Panasonic Lumix DMC-FX01PP User manual

© 2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
ORDER NO. DSC0602009CE
B26
Digital Camera
DMC-FX01PP
DMC-FX01PL
DMC-FX01EB
DMC-FX01EE
DMC-FX01EF
DMC-FX01EG
DMC-FX01EGM
DMC-FX01GC
DMC-FX01GD
DMC-FX01GK
DMC-FX01GN
DMC-FX01GT
DMC-FX01SG
Vol. 1
Colour
(S)...........Silver Type
(K)...........Black Type (except GD)
(W)..........White Type (except PL/EE/GD/GK/GN)
(P)...........Pink Type (only PP/EE/GC/GK/GT/SG)
(A)...........Blue Type (only EE/EF/EG/EGM/GK)

2
TABLE OF CONTENTS PAGE PAGE
1 Safety Precaution-------------------------------------------------3
1.1. General Guidelines ----------------------------------------3
1.2. Leakage Current Cold Check ---------------------------3
1.3. Leakage Current Hot Check (See Figure 1.)--------3
1.4. How to Discharge the Capacitor on Flash Top
PCB------------------------------------------------------------4
2Warning--------------------------------------------------------------5
2.1. Prevention of Electro Static Discharge (ESD)
to ElectrostaticallySensitive (ES) Devices-----------5
2.2. How to Recycle the Lithium Ion Battery (U.S.
Only)-----------------------------------------------------------5
2.3. Caution for AC Cord(For EB/GC/SG)-----------------6
2.4. How to Replace the Lithium Battery-------------------7
3 Service Navigation------------------------------------------------9
3.1. Introduction --------------------------------------------------9
3.2. General Description About Lead Free Solder
(PbF) ----------------------------------------------------------9
3.3. Important Notice 1:(Other than U.S.A. and
Canadian Market)------------------------------------------9
3.4. How to Define the Model Suffix (NTSC or PAL
model)-------------------------------------------------------10
4 Specifications----------------------------------------------------12
5 Location of Controls and Components------------------13
6 Service Mode-----------------------------------------------------14
6.1. Error Code Memory Function -------------------------14
6.2. Confirmation of Firmware Version -------------------17
7 Service Fixture & Tools ---------------------------------------18
7.1. Service Fixture and Tools ------------------------------18
7.2. When Replacing the Main PCB ----------------------19
7.3. Service Position ------------------------------------------19
8 Disassembly and Assembly Instructions---------------20
8.1. Disassembly Flow Chart--------------------------------20
8.2. PCB Location----------------------------------------------20
8.3. Disassembly Procedure --------------------------------21
8.4. Disassembly Procedure for the Lens ---------------24
8.5. Assembly Procedure for the Lens -------------------26
8.6. Removal of the CCD Unit ------------------------------29
8.7. The Applyment of Grease Method-------------------29
9 Measurements and Adjustments --------------------------30
9.1. Matrix Chart for Replaced Part and Necessary
Adjustment-------------------------------------------------30
10 Maintenace--------------------------------------------------------31
10.1. Cleaning Lens and LCD Panel -----------------------31

