Panasonic KX-TGP500 User manual

EarthLink Business
Panasonic TGP500 Cordless Phone
User Guide

User Guide
2
Proprietary and Confidential –EarthLink Business
Publication History
First Release: Version 1.0 –February 05, 2013
CHANGE HISTORY
Version
Date
Change Details
Changed By
1.0
2/05/2013
Original Document Draft
Danny Brickhouse

AUTHOR:
Danny Brickhouse
EarthLink Engineering

User Guide
3
Proprietary and Confidential –EarthLink Business
Table of Contents
Document Purpose ________________________________________________4
Product summary _________________________________________________4
User Guide _____________________________________________________5

User Guide
4
Proprietary and Confidential –EarthLink Business
Document Purpose
The purpose of this document is to provide a user guide for commonly used functions of the Panasonic
TGP500 cordless phone.
Product summary
The Panasonic TGP500 is a SIP DECT phone that consists of a base station that can be paired with up to 6
handsets. Each handset is associated with the same telephone number and an incoming call will ring all
handsets that are paired to the base.

User Guide
5
Proprietary and Confidential –EarthLink Business
User Guide
Pairing handset to base
TGP500/TGP550 –REGISTERING HANDSET TO BASE –
Press and hold “ALL” for 4 seconds.
ALL
Press
MENU,#,1,3,0
②Base registering mode
STATUS LED blinking
①Preparation ③Handset
registering mode
Press OK
Wait a long beep
Guidance on LCD
*Either ①→③→②or ②→①→③are OK.

User Guide
6
Proprietary and Confidential –EarthLink Business
Paging all handsets
TGP500 –CONTROLS –

User Guide
7
Proprietary and Confidential –EarthLink Business
Placing a call on Hold and answering second incoming call
TGP500/TGP550 –HOLD, CALL WAITING–
■Hold
Press “HOLD”
during a call Line on hold
■Call waiting
Press “SWITCH”
to answer 2nd call
Press “HOLD” or
“TALK” to release hold
■Release hold
An alarm tone starts after 9miniutes
Receive
2nd call
On 1st call
Press “SWITCH”
to return to 1st call
Return to 1st call
On 2nd call

User Guide
8
Proprietary and Confidential –EarthLink Business
Transferring a call
TGP500/TGP550 –TRANSFER CALLS –
■Transfer Call
Press “MENU”
during a call Select “Transfer”
then press “SELECT”
Press “TRANS”
Dial number for transfer
Call is answered
Phonebookcan
be used Press “CANCELL” twice
to return to original call
■Transfer Call (Blind Transfer)
Press “MENU”
during a call Select “Blind transfer”
then press “SELECT” Dial number for transfer
Phonebookcan
be used Press “TRANS”

User Guide
9
Proprietary and Confidential –EarthLink Business
Initiating a conference call
TGP500/TGP550 –CONFERENCE, ANOTHER CALL–
■Conference Call
Press “MENU”
during a call Select “Conference”
then press “SELECT”
Press “CONF”
Dial number for conference call
Call is answered
Phonebookcan
be used Press “CANCELL” twice
to return to original call
■Making another call during a call
Dial number then press “CALL”
Press “HOLD”
during a call
Call is answered
Press “SWITCH” to
return to 1st call
2nd call will be on hold
when return to 1st call
In conference

User Guide
10
Proprietary and Confidential –EarthLink Business
Other functions:
Dial Contacts
Menu->Phonebook->Scroll UP/DOWN->Talk
Call list Dialing
CID->Scroll UP/DOWN->Talk
Phonebook Add
Menu->Phonebook->Add
Phonebook Add from Call List
CID->Scroll UP/DOWN->Menu->Save phonebook->Save
