Panasonic Lumix DMC-FS62EB User manual

© Panasonic Corporation 2009 Unauthorized copy-
ing and distribution is a violation of law.
ORDER NO. DSC0905035AE
B26
Digital Camera
Model No. DMC-FS62EB
DMC-FS62EE
DMC-FS62EF
DMC-FS62EG
DMC-FS62EP
DMC-FS62GC
DMC-FS62GJ
DMC-FS62GN
Vol.1
Colour
(S)-------Silver Type (except EF)
(K)-------Black Type
(P)-------Pink Type (except EF/EE/GN)
(A)-------Blue Type (except EE/GN)
(R)-------Red Type (except GC/GJ)
Please use this manual together with the service manual for
Model No.DMC-FS6P/PC/PR/PU/EB/EE/EF/EG/EP/GC/GJ/GK/GN/GT Vol.1 Order No.DSC0902003CE.

2
TABLE OF CONTENTS PAGE PAGE
1 SERVICE NAVIGATION------------------------------------------3
1.1. INTRODUCTION-------------------------------------------3
1.2. Important Notice 1:(Other than U.S.A. and
Canadian Market) -----------------------------------------3
1.3. About the Lens Unit ---------------------------------------3
2 INITIAL SETTINGS------------------------------------------------4
3DIAGRAMS----------------------------------------------------------7
3.1. Overall Block Diagram------------------------------------7
3.2. Flash Top Schematic Diagram--------------------------8
4 REPLACEMENT PARTS LIST ---------------------------------9
4.1. Frame & Casing Section -------------------------------10
4.2. Packing & Accessories Section---------------------- 11

3
1 SERVICE NAVIGATION
1.1. INTRODUCTION
This Service Manual contains technical information which will help service personnel to understand and service the Digital Camera
Digital Camera; DMC-FS62 series
The Digital Camera DMC-FS62 series have been developed based on DMC-FS6 series.
Since this Service Manual does not cover the same part which is already described in the Service Manual for DMC-FS6 series,
when servicing, refer to the descriptions in the Service Manual for ; DMC-FS6P/PC/PR/PU/EB/EE/EF/EG/EP/GC/GJ/GK/GN/GT:
Order No. DSC0902003CE (Service Manual Vol. 1).
1.2. Important Notice 1:(Other than U.S.A. and Canadian Market)
When a part replacement is required for repairing MAIN PCB , replace as an assembled parts.
The following category is/are recycle module part. please send it/them to Central Repair Center.
MAIN PCB : VEP56074E
1.3. About the Lens Unit

4
2 INITIAL SETTINGS
After replacing the MAIN PCB, be sure to perform the initial settings after achieving the adjustment by ordering the following
procedure in accordance with model suffix of the unit.
1. IMPORTANT NOTICE:
Before proceeding Initial settings, be sure to read the following CAUTIONS.
2. PROCEDURES:
• Precautions: Read the above "CAUTION 1" and "CAUTION 2", carefully.
• Preparation:
1. Attach the Battery or AC Adaptor with a DC coupler to the unit.
2. Set the recording mode to the [NORMAL PICTURE] mode.
(Press the [MODE] button and select the [NORMAL PICTURE] by pressing the “[ UP ] and [DOWN] of Cursor buttons”,
then press the [MENU/SET] button.)
NOTE:
If the unit is other than [NORMAL PICTURE] mode, it does not display the initial settings menu.
•Step 1. The temporary cancellation of “INITIAL SETTINGS”:
Set the [REC]/[PLAYBACK] selector switch to “[ REC ] (Camera mark)”.
While keep pressing “[ UP ] of Cursor button” and [ iA ] button simultaneously, turn the Power on.
•Step 2. The cancellation of “INITIAL SETTINGS”:
Set the [REC]/[PLAYBACK] selector switch to “[ PLAYBACK ]”.
Press “[ UP ] of Cursor button” and [ iA ] button simultaneously, then turn the Power off.
•Step 3. Turn the Power on:
Set the [REC]/[PLAYBACK] selector switch to “[ REC ] (Camera mark)”, and then turn the Power on.
•Step 4. Display the INITIAL SETTING:
NOTE:
If the unit is other than [NORMAL PICTURE] mode, it does not display the initial settings menu.
While keep pressing [ MENU/SET ] and “[ RIGHT ] of Cursor buttons” simultaneously, turn the Power off.
The "INITIAL SETTINGS" menu is displayed.
There are two kinds of “INITIAL SETTINGS” menu form as follows:

5
[CASE 1. After replacing MAIN P.C.B.]
When MAIN P.C.B. has just been replaced, all of the model suffix is displayed as follows. (Four pages in total)
[CASE 2. Other than “After replacing MAIN P.C.B.”]
•Step 5. Chose the model suffix in “INITIAL SETTINGS”: (Refer to “CAUTION 1”)
[Caution: After replacing MAIN P.C.B.]
The model suffix can been chosen, JUST ONE TIME
Once one of the model suffix have been chosen, the model suffix lists will not be displayed, thus, it can be changed.
Therefore, select the area carefully.
Select the area with pressing “[ UP ] / [ DOWN ] of Cursor buttons”.
•Step 6. Set the model suffix in “INITIAL SETTINGS”:
Press the “[ RIGHT ] of Cursor buttons”.
The only set area is displayed, and then press the “[ RIGHT ] of Cursor buttons” after confirmation.
(The unit is powered off automatically.)