3
1 Safety Precaution
1.1. General Guidelines
1. IMPORTANT SAFETY NOTICE
There are special components used in this equipment
which are important for safety. These parts are marked by
in the Schematic Diagrams, Circuit Board Layout,
Exploded Views and Replacement Parts List. It is essen-
tial that these critical parts should be replaced with manu-
facturer’s specified parts to prevent X-RADIATION,
shock, fire, or other hazards. Do not modify the original
design without permission of manufacturer.
2. An Isolation Transformer should always be used during
the servicing of AC Adaptor whose chassis is not isolated
from the AC power line. Use a transformer of adequate
power rating as this protects the technician from acci-
dents resulting in personal injury from electrical shocks. It
will also protect AC Adaptor from being damaged by acci-
dental shorting that may occur during servicing.
3. When servicing, observe the original lead dress. If a short
circuit is found, replace all parts which have been over-
heated or damaged by the short circuit.
4. After servicing, see to it that all the protective devices
such as insulation barriers, insulation papers shields are
properly installed.
5. After servicing, make the following leakage current
checks to prevent the customer from being exposed to
shock hazards.
1.2. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the
two prongs on the plug.
2. Measure the resistance value, with an ohmmeter,
between the jumpered AC plug and each exposed metal-
lic cabinet part on the equipment such as screwheads,
connectors, control shafts, etc. When the exposed metal-
lic part has a return path to the chassis, the reading
should be between 1 MΩand 5.2 MΩ. When the exposed
metal does not have a return path to the chassis, the
reading must be infinity.
1.3. Leakage Current Hot Check
(See Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use
an isolation transformer for this check.
2. Connect a 1.5 kΩ, 10 W resistor, in parallel with a 0.15 μF
capacitor, between each exposed metallic part on the set
and a good earth ground, as shown in Figure 1.
3. Use an AC voltmeter, with 1 kΩ/V or more sensitivity, to
measure the potential across the resistor.
4. Check each exposed metallic part, and measure the volt-
age at each point.
5. Reverse the AC plug in the AC outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed 0.75 V RMS.
A leakage current tester (Simpson Model 229 or equiva-
lent) may be used to make the hot checks, leakage cur-
rent must not exceed 1/2 mA. In case a measurement is
outside of the limits specified, there is a possibility of a
shock hazard, and the equipment should be repaired and
rechecked before it is returned to the customer.
Figure. 1

4
1.4. How to Discharge the Capacitor on Flash Top PCB
CAUTION:
1. Be sure to discharge the capacitor on FLASH TOP PCB.
2. Be careful of the high voltage circuit on FLASH TOP PCB when servicing.
[Discharging Procedure]
1. Refer to the disassemble procedure and Remove the necessary parts/unit.
2. Put the insulation tube onto the lead part of Resistor (ERG5SJ102:1kΩ/5W).
(an equivalent type of resistor may be used.)
3. Put the resistor between both terminals of capacitor on FLASH TOP PCB for approx. 5 seconds.
4. After discharging confirm that the capacitor voltage is lower than 10V using a voltmeter.
Fig. F1

5
2Warning
2.1. Prevention of Electro Static Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec-
trostatically Sensitive (ES) Devices.
The following techniques should be used to help reduce the incidence of component damage caused by electro static discharge
(ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alumi-
num foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an antistatic solder removal device. Some solder removal devices not classified as "antistatic (ESD protected)" can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or compara-
ble conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
CAUTION :
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) suf-
ficient to damage an ES device).
2.2. How to Recycle the Lithium Ion Battery (U.S. Only)

6
2.3. Caution for AC Cord
(For EB/GC/SG)
2.3.1. Information for Your Safety
IMPORTANT
Your attention is drawn to the fact that recording of pre-
recorded tapes or discs or other published or broadcast
material may infringe copyright laws.
WARNING
To reduce the risk of fire or shock hazard, do not expose
this equipment to rain or moisture.
CAUTION
To reduce the risk of fire or shock hazard and annoying
interference, use the recommended accessories only.
FOR YOUR SAFETY
DO NOT REMOVE THE OUTER COVER
To prevent electric shock, do not remove the cover. No user
serviceable parts inside. Refer servicing to qualified service
personnel.
2.3.2. Caution for AC Mains Lead
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three-pin mains plug
for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the
replacement fuse has a rating of 5 amperes and it is approved
by ASTA or BSI to BS1362
Check for the ASRA mark or the BSI mark on the body of the
fuse.
If the plug contains a removable fuse cover you must ensure
that it is refitted when the fuse is replaced.
If you lose the fuse cover, the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local
Panasonic Dealer.
If the fitted moulded plug is unsuitable for the socket outlet in
your home then the fuse should be removed and the plug cut
off and disposed of safety.
There is a danger of severe electrical shock if the cut off plug is
inserted into any 13-ampere socket.
If a new plug is to be fitted please observe the wiring code as
shown below.
If in any doubt, please consult a qualified electrician.
2.3.2.1. Important
The wires in this mains lead are coloured in accordance with
the following code:
As the colours of the wires in the mains lead of this appliance
may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the ter-
minal in the plug which is marked with the letter N or coloured
BLACK.
The wire which is coloured BROWN must be connected to the
terminal in the plug which is marked with the letter L or coloured
RED.
Under no circumstances should either of these wires be con-
nected to the earth terminal of the three pin plug, marked with
the letter E or the Earth Symbol.
2.3.2.2. Before Use
Remove the Connector Cover as follows.
2.3.2.3. How to Replace the Fuse
1. Remove the Fuse Cover with a screwdriver.
2. Replace the fuse and attach the Fuse cover.
Blue Neutral
Brown Live

