Service Manual
TOP NEXT
ORDER No. ACED020270C8
AUTOMOTIVE CONSUMER ELECTRONICS
●CQ-DFX802N
CD Player/ Receiver with CD Changer Control
Specification*
General
Power Supply DC 12V (10.8V - 16V),
Test Voltage 14.4V
Negative Ground
Current Consumption Less than 2.5A (CD play mode ; 0.5W×4)
Maximum Power Output 50W×4ch (at 4Ω)
Speaker Impedance 4-8Ω
Extend Input Impedance 10kΩ(AUX IN)
Extend Input Sensitivity Max. 2V (AUX IN)
Power Output 22W×4 (DIN45 324, at 4Ω)
file:///C|/Documents and Settings/eDOK/Рабочий стол/CQ-DFX802N.htm (1 of 3)02.10.2005 1:35:29

cqdfx802n.html
View)
14.4 CD Servo Block (Top
View)
14.5 CD Servo Block
(Bottom View)
14.6 Sub. Block
15 SCHEMATIC
DIAGRAM
15.1 Main Block
15.2 Display Block
15.3 CD Servo Block
15.4 Sub. Block
16 BLOCK DIAGRAM
16.1 Main Block
16.2 Display Block
16.3 CD Servo Block
17 SCHEMATIC
DIAGRAM for Printing with
A4 Size
17.1 Main Block (Left Side)
17.2 Main Block (Right
Side)
17.3 Display Block (Left
Side)
17.4 Display Block (Right
Side)
17.5 CD Servo Block (Left
Side)
17.6 CD Servo Block (Right
Side)
Pre-Amp Output Voltage 5.0V (CD mode)
Sub-woofer output voltage 5.0V
Pre-Amp Output Impedance 60Ω
Sub-woofer Output Impedance 60Ω
FM Stereo Radio
Frequency Range 87.5 - 108.0MHz
Usable Sensitivity 7dB/μV (S/N 30dB)
MW Radio
Frequency Range 531 - 1,602kHz
Usable Sensitivity 29dB/μV (S/N 20dB)
LW Radio
Frequency Range 153 - 279kHz
Usable Sensitivity 34dB/μV (S/N 20dB)
CD Player
Sampling Frequency 8 times oversampling
Pick-Up Type Astigma 3-beam
Light Source Semiconductor Laser
Wave Length 780nm
Frequency Response 20Hz to 20,000Hz (±1dB)
Signal to Noise Ratio 95dB
Wow and Flutter Below measurable limits
Dimensions** 178×50×155mm
Weight** 1.7kg
* Specifications and the design are subject to possible modification without notice due to improvements.
** Dimensions and Weight shown are approximate.
© 2002 Matsushita Communication Industrial Co., Ltd. All rights reserved. Unauthorized copying and distribution is a
file:///C|/Documents and Settings/eDOK/Рабочий стол/CQ-DFX802N.htm (2 of 3)02.10.2005 1:35:29

cqdfx802n.html
violation of law.
TOP NEXT
file:///C|/Documents and Settings/eDOK/Рабочий стол/CQ-DFX802N.htm (3 of 3)02.10.2005 1:35:29

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/cqdfx802n.html
Table Of Contents
COVER
1 LASER PRODUCTS
2 FEATUERS
3 REPLACING THE FUSE
4 MAINTENANCE
5 NOTES
6 DIMENSIONS
7 WIRING CONNECTION
8 TERMINALS DESCRIPTION
8.1 Main Block
8.2 Display Block
8.3 CD Servo Block
9 PACKAGE AND IC BLOCK DIAGRAM
9.1 Main Block
9.2 Display Block
9.3 CD Servo Block
10 REPLACEMENT PARTS LIST
11 EXPLODED VIEW (Unit)
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/cqdfx802n.html (1 of 3)02.10.2005 1:35:46

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/cqdfx802n.html
12 CD PLAYER PARTS
13 EXPLODED VIEW (CD Deck)
14 WIRING DIAGRAM
14.1 Display Block
14.2 Main Block (Top View)
14.3 Main Block (Bottom View)
14.4 CD Servo Block (Top View)
14.5 CD Servo Block (Bottom View)
14.6 Sub. Block
15 SCHEMATIC DIAGRAM
15.1 Main Block
15.2 Display Block
15.3 CD Servo Block
15.4 Sub. Block
16 BLOCK DIAGRAM
16.1 Main Block
16.2 Display Block
16.3 CD Servo Block
17 SCHEMATIC DIAGRAM for Printing with A4 Size
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/cqdfx802n.html (2 of 3)02.10.2005 1:35:46

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/cqdfx802n.html
17.1 Main Block (Left Side)
17.2 Main Block (Right Side)
17.3 Display Block (Left Side)
17.4 Display Block (Right Side)
17.5 CD Servo Block (Left Side)
17.6 CD Servo Block (Right Side)
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/cqdfx802n.html (3 of 3)02.10.2005 1:35:46

