Panasonic KX-TCD300FXS User manual

©2004 Panasonic Communications Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
KX-TCD300FXS
KX-TCD300FXT
KX-TCA130FXS
KX-TCA130FXT
Digital Cordless Phone
Silver Version
Titanium Black Version
(for Central Europe)
Telephone Equipment
ORDER NO. KM40411554C2

1 ABOUT LEAD FREE SOLDER (PbF: Pb free) 4
1.1. Suggested PbF Solder 4
1.2. How to recognize that Pb Free solder is used 5
2 FOR SERVICE TECHNICIANS 7
3 CAUTION 7
4 BATTERY 8
4.1. Battery Installation 8
4.2. Battery Charge 8
4.3. Battery Life 9
4.4. Battery Replacement 9
5 LOCATION OF CONTROLS 10
5.1. Base Unit 10
5.2. Handset 10
6 SETTINGS 12
6.1. Connections 12
6.2. Guide to Settings 14
6.3. Ringer Volume 15
6.4. Night Mode 16
6.5. PIN Code 17
6.6. Reset 18
6.7. Key Lock 20
6.8. [R] Button ( to use the recall feature) 20
6.9. Pause Button for PBX/Long Distance Service Users 20
6.10. Setting Call Restriction 21
6.11. Turning Call BAR On/Off (Call Prohibition) 21
6.12. Changing the Display Language 22
6.13. Setting Dialling Mode (Tone/Pulse) 22
6.14. Changing the Recall Time 22
7 DISPLAY 23
7.1. Display Icons 23
7.2. Menu Icons 23
7.3. Caller ID Display 23
7.4. Screen Saver Mode 24
8 OPERATIONS 25
8.1. Turning the Power On/Off 25
8.2. Setting the Date and Time 25
8.3. Redialling 25
8.4. Phonebook 26
8.5. Registering a Handset to a Base Unit 30
8.6. Selecting a Base Unit 31
9 SMS (Short Message Service) 32
9.1. Writing and Sending a New Message 32
9.2. Available Character Entries for SMS 33
9.3. Sending a Saved Message 34
9.4. Editing and Sending a Saved Message 34
9.5. Erasing Saved Messages 34
9.6. Receiving a Message 35
9.7. Reading a Received Message 35
9.8. Replying to a Message 35
9.9. Erasing Received Messages 35
9.10. Changing SMS Message Centre Numbers 36
9.11. Turning SMS On/Off 36
10 TROUBLESHOOTING 37
11 DISASSEMBLY INSTRUCTIONS 40
11.1. Base Unit 40
11.2. Handset 41
11.3. Charger Unit 42
12 TROUBLESHOOTING FLOWCHART 43
12.1. Check Power 44
12.2. Check Battery Charge 45
12.3. Check Link 46
12.4. Check Handset Transmission 50
12.5. Check Handset Reception 50
12.6. Check Caller ID 50
12.7. Bell Reception 51
13 TROUBLESHOOTING BY SYMPTOM (BASE UNIT AND
CHARGER UNIT) 52
13.1. Check Point (Base Unit) 52
13.2. The Setting Method of JIG (Base Unit) 56
13.3. Adjustment Standard (Base Unit) 57
13.4. Check Point (Charger Unit) 58
13.5. Adjustment Standard (Charger Unit) 58
14 TROUBLESHOOTING BY SYMPTOM (HANDSET) 59
14.1. Check Point (Handset) 59
Note:
Because CONTENTS 4 to 10 are the extracts from the Operating Instructions of this model, they are subject to change without
notice. Please refer to the original Operating Instructions for further information.
CONTENTS
Page Page
2
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

14.2. Troubleshooting for Speakerphone 62
14.3. The Setting Method of JIG (Handset) 63
14.4. Adjustment Standard (Handset) 64
15 THINGS TO DO AFTER REPLACING IC 65
15.1. Base Unit 65
15.2. Handset 65
16 RF SPECIFICATION 66
16.1. Base Unit 66
16.2. Handset 66
17 HOW TO CHECK THE HANDSET SPEAKER OR RECEIVER 67
18 FREQUENCY TABLE (MHz) 67
19 BLOCK DIAGRAM (BASE UNIT) 68
20 CIRCUIT OPERATION (BASE UNIT) 69
20.1. Outline 69
20.2. Power Supply Circuit 70
20.3. Telephone Line Interface 71
20.4. Transmitter/Receiver 71
20.5. Pulse Dialing 71
21 BLOCK DIAGRAM (HANDSET) 72
22 CIRCUIT OPERATION (HANDSET) 73
22.1. Outline 73
22.2. Power Supply Circuit/Reset Circuit 73
22.3. Charge Circuit 73
22.4. Battery Low/Power Down Detector 73
22.5. Speakerphone 73
23 CIRCUIT OPERATION (CHARGER UNIT) 74
23.1. Power Supply Circuit 74
24 SIGNAL ROUTE 75
25 CPU DATA (BASE UNIT) 76
25.1. IC8 (BBIC) 76
26 CPU DATA (HANDSET) 78
26.1. IC1 (BBIC) 78
27 ENGINEERING MODE 80
27.1. Base Unit 80
27.2. Handset 83
28 EEPROM LAYOUT (BASE UNIT) 85
28.1. Scope 85
28.2. Introduction 85
28.3. EEPROM Layout 85
29 EEPROM LAYOUT (HANDSET) 90
29.1. Scope 90
29.2. Introduction 90
29.3. EEPROM contents 90
30 HOW TO REPLACE FLAT PACKAGE IC 93
30.1. Preparation 93
30.2. Procedure 93
30.3. Modification Procedure of Bridge 93
31 CABINET AND ELECTRICAL PARTS LOCATION (BASE UNIT)
94
32 CABINET AND ELECTRICAL PARTS LOCATION (HANDSET)
95
33 CABINET AND ELECTRICAL PARTS LOCATION (CHARGER
UNIT) 96
34 ACCESSORIES AND PACKING MATERIALS 97
34.1. KX-TCD300FXS/FXT 97
34.2. KX-TCA130FXS/FXT 98
35 TERMINAL GUIDE OF THE ICs, TRANSISTORS AND DIODES
99
35.1. Base Unit 99
35.2. Handset 99
35.3. Charger Unit 99
36 REPLACEMENT PARTS LIST 100
36.1. Base Unit 100
36.2. Handset 102
36.3. Charger Unit 103
36.4. Accessories and Packing Materials 103
36.5. Fixtures and Tools 104
37 FOR SCHEMATIC DIAGRAM 105
37.1. Base Unit (SCHEMATIC DIAGRAM (BASE UNIT)) 105
37.2. Handset (SCHEMATIC DIAGRAM (HANDSET)) 105
37.3. Charger Unit (SCHEMATIC DIAGRAM (CHARGER UNIT))
105
38 SCHEMATIC DIAGRAM (BASE UNIT) 106
39 SCHEMATIC DIAGRAM (HANDSET) 108
40 SCHEMATIC DIAGRAM (CHARGER UNIT) 110
41 CIRCUIT BOARD (BASE UNIT) 111
41.1. Component View 111
41.2. Flow Solder Side View 112
42 CIRCUIT BOARD (HANDSET) 113
42.1. Component View 113
42.2. Flow Solder Side View 114
43 CIRCUIT BOARD (CHARGER UNIT) 115
43.1. Component View 115
43.2. Flow Solder Side View 115
3
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

1 ABOUT LEAD FREE SOLDER (PbF: Pb free)
Note:
In the information below, Pb, the symbol for lead in the periodic table of elements, will refer to standard solder or solder that
contains lead.
We will use PbF solder when discussing the lead free solder used in our manufacturing process which is made from Tin (Sn),
Silver (Ag), and Copper (Cu).
This model, and others like it, manufactured using lead free solder will have PbF stamped on the PCB. For service and repair
work we suggest using the same type of solder although, with some precautions, standard Pb solder can also be used.
Caution
· PbF solder has a melting point that is 50°F ~ 70°F (30°C ~ 40°C) higher than Pb solder. Please use a soldering iron with
temperature control and adjust it to 700°F ± 20°F (370°C ± 10°C). In case of using high temperature soldering iron, please
be careful not to heat too long.
· PbF solder will tend to splash if it is heated much higher than its melting point, approximately 1100°F (600°C).
· If you must use Pb solder on a PCB manufactured using PbF solder, remove as much of the original PbF solder as possible
and be sure that any remaining is melted prior to applying the Pb solder.
· When applying PbF solder to double layered boards, please check the component side for excess which may flow onto the
opposite side (See the figure below).
1.1. Suggested PbF Solder
There are several types of PbF solder available commercially. While this product is manufactured using Tin, Silver, and Copper
(Sn+Ag+Cu), you can also use Tin and Copper (Sn+Cu) or Tin, Zinc, and Bismuth (Sn+Zn+Bi). Please check the
manufacturer’s specific instructions for the melting points of their products and any precautions for using their product with other
materials.
The following lead free (PbF) solder wire sizes are recommended for service of this product: 0.3mm, 0.6mm and 1.0mm.
4
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

