Panasonic CQC1103U - AUTO RADIO/CD DECK User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Tone Controls Bass ; ±12dB at 100Hz
Treble ; ±12dB at 10kHz
Current Consumption Less than 2.2A (CD play mode,
0.5W×4ch)
Maximum Power Output 50W×4ch (at 1kHz, Vol. Max.)
Suitable Speaker Impedance 4-8Ω
Pre-Amp Output Voltage 2.5V (CD play mode; 1kHz, 0dB)
Output Impedance 200Ω
FM Stereo Radio
Frequency Range 87.9 - 107.9MHz
Usable Sensitivity 11.0dBf (1.25µV, 75Ω)
AM Radio
© 2005 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-C1103U
Removable Front Panel CD Player /
Receiver
Frequency Range 530 - 1,710kHz
Usable Sensitivity 28dB/µV (25µV, S/N 20dB)
CD Player
Sampling Frequency 8 times oversampling
Pick-Up Type Astigma 3-beam
Light Source Semiconductor Laser
Wavelength 780nm
Frequency Response 20Hz to 20,000Hz (±1dB)
Signal to Noise Ratio 96dB
Dimensions** 178×50×155mm
Weight** 1.4kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
AUTOMOTIVE AFTERMARKET
Specifications*
Order No. ACED051204C7
C4

1 ABOUT LEAD FREE SOLDER (PbF) 2
2 FEATUERS 2
3 LASER PRODUCTS 2
4 REPLACEING THE FUSE 2
5 MAINTENANCE 3
6 NOTES 3
7 DIMENSIONS 3
8 WIRING CONNECTION 4
9 BLOCK DIAGRAM 5
10 TERMINALS DESCRIPTION 6
1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
• • •
• Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
• • •
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
• • •
• This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATUERS
• • •
• 18-FM, 6-AM presets with preset scan
• • •
• Digital servo for reliable CD playback.
• • •
• Removable face plate.
11 PACKAGE AND IC BLOCK DIAGRAM 8
12 REPLACEMENT PARTS LIST 12
13 EXPLODED VIEW (Unit) 17
14 CD PLAYER MECHANICAL PARTS LIST 18
15 EXPLODED VIEW (CD Deck) 19
16 PACKING PARTS LIST 20
17 WIRING DIAGRAM 21
18 SCHEMATIC DIAGRAM-1 25
19 SCHEMATIC DIAGRAM-2 27
20 SCHEMATIC DIAGRAM for printing with A4 size 29
3 LASER PRODUCTS
4 REPLACEING THE FUSE
Use fuses of the same specified rating (15A). Using different
substitutes or fuses with higher ratings, or connecting the
product directly without a fuse, could cause fire or damage to
the stereo unit.
CONTENTS
Page Page
2
CQ-C1103U

5 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a dry, a soft cloth for routine
exterior cleaning. Never use benzine, thinner or other solvents.
6 NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the
factory.
[CD DECK BLOCK]
This model has no servo alignment points because
microcomputer controls the servo circuit.
7 DIMENSIONS
3
CQ-C1103U

