A7 in Address bus O 0
16 A8 A8 in Address bus O 1.3
17 A9 A9 in Address bus O 0
18 A10 A10 in Address bus O 0
19 A11 A11 in Address bus O 1.5
20 A12 A12 in Address bus O 1.7
21 VCC +3.3V Power supply - 3.5
22 A13 A13 in Address bus O 1.4
23 A14 A14 in Address bus O 1.5
24 A15 A15 in Address bus O 1.7
25 SIN0 Serial data from Main CPU or Flash
writer I 0.5
26 SOT0 Serial data to Main CPU or Flash
writer O 1.8
27 SCK0 Serial clock for Flash writer I 3.5
28 NC Not connected - -
29 FRASH
RESET Reset for Flash memory O 3.5
30 KS1 Key scan 1 O 0
31 NC Not connected - -
32 NC Not connected - -
33 AVCC +3.3V Power supply - 3.5
34 AVRH +3.3V Power supply - 3.5
35 AVSS/
AVRL GND - -
36 TH
DETEC
T
Pulled up to H - 1.3
37 KS2 Key scan 2 O 0
38 KS3 Key scan 3 O 0
39 NC Not connected - -
40 VSS GND - -
41 KI5 Key-in return 5 I 0
42 KI4 Key-in return 4 I 0
43 KI3 Key-in return 3 I 0
44 KI2 Key-in return 2 I 0
45 NC Pulled down to L - 0
46 NC Pulled up to H - 3.5
47 MD0 Operating mode control 0 from Flash
writer I 3.5
48 MD1 Operating mode control 1: pulled up
to H - 3.5
49 MD2 Operating mode control 2 from Flash
writer I 0
50 NC Not connected - -
51 ROTA
RY 1 Volume-up detection from Rotary encoder I 2.5
52 ROTA
RY 2 Volume-down detection from Rotary encoder I 2.5
53 NC Not connected - -
Pin
No. Port Part Name & Description I/O (V)
54 NC Not connected - -
55 NC Not connected - -
56 NC Not connected - -
57 NC Not connected - -
58 FLASH
CE Chip enable for Flash memory O 3.4
59 LCD
CS LCD chip select O 3.4
60 LED R
61 NC Not connected - -
62 NC Not connected - -
63 NC Not connected - -
64 VLCD
CONT Power control for LCD O 3.4
65 NC Not connected - -
66 NC Not connected - -
67 NC Not connected - -
68 NC Not connected - -
69 OE/RD Output enable for Flash memory or
Read strobe for LCD O 3.4
70 LCD
WR Write strobe for LCD O 3.4
71 FLASH
WE Write enable for Flash memory O 3.4
72 NC Not connected - -
73 LCD
RESET Reset for LCD O 3.4
74 FLASH
RY/BY Ready/Busy from Flash memory I 3.4
75 RST Reset I 3.5
76 NC Not connected - -
77 NC Not connected - -
78 X0A GND - -
79 VSS GND - -
80 X0 System clock (12.5MHz) I 1.3
81 X1 System clock (12.5MHz) O 1.5
82 VCC +3.3V Power supply - 3.5
83 D0 D0 in Data bus I/O 0.9
84 D1 D0 in Data bus I/O 0.9
85 D2 D0 in Data bus I/O 1.1
86 D3 D0 in Data bus I/O 0.9
87 D4 D0 in Data bus I/O 1.0
88 D5 D0 in Data bus I/O 1.1
89 D6 D0 in Data bus I/O 1.1
90 D7 D0 in Data bus I/O 0.9
91 D8 D0 in Data bus I/O 0.9
92 D9 D0 in Data bus I/O 0.9
93 D10 D0 in Data bus I/O 0.9
94 D11 D0 in Data bus I/O 0.5
95 D12 D0 in Data bus I/O 0.9
96 D13 D0 in Data bus I/O 0.7
97 D14 D0 in Data bus I/O 0.7
98 D15 D0 in Data bus I/O 0.7
99 A16 A16 in Address bus O 3.0
100 A17 A17 in Address bus O 1.7
12
CQ-C7413U / CQ-C7113U

10.4. CD Servo Block
IC101 : YESAM337
Pin No. Port Descriptions I/O (V)
1 AVSS GND - 0
2 LD-MT Loading Motor drive IC control 1 O 3.2
3 CNT Loading Motor drive IC control 2 O 3.2
4 - - - -
5 LD-EJ Loading Motor drive IC control
(Eject) O 0
6 AMUTE Mute signal output O 0
7 - - - -
8 SBSY DSP IC SBSY O 0
9 - - - -
10 - - - -
11 TXD0 Serial data output O 0
12 RXD0 Serial data input I 0