7
2.4. How to Replace the Lithium Battery
2.4.1. Replacement Procedure
1. Remove the SUB PCB. (Refer to Disassembly Procedures.)
2. Remove the Lithium battery (Ref. No. “Z9101” at component side of SUB PCB) and then replace it into new one.
NOTE:
This Lithium battery is a critical component.
(Type No.: ML-421S/ZT Manufactured by Matsushita Battery Industrial Co.,Ltd.)
It must never be subjected to excessive heat or discharge.
It must therefore only be fitted in requirement designed specifically for its use.
Replacement batteries must be of same type and manufacture.
They must be fitted in the same manner and location as the original battery, with the correct polarity contacts observed.
Do not attempt to re-charge the old battery or re-use it for any other purpose.
It should be disposed of in waste products destined for burial rather than incineration.

8
NOTE:
Above caution is applicable for a battery pack which is for DMC-FX01 series, as well.

9
3 Service Navigation
3.1. Introduction
This service manual contains technical information, which allow service personnel’s to understand and service this model.
Please place orders using the parts list and not the drawing reference numbers.
If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual.
3.2. General Description About Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this
equipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin
(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that of the
normal solder.
Distinction of PCB Lead Free Solder being used
Service caution for repair work using Lead Free Solder (PbF)
• The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of “PbF” is printed on the PCB using the lead free solder.)
• To put lead free solder, it should be well molten and mixed with the original lead free solder.
• Remove the remaining lead free solder on the PCB cleanly for soldering of the new IC.
• Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt the
lead free solder.
• Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30°C
(662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
• The following 3 types of lead free solder are available through the service parts route.
RFKZ03D01K-----------(0.3mm 100g Reel)
RFKZ06D01K-----------(0.6mm 100g Reel)
RFKZ10D01K-----------(1.0mm 100g Reel)
Note
* Ingredient: tin (Sn) 96.5%, silver (Ag) 3.0%, Copper (Cu) 0.5%, Cobalt (Co) / Germanium (Ge) 0.1 to 0.3%
3.3. Important Notice 1:(Other than U.S.A. and Canadian Market)
1. The service manual does not contain the following information, because of the impossibility of servicing at component level
without concerned equipment/facilites.
a. Schematic diagram, Block Diagram and PCB layout of MAIN PCB and SUB PCB.
b. Parts list for individual parts for MAIN PCB and SUB PCB.
When a part replacement is required for repairing MAIN PCB and/or SUB PCB, replace as an assembled parts. (Main PCB/
SUB PCB)
2. The following category is/are recycle module part. please send it/them to Central Repair Center.
• MAIN PCB (VEP56032A)
• SUB PCB (VEP51004A) : Excluding replacement of Lithium Battery

10
3.4. How to Define the Model Suffix (NTSC or PAL model)
There are seven kinds of DMC-FX01, regardless of the colours.
• a) DMC-FX01S
• b) DMC-FX01PP
• c) DMC-FX01EB/EF/EG/EGM/GN
• d) DMC-FX01EE
• e) DMC-FX01GD
• f) DMC-FX01GT
• g) DMC-FX01PL/GC/GK/SG
(DMC-FX01S is exclusively Japan domestic model.)
What is the difference is that the “INITIAL SETTINGS” data which is stored in Flash ROM mounted on Main PCB.
3.4.1. Defining methods:
To define the model suffix to be serviced, refer to the nameplate which is putted on the bottom side of the Unit.
NOTE:
After replacing the MAIN PCB, be sure to achieve adjustment.
The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-PAVC” web-site
in “TSN system”, together with Maintenance software.