1.2. How to recognize that Pb Free solder is used
1.2.1. Base Unit P.C.B.
Marked
1
1
4
8
5
26
17
10
54
81
16 1
33 48
32 49
64
17
PbF
IC7
IC8
IC3
IC1
IC2
(Component View)
BUZ
CLK
VDD2
TP16
VDD3
TP15
A_1
A_2 ANT
VDD1
J101
TP19
TP20
RED
BLACK
J102J103J104
LINE_DC
L2T
L1T
CN1
L2R
L1R
DCP
DCM
Marked
PbF
(Flow Solder Side View)
Note:
The location of the “PbF” mark is subject to change without notice.
5
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

1.2.2. Handset P.C.B.
148
CN6
PbF
IC1
IC10 IC11
102
1
65
38
103
128
64
39
Marked
(Component View)
SOFT_A PUSH CLEAR
PbF
UP S1
SP MAIL
DOWN
RIGHT
LEFT
123
6
5
7
0
LED6 LED5
#
R
4
9
8
INT
MIC
TALK
CN5
LEDM
CN7
LEDP2
LEDP1
LED7 LED4
LED9
C26
C124
C59
L7
L8
Marked
(Flow Solder Side View)
Note:
The location of the “PbF” mark is subject to change without notice.
1.2.3. Charger Unit P.C.B.
Marked
Marked
(Component View) (Flow Solder Side View)
J1
TP3
TP2
TP1
D11
WHITE
BLUE
R12
PbF
R11
PbF
TP4
Note:
The location of the “PbF” mark is subject to change without notice.
6
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

2 FOR SERVICE TECHNICIANS
ICs and LSIs are vulnerable to static electricity.
When repairing, the following precautions will help prevent recurring malfunctions.
1.Cover the plastic parts boxes with aluminum foil and ground them.
2.Ground the soldering irons.
3.Use a conductive mat on the worktable.
4.Do not touch IC or LSI pins with bare fingers.
3 CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the
manufacturer.
Dispose of used batteries according to the manufacture’s Instructions.
7
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

4 BATTERY
4.1. Battery Installation
1.Insert the batteries negative ( ) terminal first.
2.Close the handset cover.
Note:
· Use only rechargeable Ni-MH batteries P03P (HHR-4EPT).
4.2. Battery Charge
Place the handset on the base unit for about 7 hours before initial use.
When charging, and battery strength icon are alternately shown on the display. When the batteries are fully charged,
flashes.
Note:
· It takes 7 hours to fully charge the batteries, however, you can use the handset before the batteries are fully charged.
· Clean the charge contacts of the handset and base unit with a soft, dry cloth, otherwise the batteries may not charge
properly. Clean if the unit is exposed to grease, dust or high humidity.
· When flashes, recharge the handset batteries. will continue to flash until the batteries have been charged for at
least 15 minutes.
· If the handset is turned off, it will be turned on automatically when it is placed on the base unit.
8
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

4.3. Battery Life
After your Panasonic batteries are fully charged, you can expect the following performance:
Ni-MH batteries (700 mAh)
Operation Operating Time
While in use (talking) 16 hours max.
While not in use (standby) 170 hours max.
Note:
· Actual battery performance depends on a combination of how often the handset is in use (talking) and how often it is not
in use (standby).
· Battery operating time may be shortened over time depending on usage conditions and ambient temperature.
4.4. Battery Replacement
If flashes even after the handset batteries have been charged for 7 hours, the batteries must be replaced.
Important:
· Use only the Panasonic rechargeable Ni-MH batteries P03P (HHR-4EPT). If you install non-rechargeable batteries and start
charging, the batteries may leak electrolyte.
· Do not mix old and new batteries.
1.Press the notch on the handset cover firmly and slide it in the direction of the arrow.
2.Remove the old batteries positive ( ) terminal first and install the new ones.
Note for Service:
· You could use other rechargeable batteries on sale, but the unit is not guaranteed to work properly.
9
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