6
•Step 7. CONFIRMATION:
Confirm the display of “PLEASE SET THE CLOCK” in concernd language when the unit is turned on again.
When the unit is connected to PC with USB cable, it is detected as removable media.
1) As for your reference, major default setting condition is as shown in the following table.
•Default setting (After “INITIAL SETTINGS”)
MODEL VIDEO OUTPUT LANGUAGE DATE REMARKS
a) DMC-FS62EG PAL English Date/Month/Year
b) DMC-FS62EP PAL English Date/Month/Year
c) DMC-FS62EF PAL French Date/Month/Year
d) DMC-FS62EB PAL English Date/Month/Year
e) DMC-FS62EE PAL Russian Date/Month/Year
f) DMC-FS62GC PAL English Date/Month/Year
g) DMC-FS62GN PAL English Date/Month/Year
h) DMC-FS62GJ PAL Thai Date/Month/Year

7
3 DIAGRAMS
3.1. Overall Block Diagram
CCD
IC3001
CCD SIGNAL
PROCESSOR
FOCUSIRIS
SDRAM/256Mbit
NAND FLASH ROM/512Mbit
SD
CARD
(POWER SUPPLY)
BATTERY
REAR OPERATION UNIT
OVERALL BLOCK DIAGRAM
OVERALL BLOCK DIAGRAM
OIS UNIT
IC9101
SYSTEM IC
MOTOR DRIVE,
OIS DRIVE&
PRE PROCESS
IC6001
VENUS4
CAMERA PROCESS
J-PEG COMP/EX PANDS
MEDIA I/F
USB I/F
MAIN MICROPROCESSOR
FLASH
TOP OPERATION UNIT
IC1001
POWER
SHUTTER
IC9101
SYSTEM IC
IC6002
ZOOM
OIS CONTROL
LENS DRIVE
LCD DRIVE
AV OUT / DIGITAL
TERMINAL
COLOR LCD
PANEL
(33mm ~ 132mm)
IC7101
GYRO
SENSOR X/Y
IC9101
SYSTEM IC
MICROPHONE
MICROPHONE AMP
SPEAKER CONTROL
SPEAKER
1/2.5" 10 MEGA PIX CDS, AGC,
A/D, TG,
CCD DRIVER
2.5" PANEL
230k dots
X6001
(24MHz)
X9101
(32.768kHz)
VIDEO OUT
IC8001
IGBT DRIVER
IC6004
FeRAM
IC3002
REGLATOR
IC1210
REGLATOR

8
3.2. Flash Top Schematic Diagram
,DRAZAHERIFTSNIAGANOITCETORPDEUNITNOCROF:NOITUAC .ESUFV23A52.1EPYTEMASEHTHTIWYLNOECALPER
SEUQSIRSELEUNI
TNOCNOITCETORPENURUOP:NOITNETTA .V23A52.1EPYTEMÉMEDELBISUFSEDEUQRESILITU'NEIDNECNI'D
V23A52.1
V23A52.1
,DRAZAHERIFTSNIAGANOITCETORPDEUNITNOCROF:NOITUAC .ESUFV23A5.1EPYTEMASEHTHTIWYLNOECALPER
SEUQSIRSELEUNIT
NOCNOITCETORPENURUOP:NOITNETTA .V23A5.1EPYTEMÉMEDELBISUFSEDEUQRESILITU'NEIDNECNI'D
V23A5.1
V23A5.1
poThsalF margaiDcitamehcS
01987654321
G
F
E
D
C
B
A
Variation Category
P8002 K4ZZ04000051 K4ZZ04000052
DMC-FS6/FS7/FS15
FS8/FS62/FS12
DMC-FS25

