Panasonic Lumix DMC-GF2C Technical specifications

VQT3C43
EB
Web Site: http://www.panasonic-europe.com
Model number suffix “EB” denotes UK model.
Basic Operating Instructions
Digital Camera/
Lens Kit/Double Lens Kit
Model No. DMC-GF2C/DMC-GF2K
DMC-GF2W
Before use, please read these instructions completely.
More detailed instructions
on the operation of this
camera are contained in
“Operating Instructions for Advanced
Features (PDF format)” in the supplied
CD-ROM. Install it on your PC to read it.
until
2010/12/31
DMC-GF2EB-VQT3C43_eng.book 1 ページ ２０１０年１１月１８日 木曜日 午後１時３３分

VQT3C43 (ENG)
2
Dear Customer,
We would like to take this opportunity to thank you for purchasing this Panasonic Digital
Camera. Please read these Operating Instructions carefully and keep them handy for
future reference. Please note that the actual controls and components, menu items, etc. of
your Digital Camera may look somewhat different from those shown in the illustrations in
these Operating Instructions.
Carefully observe copyright laws.
•Recording of pre-recorded tapes or discs or other published or broadcast material for purposes
other than your own private use may infringe copyright laws. Even for the purpose of private
use, recording of certain material may be restricted.
Information for Your Safety
∫Product identification marking
∫About the battery pack
•Do not heat or expose to flame.
•Do not leave the battery(ies) in an automobile exposed to direct sunlight for a long period of
time with doors and windows closed.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE,
•DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR
SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHALL BE PLACED ON THE APPARATUS.
•USE ONLY THE RECOMMENDED ACCESSORIES.
•DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE EQUIPMENT AND SHALL
BE EASILY ACCESSIBLE.
Product Location
Digital camera Bottom
Battery charger Bottom
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC or incinerate.
DMC-GF2EB-VQT3C43_eng.book 2 ページ ２０１０年１１月１８日 木曜日 午後１時３３分

3
(ENG) VQT3C43
Caution for AC mains lead
For your safety, please read the following
text carefully.
This appliance is supplied with a moulded
three pin mains plug for your safety and
convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced
please ensure that the replacement fuse
has a rating of 5-ampere and that it is
approved by ASTA or BSI to BS1362.
Check for the ASTA mark Ïor the BSI
mark Ìon the body of the fuse.
If the plug contains a removable fuse
cover you must ensure that it is refitted
when the fuse is replaced.
If you lose the fuse cover the plug must
not be used until a replacement cover is
obtained.
A replacement fuse cover can be
purchased from your local dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS
UNSUITABLE FOR THE SOCKET
OUTLET IN YOUR HOME THEN THE
FUSE SHOULD BE REMOVED AND
THE PLUG CUT OFF AND DISPOSED
OF SAFELY.
THERE IS A DANGER OF SEVERE
ELECTRICAL SHOCK IF THE CUT OFF
PLUG IS INSERTED INTO ANY 13-
AMPERE SOCKET.
If a new plug is to be fitted please
observe the wiring code as stated below.
If in any doubt please consult a qualified
electrician.
∫IMPORTANT
The wires in this mains lead are coloured
in accordance with the following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with
the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured Blue must be
connected to the terminal which is marked
with the letter N or coloured Black or Blue.
The wire which is coloured Brown must be
connected to the terminal which is marked
with the letter L or coloured Brown or Red.
WARNING: DO NOT CONNECT EITHER
WIRE TO THE EARTH TERMINAL
WHICH IS MARKED WITH THE LETTER
E, BY THE EARTH SYMBOL ÓOR
COLOURED GREEN OR
GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF
-
KEEP DRY.
∫Before use
Remove the connector cover.
∫How to replace the fuse
The location of the fuse differ according to
the type of AC mains plug (figures A and
B). Confirm the AC mains plug fitted and
follow the instructions below.
Illustrations may differ from actual AC
mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach
the fuse cover.
Fuse cover
Figure A Figure B
Figure A Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
DMC-GF2EB-VQT3C43_eng.book 3 ページ ２０１０年１１月１８日 木曜日 午後１時３３分