13 CLK0 Clock input I 2.9
14 - - - -
15 - - - -
16 - - - -
17 AMD - - 3.2
18 DVCC Power supply (3.3V) - 3.2
19 X2 Crystal oscillator - 1.3
20 DVSS GND - 0
21 X1 Crystal oscillator - 1.3
22 AMI - - 3.2
23 RESET Reset I 3
24 - - - -
25 - - - -
26 NMI - - 3.2
27 - - - -
28 STBY DSP IC STBY O 0
29 RST DSP IC RST O 3.2
30 CCE DSP IC CCE O 2.6
31 BUCK DSP IC CK O 2.8
32 BUS3 DSP IC BUS3 O 2.8
33 BUS2 DSP IC BUS2 O 2.8
34 BUS1 DSP IC BUS1 O 2.8
35 BUS0 DSP IC BUS0 O 2.9
36 RESET
SW Mechanics deck REST SW input I 3.2
37 SW1 Mechanics deck SW1 input I 0
38 SW2 Mechanics deck SW2 input I 0
39 CONT
(P13) DSP IC power control 1 O 3.2
40 - - - -
41 - - - -
42 - - - -
43 CONT
(P17) DSP IC power control 2 O 3.2
44 PIO0 DSP IC PIO0 O 0
45 ZDET LOAD detect I 0
46-48 - - - -
49 - - - 3.2
50-58 - - - -
59 CDFS Serial frame sink signal input
(CD ON) I 2.3
60 P50/AN0 Reference voltage I 0.3
61 P51/AN0 Loading motor detect I 2.1
62 P52/AN2 - - 0
63 P53/AN3 - - 0
64 AVCC Power supply (3.3V) - 3.2
13
CQ-C7413U / CQ-C7113U

11.1. Main Block
IC201 : C1BB00000796
IC231 : C0JBZS000003 [CQ-C7413U]
IC670 : YEAMC14584BE
IC730 : C0DAEKG00002
IC701 : C0DAZHF00004
IC755 : C0DBZGD00040
11 IC BLOCK DIAGRAM
14
CQ-C7413U / CQ-C7113U

IC752 : C0CAABG00012
IC760 : C0GBG0000032
IC770 : C0DBAHG00020 [CQ-C7413U]
11.2. Display Block
IC902 : C0EBF0000374
11.3. CD Servo Block
IC401, IC403 : YESAM341
IC402 : YESAM342
15
CQ-C7413U / CQ-C7113U

12 PACKING PARTS LIST
· Item numbers listed below should not order regular spare parts. (not available)
Item No. Part No. Part Name & Description Q´ty Remarks
1 - Inner Carton 1 Not available
2 - Polyethylene Bag 1 Not available
3 - Packing Pad Front 1 Not available
4 - Packing Pad Rear 1 Not available
5 - Instruction Kit 1 Not available
- Operating Instructions (1) Not available
- System Upgrade Guidebook (1) Not available
- Installation Instructions (1) Not available
- Owners Information Card (1) Not available
6 - Sleeve 1 Not available
7 EUR7641010 Remote Control Unit (includes a battery) 1
- CR2025/1F Lithium Battery 1
8 YGAJ021009 Power Connector 1
9 YEFX0217222 Mounting Collar 1
10 YEFC051013 Trim Plate 1
11 YEP0FZ5701 Installation Kit (Lock Cancel Plate, Mounting Bolt, Tapping Screw, Hex
Nut) 1
12 YEFG04019 Rear Support Strap 1
13 YEFA134150 Removable Face Plate Case 1
14 YEP0FZ5702 Security Screw Kit 1
16
CQ-C7413U / CQ-C7113U

13 REPLACEMENT PARTS
LIST [CQ-C7413U]
Notes :
1.Be sure to make your orders of replacement parts
according to this list.
2.Important safety notice: Components, identified by mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3.Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4.The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
5.Reference materials of parts with the “TSN“ mark in the
remarks column are uploaded in the TSN (Technical
Service Navigation) system website. Please download from
that website for references.
Ref. No. Part No. Part Name & Description Remarks
[E3108] Main/Sub Block
IC´s AND TRANSISTORs
IC201 C1BB00000796 IC
IC221 C1BB00001131 IC
IC231 C0JBZS000003 IC
IC251 C0ABBA000221 IC
IC252 C0ABCA000121 IC