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0000000000.html
Service Manual
TOP NEXT
ORDER No. ACED020270C8
AUTOMOTIVE CONSUMER ELECTRONICS
●CQ-DFX802N
CD Player/ Receiver with CD Changer Control
Specification*
General
Power Supply DC 12V (10.8V - 16V),
Test Voltage 14.4V
Negative Ground
Current Consumption Less than 2.5A (CD play mode ; 0.5W×4)
Maximum Power Output 50W×4ch (at 4Ω)
Speaker Impedance 4-8Ω
Extend Input Impedance 10kΩ(AUX IN)
Extend Input Sensitivity Max. 2V (AUX IN)
Power Output 22W×4 (DIN45 324, at 4Ω)
Pre-Amp Output Voltage 5.0V (CD mode)
Sub-woofer output voltage 5.0V
Pre-Amp Output Impedance 60Ω
Sub-woofer Output Impedance 60Ω
FM Stereo Radio
Frequency Range 87.5 - 108.0MHz
Usable Sensitivity 7dB/μV (S/N 30dB)
MW Radio
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0000000000.html (1 of 2)02.10.2005 1:35:52

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0000000000.html
Frequency Range 531 - 1,602kHz
Usable Sensitivity 29dB/μV (S/N 20dB)
LW Radio
Frequency Range 153 - 279kHz
Usable Sensitivity 34dB/μV (S/N 20dB)
CD Player
Sampling Frequency 8 times oversampling
Pick-Up Type Astigma 3-beam
Light Source Semiconductor Laser
Wave Length 780nm
Frequency Response 20Hz to 20,000Hz (±1dB)
Signal to Noise Ratio 95dB
Wow and Flutter Below measurable limits
Dimensions** 178×50×155mm
Weight** 1.7kg
* Specifications and the design are subject to possible modification without notice due to improvements.
** Dimensions and Weight shown are approximate.
© 2002 Matsushita Communication Industrial Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation
of law.
TOP NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0000000000.html (2 of 2)02.10.2005 1:35:52

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0100000000x.html
1 LASER PRODUCTS
TOP PREVIOUS NEXT
TOP PREVIOUS NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0100000000x.html02.10.2005 1:36:07

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0200000000x.html
2 FEATUERS
TOP PREVIOUS NEXT
●Removable face plate security.
●Digital servo for reliable playback.
●PLL (Phase Locked Loop) synthesized tuning.
●18-FM, 6-AM presets with preset scan.
TOP PREVIOUS NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0200000000x.html02.10.2005 1:36:12

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0300000000x.html
3 REPLACING THE FUSE
TOP PREVIOUS NEXT
Use fuses of the same specified rating (15A). Using different substitutes or fuses with higher ratings, or
connecting the unit directly without a fuse, could cause fire or damage to the stereo unit.
TOP PREVIOUS NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0300000000x.html02.10.2005 1:36:18

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0400000000x.html
4 MAINTENANCE
TOP PREVIOUS NEXT
Use a dry, soft cloth to wipe. Never use solvents such as benzine, thinner as they may mar the surface of
the unit.
TOP PREVIOUS NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0400000000x.html02.10.2005 1:36:22

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0500000000x.html
5 NOTES
TOP PREVIOUS NEXT
[RADIO BLOCK]
Do not align the AM/FM package block. When the package block is necessary, it will be supplied
already aligned at the factory.
[CD DECK BLOCK]
This model has no servo alignment points because microcomputer controls the servo circuit.
TOP PREVIOUS NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0500000000x.html02.10.2005 1:36:27

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0600000000x.html
6 DIMENSIONS
TOP PREVIOUS NEXT
TOP PREVIOUS NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0600000000x.html02.10.2005 1:36:36

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0700000000x.html
7 WIRING CONNECTION
TOP PREVIOUS NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0700000000x.html (1 of 2)02.10.2005 1:36:43

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0700000000x.html
TOP PREVIOUS NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0700000000x.html (2 of 2)02.10.2005 1:36:43

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0800000000x.html
8 TERMINALS DESCRIPTION
TOP PREVIOUS NEXT
8.1 Main Block
8.2 Display Block
8.3 CD Servo Block
TOP PREVIOUS NEXT
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0800000000x.html02.10.2005 1:36:52

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0801000000.html
8.1 Main Block
TOP PREVIOUS NEXT
IC601 C2DBKJ000087
Pin No. Port Descriptions I/O
(V) FM (V) AM (V) CD (V)
1 NC No connection - - - -
2 CH CLK Changer data clock I 0 0 0
3 CD.SO CD Deck serial data I 0 1.0 3.6
4 CD.SI CD Deck serial data O 0 0 1.4
5 CD.SCK CD Deck data clock O 0 5.0 5.0
6 EVDD +5V power supply - 5.0 5.0 5.0
7 EVSS Ground - 0 0 0
8 CD.ON CD Deck ON signal O 5.0 5.0 5.0
9 CD.RESET CD Deck reset O 5.0 5.0 5.0
10 RM.DATA Remote controller data I 4.2 4.2 0
11 RM.CONT RM.DATA control O 0 0 0
12 LCD.DO LCD data I 4.9 4.9 4.9
13 LCD.DI LCD data O 0 0 0
14 LCD.CLK LCD data shift clock O 4.9 4.9 4.9
15 LCD.CE LCD driver selection O 0 0 0.2
16 CD.MUTE CD mute signal I 0 1.0 0
17 AF.MUTE Audio mute O 0 5.0 5.0
18 VPP (Registor pull down) 0 0 0
19 NC No connection - - - -
20 NC No connection - - - -
21 MAIN.CNT Main power control O 5.0 5.0 5.0
22 SHUT.CONT Shutter control O 5.0 5.0 5.0
23 SHUT.HAFF Shutter penetration efficiency cont. O 0 0 0
24 BEEP Beep output O 0 0 0
25 CD.PW.CNT CD power control O 5.0 5.0 5.0
26 EJECT.ILL Eject LED control O 5.0 5.0 0
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0801000000.html (1 of 4)02.10.2005 1:36:58