VQT3C43 (ENG)
4
∫About the battery charger
•The battery charger is in the standby condition when the AC power supply cord is connected.
The primary circuit is always “live” as long as the power cord is connected to an electrical
outlet.
∫Cautions for Use
•Do not use any other AV cables except the supplied one.
•Do not use any other USB connection cables except the supplied one.
•Always use a genuine Panasonic HDMI mini cable (RP-CDHM15, RP-CDHM30; optional).
Part numbers: RP-CDHM15 (1.5 m) (5 feet), RP-CDHM30 (3.0 m) (10 feet)
Keep this unit as far away as possible from electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
•If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be
disrupted by electromagnetic wave radiation.
•Do not use this unit near cell phones because doing so may result in noise adversely affecting
the pictures and/or sound.
•Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields
created by speakers or large motors.
•Electromagnetic wave radiation generated by microprocessors may adversely affect this unit,
disturbing the pictures and/or sound.
•If this unit is adversely affected by electromagnetic equipment and stops functioning properly,
turn this unit off and remove the battery or disconnect AC adaptor (DMW-AC8E; optional).
Then reinsert the battery or reconnect AC adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
•If you record near radio transmitters or high-voltage lines, the recorded pictures and/or sound
may be adversely affected.
CAUTION!
•DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN CABINET OR IN
ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED. TO
PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING,
ENSURE THAT CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE
VENTILATION VENTS.
•DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH NEWSPAPERS,
TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.
•DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED CANDLES, ON
THE UNIT.
•DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY MANNER.
DMC-GF2EB-VQT3C43_eng.book 4 ページ ２０１０年１１月１８日 木曜日 午後１時３３分

5
(ENG) VQT3C43
Information for Users on Collection and Disposal of Old Equipment and used
Batteries
These symbols on the products, packaging, and/or accompanying
documents mean that used electrical and electronic products and
batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used
batteries, please take them to applicable collection points, in accordance
with your national legislation and the Directives 2002/96/EC and 2006/
66/EC.
By disposing of these products and batteries correctly, you will help to
save valuable resources and prevent any potential negative effects on
human health and the environment which could otherwise arise from
inappropriate waste handling.
For more information about collection and recycling of old products and
batteries, please contact your local municipality, your waste disposal
service or the point of sale where you purchased the items.
Penalties may be applicable for incorrect disposal of this waste, in
accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact
your dealer or supplier for further information.
[Information on Disposal in other Countries outside the European
Union]
These symbols are only valid in the European Union. If you wish to
discard these items, please contact your local authorities or dealer and
ask for the correct method of disposal.
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In this
case it complies with the requirement set by the Directive for the
chemical involved.
Cd
DMC-GF2EB-VQT3C43_eng.book 5 ページ ２０１０年１１月１８日 木曜日 午後１時３３分