5 LOCATION OF CONTROLS
5.1. Base Unit
5.2. Handset
Note:
· Up to 3 menu items can be displayed at a time. To select a menu item not shown on the current page, scroll up or down
by pressing the navigator key, or , respectively.
10
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

11
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

6 SETTINGS
Important Information
General
· Use only the AC adaptor included with this product.
· Do not connect the AC adaptor to any AC outlet other than a standard 220 - 240 V AC outlet.
· This product is unable to make calls when:
− −−
− The portable handset battery(ies) need recharging or have failed.
− −−
− There is a power failure.
− −−
− The key lock feature is turned on.
− −−
− The call bar feature is turned on (only phone numbers stored in the unit as emergency numbers can be called).
· Do not open the base unit or handset other than to replace the battery(ies).
· This product should not be used near emergency/intensive care medical equipment and should not be used by people with
pacemakers.
· Care should be taken that objects do not fall onto, and liquids are not spilled into, the unit. Do not subject this product to
excessive smoke, dust, mechanical vibration or shock.
Environment
· Do not use this product near water.
· This product should be kept away from heat sources such as radiators, cookers, etc. It should also not be placed in
rooms where the temperature is less than 5 °C or greater than 40 °C.
· The AC adaptor is used as the main disconnect device. Ensure that the AC outlet is installed near the unit and is easily
accessible.
Warning:
· To prevent the risk of electrical shock, do not expose this product to rain or any other type of moisture.
Location
· For maximum distance and noise-free operation, place your base unit:
− −−
− Away from electrical appliances such as TVs, radios, personal computers or other phones.
− −−
− In a convenient, high, and central location.
6.1. Connections
6.1.1. Base Unit
When the AC adaptor is connected, a short beep will be heard. If it is not heard, check the connections.
Important:
· Use only the AC adaptor PQLV19CEY and telephone line cord supplied with this unit.
12
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

Note:
· After connection, you must charge the batteries to make or answer calls.
· Never install telephone wiring during a lightning storm.
· The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.)
· The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet. Do not connect the AC adaptor to
a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to become disconnected.
6.1.2. Charger Unit
Important:
· Use only the AC adaptor PQLV200CEY.
Note:
· The AC adaptor must remain connected at all times (It is normal for the adaptor to feel warm during use).
13
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

6.2. Guide to Settings
For your reference, a chart of all items which can be customised for the base unit and the handset is printed below.
· When customising the base unit and the handset, the current item or setting is highlighted.
6.2.1. Base Unit
Note:
· Up to 3 menu items can be displayed at a time. To select a menu item not shown on the current page, scroll up or down
by pressing the navigator key, or , respectively.
6.2.2. Handset
Note:
· Up to 3 menu items can be displayed at a time. To select a menu item not shown on the current page, scroll up or down
by pressing the navigator key, or , respectively.
14
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

6.3. Ringer Volume
6.3.1. Base Unit
6.3.2. Handset
Note:
· When the ringer volume is turned off, is displayed.
· Alarms will sound and the handset will ring for intercom calls and when paged even if the ringer is turned off.
15
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

6.4. Night Mode
Night mode allows you to select a block of time during which the base unit and the handset will not ring for outside calls. This
feature is useful for times when you do not want to be disturbed, for example, while sleeping. Night mode can be set
independently for the handset and the base unit.
Using the phonebook’s category feature, you can also select categories of callers whose calls will override night mode and ring
the handset (Caller ID subscribers only).
Set the date and time beforehand.
6.4.1. Turning Night Mode On/Off
6.4.1.1. Base Unit
6.4.1.2. Handset
Note:
When the night mode is turned on, is displayed.
16
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