8 WIRING CONNECTION
4
CQ-C1103U

9 BLOCK DIAGRAM
5
CQ-C1103U

IC601 : LC7237819D07
Ref.
No. Part No. Part Name & Description I/O(V) FM(V )AM(V )CD(V )
1XIN 4. 5 MHz X’tal and
Connection I2.52 2.53 2.52
2TEST2 GND connection I 0 0 0
3VREG Bypass condenser
connected. O2.9 2.9 2.93
4VSSCPU GND connection - 0 0 0
5CDC_DAT
ACD changer data I 0 0 0
6N.C. None - - - -
7CDC_CLK CD changer clock I 0 0 0
8CDC_REM
_OUT CD changer Remote out O 0 0 0
9LCD_DO LCD data output I5,22 5,22 5.18
10 LCD_DI LCD data input O 0 0 0
11 LCD_CLK LCD clock O5.17 5.19 5.15
12 LCD_CE LCD chip enable output O0.1 0.14 0.12
13 CD_DO CD data output I5.34 5.35 5.12
14 CD_DI CD data input O 0 0 5.2
15 CD_CLK CD clock O5.19 5.21 5.17
16 CD_CE CD chip enable O 0 0 0.25
17 CD_LM+ CD eject O 0 0 0
18 CD_LM- CD loading O 0 0 0
19 CD_S/L CD 24PIN connection O 0 0 5.21
20 CD_WRQ CD WRQ connection I5.34 5.35 4.26
21 CD_INSW
1CD insert SW input I0.1 00.1
22 CD_SW2 CD MECHA SW2 I5.17 5.21 0.1
23 CD_LIMI
T_SW CD limit SW I 0 0 5.18
24 CD_DRF CD DRF I 0 0 5.33
25 CD_RST CD reset O5.19 5.22 5.21
26 CD_MUTE CD mute O 0 0 5.2
27 N.C. None - - - -
28 N.C. None - - - -
29 PANEL Panel detect I5.2 5.23 5.2
30 N.C. GND connection I 0 0 0
31 N.C. GND connection I 0 0 0
32 N.C. GND connection I 0 0 0
33 N.C. None - - - -
34 N.C. None - - - -
35 N.C. None - - - -
36 N.C. None - - - -
37 N.C. None - - - -
38 N.C. None - - - -
39 VDDPORT Power supply of PORT -5.19 5.22 5.21
40 VSSPORT GND of PORT - 0 0 0
41 N.C. None - - - -
42 N.C. None - - - -
43 N.C. None - - - -
44 N.C. None - - - -
45 N.C. None - - - -
46 N.C. None - - - -
47 N.C. None - - - -
48 N.C. None - - - -
49 PWR_CNT Power control O5.12 5.2 5.19
50 AMP_CNT Amp stand-by O5.12 5.2 5.19
51 AMP_MUT
EAmp mute O5.19 5.21 5.21
52 N.C. None - - - -
53 SSC Tuner search sensitivity
change O 0 0 0
54 AF_MUTE AF mute O5.19 5.21 5.21
55 I2C_DAT
AElectronic VOL data O5.2 5.21 5.21
56 I2C_CLK Electronic VOL clock O5.2 5.21 5.21
57 ANT_CNT Motor antena control O5.19 5.21 0
58 POWER_L
ED Power LED O0.15 0.15 0.12
59 N.C. None - - - -
Ref.
No. Part No. Part Name & Description I/O(V) FM(V )AM(V )CD(V )
60 N.C. (
BZ_OUT
)
None - - - -
61 N.C. None - - - -
62 N.C. None - - - -
63 N.C. None - - - -
64 N.C. None - - - -
65 N.C. None - - - -
66 TEL_MUT
EExternal MUTE input I5.36 5.35 5.33
67 BATT Battery detection I5.36 5.35 5.33
68 MODE_B ROTARY B input I5.17 5.18 0
69 N.C.(RD
S_CLK) None - - - -
70 REM_IN Remocon data input I 0 0 0
71 MODE_A ROTARY A input I5.17 5.13 5.16
72 CDC_STB CD changer strobe input I 0 0 0
73 NC None - - - -
74 MONO Compulsion MONO ON O 0 0 0
75 AM_MODE AM change O8.21 0.13 8.23
76 FM_MODE FM change O0.13 8.2 8.23
77 N.C. GND connection I 0 0 0
78 INIT_C Initial value C I 0 0 0
79 INIT_B Initial value B I5.16 5.19 5.19
80 INIT_A Initial value A I 0 0 0
81 VSS GND connection - 0 0 0
82 N.C.(RD
S_DATA) None - - - -
83 ST FM stereo input I5.34 5.2 5.4
84 SD_FM/A
MSignal detection I3.12 3.43 0
85 N.C. GND connection I 0 0 0
86 RESET Reset Input I5.2(
PWR
OFF)
6.4(
PWR
OFF)
5.2(
EJEC
T)
87 ACC Power supply I5.42 5.42 5.42
88 N.C. GND connection I 0 0 0
89 N.C. GND connection I 0 0 0
90 FM/AM_I
FC FM/AM IF input I1.42 1.42 0
91 N.C. GND connection I 0 0 0
92 SUBPD None O 2 2.02 0
93 VDDPLL Power supply of PLL -5.23 5.22 5.2
94 N.C. GND connection I 0 0 0
95 OSC_FM/
AM FM/AM osc input I1.39 1.26 0
96 VSSPLL GND connection - 0 0 0
97 N.C. None - - - -
98 EO1 PLL phase comparison
error output O 2 2.02 0
99 TEST1 GND connection I 0 0 0
100 XOUT 4. 5 MHz X’tal and
Connection O2.62 2.63 2.62
Note 1 :
Voltage measuerments are with respect to ground, with a
voltmeter (internal resistance : 10M ohms).
10.2. Display Block
IC901 : YEAMLC75853NW
Pin No. Port Descriptions I/O
(V) (V)
1-4 NC No connection - -
5-31 SEG5-31 LCD segment O2.5
32-40 NC No connection - -
41-43 COM1-3 LCD common O2.5
44-49 KS1-6 Key data output O0.9
10 TERMINALS DESCRIPTION
10.1. Main Block
6
CQ-C1103U

Pin No. Port Descriptions I/O
(V) (V)
50-54 KI1-5 Key data input I 0
55 TEST (Connecting to ground) - 0
56 VDD +5V power supply -5.1
57 VDD1 Ground through capacitor -3.3
58 VDD2 Ground through capacitor -1.7
59 Vss Ground - 0
60 OSC CR oscillator -3.9
61 DO Key data output O4.4
62 CE Chip enable I 0
63 CLK LCD clock I 0
64 DI LCD data input I 0
7
CQ-C1103U

11.1. Main Block
11 PACKAGE AND IC BLOCK DIAGRAM
P50:J3CCBB000005
IC270 : C1EA00000041
8
CQ-C1103U

IC1 : C1BB00001089
9
CQ-C1103U

IC300 : C1BB00000543
IC2 : C1BB00001088
10
CQ-C1103U