11
3.4.2. INITIAL SETTINGS:
When you replace the Main PCB be sure to perform the initial settings after achieving the Adjustment, by ordering the following pro-
cedure in accordance with model suffix.
•Step 1. The temporary cancellation of factory setting:
Set the mode dial to “[ Normal picture mode ] (Red camera mark)”.
While keep pressing [ Optical Image Stabilizer ] and “[ UP ] of Cross key” simultaneously, turn the Power on.
•Step 2. The cancellation of factory setting:
Set the mode dial to “[ Playback ]”.
Press [ Optical Image Stabilizer ] and “[ UP ] of Cross key” simultaneously, then turn the Power off.
•Step 3. Turn the Power on:
Set the mode dial to “[ Normal picture mode ] (Red camera mark)”, and then turn the Power on.
•Step 4. Display the INITIAL SETTING:
While keep pressing [ MENU ] and “[ RIGHT ] of Cross key” simultaneously, turn the Power off.
•Step 5. Set the INITIAL SETTING:
Select the area with pressing “[ UP ] / [ DOWN ] of Cross key”, and then press the “[ RIGHT ] of Cross key”.
The only set area is displayed, and then press the “[ RIGHT ] of Cross key” after confirmation.
(The unit is powered off automatically.)
Confirm the display of “PLEASE SET THE CLOCK” in English when the unit is turned on again.
•Step 6. CONFIRMATION:
The display shows “PLEASE SET THE CLOCK” when turn the Power on again.
When the unit is connected to PC with USB cable, it is detected as removable media.
(When the “GT” or “GK” model suffix is selected, the display shows “PLEASE SET THE CLOCK” in Chinese.)
1) As for your reference Default setting condition is given in the following table.
•Default setting (After “INITIAL SETTINGS”)
MODEL VIDEO OUTPUT LANGUAGE DATE REMARKS
a) DMC-FX01S NTSC Japanese Year/Month/Date
b) DMC-FX01PP/PL NTSC English Month/Date/Year
c) DMC-FX01EB/EE/EF/EG/EGM/GC/GN/SG PAL English Date/Month/Year
d) DMC-FX01GK PAL Chinese (simplified) Year/Month/Date
e) DMC-FX01GT NTSC Chinese (traditional) Year/Month/Date
f) DMC-FX01GD NTSC English Year/Month/Date

12
4 Specifications

13
5 Location of Controls and Components

14
6 Service Mode
6.1. Error Code Memory Function
1. General description
This unit is equipped with history of error code memory function, and can be memorized 32 error codes in sequence from the
latest. When the error is occurred more than 32, the oldest error is overwritten in sequence.
The error code is not memorized when the power supply is shut down forcibly (when the unit is powered on by the battery, the
battery is pulled out) because the error code is memorized to FLASH ROM when the unit is powered off.
2. How to display
The error code can be displayed by the following procedure:
Before perform the error code memory function, connect the AC adaptor or insert the battery, and insert the SD card.
•1. The temporary cancellation of factory setting:
Set the mode dial to “[ Normal picture mode ] (Red camera mark)”.
While keep pressing [ Optical Image Stabilizer Button ] and “[ UP ] of Cross key” simultaneously, turn the Power on.
•2. The display of error code:
Press [ Optical Image Stabilizer Button ], [ MENU ] and “[ LEFT ] of Cross key” simultaneously with the step 1 condition.
The display is changed as shown below when the above buttons is pressed simultaneously.
Normal display →Error code display →Operation history display →Normal display →.....
Example of Error Code Display
•3. The change of display:
The error code can be memorized 32 error codes in sequence, however it is displayed 5 errors on the LCD.
Display can be changed by the following procedure:
“[ UP ] or [ DOWN ] of Cross key” : It can be scroll up or down one.
“[ LEFT ] or [ RIGHT ] of Cross key” : It can be display last 5 error or another 5 error.
•4. How to read the error code:
One error code is displayed for 8 bit, the contents of error codes is indicated the table as shown below.