VQT3C43 (ENG)
6
Contents
Information for Your Safety...............................................................................................2
Accessories ......................................................................................................................7
Names and Functions of Components ...........................................................................11
About the Lens................................................................................................................15
Attaching/Detaching the Lens.........................................................................................16
Attaching the Shoulder Strap..........................................................................................18
Charging the Battery.......................................................................................................19
• Approximate operating time and number of recordable pictures..............................21
Inserting and Removing the Card (optional)/the Battery.................................................23
About the Card................................................................................................................24
• About cards that can be used with this unit ..............................................................24
Setting Date/Time (Clock Set) ........................................................................................26
Selecting the [REC] Mode ..............................................................................................27
Taking a Still picture .......................................................................................................28
• Taking Pictures with Your Favourite Settings
(Programme AE Mode) ............................................................................................28
Playing Back Pictures .....................................................................................................29
Recording Motion Picture ...............................................................................................30
Playing Back Motion Pictures .........................................................................................31
Taking Pictures using the Automatic Function
(Intelligent Auto Mode)....................................................................................................33
Deleting Pictures.............................................................................................................37
Setting the Menu.............................................................................................................38
• Setting menu items...................................................................................................39
Compensating the Exposure ..........................................................................................41
Taking Pictures by Specifying the Aperture/
Shutter Speed.................................................................................................................42
• Aperture-priority AE ..................................................................................................42
• Shutter-priority AE ....................................................................................................43
Taking Picture by Setting the Exposure Manually ..........................................................44
Reading the Operating Instructions (PDF format) ..........................................................45
Specifications..................................................................................................................46
DMC-GF2EB-VQT3C43_eng.book 6 ページ ２０１０年１１月１８日 木曜日 午後１時３３分

7
(ENG) VQT3C43
Accessories
Check that all the accessories are supplied before using the camera.
Product numbers correct as of December 2010. These may be subject to change.
1 Digital Camera Body
(This is referred to as camera body in these operating instructions.)
2 Interchangeable Lens
“LUMIX G 14 mm/F2.5 ASPH.”
(This is referred to as lens in these operating instructions.)
3 Lens Cap
(This is attached to the interchangeable lens at the time of purchase.)
4 Lens Rear Cap
(This is attached to the interchangeable lens at the time of purchase.)
5 Interchangeable Lens
“LUMIX G VARIO 14–42 mm/F3.5–5.6 ASPH./MEGA O.I.S.”
(This is referred to as lens in these operating instructions.)
6 Lens Hood
7 Lens Cap
(This is attached to the interchangeable lens at the time of purchase.)
8 Lens Rear Cap
(This is attached to the interchangeable lens at the time of purchase.)
9BatteryPack
(Indicated as battery pack or battery in the text)
Charge the battery before use.
10 Battery Charger
(Indicated as battery charger or charger in the text)
11 AC Mains Lead
12 AV Cable
13 USB Connection Cable
14 Body Cap
(This is attached to the camera body at the time of purchase.)
15 CD-ROM
•Software:
Use it to install the software to your PC.
16 CD-ROM
•Operating Instructions
17 Hot shoe cover
(This is attached to the camera body at the time of purchase.)
18 Shoulder Strap
19 Stylus pen
20 Battery Case
•SD Memory Card, SDHC Memory Card and SDXC Memory Card are indicated as card in the
text.
•The card is optional.
•Description in these operating instructions is based on the interchangeable lens (H-H014).
About unavailable functions such as [STABILIZER], Direction Detection function, description in
these operating instructions is based on the interchangeable lens (H-FS014042).
•Consult the dealer or your nearest Service Centre if you lose the supplied accessories. (You
can purchase the accessories separately.)
DMC-GF2EB-VQT3C43_eng.book 7 ページ ２０１０年１１月１８日 木曜日 午後１時３３分

VQT3C43 (ENG)
8
¢1 Supplied in DMC-GF2C only
¢2 Supplied in DMC-GF2K only
¢3 Supplied in DMC-GF2W only
34
VYF3371 VFC4605
567
H-FS014042 VYC1009 VYF3201
8
VFC4315
2
H-H014
DMC-GF2K
2
DMC-GF2C
1
1
91011
DMW-BLD10E DE-A94A
14 15 16
13
K1HY14YY0009
VGQ0C14
12
VKF4385 VFF0755
DMC-GF2W
3
K2CT39A00002
17 18
VKF4840 VFC4634
20
VGQ0R99
19
K1HY14YY0008
DMC-GF2EB-VQT3C43_eng.book 8 ページ ２０１０年１１月１８日 木曜日 午後１時３３分