IC271 C1ZAZ0001450 IC
IC401 C1BB00001045 IC
IC601 C2CBKG000035 IC
IC630 C0JBAA000372 IC
IC650 C0JBAA000372 IC
IC670 YEAMC14584BE IC
IC701 C0DAZHF00004 IC
IC702 C0EBZ0000035 IC
IC730 C0DAEKG00002 IC
IC752 C0CBCBG00012 IC
IC755 C0DBZGD00040 IC
IC760 C0GBG0000032 IC
IC770 C0DBAHG00020 IC
IC790 C0CBCYG00004 IC
PA51 C5BA00000122 Electronic Tuner
Q55 B1GDGFEH0001 Transistor
Q56 B1AAEC000002 Transistor
Q220 B1GBCFNN0004 Transistor
Q235 B1GBHBEA0004 Transistor
Q241 B1GBHBEA0004 Transistor
Q251 B1GBHBEA0004 Transistor
Q252 B1GBHBEA0004 Transistor
Q320 B1GBCFNN0004 Transistor
Q335 B1GBHBEA0004 Transistor
Q341 B1GBHBEA0004 Transistor
Q351 B1GBHBEA0004 Transistor
Q352 B1GBHBEA0004 Transistor
Q353 B1GBHBEA0004 Transistor
Q354 B1GDCFJJ0002 Transistor
Q371 B1GBCFNN0004 Transistor
Q372 YEANC114YKX Transistor
Q376 B1GBCFNN0004 Transistor
Q411 B1CBGF000005 Transistor
Q630 B1GBCFNN0004 Transistor
Q633 B1GDCFJJ0002 Transistor
Ref. No. Part No. Part Name & Description Remarks
Q650 YEANC114YKX Transistor
Q651 YEANC114YKX Transistor
Q652 YEANC114YKX Transistor
Q680 B1GDGFEH0001 Transistor
Q681 B1GDCFJJ0002 Transistor
Q701 B1BACF000026 Transistor
Q760 B1GBCFNN0004 Transistor
Q771 B1ABCF000187 Transistor
Q791 B1GBNCEJ0003 Transistor
Q793 YEANC114YKX Transistor
DIODEs
D201 B0JCME000012 Diode
D202 B0JCME000012 Diode
D203 B0JCME000012 Diode
D204 B0JCME000012 Diode
D251 B0JCMC000004 Diode
D301 B0JCME000012 Diode
D302 B0JCME000012 Diode
D303 B0JCME000012 Diode
D304 B0JCME000012 Diode
D601 B0JCMC000004 Diode
D630 B3AAB0000143 Diode
D631 B0BC5R600003 Diode
D632 MA152WATX Diode
D635 B0BC5R600003 Diode
D636 B0BC5R600003 Diode
D637 B0BC5R600003 Diode
D638 B0BC5R600003 Diode
D639 B0BC5R600003 Diode
D670 B0JCMC000004 Diode
D672 B0JCMC000004 Diode
D673 B0BC5R000020 Diode
D701 YEADDAM3MA47 Diode
D702 MA736TX Diode
D703 B0BC5R7A0062 Diode
D704 B0JCMC000004 Diode
D705 YEADSR1544TL Diode
D706 YEADSR1544TL Diode
D707 YEADRB051L40 Diode
D708 MA736TX Diode
D710 B0JCMC000004 Diode
D715 MA3X152A0L Diode
D716 MA721TX Diode
D751 YEADSR1544TL Diode
D752 YEADSR1544TL Diode
D760 B0BC5R000020 Diode
D761 B0BC3R0A0058 Diode
D770 B0JCMC000004 Diode
D771 B0JCQD000002 Diode
D772 B0BC013A0063 Diode
CAPACITORs
C52 YECUS1H470JC Ceramic, 47PF 50WV
C53 F1J1H103A513 Ceramic, 0.01µF 50WV
C54 F2A1A221A449 Electrolytic, 220µF 10WV
C55 F1J1H103A513 Ceramic, 0.01µF 50WV
C56 F3F1E105A001 Tantalum, 1µF 25WV
C57 F2A1A101A450 Electrolytic, 100µF 10WV
C61 YECUS1E273KX Ceramic, 0.027µF 25WV
C62 YECUS1E273KX Ceramic, 0.027µF 25WV
C65 F1J1H1020024 Ceramic, 1000PF 50WV
C206 F2A1C100A502 Electrolytic, 10µF 16WV
C213 F1J1A2250004 Ceramic, 2.2µF 10WV
C215 F1J1A2250004 Ceramic, 2.2µF 10WV
C217 YECUS1C334KX Ceramic, 0.33µF 16WV
C220 F1J1C225A138 Ceramic, 2.2µF 16WV
C237 F1J1C225A138 Ceramic, 2.2µF 16WV
C242 F1J1C225A138 Ceramic, 2.2µF 16WV
C251 YECUS1C474KX Ceramic, 0.47µF 16WV
C252 YECUS1H470JM Ceramic, 47PF 50WV
C253 F1J1C225A138 Ceramic, 2.2µF 16WV
17
CQ-C7413U / CQ-C7113U

Ref. No. Part No. Part Name & Description Remarks
C254 YECUS1C474KX Ceramic, 0.47µF 16WV
C255 YECUS1H470JM Ceramic, 47PF 50WV
C256 F1J1C225A138 Ceramic, 2.2µF 16WV
C271 F1J1H472A675 Ceramic, 4700PF 50WV