9
4 REPLACEMENT PARTS LIST

10
4.1. Frame & Casing Section
COMPARISON CHART:
The following table shows difference between DMC-FS6 series and DMC-FS62 series.
Ref No. Original Part No. New Part No. Part Name & Description Pcs Remarks
DMC-FS6 series DMC-FS62 series
1 VEP56074A VEP56074E MAIN P.C.B. 1 (RTL) E.S.D.
7 VYK2Y23 VYK3H78 FRONT CASE UNIT 1 (-S)
7 VYK2Y24 VYK3H79 FRONT CASE UNIT 1 (-K)
7 VYK2Y25 VYK3J50 FRONT CASE UNIT 1 (-A)
7 VYK2Y26 VYK3J48 FRONT CASE UNIT 1 (-P)
7 VYK2Y27 VYK3J52 FRONT CASE UNIT 1 (-R)
9 VYK2Y33 VYK3H82 REAR CASE UNIT 1 (-S)
9 VYK2Y34 VYK3H83 REAR CASE UNIT 1 (-K)
9 VYK2Y35 VYK3J51 REAR CASE UNIT 1 (-A)
9 VYK2Y36 VYK3J49 REAR CASE UNIT 1 (-P)
9 VYK2Y37 VYK3J53 REAR CASE UNIT 1 (-R)
9-2 VGU0D72 VGU0D72 CORSOR BUTTON 1 (-S,-A,-P,-R)
VGU0E98 CURSOR BUTTON 1 (-K)
27 VYK3H27 VYK3H81 TOP ORNAMENT UNIT 1
28 VGU0C05 VGU0C05 REC/PLAYBACK SELECTOR KNOB 1 (-S,-A,-P,-R)
VGU0E99 REC/PLAYBACK SELECTOR KNOB 1 (-K)
101 VDL1956 VDL2317 OPTICAL FILTER 1 [SPC]
102 VEK0N41 VEK0N42 CCD UNIT 1 E.S.D. [SPC]

11
4.2. Packing & Accessories Section
Ref.No. Part No. Part Name & Description Pcs Remarks
300 VPF1302 CAMERA BAG 1
301 DE-A60AA/SX BATTERY CHARGER 1 EG,EP,EF,EB,GN
301 DE-A60BB/SX BATTERY CHARGER 1 EE,GC,GJ
302 ----- BATTERY 1
304 K1HA08AD0001 USB CABLE 1
305 K1HA08CD0027 AUDIO/VIDEO CABLE 1 GC,GJ
306 VFC4297-A HAND STRAP 1
307 VFF0484-S CD-ROM (SOFTWARE) 1 EG,EP,EE,GJ See "Notes" [SPC]
307 VFF0512-S CD-ROM (SOFTWARE/INSTRUCTION BOOK) 1 EF,EB,GC,GN See "Notes" [SPC]
308 VGQ0D56 BATTERY PROTECTION CASE 1
310 VPF1100 BAG, POLYETHYLENE 1
314 VPK3903 PACKING CASE 1 EGS,EPS,EBS,EES,GCS,GJS,GNS
314 VPK3907 PACKING CASE 1 EGK,EPK,EFK,EBK,EEK,GCK,GJK,GNK
314 VPK3942 PACKING CASE 1 EGA,EPA,EFA,EBA,GCA,GJA
314 VPK3943 PACKING CASE 1 EGP,EPP,EBP,GCP,GJP
314 VPK3944 PACKING CASE 1 EGR,EPR,EFR,EBR,EER,GNR
315 VPN6663 CUSHION 1
319 K2CT39A00002 AC CORD W/PLUG 1 EB,GC
320 K2CP2YY00001 AC CORD W/PLUG 1 GJ
320 K2CQ29A00002 AC CORD W/PLUG 1 EG,EP,EF,EE,GC
321 K2CJ29A00002 AC CORD W/PLUG 1 GN
324 VFF0515-C CD-ROM (INSTRUCTION BOOK) 1 EG,EP
324 VFF0516-C CD-ROM (INSTRUCTION BOOK) 1 EE
325 VQT2D46 SIMPLIFIED O/I (GERMAN/FRENCH) 1 EG
325 VQT2D50 SIMPLIFIED O/I (SWEDISH/DANISH) 1 EP
325 VQT2D47 SIMPLIFIED O/I (ITALIAN/DUTCH) 1 EG
325 VQT2D52 SIMPLIFIED O/I (POLISH/CZECH) 1 EP
325 VQT2D55 SIMPLIFIED O/I (ENGLISH) 1 EB
325 VQT2D57 SIMPLIFIED O/I (ENGLISH/CHINESE(TRADITIONAL) 1 GC
325 VQT2D62 SIMPLIFIED O/I (ENGLISH) 1 GN
325 VQT2D48 SIMPLIFIED O/I (SPANISH/PORTUGUESE) 1 EG
325 VQT2D54 SIMPLIFIED O/I (HUNGARIAN/FINNISH) 1 EP
325 VQT2D93 SIMPLIFIED O/I (FRENCH) 1 EF
325 VQT2D56 SIMPLIFIED O/I (RUSSIAN/UKRAINIAN) 1 EE
325 VQT2D58 SIMPLIFIED O/I (ARABIC/PERSIAN) 1 GC
325 VQT2D59 INSTRUCTION BOOK (THAI) 1 GJ
326 VQT2B63 O/I SOFTWARE 1 EG
326 VQT2B64 O/I SOFTWARE 1 EP
326 VQT2G20 O/I SOFTWARE 1 GC
326 VQT2B65 O/I SOFTWARE 1 EF
326 VQT2B67 O/I SOFTWARE 1 EE
326 VQT2C95 O/I SOFTWARE 1 GJ
326 VQT2D89 O/I SOFTWARE 1 EB,GN

12
Exploded View:
