Panasonic LUMIX S5IIX User manual

Operating Instructions / Owner’s Manual
<Complete Guide>
Digital Camera
DC-S5M2X
Please read these instructions carefully before using this product.
Register online at
http://shop.panasonic.com/support/register
(U.S. customers only)
DVQP2992ZA
F0423NT0
until
2023/6/1

2
About Operating Instructions
This document, “Operating Instructions / Owner’s Manual <Complete
Guide>”, includes detailed explanations of all the functions and operations
of the camera.
Symbols Used in This Document
Black icons show conditions in which functions can be used, and gray icons show
conditions in which functions cannot be used.
Example:
Pictures/Videos
Recording mode
Operating symbols
In this document, camera operation is explained using the following symbols:
(A)
(B)
(C)
(C)
(D)
(E)
(F)

About Operating Instructions
3
(A) :
Front dial
(B) :
Rear dial
(C) 3421:
Cursor button up/down/left/right
or
Joystick up/down/left/right
(D) :
Press the center of the joystick
(E) :
[MENU/SET] button
(F) :
Control dial
•Other symbols, such as icons shown on the camera screen, are also used in
explanations.
•This document describes the procedure for selecting menu items as follows:
Example) Set [Picture Quality] of the [Photo] ([Image Quality]) menu to [STD.].
[][][Picture Quality] Select [STD.]

About Operating Instructions
4
Notification classification symbols
In this document, notifications are classified and described using the following
symbols:
: To confirm prior to using the function
: Hints for better use of the camera and tips for recording
: Notifications and supplementary items regarding specifications
: Related functions and information
•Images and illustrations used in this document are for explaining the functions.
•Description in this document is based on the interchangeable lens (S-R2060).

5
Contents
About Operating Instructions 2
Introduction 18
Before Use.................................................................................19
Standard Accessories................................................................22
Lenses That Can Be Used.........................................................24
Memory Cards That Can Be Used.............................................25
Names of Parts..........................................................................28
Camera.............................................................................................. 28
Supplied Lens.................................................................................... 36
Viewfinder/Monitor Displays .............................................................. 38
Getting Started 40
Attaching a Shoulder Strap........................................................41
Charging the Battery..................................................................43
Battery Insertion ................................................................................ 44
Inserting a Battery into the Camera for Charging .............................. 46
Using the Camera While Supplying It with Power (Supplying Power/
Charging)........................................................................................... 50
Notifications Regarding Charging/Power Supply............................... 52
[Power Save Mode] ........................................................................... 54
Inserting Cards (Optional)..........................................................57
Attaching a Lens........................................................................61
Attaching a Lens Hood ...................................................................... 64
Adjusting the Monitor Direction and Angle.................................67
Setting the Clock (When Turning On for the First Time)............69