15
Attribute Main item Sub item Error code Contents (Upper)
High 4 bits Low 4 bits Check point (Lower)
LENS Lens drive OIS 1800 1000 PSD (X) error. Hall element (X axis) position detect error in OIS unit.
OIS Unit
2000 PSD (Y) error. Hall element (Y axis) position detect error in OIS unit.
OIS Unit
3000 GYRO (X) error. Gyro (IC7102: X axis) detect error on Main P.C.B..
IC7102 (Gyro element) or IC6001 (VENUS PLUS)
4000 GYRO (Y) error. Gyro (IC7101: Y axis) detect error on Main P.C.B..
IC7101 (Gyro element) or IC6001 (VENUS PLUS)
5000 MREF error (Reference voltage error).
IC7001 (LENS drive) or IC6001 (VENUS PLUS)
6000 Drive voltage (X) error.
VENUS PLUS AD value error, LENS Unit, LENS flex breaks etc.
7000 Drive voltage (Y) error.
VENUS PLUS AD value error, LENS Unit, LENS flex breaks etc.
C.B./Zoom 0100 HP Low detect error (C.B. encoder (full retract) always Low detect).
FP9802-(6, 9) signal line or IC6001 (VENUS PLUS)
0200 HP High detect error (C.B. encoder (full retract) always High detect).
FP9802-(6, 9) signal line or IC6001 (VENUS PLUS)
0300 ENC1 detect error (C.B. motor encoder detect error).
0400 ENC2 detect error (C.B. motor encoder detect error).
Zoom 0010 HP Low detect error (Zoom encoder always Low detect error).
0020 HP High detect error (Zoom encoder always High detect error).
Focus 0001 HP Low detect error (Focus encoder always Low detect error).
FP9802-(35) signal line or IC6001 (VENUS PLUS)
0002 HP High detect error (Focus encoder always High detect error).
FP9802-(35) signal line or IC6001 (VENUS PLUS)
Lens 1801 0000 Power ON time out error.
Lens drive system
1802 0000 Power OFF time out error.
Lens drive system
Adj.History OIS 1900 2000 OIS adj. Yaw direction amplitude error (small)
3000 OIS adj. Pitch direction amplitude error (small)
4000 OIS adj. Yaw direction amplitude error (large)
5000 OIS adj. Pitch direction amplitude error (large)
6000 OIS adj. MREF error
7000 OIS adj. time out error
8000 OIS adj. Yaw direction off set error
9000 OIS adj. Pitch direction off set error
A000 OIS adj. Yaw direction gain error
B000 OIS adj. Pitch direction gain error
C000 OIS adj. Yaw direction position sensor error
D000 OIS adj. Pitch direction position sensor error
E000 OIS adj. other error
HARD VENUS A/D Flash 2800 0000 Flash charging error.
IC6001-(13) signal line or Flash charging circuit
FLASH ROM
(EEPROM
Area)
FLASH ROM
(EEPROM
Area)
2B00 0001 EEPROM read error
IC6002 (FLASH ROM)
0002 EEPROM write error
IC6002 (FLASH ROM)
SYSTEM RTC 2C00 0001 SYSTEM IC initialize error
Communication between IC6001 (VENUS PLUS) and IC9101 (SYSTEM)