C272 F1J1H472A675 Ceramic, 4700PF 50WV
C274 F2A1C470A630 Electrolytic, 47µF 16WV
C275 F1J1C1050013 Ceramic, 1µF 16WV
C278 YECUS1E104ZF Ceramic, 0.1µF 25WV
C279 F2A1C4720027 Electrolytic, 4700µF 16WV
C281 F1K1C1060001 Ceramic, 10µF 16WV
C282 YECUZ1C104KX Ceramic, 0.1µF 16WV
C283 F1K1C1060001 Ceramic, 10µF 16WV
C296 F1K1C4740009 Ceramic, 0.47µF 16WV
C297 F1K1C4740009 Ceramic, 0.47µF 16WV
C306 F2A1C100A502 Electrolytic, 10µF 16WV
C313 F1J1A2250004 Ceramic, 2.2µF 10WV
C315 F1J1A2250004 Ceramic, 2.2µF 10WV
C317 YECUS1C334KX Ceramic, 0.33µF 16WV
C320 F1J1C225A138 Ceramic, 2.2µF 16WV
C321 F1J1C225A138 Ceramic, 2.2µF 16WV
C323 F2A1C100A502 Electrolytic, 10µF 16WV
C324 F2A1H2R2A634 Electrolytic, 2.2µF 50WV
C325 F2A1H2R2A634 Electrolytic, 2.2µF 50WV
C326 F1J1A2250004 Ceramic, 2.2µF 10WV
C327 F2A1A221A449 Electrolytic, 220µF 10WV
C328 F1J1H103A513 Ceramic, 0.01µF 50WV
C330 F1J1A2250004 Ceramic, 2.2µF 10WV
C331 F1J1C225A138 Ceramic, 2.2µF 16WV
C332 YECUZ1C104KX Ceramic, 0.1µF 16WV
C333 F1H1E103A011 Ceramic, 0.01µF 25WV
C334 YECUZ1C104KX Ceramic, 0.1µF 16WV
C335 YECUZ1C104KX Ceramic, 0.1µF 16WV
C336 YECUZ1C104KX Ceramic, 0.1µF 16WV
C337 YECUZ1C104KX Ceramic, 0.1µF 16WV
C338 YECUZ1C104KX Ceramic, 0.1µF 16WV
C339 YECUZ1C104KX Ceramic, 0.1µF 16WV
C340 F1J1C1050013 Ceramic, 1µF 16WV
C341 F1K1C1060001 Ceramic, 10µF 16WV
C342 YECUZ1C333KX Ceramic, 0.033µF 16WV
C343 F1H1E103A011 Ceramic, 0.01µF 25WV
C344 YECUS1C334KX Ceramic, 0.33µF 16WV
C346 YECUS1C474KX Ceramic, 0.47µF 16WV
C347 YECUZ1H221JC Ceramic, 220PF 50WV
C351 YECUS1C474KX Ceramic, 0.47µF 16WV
C352 YECUS1H470JM Ceramic, 47PF 50WV
C353 F1J1C225A138 Ceramic, 2.2µF 16WV
C354 YECUS1C474KX Ceramic, 0.47µF 16WV
C355 YECUS1H470JM Ceramic, 47PF 50WV
C356 F1J1C225A138 Ceramic, 2.2µF 16WV
C361 YECUS1C474KX Ceramic, 0.47µF 16WV
C362 YECUS1H470JM Ceramic, 47PF 50WV
C363 ECEA1EKS3R3I Electrolytic, 3.3µF 25WV
C364 F2A1C100A502 Electrolytic, 10µF 16WV
C365 YECUS1C104KX Ceramic, 0.1µF 16WV
C366 YECUS1C104KX Ceramic, 0.1µF 16WV
C367 YECUS1C104KX Ceramic, 0.1µF 16WV
C368 F2A1C470A630 Electrolytic, 47µF 16WV
C371 F1J1H472A675 Ceramic, 4700PF 50WV
C372 F1J1H472A675 Ceramic, 4700PF 50WV
C374 F2A1H2R20044 Electrolytic, 2.2µF 50WV
C375 F2A1C100A502 Electrolytic, 10µF 16WV
C378 YECUS1E104ZF Ceramic, 0.1µF 25WV
C381 F1K1C1060001 Ceramic, 10µF 16WV
C382 YECUZ1C104KX Ceramic, 0.1µF 16WV
C383 F1K1C1060001 Ceramic, 10µF 16WV
C384 F2A1A101A450 Electrolytic, 100µF 10WV
C385 F1K1C1060001 Ceramic, 10µF 16WV
C386 F1K1C1060001 Ceramic, 10µF 16WV
C387 F1K1C1060001 Ceramic, 10µF 16WV
C388 F1K1C1060001 Ceramic, 10µF 16WV
C389 F1K1C1060001 Ceramic, 10µF 16WV
C396 F1K1C4740009 Ceramic, 0.47µF 16WV
C397 F1K1C4740009 Ceramic, 0.47µF 16WV
C401 F1J1H120A034 Ceramic, 12PF 50WV
Ref. No. Part No. Part Name & Description Remarks
C402 F1J1H120A034 Ceramic, 12PF 50WV
C403 F2A0J101A500 Electrolytic, 100µF 6.3WV
C404 F1J1H103A513 Ceramic, 0.01µF 50WV
C405 F1H1H101A231 Ceramic, 100PF 50WV
C411 F1J1H103A513 Ceramic, 0.01µF 50WV
C412 YECUS1E223KX Ceramic, 0.022µF 25WV
C413 ECQV1H224JL2 Plastic Film, 0.22µF 50WV
C414 F2A1A221A449 Electrolytic, 220µF 10WV
C601 YECUS1C104KX Ceramic, 0.1µF 16WV
C602 F1H1E103A011 Ceramic, 0.01µF 25WV
C603 F2A0J3310051 Electrolytic, 330µF 6.3WV
C604 ECA0JM471I Electrolytic, 470µF 6.3WV
C605 YECUS1C104KX Ceramic, 0.1µF 16WV
C606 F1H1H2200008 Ceramic, 22PF 50WV
C607 YECUS1H220JC Ceramic, 22PF 50WV
C608 YECUS1C104KX Ceramic, 0.1µF 16WV
C609 F1J1A106A023 Ceramic, 10µF 10WV
C610 YECUS1C104KX Ceramic, 0.1µF 16WV
C612 F1H1H120A231 Ceramic, 12PF 50WV
C613 F1H1H100A226 Ceramic, 10PF 50WV
C631 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C632 YECUS1E104ZF Ceramic, 0.1µF 25WV
C633 F2A1C470A630 Electrolytic, 47µF 16WV
C634 F1H1E103A011 Ceramic, 0.01µF 25WV
C635 F1J1H103A513 Ceramic, 0.01µF 50WV
C650 F1J1H103A513 Ceramic, 0.01µF 50WV
C670 F2A1C100A502 Electrolytic, 10µF 16WV
C671 F1H1E103A011 Ceramic, 0.01µF 25WV
C680 F2A1H2R2A634 Electrolytic, 2.2µF 50WV
C701 YECUS1C154KX Ceramic, 0.15µF 16WV
C702 F2A1C1020069 Electrolytic, 1000µF 16WV
C704 F2A0J3310051 Electrolytic, 330µF 6.3WV
C705 F1H1E103A011 Ceramic, 0.01µF 25WV
C707 F2A1C1020069 Electrolytic, 1000µF 16WV
C708 F2A1H1R00095 Electrolytic, 1µF 50WV
C713 YECUS1C474KX Ceramic, 0.47µF 16WV
C715 YECUS1E104ZF Ceramic, 0.1µF 25WV
C716 YECUS1C104KX Ceramic, 0.1µF 16WV
C717 YECUS1C104KX Ceramic, 0.1µF 16WV
C718 YECUS1E104ZF Ceramic, 0.1µF 25WV
C719 EEAFC1A820H Electrolytic, 82µF 10WV
C720 YECUS1C104KX Ceramic, 0.1µF 16WV
C721 YECUS1C104KX Ceramic, 0.1µF 16WV
C730 F1K1E334A022 Ceramic, 0.33µF 25WV
C731 YECUX1C334KX Ceramic, 0.33µF 16WV
C732 EEAFC1C560H Electrolytic, 56µF 16WV
C752 YECUS1C334KX Ceramic, 0.33µF 16WV
C753 YECUS1C334KX Ceramic, 0.33µF 16WV
C754 EEAFC0J560H Electrolytic, 56µF 6.3WV
C755 YECUZ1C104KX Ceramic, 0.1µF 16WV
C756 F1J1C1050013 Ceramic, 1µF 16WV
C757 F1H1E103A011 Ceramic, 0.01µF 25WV
C758 F2A0J470A558 Electrolytic, 47µF 6.3WV
C760 F1H1E103A011 Ceramic, 0.01µF 25WV
C761 YECUS1E104ZF Ceramic, 0.1µF 25WV
C762 F2A1C470A630 Electrolytic, 47µF 16WV
C763 YECUS1E104ZF Ceramic, 0.1µF 25WV
C771 F2A1C1010089 Electrolytic, 100µF 16WV
C772 YECUS1C104KX Ceramic, 0.1µF 16WV
C773 F1J1H271A025 Ceramic, 270PF 50WV
C774 EEEFK1E101P Electrolytic, 100µF 25WV
C775 YECUZ1C104KX Ceramic, 0.1µF 16WV
C776 F2A1E101A575 Electrolytic, 100µF 25WV
C777 F1J1H103A513 Ceramic, 0.01µF 50WV
C778 F2A1C100A502 Electrolytic, 10µF 16WV
C791 EEAFC1C560H Electrolytic, 56µF 16WV
C792 YECUX1C334KX Ceramic, 0.33µF 16WV
C793 F1J1E334A009 Ceramic, 0.33µF 25WV
C797 YECUS1C104KX Ceramic, 0.1µF 16WV
RESISTORs
J401 ERJ6GEY0R00V Chip, 0Ω1/10W
J403 ERJ8GEY0R00V Chip, 0Ω1/8W
18
CQ-C7413U / CQ-C7113U

Ref. No. Part No. Part Name & Description Remarks
J404 ERJ6GEY0R00V Chip, 0Ω1/10W
J474 ERJ8GX0R00V Chip, 0Ω1/8W
J475 ERJ8GX0R00V Chip, 0Ω1/8W
J476 ERJ8GX0R00V Chip, 0Ω1/8W
J477 ERJ8GX0R00V Chip, 0Ω1/8W
J478 ERJ8GX0R00V Chip, 0Ω1/8W
J479 ERJ8GX0R00V Chip, 0Ω1/8W
J480 ERJ8GX0R00V Chip, 0Ω1/8W
J481 ERJ8GX0R00V Chip, 0Ω1/8W
J482 ERJ8GX0R00V Chip, 0Ω1/8W
J483 ERJ8GX0R00V Chip, 0Ω1/8W
J501 ERJ8GEY0R00V Chip, 0Ω1/8W
J502 ERJ8GEY0R00V Chip, 0Ω1/8W
J503 ERJ8GEY0R00V Chip, 0Ω1/8W
J504 ERJ8GEY0R00V Chip, 0Ω1/8W
J506 ERJ8GEY0R00V Chip, 0Ω1/8W
J507 ERJ8GEY0R00V Chip, 0Ω1/8W
J508 ERJ8GEY0R00V Chip, 0Ω1/8W
