Panasonic KX-TG6700 User manual

PQQW15182YA DM0406PM1088
Continue page 2.
Setting up
Connect the included telephone line cord depending on your situation.
If you subscribe to a DSL service, connect a noise filter to the telephone line between the
base unit and the telephone line jack. Refer to the operating instructions for connections.
For further information, visit http://www.panasonic.com/phonehelp
To connect to a 2-line telephone jack
Base unit
To 2 single-line telephone jacks
Base unit
Line 1
Line 2
To single-line telephone jacks (RJ11C)
2-wire telephone line cord
with transparent plugs
4-wire telephone line cord
with green plugs
“Click”
To 2-line telephone jack (RJ14C)
4-wire telephone line cord with green plugs
“Click”
Model No. KX-TG6700
KX-TG6702
Quick Guide
TG6700_QG(e).fm Page 1 Monday, August 18, 2008 12:10 PM

–2 –
Continued
Setting up
For further information, visit http://www.panasonic.com/phonehelp or refer to
Operating Instructions.
Base unit CHARGE 7 HOURS
Handset
Use only the included Panasonic AC adaptor
PQLV207 or PQLV219. Confirm the charge
indicator is on.
A
BC
D
Confirm the charge
indicator is on.
Charger
(120 V AC, 60 Hz)
KX-TG6702 only
(120 V AC,
60 Hz)
Press plug firmly.
Hook
TG6700_QG(e).fm Page 2 Monday, August 18, 2008 12:10 PM

–3 –
Operating tips
{}: indicates button names/soft key names.
Using the navigator key
Press {^}, {V}, {<}, or {>}to navigate through
menus and to select items shown on the display.
Adjusting audio volume
Press {^} or {V} repeatedly while talking.
Handset soft keys
The handset features 3 soft keys. By pressing a soft
key, you can select the feature shown directly above
it on the display.
{ SELECT}, { SAVE}, { OK}and additional other
functions are assigned to soft keys. Pay attention to
soft keys to find functions you need during handset
operation.
Date and time (Handset)
1{MENU}i{4}
2Enter the current month, day, and year by selecting 2 digits for each.
3Enter the current hour and minute (12-hour clock format) by selecting 2 digits for each.
4Press {AM/PM}to select “AM” or “PM”. i { SAVE}i { OFF}
Adding items to the phonebook (Handset)
1Press {^} or {V} i{C}i{ADD}
2Enter the name (max. 16 characters). i{NEXT}
3Enter the phone number (max. 32 digits). i{NEXT}
4 { SAVE}i { OFF}
For further information, visit http://www.panasonic.com/phonehelp or refer to
Operating Instructions.
{V}
{^}
{<}{>}
LINE1
REDIAL LINE2
TG6700_QG(e).fm Page 3 Monday, August 18, 2008 12:10 PM

–4 –
Basic operation (Handset)
Feature Operation
Adjusting the receiver/
speaker volume
Press {^} or {V} repeatedly while talking.
Viewing the caller list and
calling back
1Press {^} or {V} i{CID}
2Press {^} or {V} repeatedly to select the desired item. i
{C}
Ringer volume 1{MENU}i{1}{1}
2Select the desired line.
3Select the desired volume. i { SAVE}i { OFF}
Answering call-waiting
call (2nd call)
Press {CALL WAIT}when you hear call waiting tone.
Basic operation (Base unit)
Feature Operation
Adjusting the speaker
volume
Press {^} or {V} repeatedly while talking.
Ringer volume 1Press {LINE SELECT}repeatedly to select the desired
line.
2Press {^} or {V} repeatedly to select the desired volume.
LTo turn the ringer off, press and hold {V} until the unit
beeps.
Answering call-waiting
call (2nd call)
Press {CALL WAIT}when you hear call waiting tone.
For further information, visit http://www.panasonic.com/phonehelp or refer to
Operating Instructions.
TG6700_QG(e).fm Page 4 Monday, August 18, 2008 12:10 PM

–5 –
Answering system (Base unit)
Feature Operation
Auto answer on/off 1Press {LINE SELECT}repeatedly to select the desired
line(s).
2{ANSWER ON}
Recording your greeting
message
(max. 2 minutes)
1Press {LINE SELECT}repeatedly to select the desired
line(s).
2{GREETING REC}
3Within 10 seconds, press {GREETING REC}again.
4Speak clearly about 20 cm (8 inches) away from the MIC.
5To stop recording, press {STOP}.
Listening to new
messages
When the {MESSAGE}button flashes on the base unit,
press {MESSAGE}.
Listening to old
messages
When the {MESSAGE}button does not flash on the base
unit, press {MESSAGE}.
Erasing a message Press {ERASE}during playback.
Using the answering
system remotely
1Dial your phone number from a touch tone phone.
2After the greeting message starts, enter your remote
code. (Default remote code is “11”.)
LThe unit plays back new messages including memo
messages.
L After playing back new messages, the voice guidance starts.
3Follow the voice guidance as necessary.
For further information, visit http://www.panasonic.com/phonehelp or refer to
Operating Instructions.
TG6700_QG(e).fm Page 5 Monday, August 18, 2008 12:10 PM