16
•5. How to returned to Normal Display:
Turn the power off and on, to exit from Error code display mode.
NOTE:
The error code can not be initialized.
SOFT CPU Reset 3000 0001
|
0007
NMI reset
Non Mask-able Interrupt
(30000001-30000007 are caused by factors)
Card Card 3100 0001 Card logic error
SD card data line or IC6001 (VENUS PLUS)
0002 Card physical error
SD card data line or IC6001 (VENUS PLUS)
0004 Write error
SD card data line or IC6001 (VENUS PLUS)
3900 0005 Format error
CPU,
ASIC hard Stop 3800 0001 Camera task finish process time out.
Communication between Lens system and IC6001 (VENUS PLUS)
0002 Camera task invalid code error.
IC6001 (VENUS PLUS)
0100 File time out error in recording motion image
IC6001 (VENUS PLUS)
0200 File data send error in recording motion image
IC6001 (VENUS PLUS)
Operation Power on 3B00 0000 FLASHROM processing early period of camera during movement.
Zoom Zoom 3C00 0000 I do not complete zoom lens processing
Zoom lens
3500 0000 I jumped into dummy processing
(0-7bit : command, 8-15bit : Status)
3501 0000 Though record preprocessing is necessary, it is not called.
3502 0000 Though record preprocessing is necessary, it is not completed.
Attribute Main item Sub item Error code Contents (Upper)
High 4 bits Low 4 bits Check point (Lower)

17
6.2. Confirmation of Firmware Version
The Firmware version can be confirmed by ordering the following steps:.
•Step 1. The temporary cancellation of factory setting:
Set the mode dial to “[ Normal picture mode ] (Red camera mark)”.
Insert the SD memory card which has a few photo data.
While keep pressing [ Optical Image Stabilizer ] and “[ UP ] of Cross key” simultaneously, then turn the power on.
•Step 2. Confirm the version:
Set the mode dial to “[ Playback ]” and then press [ DISPLAY ] to switch to LCD with indication. (Fig. A)
Press [ Optical Image Stabilizer ] and “[ DOWN ] of Cross key” simultaneously. (No need to keep pressing.)
(The version information is displayed on the LCD with light blue colour letters.) (Fig. B)
CAUTION:
The version information does not display if the LCD has switched to LCD with indication already.
In this case, press [ DISPLAY ] to switch to LCD with indication.
<Point>
• The firmware version and EEPROM version can be confirmed with the information (1).
• The information (2), (3) are just reference.

18
7 Service Fixture & Tools
7.1. Service Fixture and Tools
The following Service Fixture and tools are used for checking and servicing this unit.

19
7.2. When Replacing the Main PCB
After replacing the MAIN PCB, be sure to achieve adjustment.
The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-PAVC” web-site in
“TSN system”, together with Maintenance software.
7.3. Service Position
This Service Position is used for checking and replacing parts. Use the following Extension cables for servicing.
Table S1 Extension Cable List
CAUTION-1. (When servicing FLASH TOP PCB)
1. Be sure to discharge the capacitor on FLASH TOP PCB.
Refer to “HOW TO DISCHARGE THE CAPACITOR ON FLASH TOP PCB”.
The capacitor voltage is not lowered soon even if the AC Cord is unplugged or the battery is removed.
2. Be careful of the high voltage circuit on FLASH TOP PCB.
3. DO NOT allow other parts to touch the high voltage circuit on FLASH TOP PCB.
No. Parts No. Connection Form
1 RFKZ0363 FP9001 (MAIN) - LCD UNIT 19PIN 0.5 FFC
2 VFK1974 FP9002 (MAIN) - LCD UNIT 4PIN 0.5 FFC
3 VFK1950 FP9801 (SUB) - CCD UNIT 33PIN 0.3 FFC
4 VFK1951 FP9802 (SUB) - LENS UNIT 39PIN 0.3 FFC
5 RFKZ0362 PP9001 (MAIN) - PS9801 (SUB) 100PIN B to B
6 VFK1541 PP9802 (SUB) - PS8001 (FLASH TOP) 40PIN B to B

20
8 Disassembly and Assembly Instructions
8.1. Disassembly Flow Chart
8.2. PCB Location