6.5. PIN Code
6.5.1. Base Unit
For security, the base unit PIN must be entered when changing certain settings. The default PIN is “ ”.
For Service Hint:
*: If the current 4-digit Base Unit PIN is forgotten, follow the procedures below.
1.If Base Unit and Handset are not linked with, first, follow the steps in Registering a Handset to a Base Unit (P.30).
2.Follow the steps above in Base Unit (P.17) of PIN Code. At step 3, enter , and you will able to enter new
Base Unit PIN.
6.5.2. Handset
For security, the handset PIN must be entered when changing certain settings. The default PIN is “ ”.
For Service Hint:
*: If the current 4-digit PIN is forgotten, press and you will be able to enter new Handset PIN.
This password is useful whether Base Unit and Handset are linked with or not.
17
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

6.6. Reset
6.6.1. Base Unit
Note:
· The following items will be deleted or reset to their default settings:
− −−
− All SMS messages
− −−
− Caller list
· The following items will be retained:
− −−
− Date and time
− −−
− Repeater mode
Base Unit Initial Settings
Function Initial Setting Remarks (selectable options)
Base Unit Ringer Volume Medium Off/Low/Medium/High
Night Mode Off On/Off
Dialling Mode Tone Tone/Pulse
Recall Time 600 msec 80/90/100/110/160/200/250/300/400/600/700/900 msec
Emergency Call Number - -
Pause Length Short (3 sec) 3 sec/5 sec
Call Restricted Handset (s) Delete All -
Call Restricted Number (s) Delete All -
4-Digit Base Unit PIN 0000 -
SMS Message Center 1 - -
SMS Message Center 2 - -
Caller List Delete All -
SMS Message Lists Delete All -
SMS PBX Line Access Number Support
On/Off Off On/Off
SMS PBX Line Access Number Delete All -
SMS Feature Off On/Off
18
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

6.6.2. Handset
Note:
· The following items will be deleted or reset to their default settings:
− −−
− Redial list
− −−
− Voice enhancer
− −−
− Category names
− −−
− Category ringtones
− −−
− Category display colours
· The following items will be retained:
− −−
− Phonebook entries (category names, ringtones, and display colours will be reset to their default settings.)
− −−
− Date and time
Handset Initial Settings
Function Initial Setting Remarks (selectable options)
Date and Time (*1) -
Alarm Mode Off Once/Daily/Off
Handset Ringer Volume 6Off/1 to 6
Handset External Ringtone 11to20
Handset Internal Ringtone 11to20
Night Mode Off On/Off
Wallpaper 1Off/1 to 4
Display Colour 11to4
Standby Mode Display Off Base Number/Handset Number/Off
Display Language English -
Display Contrast 31to6
Call Bar Off On/Off
Auto Talk Off On/Off
Select Base Unit Auto -
4-Digit Handset PIN 0000 -
SMS Text Input Mode LetterWise® (*2) LetterWise/Alphabet/Numeric/Greek/Extended
LetterWise Language English -
Keytones On On/Off
Redial Memory Delete All -
Handset Receiver Volume 2/4 1to4
Handset Speaker Volume 3/6 1to6
Note:
(*1) Date and time will be retained when resetting base unit or handset. If you want to reset Date and time, follow the procedure
below.
1.Turn the base unit power “Off”.
2.Turn the handset power “Off”.
3.Turn the base unit power “On”.
4.Turn the handset power “On”.
(*2) Eatoni and LetterWise are trademarks of Eatoni Ergonomics, Inc.
19
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT

6.7. Key Lock
The handset can be locked so that no calls or settings can be made. Incoming calls can be answered, but all other functions
are disabled while key lock is on.
To turn key lock on, press (middle soft key) for about 2 seconds.
· is displayed.
· To turn key lock off, press (middle soft key) for about 2 seconds.
Note:
· Calls to emergency numbers cannot be made until key lock is turned off.
· Key lock is turned off when the handset is turned off.
6.8. [R] Button ( to use the recall feature)
[R] is used to access optional telephone services, Contact your service provider for details.
Note:
· If your unit is connected to a PBX (private branch exchange), pressing [R] can allow you to access certain features of your
host PBX such as transferring an extension call. Consult your PBX dealer for details.
· You can change the recall time.
6.9. Pause Button for PBX/Long Distance Service Users
A pause is sometimes required when making calls using a PBX or long distance service.
Example:
· If you have to dial before dialling outside numbers manually, you will probably pause after dialling until you hear a
dial tone.
Note:
· Pressing 1 time creates 1 pause. Press repeatedly to create longer pauses.
20
KX-TCD300FXS / KX-TCD300FXT / KX-TCA130FXS / KX-TCA130FXT
