Panasonic Lumix S1H User manual

Handbook

INDEX
1. Main Parts and Displays
2. Video Recording Settings
3. HDMI Output and TC IN/OUT
4. Audio Settings
5. Expandability
6. Power Supply and Recording Media
7. Video Shooting Assist Functions
8. Support
9. Appendix
Page 4
Page 17
Page 32
Page 43
Page 50
Page 57
Page 67
Page 88
Page 91
--------------
--------------
-----------
---------------------
---------------------
-------
---------
-------------------------
-------------------------

Responding to the demanding requirements of videographers today,
the full-frame mirrorless camera LUMIX S1H offers an outstanding combination of
image quality, functionality and usability.
Dual Native ISO Technology
The 24.2MP CMOS sensor features Dual Native ISO technology, leveraging
a dual-base ISO setting to minimize noise and maximize image quality
from low to high sensitivity.
V-Log/V-Gamut with 14+ Stops of Dynamic Range
V-Log and V-Gamut come preinstalled. With 14+ stops of dynamic range and a wide
color spectrum, performance rivals that of a VariCam professional cinema camera.
Multiple Recording Formats and Unlimited Recording
In addition to C4K/4K 60p/50p 4:2:0 10-bit and C4K/4K 30p/25p/24p 4:2:2 10-bit,
the camera newly offers 6K/24p 4:2:0 10-bit in 3:2 and 5.9K 30p/25p/24p 4:2:0
10-bit in 16:9. Unlimited recording is offered on all settings.
RAW Data Output
With firmware version 2.1, 12-bit RAW video data with a maximum resolution of 5.9K
can be output via HDMI to an external recorder.
Robust Video Expression Features
A variety of recording modes including 4:3 Anamorphic mode, VFR (variable frame
rate), HFR (high frame rate) and 4K HDR are also provided.
1
2
3
4
5

Main Parts and Displays
4
1. Main Parts and Displays
Main Parts
Displays
Page 5
Page 9
----------------------
----------------------

1Hot Shoe
2REMOTE Socket Φ2.5 mm
3MIC Socket
Φ3.5 mm Stereo Mini Jack
Mic Input (Plug-in Power) / Mic Input / Line Input
Standard Input Level : -55dBV (Mic) / -10dBV (Line)
4Headphone Socket Φ3.5 mm Stereo Mini Jack
5USB Port USB 3.1 Type-C / Super Speed USB3.1 GEN1
Supports USB Power Delivery (9.0V / 3.0A)
6HDMI Socket Type A
7Card Slot 1 / 2
SD / SDHC / SDXC Memory Card
Compliant with UHS-I/UHS-II UHS Speed Class 3
Compliant with UHS-II Video Speed Class 90
6
5
4
3
2
7
Input-Output Terminal / Extended Capability 1 / 2
Main Parts
5
1. Main Parts and Displays
1

Input-Output Terminal / Extended Capability 2 / 2
8
Flash Synchro Socket Use the flash with a synchronization voltage of 250V or less.
TC IN/OUT Socket
Use the bundled BNC conversion cable.
Input: 1.0V to 4.0V [p-p], 10 kΩ, Output: 2.0V ±0.5 V [p-p], low impedance
9
Screw Hole for Function Expansion
Use the screw hole for attaching the lens or lens mount adaptor
that can be secured with a screw.
10
Focus Distance Reference Mark
Positioned coaxially with the strap eyelet in consideration of the attachment of
a tape measure to the strap eyelet.
11 Tripod Mount
12 Pinhole for Anti-rotation Pin of Video Tripod Mount
8
Main Parts
6
1. Main Parts and Displays
9
10
11 12
Note : If you attempt to attach a tripod with a screw length of 5.5mm (0.22 inch) or
more, you may not be able to securely fix it in place or it may damage the camera.
Fn1 Button
Preview Button / Fn2 Button

Double Video Rec. Button
Main Parts
7
1. Main Parts and Displays
Video Rec/Stop can be operated with either button.
Video Rec. Button on the Top
When Handheld Shooting, Using a Tripod, etc.
Sub Video Rec. Button on the Front
When Using a Shoulder Rig, etc.
Start and stop video recording using the shutter button can be enabled
or disabled*. * Firmware must be updated to version 2.0 or later.
[ ] > [ ] > 2> [ Assign REC to Shutter Button ] > [ ON ]

Operation Lock
Main Parts
Set the operation lock lever to the [ LOCK ] position to
disable operation, thus preventing operation errors.
[ ] > [ ] > [ Lock Lever Setting ]
1
Select the operation function to disable.
2
Cursor Cursor Button, MENU/SET Button, Control Dial
Joystick Joystick
Touch Screen Touch Screen
Dial Front Dial, Rear Dial, Control Dial
8
1. Main Parts and Displays
When a malfunction such as an operation failure occurs, check this function first.

GUI Structure
Displays
③Setup
⑤Playback
④My Menu
②Custom
①Video
By Usage Main Tab
③Focus
④Audio
②Image Format
①Image Quality
Setting Sequence Sub Tab
Shooting Usage Sequence Menu Item
⑤Others (Video)
* In the case of the Video Menu
9
1. Main Parts and Displays

1
Frame Rate / Variable Frame Rate
Shutter Speed
Aperture Value
3
File Format / Recording Quality
Card Slot
Double Card Slot Function
Video Recording Time
Wi-Fi / Bluetooth Connection State
Fan Operating Mode
Power Supply / Battery Indication
Battery Indication (Battery Grip)
Control Panel Display * Creative Video Mode
Displays
2
Exposure Mode
Exposure Compensation Value
Manual Exposure Assist
Image Area of Video
Time Code
Recording State
4
Built-in Microphone
External Microphone
XLR Microphone Adaptor Setting
Sound Rec Level Limiter
Mute
Sound Recording Level
5
ISO / Dual Native ISO
Photo Style
LUT View Assist
HLG View Assist
White Balance
3
1
5
4
2
10
1. Main Parts and Displays

6
1
4
Status LCD Display * Creative Video Mode
Displays
1 Frame Rate / Variable Frame Rate
2 Shutter Speed
3 Aperture Value
4 White Balance
5 ISO / Dual Native ISO Setting
6 Exposure Mode
7 Photo Style / Filter Settings
8 Exposure Compensation Value
9 Image Area of Video
10 Recording File Format /
Recording Quality
11 Recording State
12 Wi-Fi / Bluetooth Connection State
11
1. Main Parts and Displays
23
7
9
5
12
11
8
10
14
13
15
16 17 18
13 Time Code
14
Built-in Microphone
External Microphone
XLR Microphone Adaptor Setting
Sound Rec Level Limiter
15 Sound Recording Level Display
16 Card Slot
Double Card Slot Function
17 Video Recording Time
18 Battery Indication
Power Supply
Use the [ Status-LCD Display (Video) ]
of the Fn button.
In default settings, this is registered
in the [ Fn1 ] button.
Switchable between two display types

1
White Balance
White Balance Adjustment
Photo Style
Filter / Filter Effect Adjustment
LUT View Assist
HLG View Assist
Recording File Format
Recording Quality
Recording Frame Rate
Variable Frame Rate
Focus Mode
AF Lock
Focus Peaking
Image Area of Video
AF Mode
LVF / Rear Monitor Display 1 / 2 * Creative Video Mode
Displays
1
Wi-Fi Connection State
Bluetooth Connection State
Location Logging
Image Stabilizer
Camera Shake Alert
2
Silent Mode
Anamorphic Desqueeze Display
Loop Recording
3
Time Code
Built-in Microphone
External Microphone
XLR Microphone Adaptor Setting
Sound Rec Level Limiter
Mute
Sound Recording Level
Exposure Meter
12
1. Main Parts and Displays
1
5
3
2
4

4
Histogram
AF Area
Spot Metering Target
Centre Marker
Lock Lever
Elapsed Recording Time
Image Being Sent
5
Time Stamp Recording
Focus (Green)
Recording State (Red)
Recording Mode
Program Shift
Metering Mode
AE Lock
Shutter Speed
Aperture Value
Exposure Compensation Value 6
Temperature Rise Warning Icon
Fan Error Warning Icon
Manual Exposure Assist
5
ISO / Dual Native ISO
Card Access Indication (Red)
Card Slot
Double Card Slot Function
No Card
Card Full
Video Recording Time
Remaining recording time of one SD card
Battery Indication
Power Supply
Battery Grip
13
1. Main Parts and Displays
1
5
3
2
4
LVF / Rear Monitor Display 2 / 2 * Creative Video Mode
Displays

Features an operation style familiar to users of video cameras or cinema cameras
to support smooth video production.
ANGLE / ISO
SEC / ISO
SEC / dB
Control Panel Display Selector
Displays
In Creative Video Mode
[ ] > [ ] > [ SS/Gain Operation ]
14
1. Main Parts and Displays
TIPS

Enables the black/white reverse display of character (text) color and background color
and the adjustment (2 steps) of backlight brightness.
[ ] > [ ] > [ Status-LCD ]
Status LCD Display Selector
Displays
[ Character/Background Color ] > [Black ][Character/Background Color ] > [ White ]
1
2• Character/Background Color
• Backlight Illumination Period*
• Backlight Illumination
• Display While Power Off
* Firmware must be updated to version 2.0 or later.
15
1. Main Parts and Displays
TIPS

Use to select whether to display the image on the entire screen or
to show the information display outside the image frame.
LVF / Rear Monitor Display Selector
Displays
1
2Select the LVF / Monitor Display Setting
and set a desirable display style.
[ ] > [ ] > [ LVF/Monitor Disp. Set ]
Display the icons outside of the image frame. Display the icons within the image frame.
16
1. Main Parts and Displays
When you press the DISP.
button, the icon can be hidden.

17
Video Recording Settings
Basic Setting
Log Recording
Anamorphic
VFR / HFR
HDR
Page 18
Page 22
Page 26
Page 28
Page 30
--------------------
--------------------
--------------------
--------------------
--------------------
2. Video Recording Settings

Set the Creative Video mode to use all video functions.
For Optimal Video Recording 1 / 2
Basic Setting
18
2. Video Recording Settings

For Optimal Video Recording 2 / 2
Follow the steps 1 to 4 below for efficient setting.
2
[ ] > [ ] > [ Rec Quality ]
4
[ ] > [ ] > [ Rec. File Format ]
•MOV
•MP4
• AVCHD
[ ] > [ ] > [ System Frequency ]
• 59.94Hz (NTSC)
• 50.00Hz (PAL)
• 24.00Hz (CINEMA)
• This setting may become fixed depending on the [ Rec Quality ] setting.
• The setting changes automatically to [ S35mm ]
When using Super 35mm or APS-C lenses.
When [ Image Circle ] in [ Lens Information ] is set to [ S35mm ].
3[ ] > [ ] > [ Image Are of Video ]
•FULL
• S35mm
• PIXEL/PIXEL
Basic Setting
1
19
►PAGE 92-93 : Image Area
►PAGE 94-97 : ALL Rec Qualities
2. Video Recording Settings

Applies filtering by condition to narrow down various Rec Quality setting options.
Press [ DISP. Filtering ] button.
[ Filtering Options ]
• Frame Rate
• Resolution
• Codec
• Variable Frame Rate
• Hybrid Log Gamma
42 results to 10 results after filtering
Rec Quality Filtering 1 / 2
Basic Setting TIPS
1
2
20
2. Video Recording Settings