–6 –
Frequently asked questions
Question Cause/solution
How can I increase
handset volume level?
LPress {^} repeatedly while talking.
Why is the conversation
noisy or cutting off?
LTry to relocate the base unit so that distance from location
to use the handset will be minimized.
LSend your unit to service, if your unit has same problem
when the handset is next to the base unit.
Can I add another
accessory handset to my
base unit?
LYes, you can add up to 8 handsets (including the
handset(s) sold with KX-TG6700 or KX-TG6702 base unit)
to a single base unit.
LTo purchase accessory handsets (KX-TGA670),
please visit http://www.panasonic.com
or call 1-800-332-5368. TTY users (hearing or speech
impaired users) can call 1-866-605-1277.
Can I keep battery
charging all the time?
LYou can leave handset on the base unit or charger
anytime. There is no damage to the battery.
How can I answer a call-
waiting call (2nd call)?
LPress {CALL WAIT}when you hear call-waiting tone.
For further troubleshooting information, visit http://www.panasonic.com/phonehelp or
refer to Operating Instructions.
TG6700_QG(e).fm Page 6 Monday, August 18, 2008 12:10 PM

–7 –
Quick troubleshooting
Place the handset on the base unit,
then check if the charge indicator is on.
The charge indicator is OFF. The charge indicator
is ON.
Unplug and then plug AC
adaptor properly to both
the base unit and AC
outlet.
Unplug the AC adaptor of the base unit and remove the
battery from the handset, then plug in the AC adaptor
and insert the battery into the handset again. Try re-
registration as explained later in this guide.
Lift the handset, then try again.
If handset still shows the same
message, try re-registration as
explained later in this guide.
The charge indicator
is still OFF.
Re-registration
failed.
Re-registration
failed.
The charge
indicator is ON,
now.
Your telephone may need service. For further troubleshooting,
please visit http://www.panasonic.com/phonehelp
“No link to base. Move closer to base, try again.”
1Handset shows:
TG6700_QG(e).fm Page 7 Monday, August 18, 2008 12:10 PM

–8 –
Quick troubleshooting
Lift up the handset from
the base unit or charger.
Press {C} (TALK) at the
handset, then check if the
display shows “Talk”.
Press {s} (SP-PHONE),
then check if the dial
tone is heard from the
speaker on the back.
No dial tone
Dial tone is heard.
“No link to base.
Move closer to
base, try again.”
is displayed.
“Talk” is
displayed.
Check the telephone
cord is properly
connected to both
the base unit and
telephone jack on
the wall.
Try remedy for 1
on previous page.
Your telephone may
need service when
only back speaker
provides a dial tone.
2No dial tone is heard from handset.
Your telephone may need service.
Please visit http://www.panasonic.com/phonehelp for further
troubleshooting.
Still no dial tone
{C}
{s}
No link to base.
Move closer to
base, try again.
11
Talk
00-00-00
Line 1
(VE)
LINE2
L1
dB
=Volume
TG6700_QG(e).fm Page 8 Monday, August 18, 2008 12:10 PM

–9 –
Registering a handset to base unit
The included handset and base unit are preregistered. If for some reason the handset is
not registered to the base unit, register the handset.
For further registration information, visit
http://www.panasonic.com/RegisterYourHandset
Handset
Handset
Base unit
Press INTERCOM
on base for 3 sec
Then press
OK L
Press {MENU}, then press {0}{0}{1}.
Press and hold {INTERCOM}until the IN USE
indicator flashes.
LComplete next step within 1 minute.
Press {OK}, then press {OFF}
after a beep sounds.
{MENU}
TG6700_QG(e).fm Page 9 Monday, August 18, 2008 12:10 PM

1Read this Quick Guide or Operating
Instructions
LIf lost, you can download your Operating Instructions at
http://www.panasonic.com/phonehelp
2Visit our website:
http://www.panasonic.com/phonehelp
LFAQs and troubleshooting hints are available.
3Contact us via the web at:
http://www.panasonic.com/contactinfo
4Call us at:
1-800-211-PANA (1-800-211-7262)
LMonday - Friday 9:00am - 9:00pm (EST),
Saturday/Sunday 10:00am - 7:00pm (EST)
To order a replacement battery,
please call: 1-800-332-5368
Or visit:
http://www.panasonic.com/batterystore
IMPORTANT!
If your product is not
working properly. . .
