Panasonic CQ-C9901N User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Tone Controls (Bass/Treble) Bass: ±12dB at 80Hz
Treble: ±12dB at 6kHz
Equalizer Center Frequency
(SQ) 62.5, 125, 250, 500, 1k, 2k, 4K, 8k, 16k (Hz, default)
Variable Range of Equalizer -12dB to 12dB (2dB step)
Current Consumption Less than 2.5A
(CD mode; 0.5W × 4-speaker)
Maximum Power Output 70W × 4 (at 4Ω)
Power Output 33W × 4 (DIN45 324,at 4Ω)
Speaker Impedance 4-8Ω
Pre-amp Output Voltage 5V (CD mode)
Subwoofer Output Voltage 5V
Pre-amp Output Impedance 60Ω
Subwoofer Output Impedance 60Ω
External Input Impedance 10kΩ(AUX1, CH/AUX2 IN)
External Input Sensitivity Max. 2V (AUX1, CH/AUX2 IN)
CD Player
Sampling Frequency 8 Times Oversampling
Pick-up Type Astigma 3-Beam
Light Source Semiconductor Laser
Wavelength 790 nm
© 2005 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-C9901N
CQ-C9701N
WMA MP3 CD Player/Receiver with 512
Color OEL Display
Frequency Response 20 Hz-20kHz (±1dB)
Signal to Noise Ratio 96dB (2V), 106 dB (5V)
Total Harmonic Distortion 0.01% (1kHz)
Wow and Flutter Below Measurable Limits
Channel Separation 85dB (2V)
FM Stereo Radio
Frequency Range 87.5MHz - 108MHz
Usable Sensitivity 8dB/µV (S/N 30dB)
Stereo Separation 40dB(at 1kHz)
AM (MW) Radio
Frequency Range 531kHz - 1,602kHz
Usable Sensitivity 25dB/µV (S/N 20dB)
AM (LW) Radio
Frequency Range 153kHz - 279kHz
Usable Sensitivity 30dB/µV (S/N 20dB)
Dimensions (W×H×D)** 178×50×155mm
Weight** 1.7kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
** Above specifications comply with EIA standards.
AUTOMOTIVE AFTERMARKET
Specifications*
ORDER NO. ACED050210C8

1 ABOUT LEAD FREE SOLDER (PbF) 3
2 FEATURES 3
3 REPLACEING THE FUSE 3
4 MAINTENANCE 3
5 NOTES 3
6 DIMENSIONS 3
7 LASER PRODUCTS 3
8 WIRING CONNECTION 4
9 BLOCK DIAGRAM 6
10 DISASSEMBLY INSTRUCTIONS 12
11 TERMINALS DESCRIPTION 15
12 PACKGE AND IC BLOCK DIAGRAM 21
13 REPLACEMENT PARTS LIST [CQ-C9901N] 25
14 EXPLODED VIEW (Unit) [CQ-C9901N] 34
15 REPLACEMENT PARTS LIST [CQ-C9701N] 35
16 EXPLODED VIEW (Unit) [CQ-C9701N] 44
17 CD PLAYER PARTS LIST 45
18 EXPLODED VIEW (CD PLAYER) 47
19 WIRING DIAGRAM 48
20 SCHEMATIC DIAGRAM-1 56
21 SCHEMATIC DIAGRAM-2 57
CONTENTS
Page Page
2
CQ-C9901N / CQ-C9701N

1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
• • •
• Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
• • •
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
• • •
• This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATURES
• • •
• MP3/WMA Playback from CD-R/RW
• • •
• Full Digital CD Receiver
• • •
• Radio DSP
• • •
• Fully Motorized Front Panel
• • •
• 256×64 pixel 512-color OEL display (CQ-C9901N only)
• • •
• CS Auto (Circle Surround Automotive)
• • •
• Six Preset Modes (FLAT, POP, ROCK, VOCAL, JAZZ,
CLUB)
• • •
• SQ9 (9 Bands Sound Quality)
• • •
• Full Lineup of optional parts
• • •
• Innovated APM (Auto Preset Memory) method
• • •
• CD Changer Control
• • •
• DVD Changer Control
• • •
• Differences Among 2 Models
3 REPLACEING THE FUSE
Use fuses of the same specified rating 15 amps. Using different
substitutes or fuses with higher ratings, or connecting the unit
directly without a fuse, could cause fire or damage to the stereo
unit.
4 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvent.
5 NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the
factory.
[CD DECK BLOCK]
This model has no servo alignment points because
microcomputer controls the servo circuit
6 DIMENSIONS
7 LASER PRODUCTS
3
CQ-C9901N / CQ-C9701N