9
(ENG) VQT3C43
Sales and Support Information
Customer Care Centre
•For customers within the UK: 0844 844 3852
•For customers within the Republic of Ireland: 01 289 8333
•Visit our website for product information
www.panasonic.co.uk
•E-mail: [e-mail]
Technical Support for AV Software
•For customers within the UK: 0844 844 3869
•For customers within the Republic of Ireland: 01 289 8333
Direct Sales at Panasonic UK
•For customers: 0844 844 3856
• Order accessory and consumable items for your product with ease and confidence by phoning our
Customer Care Centre Monday – Thursday 9.00 a.m. – 5.30 p.m., Friday 9.30 a.m. – 5.30 p.m.
(Excluding public holidays)
•Or go on line through our Internet Accessory ordering application at www.pas-europe.com.
•Most major credit and debit cards accepted.
•All enquiries transactions and distribution facilities are provided directly by Panasonic UK Ltd.
•It couldn’t be simpler!
•Also available through our Internet is direct shopping for a wide range of finished products, take
a browse on our website for further details.
DMC-GF2EB-VQT3C43_eng.book 9 ページ ２０１０年１１月１８日 木曜日 午後１時３３分

VQT3C43 (ENG)
10
∫Optional Accessories
Some optional accessories may not be available in some countries.
¢1 The AC Adaptor (optional) can only be used with the designated Panasonic DC Coupler
(optional). The AC adaptor (optional) cannot be used by itself.
¢2 The interchangeble lens (H-H014) is not used.
¢3When the interchangeable lens (H-H014) is used
¢4When the interchangeable lens (H-FS014042) is used
¢5Use if the attached lens is in contact with the tripod pedestal.
•Battery Pack
DMW-BLD10E
•AC Adaptor¢1
DMW-AC8EB
•DC Coupler¢1
DMW-DCC9GU
•Zoom Lever
DMW-ZL1E¢2
•Live Viewfinder
DMW-LVF1
•Lens Cap
DMW-LFC46¢3, DMW-LFC52¢4
•Lens Rear Cap
DMW-LRC1
•Body Cap
DMW-BDC1
•Flash
DMW-FL220E
DMW-FL360E
DMW-FL500E
•Interchangeable Lens
H-VS014140E, H-FS014042E,
H-FS014045E, H-FS045200E, H-F007014E,
H-ES045E, H-H020E, H-F008E, H-H014E,
H-FS100300E
(Read P15 for information about other lenses
that can be used.)
•The 3D Interchangeable Lens
H-FT012
•MC Protector
DMW-LMC46E¢3, DMW-LMC52E¢4
•ND Filter
DMW-LND46E¢3, DMW-LND52E¢4
•PL Filter (Circular Type)
DMW-LPL46E¢3, DMW-LPL52E¢4
•Leather Bag
DMW-BAL1
•Soft Bag
DMW-BAG1
•Soft Case
DMW-CG3
•Shoulder Strap
DMW-SSTL1, DMW-SSTG1, DMW-SSTG2
DMW-SSTG3, DMW-SSTG5, DMW-SSTG6
•HDMI mini cable
RP-CDHM15E, RP-CDHM30E
•Mount Adaptor
DMW-MA1E, DMW-MA2ME, DMW-MA3RE
•Tripod Adaptor
DMW-TA1E¢5
•SDXC Memory Card
64 GB: RP-SDW64GE1K
48 GB: RP-SDW48GE1K
•SDHC Memory Card
32 GB: RP-SDW32GE1K/RP-SDP32GE1K
24 GB: RP-SDP24GE1K
16 GB: RP-SDW16GE1K/RP-SDP16GE1K
8 GB: RP-SDW08GE1K/RP-SDP08GE1K/RP-SDR08GE1A
4 GB: RP-SDW04GE1K/RP-SDP04GE1K/RP-SDR04GE1A
•SD Memory Card
2 GB: RP-SDP02GE1K/RP-SDR02GE1A
VQT3C43~Body1_eng.fm 10 ページ ２０１０年１１月２２日 月曜日 午後８時１１分