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0801000000.html
27 S.LED S LED control O 5.0 5.0 5.0
28 NC No connection - - - -
29 NC No connection - - - -
30 NC No connection - - - -
31 /RESET System reset input I 4.8 4.8 4.8
32 SUB XT1 (Connecting to ground) - 0 0 0
33 SUB XT2 Not use - - - -
34 REGC Capacitor terminal for Reg. stabilization - 3.4 3.4 3.4
35 X2 Crystal oscillator - 1.5 1.5 1.5
36 X1 Crystal oscollator - 1.3 1.3 1.3
37 VSS Ground - 0 0 0
38 VDD +5V power supply - 4.9 4.9 4.9
39 CLK OUT Not used - - - -
40 NC No connection - - - -
41 NC No connection - - - -
42 NC No connection - - - -
43 NC No connection - - - -
44 NC No connection - - - -
45 NC No connection - - - -
46 NC No connection - - - -
47 NC No connection - - - -
48 RDS.DATA RDS data I 2.8 0 0
49 PLL CE PLL chip enable O 0 0 0
50 SDA Volume control IC data O 1.4 5.0 1.2
51 SCL Volume control IC clock O 1.2 5.0 5.0
52 SUB.W-F.CNT Sub. woofer control O 0 0 0
53 SPE SEL Spectrum Analyzer IC select O 0 0 0
54 SPE C Spectrum Analyzer IC control O 5.0 5.0 5.0
55 BVDD +5V power supply (for bus I/F) - 5.0 5.0 5.0
56 BVSS Ground (for bus I/F) - 0 0 0
57 SPE.B Spectrum Analyzer IC control O - - -
58 SPE.A Spectrum Analyzer IC control O - - -
59 NC No connection - - - -
60 NC No connection - - - -
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0801000000.html (2 of 4)02.10.2005 1:36:58

http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0801000000.html
61 NC No connection - - - -
62 NC No connection - - - -
63 DIM1 Dimmer control 1 O 0 0 0
64 DIM2 Dimmer control 2 O 0 0 0
65 INV.CNT Display back light control O 5.0 5.0 0
66 DC/DC CNT Not used - - - -
67 CD.CH 1/2 Changer 1/2 select O 0 0 0
68 ANT.CNT Antenna control O 0 5.0 0
69 AMP.CNT Power IC standby control O 0 5.0 5.0
70 AMP.MUTE Power IC mute control O 0 5.0 5.0
71 AVDD +5V power supply (for A/D converter) - 5.0 5.0 5.0
72 AVSS Ground (for A/D converter) - 0 0 0
73 AVREF Reference voltage (for A/D converter) I 5.0 5.0 5.0
74 ST FM stereo signal I 0 4.9 4.9
75 SD Tuner receiving signal strength I 0 0.8 0
76 INIT.A Initialize input A I 0 0 0
77 INIT.B Initialize input B I 0 0 0
78 INIT.C Initialize input C I 0 0 0
79 A.IN Spectrum Analyzer level input I 0 0 0
80 EXT.MUTE External mute I 4.9 4.9 4.9
81 NC (Connecting to ground) - 0 0 0
82 PANEL.OP/CL Front panel open/close signal I 0 0 5.2
83 EJECT.KEY CD Eject switch signal I 5.3 5.3 5.2
84 PNL.SENS Front panel open/close sensor I 5.2 5.2 5.2
85 TWIN CH.SENS Twin Changer Adaptor sensor I 4.9 4.9 4.9
86 CH REM.DATA Changer remote data O 5.0 5.0 5.0
87 CH.STRB Changer control strobe signal I 0 0 0
88 RDS.CLK RDS clock I 2.5 0 0
89 BATT.SENS Battery voltage sensor I 5.0 5.0 5.0
90 ACC.SENS ACC voltage sensor I 5.0 5.0 5.0
91 NC No connection - - - -
92 NC No connection - - - -
93 EP.CS Not used - - - -
94 PLL.DO (MI) PLL data I 4.9 4.9 4.9
http://217.7.21.70/viewing/EUOT/CQ-DFX802N/SVC/s0801000000.html (3 of 4)02.10.2005 1:36:58