8 WIRING CONNECTION
8.1. CQ-C9901N
4
CQ-C9901N / CQ-C9701N

8.2. CQ-C9701N
5
CQ-C9901N / CQ-C9701N

9 BLOCK DIAGRAM
9.1. Main-1/DAC Block (CQ-C9901N/C9701N)
6
CQ-C9901N / CQ-C9701N

9.2. Main-2/Connector/DC-DC Block (CQ-C9901N)
7
CQ-C9901N / CQ-C9701N

9.3. Main-2/Connector/DC-DC Block (CQ-C9701N)
8
CQ-C9901N / CQ-C9701N

9.4. Display Block (CQ-C9901N)
9
CQ-C9901N / CQ-C9701N

9.5. Display Block (CQ-C9701N)
10
CQ-C9901N / CQ-C9701N

9.6. CD Servo Block
11
CQ-C9901N / CQ-C9701N

10 DISASSEMBLY INSTRUCTIONS
10.1. How to Remove the Flexible PCB(AP2)
12
CQ-C9901N / CQ-C9701N

10.2. How to Install the Main P.C.B. of the Electric Display
13
CQ-C9901N / CQ-C9701N

14
CQ-C9901N / CQ-C9701N

11.1. Main Block [CQ-C9901N]
IC601 : C2CBKG000024
Pin
No. Port Description (I/O) (V)
FM AM CD
1 PANEL
OPEN PANEL OPEN detection I 5.2 5.2 5.2
2 PANEL
CLOSE PANEL CLOSE detection I 0 0 0
3 FR WP Write-protection of
FRAM O 4.8 4.8 4.8
4 BATT BATT detection I 5.0 5.0 5.0
5 ACC ACC detection I 5.0 5.0 5.0
6 I2C DATA DSP data I/O I/O 4.9 4.9 4.9
7 I2C CLK DSP clock output O 4.6 4.6 4.6
8 FR HOLD Holding signal to FRAM O 4.8 4.8 4.8
9 Vss GND power supply I 0 0 0
10 NC(LMTR
FR) No Connection - - - -
11 NC(LMTR S L
MONO) No Connection - - - -
12 NC(LMTR S
R CENT) No Connection - - - -
13 DSP INIT OK DSP initialization
notifying of timer end
input
I 0 0 0
14 NC(DE EMPH
I2S1) No Connection - - - -
15 CD RST CD deck reset output O 4.7 4.7 4.7
16 SUB SI Data transmission to
SUB u-com SO 0.8 0.8 0.8
17 NC No Connection - - - -
18 SUB SO Data reception from
SUB u-com SI 2.4 2.4 2.4
19 CH DATA Data reception from CD
changer SI 0 0 0
20 CH CLK Clock reception from
CD Changer SCK 0 0 0
21 Vdd 5V Power input I 4.8 4.8 4.8
22 UP SI FLASH W SI S0 0.2 4.8 4.8
23 CD SI CD DATA transmission SO 0.3 0.3 0.3
24 CD SCLK CD clock transmission SCK 4.6 4.6 4.6
25 CONDENSO
RCapacitor terminal for power supply - 3.1 3.1 3.1
26 CD SO CD DATA reception SI 0 0 1.4
27 CDC STB Changer stororb signal
input INT 5.2 5.2 5.2
28 CD IN DISC Holding detection O 5.0 5.0 5.0
29 DECK V
CONT DECK power supply control output O 4.8 4.8 4.8
30 CD FS CD deck frame sink
output O 3.5 3.5 3.5
31 DSP RST Reset output to DSP O 4.6 4.6 4.6
32 Avdd Positive power supply of
D/A converter I 5.1 5.1 5.1
33 AVREF Reference voltage for
D/A converter I 5.1 5.1 5.1
34 AVGND Standard GND for D/A
converter I 0 0 0
35 AVSS Grand potential for A/D
and D/A converter I 0 0 0
36 NC No Connection - - - -
37 INIT A Initialization A A/D 0 0 5.0
38 INIT B Initialization B A/D 0 0 0
39 NC No Connection - - - -
40 Vss GND, power supply I 0 0 0
41 CD MUTE CD deck mute detection I 0 0 5.0
42 CD SW1 CD deck DISC
detection switch 1 I 5.1 5.1 0
Pin
No. Port Description (I/O) (V)
FM AM CD
43 CD SW2 CD deck DISC
detection switch 2 I 0 0 5.0
44 NC No Connection - - - -
45 NC No Connection - - - -
46 NC No Connection - - - -
47 MOD0 Operating mode input 0 I 5.1 5.1 5.1
48 MOD1 Operating mode input 1 I 5.1 5.1 0
49 MOD2 Operating mode input 2 I 0 0 0
50 H STANDBY External standby input I 4.9 4.9 4.9
51 DC DC CNT DC/DC control for 60W O 0 0 0
52 FP MOTOR1 Front switching control 1 O 4.7 4.7 4.7
53 FP MOTOR2 Front switching control 2 O 4.7 4.7 4.7
54 V CNT1 Coordinated control 1 of
driving voltage of panel O 0 0 0
55 V CNT2(NC) No Connection - - - -
56 NC No Connection - - - -
57 EXT MUTE TEL/NAVI MUTE input I 5.1 5.1 5.1
58 AMP CONT External AMP control O 4.8 4.8 4.8
59 OEL VCNT OEL power supply
control terminal O 3.8 3.8 3.8
60 ANT CONT Motor antenna control O 4.8 4.8 0
61 DIM1 Dimmer control output 1 O 0 0 0
62 DIM2 Dimmer control output 2 O 0 0 0
63 CDC REM
OUT Remote control code output to Changer O 4.8 4.8 4.8
64 CDC SENS CDC 1/2 detection I 5.2 5.2 5.2
65 CDC 1/2(NC) No Connection - - - -
66 DCDC
FRQ20V Output the 70th DCDC FRQ and opposite. O 4.8 4.8 4.8
67 MAIN.W.U.R
EQ MAIN.WAKE.UP.REQ input I 5.0 5.0 5.0
68 NC No Connection - - - -
69 RDS CLK RDS Clock I 2.6 2.6 2.6
70 DCDC FRQ Frequency switch of
power circuit DC/DC O 0 0 0
71 RDS DATA RDS Data I 2.6 0 0
72 MAIN CONT MAIN power supply
control output O 4.8 4.8 4.8
73 INV CONT INV power supply
control output O 4.8 4.8 4.8
74 AF MUTE Tr-MUTE control O/I 0 5.0 5.0
75 RESET Reset input I 4.9 4.9 4.9
76 NC No Connection - - - -
77 NC No Connection - - - -
78 NC Ground I 0 0 0
79 Vss Ground I 0 0 0
80 X1 Crystal input I 2.0 2.0 2.0
81 X2 Crystal output O 2.5 2.5 2.5
82 Vdd Positive power supply I 5.0 5.0 5.0
83 P00 Pull-doÇón specification
port for writing I 0 0 0
84 P01 Pull-up specification
port for writing I 5.1 5.1 5.1
85 HB AM Analog mode of hybrid
IC switch control O 4.9 4.9 0
86 HB SLEEP SLEEP control of hybrid
IC O 4.9 4.9 4.9
87 N.C(HB
MUTE) No Connection - - - -
88 ILL SENS External dimmer control
input I 5.0 5.0 5.0
89 SUBM CNT 3.3V control for SUB
microcomputer O 4.9 4.9 4.9
90 FR DO(MI) FRAM communication
data entry I 0 0 0
91 FR DI(MO) FRAM communication
data output O 0 0 0
11 TERMINALS DESCRIPTION
15
CQ-C9901N / CQ-C9701N

Pin
No. Port Description (I/O) (V)
FM AM CD
92 FR CLK FRAM communication
CLK O 0 0 0
93 SUB W U
REQ SUB.WAKE.UP.REQ O 4.8 4.8 4.8
94 DISPM CNT Power supply control
output of display 5V O/I 0 0 0
95 HB CLK Clock output to DAC in
hybrid IC O 4.9 4.9 4.9
96 HB DATA Data I/O to DAC in
hybrid IC O 4.9 4.9 4.9
97 HB GAIN Hybrid IC GAIN change O 0 0 0
98 S LED Security LED control
output(CD ILL using
combinedly)
O 0 0 0
99 PANEL IN There is PANEL and it
detects it. I 0 0 0
100 FR CS Chip selection of FRAM O 4.9 4.9 4.9
11.2. Main Block [CQ-C9701N]
IC601 : C2CBKG000026
Pin
No. Port Description (I/O) (V)
FM AM CD
1 PANEL
OPEN PANEL OPEN detection I 5.2 5.2 5.2
2 PANEL
CLOSE PANEL CLOSE detection I 0 0 0
3 FR WP Write-protection of
FRAM O 4.8 4.8 4.8
4 BATT BATT detection I 5.0 5.0 5.0
5 ACC ACC detection I 5.0 5.0 5.0
6 I2C DATA DSP data I/O I/O 4.9 4.9 4.9
7 I2C CLK DSP clock output O 4.6 4.6 4.6
8 FR HOLD Holding signal to FRAM O 4.8 4.8 4.8
9 Vss GND, power supply I 0 0 0
10 NC(LMTR
FR) No Connection - - - -
11 NC(LMTR S L
MONO) No Connection - - - -
12 NC(LMTR S
R CENT) No Connection - - - -
13 DSP INIT OK DSP initialization
notifying of timer end
input
I 0 0 0
14 NC(DE EMPH
I2S1) No Connection - - - -
15 CD RST CD deck reset output O 4.7 4.7 4.7
16 SUB SI Data transmission to
SUB u-com SO 0.8 0.8 0.8
17 NC No Connection - - - -
18 SUB SO Data reception from
SUB u-com SI 2.4 2.4 2.4
19 CH DATA Data reception from CD
changer SI 0 0 0
20 CH CLK Clock reception from
CD Changer SCK 0 0 0
21 Vdd 5V Power input I 4.8 4.8 4.8
22 UP SI FLASH W SI S0 0.2 4.8 4.8
23 CD SI CD DATA transmission SO 0.3 0.3 0.3
24 CD SCLK CD clock transmission SCK 4.6 4.6 4.6
25 CONDENSO
RCapacitor terminal for power supply - 3.1 3.1 3.1
26 CD SO CD DATA reception SI 0 0 1.4
27 CDC STB Changer stororb signal
input INT 5.2 5.2 5.2
28 CD IN DISC Holding detection O 5.0 5.0 5.0
Pin
No. Port Description (I/O) (V)
FM AM CD
29 DECK V
CONT DECK power supply control output O 4.8 4.8 4.8
30 CD FS CD deck frame sink
output O 3.5 3.5 3.5
31 DSP RST Reset output to DSP O 4.6 4.6 4.6
32 Avdd Positive power supply of
D/A converter I 5.1 5.1 5.1
33 AVREF Reference voltage for
D/A converter I 5.1 5.1 5.1
34 AVGND Standard GND for D/A
converter I 0 0 0
35 AVSS Grand potential for A/D
and D/A converter I 0 0 0
36 NC No Connection - - - -
37 INIT A Initialization A A/D 0 0 5.0
38 INIT B Initialization B A/D 0 0 0
39 NC No Connection - - - -
40 Vss GND, power supply I 0 0 0
41 CD MUTE CD deck mute detection I 0 0 5.0
42 CD SW1 CD deck DISC
detection switch 1 I 5.1 5.1 0
43 CD SW2 CD deck DISC
detection switch 2 I 0 0 5.0
44 NC No Connection - - - -
45 NC No Connection - - - -
46 NC No Connection - - - -
47 MOD0 Operating mode input 0 I 5.1 5.1 5.1
48 MOD1 Operating mode input 1 I 5.1 5.1 0
49 MOD2 Operating mode input 2 I 0 0 0
50 H STANDBY External standby input I 4.9 4.9 4.9
51 DC DC CNT DC/DC control for 60W O 0 0 0
52 FP MOTOR1 Front switching control 1 O 4.7 4.7 4.7
53 FP MOTOR2 Front switching control 2 O 4.7 4.7 4.7
54 V CNT1 Coordinated control 1 of
driving voltage of panel O 0 0 0
55 V CNT2(NC) No Connection - - - -
56 NC No Connection - - - -
57 EXT MUTE TEL/NAVI MUTE input I 5.1 5.1 5.1
58 AMP CONT External AMP control O 4.8 4.8 4.8
59 NC No Connection - - - -
60 ANT CONT Motor antenna control O 4.8 4.8 0
61 DIM1 Dimmer control output 1 O 0 0 0
62 DIM2 Dimmer control output 2 O 0 0 0
63 CDC REM
OUT Remote control code output to Changer O 4.8 4.8 4.8
64 CDC SENS CDC 1/2 detection I 5.2 5.2 5.2
65 CDC 1/2(NC) No Connection - - - -
66 DCDC
FRQ20V Output the 70th DCDC FRQ and opposite. O 4.8 4.8 4.8
67 MAIN.W.U.R
EQ MAIN.WAKE.UP.REQ input I 5.0 5.0 5.0
68 NC No Connection - - - -
69 RDS CLK RDS Clock I 2.6 2.6 2.6
70 DCDC FRQ Frequency switch of
power circuit DC/DC O 0 0 0
71 RDS DATA RDS Data I 2.6 0 0
72 MAIN CONT MAIN power supply
control output O 4.8 4.8 4.8
73 INV CONT INV power supply
control output O 4.8 4.8 4.8
74 AF MUTE Tr-MUTE control O/I 0 5.0 5.0
75 RESET Reset input I 4.9 4.9 4.9
76 NC No Connection - - - -
77 NC No Connection - - - -
78 NC Ground I 0 0 0
79 Vss Ground I 0 0 0
80 X1 Crystal input I 2.0 2.0 2.0
81 X2 Crystal output O 2.5 2.5 2.5
82 Vdd Positive power supply I 5.0 5.0 5.0
16
CQ-C9901N / CQ-C9701N

Pin
No. Port Description (I/O) (V)
FM AM CD
83 P00 Pull-doÇón specification
port for writing I 0 0 0
84 P01 Pull-up specification
port for writing I 5.1 5.1 5.1
85 HB AM Analog mode of hybrid
IC switch control O 4.9 4.9 0
86 HB SLEEP SLEEP control of hybrid
IC O 4.9 4.9 4.9
87 N.C(HB
MUTE) No Connection - - - -
88 ILL SENS External dimmer control
input I 5.0 5.0 5.0
89 SUBM CNT 3.3V control for SUB
microcomputer O 4.9 4.9 4.9
90 FR DO FRAM communication
data entry I 0 0 0
91 FR DI FRAM communication
data output O 0 0 0
92 FR CLK FRAM communication
CLK O 0 0 0
93 SUB W U
REQ SUB.WAKE.UP.REQ O 4.8 4.8 4.8
94 DISPM CNT Power supply control
output of display 5V O/I 0 0 0
95 HB CLK Clock output to DAC in
hybrid IC O 4.9 4.9 4.9
96 HB DATA Data I/O to DAC in
hybrid IC O 4.9 4.9 4.9
97 HB GAIN Hybrid IC GAIN change O 0 0 0
98 S LED Security LED control
output(CD ILL using
combinedly)
O 0 0 0
99 PANEL IN There is PANEL and it
detects it. I 0 0 0
100 FR CS Chip selection of FRAM O 4.9 4.9 4.9
11.3. Display Block [CQ-C9901N]
IC900 : C2DBKJ000248
Pin
No. Port Description I/O (V)
1 D0 FLASH D0/OEL D0 I 0.7
2 D1 FLASH D1/OEL D1 I 1.3
3 D2 FLASH D2/OEL D2 I 1.3
4 D3 FLASH D3/OEL D3 I 1.6
5 D4 FLASH D4/OEL D4 I 1.7
6 D5 FLASH D5/OEL D5 I 1.6
7 D6 FLASH D6/OEL D6 I 1.4
8 D7 FLASH D7/OEL D7 I 1.3
9 D8 FLASH D8/OEL D8 I/O 1.4
10 D9 FLASH D9/OEL D9 I/O 1.3
11 D10 FLASH D10/OEL D10 I/O 1.6
12 D11 FLASH D11/OEL D11 I/O 1.6
13 D12 FLASH D12/OEL D12 I/O 1.6
14 D13 FLASH D13/OEL D13 I/O 1.5
15 D14 FLASH D14/OEL D14 I/O 1.6
16 D15 FLASH D15/OEL D15 I/O 1.5
17 N.C No Connection - -
18 VSS Ground - 0
19 VCC Positive power supply - 3.0
20 A1/OEL RS FLASH A0/OEL controller data
command distinction
H:Data, L:Command
O 0
21 A2 FLASH A1 O 0.6
22 A3 FLASH A2 O 0.1
23 A4 FLASH A3 O 0.6
24 A5 FLASH A4 O 0.6
25 A6 FLASH A5 O 0.8
26 A7 FLASH A6 O 0.9
27 A8 FLASH A7 O 0.6
28 A9 FLASH A8 O 0
29 A10 FLASH A9 O 0
30 A11 FLASH A10 O 0.8
31 A12 FLASH A11 O 1.2
32 A13 FLASH A12 O 1.2
33 A14 FLASH A13 O 0
34 A15 FLASH A14 O 0
35 A16 FLASH A15 O 1.0
36 A17 FLASH A16 O 0
37 A18 FLASH A17 O 0
38 A19 FLASH A18 O 0
39 A20 FLASH A19 O 0
40 VSS Ground - 0
41 FLASH
RY/BY Busy FLASH lady/input I -
42 NC No Connection - -
43 VSS Ground - 0
44 VCC Positive power supply - 3.2
45 OEL WAIT OEL controller WAIT signal input I 3.2
46 REMO 1 Remote control signal input I 3.3
47 OEL LPA OEL module Horizontal
Synchronizing signal input I 18.7
48 FLASH
OE/OEL RD FLASH output enable/OEL controller lead strobing output O 3.2
49 OEL WR OEL controller write strobing signal
output O 3.2
50 FLASH WE FLASH write enable signal output O 3.2
51 NMI Connecting to VDD I 3.2
52 MD2 Mode setting I 0
53 MD1 Mode setting I 0
54 MD0 Mode setting I 0
55 INITX System RESET signal input I 3.2
56 VCC Positive power supply - 3.3
57 X1 MAIN system clock output
(12.5MHz) O 1.5
58 X0 MAIN system clock input (12.5MHz) I 1.2
17
CQ-C9901N / CQ-C9701N

Pin
No. Port Description I/O (V)
59 VSS Ground - 0
60 X0A Ground I 0
61 X1A No Connection - -
62 OEL CLK OEL controller system clock output O -
63 FLASH
WP/ACC FLASH write- protection/Acseraration output O -
64 OEL RESET OEL controller reset control output O -
65 FLASH
RESET FLASH reset control output O -
66 A21 FLASH A20 O -
67 OEL OE OEL output enable output O -
68 OEL CS OEL controller chip selection output O -
69 VLCD
CONT VLCD 16V control O -
70 PN0 - - 0
71 PN2 - - 3.2
72 SW3.3
SENS OEL controller power supply supply detection input I 0
73 ICLK Anode output current adjustment
data transfer clock output O -
74 FLASH CE FLASH chip enable O -
75 IADJ Anode output current adjustment
data output O -
76 VSS Ground - 0
77 VCC Positive power supply supply - 3.2
78 A22 FLASH A21 O -
79 A23 FLASH A22 O -
80 LED ON P.LED control output O -
81 KI1(SOURC
E) Key return signal 1input INT/I 0
82 REMO INT Remote control signal interrupt
input INT 3.2
83 S W U REQ SUB-u-com wake up demand input INT 3.0
84 ROTARY.1 Rotary encoder signal input 1(VOL
UP) I 2.3
85 ROTARY.2 Rotary encoder signal input 2(VOL
DOWN) I 2.3
86 OEL YD OEL module Vertical Synchronizing
signal input I 3.1
87 MWU
REQ MAIN-u-com wake up demand output O 0
88 OEL INIT OEL controller interrupt signal input I 3.1
89 SUB SI MAIN-u-com communication data
entry I 0.2
90 SUB SO MAIN-u-com communication data
output O 2.5
91 KI2 Key return signal 2 input I 0
92 KI3 Key return signal 3 input I 0
93 KI4 Key return signal 4 input I 0
94 KI5 Key return signal 5 input I 0
95 VCC Positive power supply supply - 3.2
96 VSS Ground - 0
97 N.C No Connection - -
98 KS1 Key scann signal 1 output O 0
99 KS2 Key scann signal 2 output O 0
100 KS3 Key scann signal 3 output O -
101 Byt SWAP OEL controller byte SWAP control O -
102 UP SO External Flash rewriting input I -
103 UP SI External Flash rewriting output O -
104 UP CLK External Flash rewriting switch I 3.2
105 NC No Connection - -
106 NC No Connection - -
107 DAVS D/A converter grand potential - 0
108 DAVC Positive power supply supply for
D/A converter - 3.2
109 AVCC Positive power supply supply for
A/D converter - 3.2
110 AVRH Input of reference voltage of A/D
converter - 3.2
Pin
No. Port Description I/O (V)
111 AVSS/AVRL Ground potential of A/D converter - 0
112 VSS Ground - 0
113 INIT Initialization switch input (Not used) I 3.2
114 TH DETECT Temperature detection input I 1.2
115 NC Ground - 0
116 NC Ground - 0
117 NC Ground - 0
118 NC Ground - 0
119 NC Ground - 0
120 NC Ground - 0
11.4. Display Block [CQ-C9701N]
IC900 : C2DBKJ000247
Pin
No. Port Description I/O (V)
1 D0 FLASH D0 I 0.7
2 D1 FLASH D1 I 1.3
3 D2 FLASH D2 I 1.3
4 D3 FLASH D3 I 1.6
5 D4 FLASH D4 I 1.7
6 D5 FLASH D5 I 1.6
7 D6 FLASH D6 I 1.4
8 D7 FLASH D7 I 1.3
9 D8 FLASH D8 I/O 1.4
10 D9 FLASH D9 I/O 1.3
11 D10 FLASH D10 I/O 1.6
12 D11 FLASH D11 I/O 1.6
13 D12 FLASH D12 I/O 1.6
14 D13 FLASH D13 I/O 1.5
15 D14 FLASH D14 I/O 1.6
16 D15 FLASH D15 I/O 1.5
17 A0 LCD driver data command
distinction O 0.8
18 VSS Ground - 0
19 VCC Positive power supply - 3.0
20 A1 FLASH A0 O 0
21 A2 FLASH A1 O 0.6
22 A3 FLASH A2 O 0.1
23 A4 FLASH A3 O 0.6
24 A5 FLASH A4 O 0.6
25 A6 FLASH A5 O 0.8
26 A7 FLASH A6 O 0.9
27 A8 FLASH A7 O 0.6
28 A9 FLASH A8 O 0
29 A10 FLASH A9 O 0
30 A11 FLASH A10 O 0.8
31 A12 FLASH A11 O 1.2
32 A13 FLASH A12 O 1.2
33 A14 FLASH A13 O 0
34 A15 FLASH A14 O 0
35 A16 FLASH A15 O 1.0
36 A17 FLASH A16 O 0
37 A18 FLASH A17 O 0
38 A19 FLASH A18 O 0
39 A20 FLASH A19 O 0
40 VSS Ground - 0
41 NC No Connection - -
42 NC No Connection - -
43 VSS Ground - 0
44 VCC Positive power supply - 3.2
45 FLASH RY/BY Busy FLASH lady/input I 3.2
46 REMO 1 Remote control signal input I 3.3
47 A22 FLASH A21 I 18.7
18
CQ-C9901N / CQ-C9701N

Pin
No. Port Description I/O (V)
48 FLASH
OE/LCD RD FLASH output enable/LCD driver lead strobing output O 3.2
49 LCD WR LCD driver write strobing signal
output O 3.2
50 FLASH WE FLASH write enable signal output O 3.2
51 NC No Connection - -
52 MD2 Mode setting I 0
53 MD1 Mode setting I 0
54 MD0 Mode setting I 0
55 INITX System RESET signal input I 3.2
56 VCC Positive power supply - 3.3
57 X1 MAIN system clock output
(12.5MHz) O 1.5
58 X0 MAIN system clock input
(12.5MHz) I 1.2
59 VSS Ground - 0
60 X0A Ground I 0
61 X1A No Connection - -
62 NC No Connection - -
63 FLASH
WP/ACC FLASH write- protection/Acseraration output O -
64 LCD RESET LCD driver reset control output O -
65 FLASH
RESET FLASH reset control output O -
66 A21 FLASH A20 O -
67 NC No Connection - -
68 LCD CS LCD driver chip selection output O -
69 NC No Connection - -
70 PN0 - - 0
71 PN2 - - 3.2
72 NC No Connection - -
73 NC No Connection - -
74 FLASH CE FLASH chip enable O -
75 NC No Connection - -
76 VSS Ground - 0
77 VCC Positive power supply - 3.2
78 NC No Connection - -
79 NC No Connection - -
80 NC No Connection - -
81 KI1(SOURCE) Key return signal 1input INT/I 0
82 REMO INT Remote control signal interrupt
input INT 3.2
83 S W U REQ SUB-u-com wake up demand
input INT 3.0
84 ROTARY.1 Rotary encoder signal input 1(VOL
UP) I 2.3
85 ROTARY.2 Rotary encoder signal input 2(VOL
DOWN) I 2.3
86 VLCD CONT VLCD 16V control terminal I 3.1
87 M W U REQ MAIN-u-com wake up demand
output O 0
88 LED ON P.LED control output I 3.1
89 SUB SI MAIN-u-com communication data
input I 0.2
90 SUB SO MAIN-u-com communication data
output O 2.5
91 KI2 Key return signal 2 input I 0
92 KI3 Key return signal 3 input I 0
93 KI4 Key return signal 4 input I 0
94 KI5 Key return signal 5 input I 0
95 VCC Positive power supply - 3.2
96 VSS Ground - 0
97 KI6(NC) No Connection - -
98 KS1 Key scann signal 1 output O 0
99 KS2 Key scann signal 2 output O 0
100 KS3 Key scann signal 3 output O 0
101 NC No Connection - -
102 UP SO External Flash rewriting input I -
Pin
No. Port Description I/O (V)
103 UP SI External Flash rewriting output O -
104 UP CLK External Flash rewriting switch I 3.2
105 NC No Connection - -
106 NC No Connection - -
107 DAVS D/A converter grand potential - 0
108 DAVC Positive power supply supply for
D/A converter - 3.2
109 AVCC Positive power supply supply for
A/D converter - 3.2
110 AVRH Input of reference voltage of A/D
converter - 3.2
111 AVSS/AVRL Ground potential of A/D converter - 0
112 VSS Ground - 0
113 INIT Initialization switch input (Not
used) I 3.2
114 TH DETECT Temperature detection input I 1.2
115 NC Ground - 0
116 NC Ground - 0
117 NC Ground - 0
118 NC Ground - 0
119 NC Ground - 0
120 NC Ground - 0
11.5. CD Servo Block
IC401 : YESAM275
Pin
No. Port Descriptions I/O (V)
1 CVSS1 GND - 0
2 A22 TP407 - 0
3 CVSS2 GND - 0
4DVDD1 I/O system (3.3V) power supply - 3.1
5 A10 Address bus of FLASH ROM O 3.1
6HD7(NC) No Connection - -
7 A11 Address bus of FLASH ROM O 0
8 A12 O 3.1
9 A13 O 3.1
10 A14 O 3.1
11 A15 O 0
12 /CVDD1 CORE CPU system (1.6V) power
supply - 1.6
13 HAS(NC) No Connection - -
14 DVSS1 GND - 0
15 CVSS3 GND - 0
16 /CVDD2 I/O system (3.3V) power supply - 1.6
17 HCS(NC) No Connection - -
18 HR/W(NC) No Connection - -
19 READY - - 3.1
20 /PS FLASH ROM selection signal O 3.1
21 /DS(NC) No Connection - -
22 /IS(NC) No Connection - -
23 R/W Lead/light signal to FLASH ROM O 3.1
24 /MSTRB Memory access signal O 3.1
25 /IOSTRB(NC) No Connection - -
26 /MSC - - 3.1
27 MUTE Mute signal output (H:Mute on) O 0
28 /HOLDA(NC) No Connection - -
29 /IAQ(NC) No Connection - -
30 /HOLD - - 3.1
31 BIO SUBO input I 0
32 MP/MC Operation mode setting (external
pull-up) I 3.1
33 DVDD2 I/O system (3.3V) power supply - 3.1
34 CVSS4 GND - 0
35 BD R1 GND I 0
19
CQ-C9901N / CQ-C9701N

Pin
No. Port Descriptions I/O (V)
36 BFSR1 - - -
37 CVSS5 GND - 0
38 SW1 - - -
39 HCNTL0 No Connection - -
40 DVSS2 GND - 0
41 CLK C M AUDIO bit clock input I 1.6
42 SCK Clock input I 3.0
43 LRCK C M AUDIO L/R identifying signal input I 1.6
44 CDFS Serial frame sink signal input I 2.4
45 DATA CM AUDIO serial data input I 1.6
46 /HCNTL1(NC) No Connection - -
47 SI Serial data input I 0
48 CLK M C AUDIO bit clock output O 1.6
49 SCK Clock input I 3.0
50 CVSS6 GND - 0
51 /HINT(NC) No Connection - -
52 CVDD3 CORE CPU system (1.6V) power
supply - 1.6
53 LRCK M C AUDIO L/R identifying signal
output O 1.5
54 CDFS Serial frame sink signal input I 2.4
55 HRDY(NC) No Connection - -
56 DVDD3 I/O system (3.3V) power supply - 3.1
57 DVSS3 GND - 0
58 REST SW Mechanics deck REST SW input I 3.1
59 DATA M C AUDIO serial data output O 1.6
60 SO Serial data output O 1.1
61 /IACK(NC) No Connection - -
62 HBIL(NC) No Connection - -
63 /NMI - - 3.1
64 /INT0 - - 3.1
65 /INT1 - - 3.1
66 BLKCK Subcode block clock pulse input I 0
67 /INT3 - - 3.1
68 CV DD4 CORE CPU system (1.6V) power
supply - 1.6
69 MCLK Clock output (To Servo DSP) I 0
70 CVSS7 GND - 0
71 BCLKX1(NC) No Connection - -
72 DVSS4 GND - 0
73 BFSX1(NC) No Connection - -
74 BDX1 - O 3.1
75 DVDD4 I/O system (3.3V) power supply - 3.1
76 DVSS5 GND - 0
77 CLK MD1 Clock mode setting (L fixation) I 0
78 CLK MD2 Clock mode setting (H fixation) I 3.1
79 CLK MD3 Clock mode setting (L fixation) I 0
80 HPI16(NC) No Connection - -
81 MLD Command load signal output (To
Servo DSP) I 0.2
82 TOUT(NC) No Connection - -
83 EMU0 - - 3.1
84 EMU/OFF - - 3.1
85 TDO - - 0
86 TDI - - 3.1
87 /TRST - - 0
88 TCK - - 3.1
89 TMS - - 3.1
90 CVSS8 GND - 0
91 CVDD5 CORE CPU system (1.6V) power
supply - 1.6
92 HPIENA GND I 0
93 DVSS6 GND - 0
94 CLKOUT(NC) No Connection - -
95 CLKENA Oscillation output Cainabl signal O 0
96 X1 Crystal Connection O 0.7
97 X2/CLKIN Crystal Connection I 1.0
Pin
No. Port Descriptions I/O (V)
98 RS Reset signal input I 3.1
99 D0 Data base of FLASH ROM I/O 0
100 D1 I/O 0
101 D2 I/O 0
102 D3 I/O 0
103 D4 I/O 0
104 D5 I/O 0
105 A16 Address bus of FLASH ROM O 3.1
106 DVSS7 GND - 0
107 A17 Address bus of FLASH ROM O 3.1
108 A18 Address bus of FLASH ROM O 0
109 A19 TP415 O 0
110 A20 TP416 O 0
111 CVSS9 GND - 0
112 DVDD5 I/O system (3.3V) power supply - 3.1
113 D6 Data bus of FLASH ROM I/O 0
114 D7 I/O 0
115 D8 I/O 0
116 D9 I/O 0
117 D10 I/O 0
118 D11 Data bus of FLASH ROM I/O 0
119 D12 I/O 0
120 STAT Status signal input I 3.0
121 D13 Data path of FLASH ROM I/O 3.1
122 D14 I/O 0
123 D15 I/O 0
124 HD5(NC) No Connection - -
125 CVDD6 CORE CPU system (1.6V) power
supply - 1.6
126 CVSS10 GND - 0
127 /HDSI(NC) No Connection - -
128 DVSS8 GND - 0
129 /HDS2(NC) No Connection - -
130 DVDD6 I/O system (3.3V) power supply - 3.1
131 A0 Address bus of FLASH ROM O 3.1
132 A1 O 0
133 A2 O 0
134 A3 O 0
135 /RST Reset signal output(To Servo
DSP) O 3.1
136 A4 Address bus of FLASH ROM O 0
137 A5 O 3.1
138 A6 O 3.1
139 A7 O 0
140 A8 O 3.1
141 A9 O 3.1
142 CVDD7 CORE CPU system (1.6V) power
supply - 1.6
143 A12 TP406 - 0
144 DVSS9 GND - 0
20
CQ-C9901N / CQ-C9701N