J509 ERJ8GEY0R00V Chip, 0Ω1/8W
J510 ERJ8GEY0R00V Chip, 0Ω1/8W
J511 ERJ8GEY0R00V Chip, 0Ω1/8W
J512 ERJ8GEY0R00V Chip, 0Ω1/8W
J513 ERJ8GEY0R00V Chip, 0Ω1/8W
J514 ERJ8GEY0R00V Chip, 0Ω1/8W
J515 ERJ8GEY0R00V Chip, 0Ω1/8W
J516 ERJ8GEY0R00V Chip, 0Ω1/8W
J523 ERJ8GX0R00V Chip, 0Ω1/8W
J524 ERJ8GX0R00V Chip, 0Ω1/8W
J525 ERJ8GX0R00V Chip, 0Ω1/8W
J526 ERJ8GX0R00V Chip, 0Ω1/8W
J529 ERJ8GX0R00V Chip, 0Ω1/8W
J531 ERJ8GX0R00V Chip, 0Ω1/8W
J534 ERJ8GX0R00V Chip, 0Ω1/8W
J536 ERJ8GX0R00V Chip, 0Ω1/8W
J537 ERJ8GX0R00V Chip, 0Ω1/8W
J538 ERJ8GX0R00V Chip, 0Ω1/8W
J539 ERJ8GX0R00V Chip, 0Ω1/8W
J540 ERJ8GX0R00V Chip, 0Ω1/8W
J542 ERJ8GX0R00V Chip, 0Ω1/8W
J544 ERJ8GX0R00V Chip, 0Ω1/8W
J545 ERJ8GX0R00V Chip, 0Ω1/8W
J546 ERJ8GX0R00V Chip, 0Ω1/8W
J550 ERJ8GX0R00V Chip, 0Ω1/8W
J551 ERJ8GX0R00V Chip, 0Ω1/8W
J552 ERJ8GX0R00V Chip, 0Ω1/8W
J553 ERJ8GX0R00V Chip, 0Ω1/8W
J554 ERJ8GX0R00V Chip, 0Ω1/8W
J555 ERJ8GEY0R00V Chip, 0Ω1/8W
J556 ERJ8GX0R00V Chip, 0Ω1/8W
J557 ERJ8GX0R00V Chip, 0Ω1/8W
J560 ERJ8GEY0R00V Chip, 0Ω1/8W
J561 ERJ8GEY0R00V Chip, 0Ω1/8W
J563 ERJ8GX0R00V Chip, 0Ω1/8W
J565 ERJ8GX0R00V Chip, 0Ω1/8W
J570 ERJ8GX0R00V Chip, 0Ω1/8W
J571 ERJ8GX0R00V Chip, 0Ω1/8W
J573 ERJ8GX0R00V Chip, 0Ω1/8W
J579 ERJ8GEY0R00V Chip, 0Ω1/8W
J580 ERJ8GX0R00V Chip, 0Ω1/8W
J582 ERJ8GEY0R00V Chip, 0Ω1/8W
J583 ERJ8GEY0R00V Chip, 0Ω1/8W
J590 ERJ8GEY0R00V Chip, 0Ω1/8W
J591 ERJ6GEY0R00V Chip, 0Ω1/10W
J592 ERJ8GX0R00V Chip, 0Ω1/8W
R50 ERJ6GEYJ5R6V Chip, 5.6Ω1/10W
R54 ERJ6GEYJ101 Chip, 100Ω1/10W
R55 ERJ6GEYJ221 Chip, 220Ω1/10W
R56 ERJ6GEYJ102 Chip, 1kΩ1/10W
R59 ERJ3GEYJ104V Chip, 100kΩ1/16W
R65 ERJ6GEYJ393 Chip, 39kΩ1/10W
R202 ERJ6GEYJ152 Chip, 1.5kΩ1/10W
R203 ERJ6GEYJ103 Chip, 10kΩ1/10W
R213 ERJ6GEYJ562 Chip, 5.6kΩ1/10W
R214 ERJ6GEYJ103 Chip, 10kΩ1/10W
Ref. No. Part No. Part Name & Description Remarks
R215 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R216 ERJ3GEYJ123V Chip, 12kΩ1/16W
R217 ERJ3GEYJ183V Chip, 18kΩ1/16W
R220 ERJ3GEYJ750V Chip, 75Ω1/16W
R221 ERJ3GEYJ153V Chip, 15kΩ1/16W
R235 ERJ3GEYJ104V Chip, 100kΩ1/16W
R237 ERJ3GEYJ271V Chip, 270Ω1/16W
R241 ERJ3GEYJ104V Chip, 100kΩ1/16W
R242 ERJ3GEYJ271V Chip, 270Ω1/16W
R251 ERJ3GEYJ104V Chip, 100kΩ1/16W
R252 ERJ3GEYJ393V Chip, 39kΩ1/16W
R253 ERJ3GEYJ433V Chip, 43kΩ1/16W
R254 ERJ3GEYJ560V Chip, 56Ω1/16W
R255 ERJ3GEYJ104V Chip, 100kΩ1/16W
R256 ERJ3GEYJ104V Chip, 100kΩ1/16W
R257 ERJ3GEYJ393V Chip, 39kΩ1/16W
R258 ERJ3GEYJ433V Chip, 43kΩ1/16W
R259 ERJ3GEYJ560V Chip, 56Ω1/16W
R260 ERJ6GEYJ104 Chip, 100kΩ1/10W
R275 ERJ8GEYJ223V Chip, 22kΩ1/8W
R281 ERJ3GEYJ104V Chip, 100kΩ1/16W
R282 ERJ3GEYJ104V Chip, 100kΩ1/16W
R283 ERJ3GEYJ103V Chip, 10kΩ1/16W
R284 ERJ3GEYJ103V Chip, 10kΩ1/16W
R285 ERJ3GEYJ272V Chip, 2.7kΩ1/16W
R286 ERJ3GEYJ102V Chip, 1kΩ1/16W
R291 ERJ3GEYJ104V Chip, 100kΩ1/16W
R296 ERJ6GEYJ271 Chip, 270Ω1/10W
R297 ERJ6GEYJ271 Chip, 270Ω1/10W
R298 ERJ3GEYJ222V Chip, 2.2kΩ1/16W
R302 ERJ3GEYJ152V Chip, 1.5kΩ1/16W
R303 ERJ3GEYJ103V Chip, 10kΩ1/16W
R313 ERJ6GEYJ562 Chip, 5.6kΩ1/10W
R314 ERJ6GEYJ103 Chip, 10kΩ1/10W
R315 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R316 ERJ3GEYJ123V Chip, 12kΩ1/16W
R317 ERJ3GEYJ183V Chip, 18kΩ1/16W
R320 ERJ3GEYJ750V Chip, 75Ω1/16W
R321 ERJ3GEYJ153V Chip, 15kΩ1/16W
R323 ERJ3GEYJ102V Chip, 1kΩ1/16W
R324 ERJ3GEYJ103V Chip, 10kΩ1/16W
R325 ERJ6GEYJ102 Chip, 1kΩ1/10W
R326 ERJ6GEYJ101 Chip, 100Ω1/10W
R327 ERJ6GEYJ823 Chip, 82kΩ1/10W
R330 ERJ6GEYJ221 Chip, 220Ω1/10W
R335 ERJ3GEYJ104V Chip, 100kΩ1/16W
R336 ERJ3GEYJ271V Chip, 270Ω1/16W
R341 ERJ3GEYJ104V Chip, 100kΩ1/16W
R342 ERJ3GEYJ271V Chip, 270Ω1/16W
R351 ERJ3GEYJ104V Chip, 100kΩ1/16W
R352 ERJ3GEYJ393V Chip, 39kΩ1/16W
R353 ERJ3GEYJ433V Chip, 43kΩ1/16W
R354 ERJ3GEYJ560V Chip, 56Ω1/16W
R355 ERJ3GEYJ104V Chip, 100kΩ1/16W
R356 ERJ3GEYJ104V Chip, 100kΩ1/16W
R357 ERJ3GEYJ393V Chip, 39kΩ1/16W
R358 ERJ3GEYJ433V Chip, 43kΩ1/16W
R359 ERJ3GEYJ560V Chip, 56Ω1/16W
R360 ERJ3GEYJ104V Chip, 100kΩ1/16W
R361 ERJ6GEYJ104 Chip, 100kΩ1/10W
R362 ERJ6GEYJ393 Chip, 39kΩ1/10W
R363 ERJ6GEYJ393 Chip, 39kΩ1/10W
R364 ERJ6GEYJ560 Chip, 56Ω1/10W
R365 ERJ6GEYJ104 Chip, 100kΩ1/10W
R366 ERJ6GEYJ103 Chip, 10kΩ1/10W
R367 ERJ6GEYJ103 Chip, 10kΩ1/10W
R368 ERJ3GEYJ563V Chip, 56kΩ1/16W
R369 ERJ3GEYJ133V Chip, 13kΩ1/16W
R370 ERJ3GEYJ363V Chip, 36kΩ1/16W
R371 ERJ3GEYJ822V Chip, 8.2kΩ1/16W
R372 ERJ3GEYJ103V Chip, 10kΩ1/16W
R373 ERJ6GEYJ183 Chip, 18kΩ1/10W
R374 ERJ3GEYJ164V Chip, 160kΩ1/16W
R375 ERJ6GEYJ562 Chip, 5.6kΩ1/10W
19
CQ-C7413U / CQ-C7113U

Ref. No. Part No. Part Name & Description Remarks
R376 ERJ3GEYJ103V Chip, 10kΩ1/16W
R377 ERJ3GEYJ104V Chip, 100kΩ1/16W
R378 ERJ3GEY0R00V Chip, 0Ω1/16W
R379 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R381 ERJ3GEYJ104V Chip, 100kΩ1/16W
R382 ERJ3GEYJ104V Chip, 100kΩ1/16W
R383 ERJ3GEYJ103V Chip, 10kΩ1/16W
R384 ERJ3GEYJ103V Chip, 10kΩ1/16W
R385 ERJ3GEYJ272V Chip, 2.7kΩ1/16W
R386 ERJ3GEYJ102V Chip, 1kΩ1/16W
R387 ERJ6GEYJ103 Chip, 10kΩ1/10W
R388 ERJ6GEYJ103 Chip, 10kΩ1/10W
R389 ERJ6GEYJ103 Chip, 10kΩ1/10W
R390 ERJ3GEYJ473V Chip, 47kΩ1/16W
R391 ERJ3GEYJ104V Chip, 100kΩ1/16W
R392 ERJ6GEYJ104 Chip, 100kΩ1/10W
R393 ERJ3GEYJ104V Chip, 100kΩ1/16W
R396 ERJ6GEYJ271 Chip, 270Ω1/10W
R397 ERJ6GEYJ271 Chip, 270Ω1/10W
R398 ERJ3GEYJ222V Chip, 2.2kΩ1/16W
R401 ERJ3GEYJ152V Chip, 1.5kΩ1/16W
R402 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R403 ERJ3GEYJ473V Chip, 47kΩ1/16W
R404 ERJ3GEYJ102V Chip, 1kΩ1/16W
R405 ERJ3GEYJ102V Chip, 1kΩ1/16W
R406 ERJ3GEYJ102V Chip, 1kΩ1/16W
R407 ERJ3GEYJ102V Chip, 1kΩ1/16W
R408 ERJ3GEYJ473V Chip, 47kΩ1/16W
R409 ERJ3GEYJ102V Chip, 1kΩ1/16W
R410 ERJ3GEY0R00V Chip, 0Ω1/16W
R411 ERJ3GEYJ221V Chip, 220Ω1/16W
R413 ERJ6GEYJ182 Chip, 1.8kΩ1/10W
R414 ERJ8GEYJ561V Chip, 560Ω1/8W
R417 ERJ3GEYJ100V Chip, 10Ω1/16W
R600 ERJ8GX0R00V Chip, 0Ω1/8W
R601 ERJ3GEYJ432V Chip, 4.3kΩ1/16W
R602 ERJ3GEYJ432V Chip, 4.3kΩ1/16W
R603 ERJ6GEYJ103 Chip, 10kΩ1/10W
R604 ERJ6GEYJ103 Chip, 10kΩ1/10W
R605 ERJ3GEYJ102V Chip, 1kΩ1/16W
R607 ERJ3GEYJ333V Chip, 33kΩ1/16W
R608 ERJ3GEYJ822V Chip, 8.2kΩ1/16W
R609 ERJ3GEYJ473V Chip, 47kΩ1/16W
R611 ERJ3GEYJ683V Chip, 68kΩ1/16W
R612 ERJ3GEYJ153V Chip, 15kΩ1/16W
R613 ERJ3GEYJ103V Chip, 10kΩ1/16W
R614 ERJ3GEYJ103V Chip, 10kΩ1/16W
R615 ERJ6GEYJ103 Chip, 10kΩ1/10W
R616 ERJ3GEYJ684V Chip, 680kΩ1/16W
R617 ERJ3GEYJ103V Chip, 10kΩ1/16W
R618 ERJ3GEYJ223V Chip, 22kΩ1/16W
R619 ERJ3GEYJ473V Chip, 47kΩ1/16W
R620 ERJ3GEYJ103V Chip, 10kΩ1/16W
R621 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R622 ERJ6GEYJ473 Chip, 47kΩ1/10W
R624 ERJ3GEYJ104V Chip, 100kΩ1/16W
R625 ERJ3GEYJ473V Chip, 47kΩ1/16W
R626 ERJ6GEYJ102 Chip, 1kΩ1/10W
R627 ERJ3GEYJ103V Chip, 10kΩ1/16W
R628 ERJ3GEYJ103V Chip, 10kΩ1/16W
R629 ERJ8GEYJ104V Chip, 100kΩ1/8W
R631 ERJ6GEYJ821 Chip, 820Ω1/10W
R632 ERJ6GEYJ473 Chip, 47kΩ1/10W
R634 ERJ6GEYJ561 Chip, 560Ω1/10W
R638 ERJ3GEYJ102V Chip, 1kΩ1/16W
R639 ERJ3GEYJ102V Chip, 1kΩ1/16W
R640 ERJ6GEYJ561 Chip, 560Ω1/10W
R641 ERJ3GEYJ102V Chip, 1kΩ1/16W
R646 ERJ3GEYJ104V Chip, 100kΩ1/16W
R653 ERJ3GEYJ512V Chip, 5.1kΩ1/16W
R654 ERJ6GEYJ512V Chip, 5.1kΩ1/10W
R655 ERJ6GEYJ103 Chip, 10kΩ1/10W
R656 ERJ6GEYJ272 Chip, 2.7kΩ1/10W
R657 ERJ3GEYJ272V Chip, 2.7kΩ1/16W
Ref. No. Part No. Part Name & Description Remarks
R658 ERJ6GEYJ473 Chip, 47kΩ1/10W
R659 ERJ6GEYJ272 Chip, 2.7kΩ1/10W
R660 ERJ6GEYJ272 Chip, 2.7kΩ1/10W
R661 ERJ6GEYJ473 Chip, 47kΩ1/10W
R662 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R663 ERJ6GEYJ512V Chip, 5.1kΩ1/10W
R664 ERJ6GEYJ512V Chip, 5.1kΩ1/10W
R670 ERJ3GEYJ104V Chip, 100kΩ1/16W
R671 ERJ3GEYJ104V Chip, 100kΩ1/16W
R673 ERJ3GEYJ104V Chip, 100kΩ1/16W
R674 ERJ3GEYJ272V Chip, 2.7kΩ1/16W
R675 ERJ6GEYJ272 Chip, 2.7kΩ1/10W
R676 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R677 ERJ6GEYJ561 Chip, 560Ω1/10W
R678 ERJ3GEYJ104V Chip, 100kΩ1/16W
R680 ERJ6GEYJ271 Chip, 270Ω1/10W
R681 ERJ6GEYJ562 Chip, 5.6kΩ1/10W
R682 ERJ3GEYJ473V Chip, 47kΩ1/16W
R684 ERJ6GEYJ561 Chip, 560Ω1/10W
R685 ERJ3GEYJ561V Chip, 560Ω1/16W
R686 ERJ3GEYJ561V Chip, 560Ω1/16W
R687 ERJ6GEYJ561 Chip, 560Ω1/10W
R688 ERJ6GEYJ561 Chip, 560Ω1/10W
R689 ERJ3GEYJ561V Chip, 560Ω1/16W
R690 ERJ3GEYJ561V Chip, 560Ω1/16W
R701 ERJ6GEYJ102 Chip, 1kΩ1/10W
R702 ERJ3GEYJ224V Chip, 220kΩ1/16W
R703 ERJ6GEYJ473 Chip, 47kΩ1/10W
R704 ERJ8GEYJ4R7V Chip, 4.7Ω1/8W
R705 ERJ6GEYJ682 Chip, 6.8kΩ1/10W
R715 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R716 ERJ6GEYJ473 Chip, 47kΩ1/10W
R717 ERJ3GEYJ433V Chip, 43kΩ1/16W
R719 ERJ3GEYJ684V Chip, 680kΩ1/16W
R722 ERJ3GEYJ104V Chip, 100kΩ1/16W
R732 ERJ6ENF1802V Chip, 18kΩ1/10W
R733 ERJ6ENF1303V Chip, 130kΩ1/10W
R734 ERJ6ENF2201V Chip, 2.2kΩ1/10W
R755 ERJ6GEYJ102 Chip, 1kΩ1/10W
R760 ERJ6GEYJ152 Chip, 1.5kΩ1/10W
R761 ERDS1FJ3R9 Carbon, 3.9Ω1/2W
R771 D0GFR47JA016 Metal Film, 0.47Ω1/2W
R772 ERJ3GEYJ181V Chip, 180Ω1/16W
R773 ERJ6ENF7501V Chip, 7.5kΩ1/10W
R774 ERJ6ENF6340V Chip, 634Ω1/10W
R776 ERJ6GEYJ561 Chip, 560Ω1/10W
R778 ERJ8GEYJ1R0V Chip, 1Ω1/8W
R779 ERJ8GX0R00V Chip, 0Ω1/8W
R780 ERJ8GEYJ470V Chip, 47Ω1/8W
R790 ERJ3GEYJ223V Chip, 22kΩ1/16W
R791 ERJ6GEYJ223 Chip, 22kΩ1/10W
R795 ERJ6ENF1002 Chip, 10kΩ1/10W
R796 ERJ6ENF2703V Chip, 270kΩ1/10W
R797 ERJ6ENF2001V Chip, 2kΩ1/10W
CONNECTORs
CN201 K2KF29Z00040 Plug, 4P
CN253 K2KF29Z00036 Plug, 4P
CN301 K2KF29Z00039 Plug, 4P
CN351 K2KF29Z00033 Plug, 4P
CN361 YEAE0108TUCP Connector, 8P
CN371 YEAE0108TUCX Connector, 8P
CN601 K1MN16BA0111 Connector, 16P
CN651 K1KA18A00074 Connector, 18P
CN670 K1PQ07A00005 Connector, 7P
CN680 K1AA113B0002 Connector, 13P
CN701 K1FA116B0028 Connector, 16P
CN760 YEAE5339802 Connector, 2P
COILs
L50 G1C150K00011 Coil
L52 G1CR56JA0036 Coil
20
CQ-C7413U / CQ-C7113U
